Sullivan-palatek Vfd series User manual

User Manual

Industrial Air Compressors

2014

JULY

Document: 18730-020 / 00

Issued: July 07, 2014

VFD-Series

SP20 Models

T1 Microprocessor Control

Variable Frequency Drive

DOCUMENT INFORMATION:

Part Number: 18730-020

Revision: 00

CONTACT INFORMATION:

Sullivan-Palatek, Inc.

1201 West US Highway 20

Michigan City, IN 46360

Tel: 219-874-2497

Fax: 219-872-5043

Toll Free: 800-438-6203

Website: www.sullivanpalatek.com

RECORD KEEPING:

Record the model and serial number of the compressor for

future reference when contacting the factory for service or

parts.

Model Number:

Serial Number:

DISCLAIMER:

Although this manual is checked for conformity with the

machines described, we cannot guarantee that all errors will

be excluded. Necessary corrections will be made in future

editions of this manual. This manual is subject to change

without notice.

REVISION HISTORY:

#DATE SECTION(S) DESCRIPTION

00 2014-07-07 --- Released for publication

Standard Warranty

Industrial Compressors — 15hp and Larger

Sullivan-Palatek warrants its new stationary industrial air compressor products to be free from defects in material and

workmanship and against loss of capacity due to wear, subject to the following provisions:

Warranty Duration: The warranty period for applicable Sullivan-Palatek products is as follows

Compressor Package: 12 months from the date of start-up by authorized distributor or 18 months from date of shipment

by Sullivan-Palatek; whichever is the rst to occur.

Compressor unit (excluding shaft seal) and Coupling Assembly (excluding elements): 24 months from the date of start-up

by an authorized distributor or 30 months from date of shipment by Sullivan-Palatek; whichever is the rst to occur.

Parts replaced under warranty: Remainder of the original warranty period for the replaced part.

Parts, accessories and attachments sold separately from machines, excluding warranty replacement parts: the rst to

expire; 6 months from shipment by Sullivan-Palatek or 3 months from delivery to the rst user.

Registration and Obtaining Warranty Service: The purchaser, or authorized Sullivan-Palatek distributor on his behalf, must

complete and return the warranty registration form within 10 days of start-up and before the end of 18 months from ship-

ment from Sullivan-Palatek to initiate the warranty. If the warranty registration is not initiated in this manner the warranty

effective date will be deemed to be the date of shipment from Sullivan-Palatek. Service under this warranty is obtained by

contacting the authorized Sullivan-Palatek distributor before the expiration of the warranty.

Sullivan-Palatek’s Obligations: Sullivan-Palatek will repair or replace, at Sullivan-Palatek option, any defective part, pay the

reasonable labor cost of making the repair or installing the replacement part, pay ground freight for the return of defective

parts and shipment of replacement parts.

Purchaser’s Responsibility: Performance of proper maintenance as indicated in the Operation Manual furnished with the

compressor, a copy of which is made a part of this contract. Provide any claim for warranty in writing to Sullivan-Palatek

within the warranty period. The purchaser is also responsible for the following: the cost of normal maintenance and main-

tenance items, the consequences of service performed by someone other than a party authorized to perform warranty

service if such service, in the judgment of Sullivan-Palatek, has adversely affected the performance of the compressor, the

consequences of negligence, misuse, accident, installation, or storage. The consequences of compressor lubrication ne-

glect as manifested by varnishing, pitting, erosion of the rotors or stator or both. Any premium for overtime labor requested

by purchaser to make warranty repairs and any premium freight cost to ship warranty replacement parts. Costs incurred in

gaining access to the compressor such as overcoming barriers such as walls, fences or similar structures or the construc-

tion of ramps or lifts necessary for removal or reinstallation of the compressor, incidental travel costs such as tolls, meals,

lodging and similar.

Exclusions and Limitations: Oil leaks except oil leaks that require no more than tightening joints will be covered under

warranty for a period of 60 days from start up. Including but not limited to electric motors, drives and dryers unless speci-

cally and otherwise identied in this warranty Sullivan-Palatek’s obligation shall not apply to components not of its own

manufacture and is only to extend to the purchaser the warranty provided to Sullivan-Palatek by the component supplier.

Disassembly of the air compressor air end will void the compressor air end warranty and render the air end ineligible for

exchange. The attachment of accessories or service parts not supplied or recommended by Sullivan-Palatek may void the

warranty of the product.

THIS WARRANTY IS SULLIVAN-PALATEK’S ONLY WARRANTY OF ITS STATIONARY INDUSTRIAL AIR COMRESSOR PROD-

UCTS AND IS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED. ANY IMPLIED WARRANTIES OF MERCHANT-

ABILITY OR OF FITNESS FOR A PARTICULAR PURPOSE ARE EXCLUDED. SULLIVAN-PALATEK HAS NO OBLIGATION UNDER

THIS WARRANTY OR OTHERWISE (REGARDLESS OF THE FORM OF ACTION) FOR SPECIAL, INDIRECT, CONSEQUENTIAL

OR INCIDENTAL DAMAGES, INCLUDING WITHOUT LIMITATION, LOSS OF USE, LOST PROFITS, LOST INCOME, WHETHER

SUFFERED BY THE BUYER OR A THIRD PARTY. THE TOTAL RESPONSIBILITY OF SULLIVAN PALATEK FOR CLAIMS, LOSSES,

LIABILITIES OR DAMAGES, WHETHER IN CONTRACT OR TORT ARISING OUT OF OR RELATED TO ITS PRODUCTS SHALL

NOT EXCEED THE PURCHASE PRICE OF THE COVERED PRODUCT.

This warranty applies to all Sullivan-Palatek stationary industrial air compressors of 15 horsepower or greater shipped after

April 1, 2011 and supersedes previous warranty policies. In the event of any conict between this warranty and earlier war-

ranty statements, the terms of this warranty will prevail.

Platinum and Platinum-Plus Warranty

Industrial Compressors — 15hp and Larger

Sullivan-Palatek hereby offers the following Platinum Extended Warranty to the rst retail purchaser of an industrial com-

pressors of 15 HP or larger, excluding XH high pressure models designed to operate at 250 psi or more. The Platinum

Extended Warranty is limited and applies to specic components as detailed below. The terms, conditions and limitations

contained in the Sullivan-Palatek standard warranty, which is printed on the reverse, apply to the Platinum Warranty and

that warranty is herein incorporated by reference.

Component Coverage:

Platinum Warranty: Parts and labor to repair or replace as deemed necessary solely by Sullivan-Palatek, Inc. the Com-

pressor Air End, Compressor Motor, VFD Drive, Fan Motor (if installed) Air and Oil Coolers, Sump Tank, and Drive Coupling

Assembly (excluding elements).

Platinum Plus Warranty: Compressor Air End (stator and rotor assembly) repair or replacement, parts only. Labor, freight,

travel and other costs are expressly excluded.

Duration:

Platinum Warranty: 60 months from the date of start-up as evidenced by the required warranty registration documents.

Platinum Plus Warranty Duration: 120 months from date of start-up as evidenced by the required warranty registration

documents.

The Platinum and Platinum-Plus Extended Warranties are an extension of the standard Sullivan-Palatek, Inc. warranty and

begin upon expiration of that warranty and continue to the time limit measured from the delivery and start up of the com-

pressor to the original retail purchaser. Parts repaired or replaced under warranty are warranted for the remainder of the

warranty period applicable to the replaced part.

Registration and Obtaining Warranty Service: The platinum warranty registration and startup card supplied with the

compressor must be completed and returned within 10 days of delivery and start up to register the compressor in to the

Platinum program. Eligibility for the Platinum warranty will expire 180 days after shipment of the product from the factory

and can only be reestablished by application to the Sullivan-Palatek Product Support department, which may require a paid

on-site inspection before granting. Service under this warranty is obtained by contacting the authorized Sullivan-Palatek

distributor before the expiration of the warranty.

Sullivan-Palatek’s Obligations: Sullivan-Palatek, Inc. will repair or replace, at Sullivan-Palatek option any defective part, pay

the reasonable labor cost of making the repair or installing the replacement part when coverage includes labor, pay ground

freight for the return of defective parts and shipment of replacement parts.

Purchaser’s Responsibility: In addition to the responsibilities detailed in the standard Sullivan-Palatek, Inc. warranty the

Platinum Extended Warranty requires that the purchaser use Sullivan-Palatek brand compressor lubricant, lters and

service parts obtained from Sullivan-Palatek or one of its authorized distributors or service outlets. Proof of compliance

with these terms must be available and rendered upon request in the event of a claim under this warranty. To facilitate and

ensure purchaser’s compliance with the service requirements of the Platinum and Platinum Plus extended warranties pur-

chaser will be required to buy one annual maintenance kit per year during the period of the extended warranty and advise

the model and serial number of the compressor for which the kit is purchased.

This warranty applies to all Sullivan-Palatek stationary industrial air compressors of 15 horsepower or greater, excluding

XH models designed to operate at 250 psi or more shipped after April 1, 2011 and supersedes previous warranties. In the

event of any conict between this warranty and earlier warranty statements, the terms of this warranty will prevail.

I ABOUT THIS MANUAL

I.I FOREWARD

The new line of Sullivan-Palatek compressors is here! Designed and built with some of the latest technol-

ogy, this robust unit will provide high quality as the performer in many applications.

Your new Sullivan-Palatek rotary screw compressor will supply many years of performance with standard

routine maintenance. The heart of the package is equipped with the new line of SP compressor units which

are robust in design for long life in numerous applications.

The following sections of this manual will show how easy it is to operate and maintain to ensure top perfor-

mance throughout the life of the compressor. If questions arise, and this manual does not supply proper

answers, feel free to contact your nearest Sullivan-Palatek representative for further assistance.

I.II SAFETY INSTRUCTIONS

Instructions for the safe operation and maintenance of the Sullivan-Palatek air compressor are located

throughout this manual. These instructions are presented with different labels according to the level of risk

involved, described as follows.

WARNING! is used when death or personal injury could occur if the instruction is not followed.

CAUTION! is used when damage to property could occur if the instruction is not followed.

NOTE! is used to inform the reader of installation, operation or maintenance information that is important but not

hazardous.

I.III MANUAL ORGANIZATION

Anyone operating or servicing the Sullivan-Palatek air compressor should read this entire manual and be

familiar with its information. The chart below is a quick guide to the contents in this manual.

SECTION 1: INTRODUCTION

This section contains important basic information regarding the compressor such as safety precautions

and warranty information.

SECTION 2: SPECIFICATIONS

This section contains all the engineering information related to the specic air compressor, such as appli-

cation data and drawings.

SECTION 3: COMPONENT DESCRIPTION

This section contains information about how the different systems and components function within an air

compressor.

SECTION 4: INSTALLATION

This section contains information and guidelines to follow when choosing a site for and installing the air

compressor.

SECTION 5: OPERATION

This section contains an overview of the compressor controls, initial start-up procedures, and how to start

and stop the air compressor.

SECTION 6: MAINTENANCE

This section contains a maintenance schedule and step-by-step instructions for performing common main-

tenance procedures.

SECTION 7: TROUBLESHOOTING

This section contains symptoms, causes and remedies for common air compressor malfunctions.

VI ABOUT THIS MANUAL

SECTION 8: PARTS LISTING

This section contains procedures for ordering parts, a list of recommended spare parts to keep on hand,

and exploded assembly drawings with corresponding parts lists of all the parts on the air compressor.

I.IV SUPPLEMENTAL DOCUMENTS

For more detailed information on certain components or optional equipment specic to this compressor,

supplemental documents are provided in addition to the standard compressor manual.

VII

II CONTENTS

I ABOUT THIS MANUAL ...................................................................V

I.I Foreward ..............................................................................v

I.II Safety Instructions ......................................................................v

I.III Manual Organization ....................................................................v

I.IV Supplemental Documents ...............................................................vi

1 INTRODUCTION ........................................................................1

1.1 General Compressor Safety Precautions ................................................... 2

1.2 Safety Decals ......................................................................... 2

1.3 Screw Compressor Airend Exchange Program ............................................... 3

2 SPECIFICATIONS .......................................................................5

2.1 Technical Data ........................................................................6

2.2 Dimensional Drawing, Air-Cooled (125–150hp) ............................................. 7

2.3 Dimensional Drawing, Air-Cooled (200–250hp) ............................................. 8

2.4 Piping and Instrumentation Diagram, Air-Cooled............................................. 9

2.5 Piping and Instrumentation Diagram, Water-Cooled .........................................10

2.6 Wiring Diagram, 460V (<10hp Fan Motor) ................................................. 11

2.7 Wiring Diagram, 460V (≥ 10hp Fan Motor) ................................................12

3 COMPONENT DESCRIPTION............................................................ 13

3.1 Air Compressor Package ...............................................................14

3.2 Compression Cycle ....................................................................14

3.3 Drive System.........................................................................14

3.4 Protective Devices ....................................................................15

3.5 Air/Oil Discharge System ...............................................................15

3.6 Cooling and Lubricating System .........................................................16

3.7 Air Inlet and Capacity Control System..................................................... 17

3.8 Monitoring System ....................................................................22

4 INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

4.1 Receiving............................................................................24

4.2 Moving and Lifting ....................................................................24

4.3 Location and Support..................................................................24

4.4 Intake Air ............................................................................ 24

4.5 Ventilation and Cooling ................................................................ 24

4.6 Electrical Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

4.7 Fluid Level Check .....................................................................25

4.8 Direction of Rotation ..................................................................25

4.9 Compressed Air System ................................................................26

4.10 Multiple Machine Installation ...........................................................26

4.11 Storage .............................................................................26

5 OPERATION ..........................................................................27

5.1 T1 User Interface .....................................................................28

5.2 Access Codes ........................................................................29

5.3 Prior to Starting ......................................................................30

5.4 Normal Start .........................................................................30

5.5 Normal Stop .........................................................................30

5.6 Restarts.............................................................................30

6 MAINTENANCE........................................................................31

6.1 Maintenance Schedule ................................................................32

6.2 General Maintenance Safety............................................................33

VIII CONTENTS

6.3 Stopping for Maintenance ..............................................................33

6.4 Bolt Torque Guidelines.................................................................33

6.5 Compressor Lubricant .................................................................34

6.6 Oil Filter ............................................................................. 37

6.7 Air/Oil Separator......................................................................38

6.8 Oil/After Cooler.......................................................................39

6.9 Minimum Pressure Valve ...............................................................39

6.10 Pressure Adjustment ..................................................................40

7 TROUBLESHOOTING ...................................................................41

7.1 Compressor Will Not Start ..............................................................42

7.2 Machine Will Not Build Up Full Discharge Pressure..........................................42

7.3 Machine Shuts Down With Air Demand Present ............................................43

7.4 Line Pressure Rises Above Unload Pressure ...............................................43

7.5 Excessive Lubricant Consumption .......................................................43

7.6 Pressure Relief Valve Opens Repeatedly ..................................................44

7.7 Receiver Pressure Venting Through Blow-Down.............................................44

8 PARTS CATALOG ..................................................................... 45

8.1 Ordering Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

8.2 Parts Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

8.3 Spare Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

8.4 Compressor Lubricants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

8.5 Compressor, Frame and Drive Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

8.6 Control Box Assembly, 460V (<10hp Fan Motor) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

8.7 Control Box Assembly, 460V (≥10hp Fan Motor) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

8.8 Control Box Assembly, 460V (20hp Fan Motor) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

8.9 Electrical/Pneumatic Controls Assembly (125–150hp) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

8.10 Electrical/Pneumatic Controls Assembly (200–250hp) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

8.11 Electrical/Pneumatic Controls Assembly (350hp) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

8.12 Electrical/Pneumatic Controls Assembly, Remote (NEMA 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

8.13 Electrical/Pneumatic Controls Assembly, Remote (NEMA 4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

8.14 Air Inlet Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

8.15 Air Inlet Assembly, Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

8.16 Receiver Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

8.17 Air Piping Assembly, Air-Cooled (SP20-125 & SP20-150). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

8.18 Air Piping Assembly, Air-Cooled (SP20-200 & SP20-250). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

8.19 Air Piping Assembly, Air-Cooled (SP20-300 & SP20-350). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

8.20 Air Piping Assembly, Water-Cooled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

8.21 Air Cooler Assembly (125–150hp) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

8.22 Air Cooler Assembly (200hp) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

8.23 Air Cooler Assembly (250hp) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

8.24 Air Cooler Assembly (300hp) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

8.25 Air Cooler Assembly (350hp) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

8.26 Water Cooler Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

8.27 Water Piping Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

8.28 Fluid Piping Assembly, Air-Cooled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

8.29 Fluid Piping Assembly, Water-Cooled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

8.30 Enclosure Assembly, Air-Cooled. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

8.31 Enclosure Assembly, Water-Cooled & Remote Air-Cooled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

1 INTRODUCTION

TOPICS IN THIS SECTION:

»General Compressor Safety Precautions....................................................2

»Safety Decals..........................................................................2

»Screw Compressor Airend Exchange Program ...............................................3

2INTRODUCTION

1.1 GENERAL COMPRESSOR SAFETY PRECAUTIONS

Safety is a prime consideration in the design and manufacture of the compressor. Ultimately, the respon-

sibility for safe operation rests with the individuals who use and maintain the compressor. The following

safety precautions are offered as a guide for the safe operation and maintenance of this machinery.

»Only trained and authorized personnel who have read and understand this operator’s manual should

operate the air compressor. Failure to follow the instructions, procedures and safety precautions in

this manual will increase the possibility of accidents and injuries.

»Never start the compressor unless it is safe to do so. Do not attempt to operate the air compressor

with a known unsafe condition. If an unsafe condition exists or maintenance is required, disconnect

and lockout the main power source to render it inoperative and tag the air compressor so others

who may not know of the unsafe condition cannot attempt to operate it until the unsafe condition is

corrected.

»Use and operate the air compressor only in full compliance with all pertinent Federal, State and Local

codes or requirements including OSHA, EPA and other relevant agency requirements.

»Do not modify this compressor without consulting the manufacturer and receiving specic written

approval.

»Do not use accessories (such as tools, valves, lters, hoses, piping dryers, etc.) that are rated lower

than the maximum pressure or temperature rating of this air compressor. Do not exceed the accessory

component manufacturer’s rated safe operating pressure or temperature for these items.

»Air gun cleaning devices must not be used at pressures above 30 psi (2 bar). Always use an

appropriate regulator to reduce pressure at the cleaning tool and always use with effective chip

guarding and personal protective equipment per OSHA Standard 29 CFR 1910.242 (b).

»Keep all parts of the body away from all potential points of air discharge, including pressure relief

valve ports, hoses or tools.

»Avoid bodily contact with hot oil, hot surfaces, sharp edges and corners.

»Serious injury or death may result from horseplay with air hoses and compressed air. Do not do it, do

not allow it!

»Do not operate the compressor if there is a possibility of it ingesting ammable, toxic or explosive

fumes, mists or particulate.

»Do not operate the compressor with its fan guard removed.

»Keep clothing, hands, arms and other parts of the body away from the fan and drive coupling.

»Wear OSHA approved personal protective gear including gloves, safety shoes, safety glasses, head

covering and ear protection when working on or around the compressor.

»Wear snug-tting clothing (no neckties) and conne long hair when working around the compressor.

»Keep an adequate rst-aid kit nearby. Obtain medical assistance promptly in case of injury. Do not

ignore small cuts, burns or minor eye injuries as they may lead to infection.

»Do not use air from this compressor for breathing, as it may contain colorless, odorless yet lethal

gases. Severe injury or death may result within a few seconds.

»Do not permit air from this compressor to contact foodstuff except in compliance with FDA Standard

21 CFM 178.3570 and all other applicable regulations. Use food grade lubricant for such applications.

»Keep all parts of the body, tools or other conductive objects away from exposed live parts of the

electrical system. Maintain dry footing, stand on insulating surfaces and do not contact any other

portion of the compressor when making adjustments.

Not all hazards can be anticipated, and the operator of the equipment is ultimately responsible for identify-

ing hazardous and dangerous conditions, avoiding dangerous operation and preventing accidents.

1.2 SAFETY DECALS

Sullivan-Palatek compressors are all equipped with brightly colored, weather-resistant, pictorial/verbal

decals. These are designed to warn the operator against potential hazards in order to minimize risk of

property damage, bodily injury and/or death. The warning decals are located where the danger is most

prevalent. All operators must be aware of the warning decals and follow the instructions.

3INTRODUCTION

If any warning decals are missing, damaged, painted over or located in such a position as to be unread-

able in a given installation, new warning decals must be ordered. Be sure they are properly positioned

and installed correctly. If any operators are not fully conversant with the English language and/or cannot

comprehend the intended pictorial warnings, it becomes incumbent upon the owner, lessor or other

responsible administrator to be sure the operator is properly trained, made aware of and understands the

meaning of all warning decals.

1.3 SCREW COMPRESSOR AIREND EXCHANGE PROGRAM

After the warranty period has expired a factory-remanufactured airend can be purchased on an exchange

basis. All bearings and seals have been replaced. All other parts not meeting our quality standards are also

replaced. A remanufactured airend has a warranty which is 12 months from start-up date or 18 months

from date of shipment in accordance with the terms set forth in the new airend warranty found on the

previous pages.

4INTRODUCTION

2 SPECIFICATIONS

TOPICS IN THIS SECTION:

»2.1 Technical Data...................................................................6

»2.2 Dimensional Drawing, Air-Cooled (125–150hp)........................................7

»2.3 Dimensional Drawing, Air-Cooled (200–250hp)........................................8

»2.4 Piping and Instrumentation Diagram, Air-Cooled .......................................9

»2.5 Piping and Instrumentation Diagram, Water-Cooled ...................................10

»2.6 Wiring Diagram, 460V (<10hp Fan Motor) ...........................................11

»2.7 Wiring Diagram, 460V (≥ 10hp Fan Motor) ...........................................12

6SPECIFICATIONS

2.1 TECHNICAL DATA

2.1.1 SP20-125, SP20-150, SP20-200, SP20-250 & SP20-300

COMPRESSOR DATA [100 PSI] SP20-125 SP20-150 SP20-200 SP20-250 SP20-300

Capacity acfm 630 740 980 1140 1150

Full Load Pressure psig (bar) 100 100 100 100 100

Minimum Pressure psig (bar) 70 70 70 70 70
