Sunea 40 Solar io EN
Copyright© 2022 SOMFY ACTIVITES SA. All rights reserved. 3
ORIGINAL INSTRUCTIONS
These instructions apply to all Sunea 40 Solar io drives, the different versions of which are available in the current catalogue.
CONTENTS
1.
Prior information.......................................................................................................................................................... 4
1.1. Field of application.......................................................................................................................................... 4
1.2. Liability ............................................................................................................................................................. 4
2.
Installation..................................................................................................................................................................... 4
2.1. Assembly .......................................................................................................................................................... 5
2.2. Wiring ............................................................................................................................................................... 6
2.3. Commissioning ................................................................................................................................................ 8
2.4. Tips and advice on installation....................................................................................................................... 13
3.
Use and maintenance ................................................................................................................................................... 14
3.1. Up and Down buttons..................................................................................................................................... 14
3.2. Stop function ................................................................................................................................................... 14
3.3. Favourite position (my) .................................................................................................................................. 15
3.4. Operation with sensors .................................................................................................................................. 15
3.5. Tips and advice on operation......................................................................................................................... 15
4.
Technical data ............................................................................................................................................................... 16
GENERAL INFORMATION
Safety instructions
DANGER
Indicates a danger which may result in immediate death or serious injury.
WARNING
Indicates a danger which may result in death or serious injury.
PRECAUTION
Indicates a danger which may result in minor or moderate injury.
CAUTION
Indicates a danger which may result in damage to or destruction of the product.

EN Sunea 40 Solar io
4Copyright© 2022 SOMFY ACTIVITES SA. All rights reserved.
1.PRIOR INFORMATION
1.1.Field of application
The Sunea 40 drives are designed to drive all types of external vertical screens (without locks), valances and lateral arms
awnings.
The Sunea 40 drives are designed to motorise all types of:
▪ Outdoor awning with or without cassette. All shearing zones shall be protected or inaccessible e.g. at a height ≥
2.50m from the ground or any other access level. There is no shearing risk with the front rail when e.g. the front rail
moves solely by gravity with a mass of less than 15kg or it is pushed with force less than 150N.
▪ External vertical screen which front rail moves solely by gravity with a mass less than 15kg.
Do not use for a lateral arms awning which has a torque peak during its upward movement.
1.2.Liability
Before installing and using the drive, please read these instructions carefully.
In addition to the instructions provided in this guide, please also comply with the instructions provided in the attached Safety
instructions document.
The drive must be installed by a home motorisation and automation professional, in accordance with Somfy’s
instructions and the applicable regulations in the country of installation.
Any operation of the drive outside the field of application described above is prohibited. Such use, and any failure to comply
with the instructions given in this guide and in the attached Safety instructions document, absolves Somfy of any liability and
invalidates the warranty.
After installing the drive, the installer must inform his customers of the operating and maintenance conditions for the drive
and must provide them with the operating and maintenance instructions, and the attached Safety instructions document.
Any After-Sales Service operation on the drive must be performed by a home motorisation and automation professional.
Never begin installing without first checking the compatibility of this product with the associated equipment and
accessories. If in doubt when installing this product and/or to obtain additional information, contact a Somfy representative
or visit the website www.somfy.com.
2.INSTALLATION
WARNING
• These instructions are mandatory for the home motorisation and automation professional installing the drive.
• Comply with current standards and legislation in the country of installation.
CAUTION
• Never drop, knock or puncture the drive or immerse it in liquid.
• Install an individual control point for each drive.
• The Sunea 40 Solar io drive must be installed with a 3.2 W Solar Panel solar panel and with either Oximo WireFree
Battery, Oximo WireFree Battery Stick, or Somfy 12V NAKED BATTERY.
NOTICE
Minimum distance to be kept between two drives: 20 cm.

Sunea 40 Solar io EN
Copyright© 2022 SOMFY ACTIVITES SA. All rights reserved. 5
2.1.Assembly
2.1.1.Preparing the drive
CAUTION
Sunea 40 Solar io : interior diameter of the tube has to be Ø37 mm or greater.
1] Fit the accessories required to integrate the drive into the tube:
ð Either only wheel (a) on the drive
ð or crown (b) and wheel (c) on the drive.
2] Measure the length (L) between the inner edge of the drive head and the rim
of the wheel.
1]
2]
L
L = …
Ø Ø Ø Ø
ab c
2.1.2.Preparing the tube
CAUTION
Install the drive in a tube with a minimum thickness of 0.5 mm and a smooth inner surface: with no welding, crimping,
folding, etc. inside the tube.
1] Cut the tube to the required length, depending on the motorised product.
2] Deburr the tube and remove the swarf.
3] For tubes which are smooth inside, cut a notch with the following
measurements:
d e
Ø 40 x 1 6mm 8.5mm
Ø 40 x 1.5 7mm 8.5mm
1]
3]
2]
d e
2.1.3.Assembling the drive-tube
1] Slide the drive into the tube. For tubes with a smooth interior, position the cut
notch on the crown.
2] The wheel must be locked in place to prevent any movement in the tube.
•
This can be achieved by fastening the tube to the wheel using 4 self-tapping screws, Ø 5 mm, or 4steel pop
rivets, Ø4.8mm, placed between 5mm and 15mm from the outer edge of the wheel, regardless of the tube.
CAUTION
The screws or pop rivets must only be fastened onto the wheel and not on the drive.

EN Sunea 40 Solar io
6Copyright© 2022 SOMFY ACTIVITES SA. All rights reserved.
2.1.4.Installing the drive-tube assembly
CAUTION
The motorised product must not be compressed between the brackets.
1] If necessary, screw the bracket adapter to the drive head (f).
2] Assemble and fix the drive-tube assembly onto the end bracket (g) and onto
the drive bracket (h).
1]
2]
f
gh
CAUTION
Ensure that the drive-tube assembly is secured onto the end bracket. This operation prevents the tube-drive
assembly from coming out of the end bracket attachment.
2.1.5.Installation of the antenna
For optimal radio reception, it is recommended that the drive antenna extends at
least 10 cm outside of the motorised product housing and at least 1 cm from all
metal surfaces.
To fix the drive antenna in the ideal position, it is recommended to use the Somfy
MOUNTED ANTENNA BRACKET accessory.
≥1 cm
≥10 cm
x
i
CAUTION
• Do not wind or cut the antenna wire. Observe a minimum bending radius (i) of 9mm.
• Do not protrude the antenna wire from the side of the valances (risk of cutting the antenna)!
2.2.Wiring
WARNING
• To ensure electrical safety, this Class III drive must be powered by a «SELV» voltage source (Safety Extra Low
Voltage).
• Improper using battery pack may cause overheat, fire, explosion, resulting in serious injury or death.
• Do not expose the drive or battery to excessive temperatures.
• There is a risk if terminals of the battery-operated drive or battery being short circuited by metal objects.
PRECAUTION
• Cables routed through a metal wall must be protected and insulated by sleeving or sheathing.
• Secure the cables to prevent any contact with moving parts.
• If the drive is used outdoors and if the power supply cable is of the H05-VVF type or PVC type, run the cable in a
UV-resistant duct, e.g. trunking.
• The drive cable cannot be removed. If it is damaged, return the drive to the After-Sales department.
CAUTION
• The cable between the drive and the battery must not exceed 2.5m (with wire cross-section min. 0.75mm²). For
lengths longer than 2.5m, it is recommended to use an extension cable with a larger cross section.
• Leave the drive power supply cable accessible: the product must be easily replaceable.
• Always make a loop in the power supply cable to prevent water from entering the drive.

Sunea 40 Solar io EN
Copyright© 2022 SOMFY ACTIVITES SA. All rights reserved. 7
CAUTION
• Ensure battery is fully charged prior to installation on site.
• Do not unplug the battery when the drive works.
• For the purposes of recharging the battery, only use the detachable supply unit provided with this drive.
2.2.1.Wiring with connectors
1] Wire the 4-pin drive connector (j) to the 4-pin cable Y connector (k).
2] Wire the 2-pin cable Y connector (m) to the 2-pin battery connector (o).
3] Wire the 4-pin cable Y connector (p) to the 2-pin solar panel connector (q).
j k
p q
m o
2.2.2.Wiring without connectors
Wire the drive to the Oximo WireFree Battery, Oximo WireFree Battery Stick or Somfy 12V NAKED BATTERY battery (r)
and the 3.2 W Solar Panel solar panel (s), following the figure:
▪ L = Blue wire (+)
▪ N = Brown wire (-)
▪ SP = Yellow wire.
The wires must have a minimum conductor cross-section of 0.5mm2.
N
N
SP
s
L
r
SP
L

EN Sunea 40 Solar io
8Copyright© 2022 SOMFY ACTIVITES SA. All rights reserved.
2.3.Commissioning
Identifying the steps to follow
The end limit setting depends on the type of motorised product:
Step 1: Pre-programming the control point [⇢2.3.1.]
Step 2: Checking the direction of rotation [⇢2.3.2.]
For a motorised
product with upper end
stops
The end limits must be set in semi-automatic
mode.
For a motorised
product without upper
end stops
The end limits must be set in manual mode.
Step 3 a:
Setting the end limits in semi-automatic mode
(for a motorised product with upper end stops)
[⇢2.3.3.1.]
Step 3 b:
Setting the end limits in manual mode [⇢2.3.3.2.]
Step 4: Programming the control point [⇢2.3.4.]
Use and maintenance [⇢3.]
NOTICE
For information about the compatibility of the drive with the motorised product and accessories, contact the product
manufacturer or Somfy.

Sunea 40 Solar io EN
Copyright© 2022 SOMFY ACTIVITES SA. All rights reserved. 9
2.3.1.Pre-programming the control point
1] Connect the drive to the battery, referring to Wiring.
2] Press the Up and Down buttons simultaneously on the control point:
ð The motorised product moves up and down.
g The control point is pre-programmed.
1] 2]
ON
2.3.2.Checking the direction of rotation
Press the Up button on the control point:
a] If the motorised product rises, the direction of rotation is correct: move onto
section Setting the end limits.
b] If the motorised product lowers, the direction of rotation is incorrect: move onto
the next step.
b1] Press the my button on the control point until the motorised product moves up
and down: The direction of rotation has been modified.
b2] Press the Up button on the control point to check the direction of rotation.
a]
b]
b1] b2]
2.3.3.Setting the end limits
2.3.3.1. Setting the end limits in semi-automatic mode (for a motorised product with
upper end stops)
The lower end limit must be set in manual mode, and the upper end limit is set
automatically:
1] Lower the motorised product to the desired position by pressing the Down
button.
ð Pressing and holding the Down button for more than 2 seconds will lower
the motorised product in one continuous movement.
2] Stop the motorised product at the desired point.
3] If necessary, adjust the position of the motorised product using the Up or
Down buttons.
4] Press the my and Up buttons simultaneously until the motorised product
rises.
ð The lower end limit is set.
5] Press the my button briefly to stop the motorised product.
6] To confirm the end limits, press the my button until the motorised product
briefly moves up and down.
g The end limits are programmed.
1] 2]
3]
5]
4]
6]
2.3.3.2. Setting the end limits in manual mode
NOTICE
The end limits can be set in any order.

EN Sunea 40 Solar io
10 Copyright© 2022 SOMFY ACTIVITES SA. All rights reserved.
1] Raise the motorised product to the desired upper position by pressing the Up
button.
ð Pressing and holding the Up button for more than 2 seconds will rise the
motorised product in one continuous movement.
2] Stop the motorised product at the desired point.
3] If necessary, adjust the position of the motorised product using the Up or
Down buttons.
4] Press the my and Down buttons simultaneously until the motorised product
moves.
ð The upper end limit is memorized.
5] Press the my button briefly when the motorised product reaches the desired
lower position.
6] If necessary, adjust the down position using the Up and Down buttons.
ð Pressing and holding the Down button for more than 2 seconds will lower
the motorised product in one continuous movement.
7] Press the my and Up buttons simultaneously until the motorised product
moves.
ð The lower end limit is memorized. The motorised product rises and stops
in the upper position.
8] To confirm the end limits, press the my button until the motorised product
briefly moves up and down.
g The end limits are programmed.
1] 2]
3]
5]
4]
7]
6]
8]
2.3.4.Programming the control point
The drive is in programming mode:
▪ Briefly press the PROG button on the control point to be programmed:
◦ The motorised product moves up and down.
→ The control point is programmed in the drive.
0.5 s
PROG.
NOTICE
If the drive is no longer in programming mode, repeat Step Pre-programming the control point before performing Step
Programming the control point [ } 10].
2.3.5."Back impulse" function
NOTICE
- This function allows the fabric to be stretched after each opening movement of the motorised product. It can be
adjusted up to ½ turn of the tube of the motorised product.
- This function can only be activated once the end-limit setting of the drive is completed.

Sunea 40 Solar io EN
Copyright© 2022 SOMFY ACTIVITES SA. All rights reserved. 11
1] Press the Down button on the control point to move the motorised product
to the down end limit.
2] Press the Up and my buttons simultaneously until the motorised product
moves up and down.
3] Press the Up or Down button to adjust the tension of the fabric (maximum ½
turn of tube).
4] To confirm the setting, press the my button until the motorised product
moves up and down.
g The “Back impulse” function is set.
1]
3]
2]
4]
NOTICE
- To deactivate the “Back impulse” function, set the angle of the tube to 0°.
- The “Back impulse” function is disabled in factory mode.
2.3.6."Back release" function
NOTICE
This function enables the release of the fabric tension after the complete closing of the motorised product. It is only
accessible for motorised products set in semi-automatic mode.
For safety reasons, this function can only be activated or deactivated by the individual control point in 3 situations:
- After the settings confirmation and before programming the first control point.
- After programming the first control point and during the next 4 cycles.
- After a single power outage and during the next 4 cycles.
To activate or deactivate this function, the procedure is identical:
1] Press the Up button on the control point to move the motorised product to
the upper end limit.
2] Press the my and Down buttons simultaneously until the motorised product
moves up and down.
g The “Back release” function is activated or deactivated.
1] 2]
NOTICE
The “Back release” function is disabled in factory mode.
2.3.7."Closing force" function
NOTICE
This function allows the closing force of the motorised product to be increased or decreased to 3 levels (high/
medium/low). It is only accessible for motorised products set in semi-automatic mode.
Contact the motorised product’s manufacturer before using this function to check the compatibility of the
installation.
For safety reasons, this function can only be accessed via the individual control point in 3 situations:
- After the settings confirmation and before programming the first control point.
- After programming the first control point and during the next 4 cycles.
- After a single power outage and during the next 4 cycles.

EN Sunea 40 Solar io
12 Copyright© 2022 SOMFY ACTIVITES SA. All rights reserved.
1] Position the motorised product at the mid-height position.
2] To activate the “Closing force” function, make two successive presses:
•
Firstly, press the my and Up buttons briefly and simultaneously, with no
moving of the motorised product.
•
Secondly, press and hold the my and Up buttons simultaneously, until the
motorised product moves up and down.
ð The drive is now in programming mode for only 10 seconds. By default,
the drive is factory set at the medium level.
3] To increase the closing force, press the Up button until the motorised
product makes a slow movement:
ð The cassette’s closing force has moved up a level.
4] To decrease the closing force, press the Down button until the motorised
product makes a slow movement:
ð The cassette’s closing force has moved down a level.
5] To confirm the new setting, press the my button until the motorised product
moves up and down.
g The new value for the "Closing force" function is recorded.
0.5 s
1] 2]
3]
5]
4]
2.3.8.Adding/Deleting sensors
1] To add or delete a sensor, press and hold the PROG button on the
programmed control point until the motorised product briefly moves up and
down.
2] Briefly press the PROG button on the sensor to be added/deleted: the
motorised product briefly moves up and down.
g The sensor is added/deleted.
1]
2]
2 s
PROG.
0.5 s
PROG.
NOTICE
If the sensor on an installation is changed or deleted, it is important to delete it from the memory of all the drives in
which it was programmed: perform step 1 with a programmed control point, then perform step 2 with the sensor to
be deleted.
NOTICE
For information about the compatibility of the drive with the motorised product and accessories, contact the product
manufacturer or Somfy.

Sunea 40 Solar io EN
Copyright© 2022 SOMFY ACTIVITES SA. All rights reserved. 13
2.4.Tips and advice on installation
2.4.1.Questions about the product?
Observations Possible causes Solutions
The motorised product does not
operate.
The battery is discharged. Refer to the battery instructions guide.
The wiring is incorrect. Check the wiring and modify it if
necessary, referring to Wiring.
The control point battery is low. Check the battery and replace it as
required.
The control point is not compatible. Check the compatibility and replace the
control point if necessary.
The control point used has not been
programmed into the drive.
Use a programmed control point or
program this control point, referring to
Programming the control point.
The motorised product stops too soon. The crown is incorrectly positionned. Fit the crown correctly, referring to
Assembly.
The end limits have been incorrectly set. Readjust the end limits, referring to Re-
setting the end limits.
2.4.2.Re-setting the end limits
NOTICE
Only available for end limits set in manual mode.
1] Position the motorised product at the end limit to be readjusted.
2] Press the Up and Down buttons simultaneously until the motorised product
moves up and down.
3] Press the Up or Down button to move the motorised product to the new
desired position.
4] To confirm the new end limit, press the my button until the motorised
product moves up and down.
1]
2]
3]
4]
2.4.3.Replacing a lost or broken Somfy control point
NOTICE
This reset deletes all the local control points, however the sensors, end limit settings and favourite position (my) are
retained.

EN Sunea 40 Solar io
14 Copyright© 2022 SOMFY ACTIVITES SA. All rights reserved.
1] Disconnect the drive from the battery and the solar panel for 2 s.
2] Reconnect the drive to the battery for 5 to 15 s.
3] Disconnect the drive for 2 s.
4] Reconnect the drive: the motorised product moves for a few seconds. (If the
motorised product is in the upper or lower end limit, it makes a brief up and
down movement).
5] Press the PROG button on the new control point briefly : the motorised
product moves up and down.
g The new control point is programmed and all the other control points are
deleted.
1] 2]
3]
5]
4]
0.5 s
PROG.
OFF ON
ON
OFF
2 s 10 s
2 s
2.4.4.Restoring the original configuration
NOTICE
This reset deletes all control points, sensors, end limit settings and resets the drive’s favourite position (my).
1] Position the motorised product at the mid-height position (if possible).
2] Disconnect the drive from the battery for 2 s.
3] Reconnect the drive for 5 to 15 s.
4] Disconnect the drive for 2 s.
5] Reconnect the drive: the motorised product moves for a few seconds. (If the
motorised product is in the upper or lower end limit, it makes a brief up and
down movement).
6] Press the PROG button on the Somfy local control point for≈ 7 s, until the
motorised product moves up and down twice.
g The drive is reset to the original configuration.
Repeat the commissioning procedure (Refer to Commissioning).
1] 2]
3]
5]
4]
6]
7 s
PROG.
my
ON
OFF
OFFON
2 s
10 s 2 s
3.USE AND MAINTENANCE
NOTICE
This drive does not require any maintenance operations.
3.1.Up and Down buttons
Briefly press the Up or Down button to raise or lower the motorised product fully.
3.2.Stop function
The motorised product is moving.
▪ Briefly press my:
◦ The motorised product stops.

Sunea 40 Solar io EN
Copyright© 2022 SOMFY ACTIVITES SA. All rights reserved. 15
3.3.Favourite position (my)
NOTICE
An intermediate position, which is called the “favourite (my) position” and is different from the upper and lower
positions, can be programmed.
3.3.1.Programming or modifying the favourite position (my)
1] Place the motorised product in the desired favourite position (my).
2] Press the my button for ≈ 5 s until the motorised product moves up and
down:
g The desired favourite position (my) is programmed.
1]
2]
3.3.2.Using the favourite position (my)
Briefly press my: the motorised product starts to move, and stops in the favourite
position (my).
3.3.3.Deleting the favourite position (my)
1] Press my:
ð The motorised product starts to move, and stops in the favourite position
(my).
2] Press my again until the motorised product moves up and down:
g The favourite position (my) is deleted.
1]
2]
3.4.Operation with sensors
Refer to the corresponding instructions.
3.5.Tips and advice on operation
3.5.1.Questions about the product?
Observations Possible causes Solutions
The motorised product does not
operate.
The control point battery is low. Change control point battery as
required.
The battery level is low, or the battery is
discharged.
Refer to the battery instructions guide.
NOTICE
If the motorised product still does not work, contact a drive and home automation professional.
3.5.2.Replacing a lost or broken Somfy control point
To replace a lost or broken control point, contact a drive and home automation professional.

EN Sunea 40 Solar io
16 Copyright© 2022 SOMFY ACTIVITES SA. All rights reserved.
4.TECHNICAL DATA
Power supply 12 Vdc battery
Radio frequency 868-870 MHz
Frequency bands and maximum power used 868.000 MHz - 868.600 MHz e.r.p. < 25 mW
868.700 MHz - 869.200 MHz e.r.p. < 25 mW
869.700 MHz - 870.000 MHz e.r.p. < 25 mW
Protection rating IP44
Operating temperature -20°C to 70°C
Charging temperature 0°C to 40°C
Maximum number of associated control
points
9
NOTICE
For additional information on the technical data for this drive contact your Somfy representative.
Please separate storage cells and batteries from other types of waste and recycle them via the local collection
facility.
We care about our environment. Do not dispose of the appliance with usual household waste. Give it to an
approved collection point for recycling.
SOMFY ACTIVITES SA, 74300 CLUSES FRANCE as manufacturer hereby declares that the drive covered by
these instructions and used as intended according to these instructions is in compliance with the essential
requirements of the applicable European Directives and in particular of the Machinery Directive 2006/42/EC,
and the Radio Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at www.somfy.com/ce.
Philippe Geoffroy, Approval manager, acting on behalf of Activity director, Cluses, 04/2022.
Somfy limited, Yeadon LS19 7ZA UK hereby declares that the drive covered by these instructions when
marked for input voltage 12 V DC and used as intended according to these instructions, is in compliance with
UK legislation of Machinery safety regulations S.I.2008 N°1597 and the Radio Equipment Regulations S.I. 2017
N°1206. The full text of the UKCA declaration of conformity is available at www.somfy.co.uk. Steven
MONTGOMERY, Managing Director Somfy Ltd UK & Ireland, Yeadon, 04/2022.

Sunea 40 Solar io SL
Copyright© 2022 SOMFY ACTIVITES SA. All rights reserved. 17
PREVEDENA NAVODILA
Ta navodila veljajo za vse pogonske sisteme Sunea 40 Solar io, katerih različice so naštete v tej knjižici.
VSEBINA
1.
Uvod ............................................................................................................................................................................... 18
1.1. Področje uporabe ............................................................................................................................................ 18
1.2. Odgovornost.................................................................................................................................................... 18
2.
Namestitev .................................................................................................................................................................... 18
2.1. Montaža ........................................................................................................................................................... 19
2.2. Kabelska napeljava.......................................................................................................................................... 20
2.3. Prvi zagon......................................................................................................................................................... 22
2.4. Namigi in nasveti za namestitev.................................................................................................................... 27
3.
Uporaba in vzdrževanje ............................................................................................................................................... 28
3.1. Gumba Gor in Dol ........................................................................................................................................... 28
3.2. Funkcija stop.................................................................................................................................................... 29
3.3. Priljubljeni položaj (my) .................................................................................................................................. 29
3.4. Uporaba skupaj s senzorji............................................................................................................................... 29
3.5. Namigi in nasveti za uporabo......................................................................................................................... 29
4.
Tehnični podatki ........................................................................................................................................................... 31
SPLOŠNO
Varnostna navodila
NEVARNOST
Označuje nevarnost, ki lahko povzroči takojšnjo smrt ali hude telesne poškodbe.
OPOZORILO
Označuje nevarnost, ki lahko povzroči smrt ali hude telesne poškodbe.
PREVIDNO
Označuje nevarnost, ki lahko povzroči lažje ali srednje hude telesne poškodbe.
POZOR
Označuje nevarnost, ki lahko poškoduje ali uniči napravo.

SL Sunea 40 Solar io
18 Copyright© 2022 SOMFY ACTIVITES SA. All rights reserved.
1.UVOD
1.1.Področje uporabe
Pogonski sistemi Sunea 40 so zasnovani za pogon vseh vrst zunanjih navpičnih senčil (brez zaklepnih mehanizmov),
notranjih senčil in tend s pregibnimi rokami.
Pogonski sistemi Sunea 40 so namenjeni poganjanju vseh naslednjih tipov:
▪ Zunanja tenda z ali brez kasete. Vsa strižna območja morajo biti zaščitena oziroma nedostopna, npr. na višini najmanj
2,5 m od tal ali od katere koli druge dostopne ravni. Na prednji prečnici ni nevarnosti striženja, če se ta pomika na
primer samo na osnovi težnosti in je masa manjša od 15 kg oziroma je sila potiskanja manjša od 150 N.
▪ Zunanji rolo senčnik, pri katerem se prednja prečnica pomika samo na osnovi težnosti in je masa manjša od 15 kg.
Ne uporabljajte za senčila s stranskimi rokami, ki izkazujejo največji navor med premikanjem navzgor.
1.2.Odgovornost
Pred namestitvijo in uporabo pogona skrbno preberite ta navodila.
Poleg navodil, navedenih v tem priročniku, upoštevajte tudi napotke v priloženi dokumentaciji Varnostna navodila .
Pogon mora namestiti strokovnjak za pogonske sisteme in hišno avtomatizacijo v skladu z navodili družbe Somfy
in veljavnimi predpisi v državi uporabe.
Vsaka uporaba pogona izven zgoraj opisanega področja uporabe je prepovedana. Takšno ravnanje, kot tudi vsako
neupoštevanje navodil iz tega priročnika ali priložene dokumentacije Varnostna navodila, družbo Somfy odvezuje kakršne
koli odgovornosti in razveljavlja garancijo proizvajalca.
Po namestitvi pogonskega sistema mora monter uporabnike poučiti o pogojih uporabe in vzdrževanja pogonskega sistema
ter jim posredovati navodila za uporabo in vzdrževanje skupaj s priloženo dokumentacijo Varnostna navodila. Vse servisne
posege na pogonskem sistemu mora izvajati strokovno usposobljen monter pogonskih sistemov in sistemov za hišno
avtomatizacijo.
Pred vsako namestitvijo preverite, ali je izdelek združljiv z ostalo priključeno opremo in dodatki. Če se med nameščanjem
naprave pojavi kakršen koli dvom ali če potrebujete dodatne informacije, se obrnite na predstavnika družbe Somfy ali
obiščite spletno stran www.somfy.com.
2.NAMESTITEV
OPOZORILO
• Strokovnjak za pogonske sisteme in hišno avtomatizacijo, ki namešča pogon, mora ta navodila obvezno
upoštevati.
• Upoštevati je treba veljavne predpise in zakonodajo v državi namestitve.
POZOR
• Pogonski sistem ne sme nikoli pasti na tla, ni ga dovoljeno tresti, vrtati vanj ali ga potapljati v tekočine.
• Za vsak pogonski sistem namestite ločen upravljalnik.
• Pogonski sistem Sunea 40 Solar io mora biti nameščen s sončnim panelom 3.2 W Solar Panel in Oximo WireFree
Battery, Oximo WireFree Battery Stick ali Somfy 12V NAKED BATTERY.
OBVESTILO
Najmanjša razdalja med dvema pogonskima sistemoma: 20 cm.

Sunea 40 Solar io SL
Copyright© 2022 SOMFY ACTIVITES SA. All rights reserved. 19
2.1.Montaža
2.1.1.Priprava pogonskega sistema
POZOR
Sunea 40 Solar io : notranji premer cevi mora znašati Ø37 mm ali več.
1] Namestite dele, ki so potrebni za vgradnjo pogonskega sistema v cev, in sicer
sta na voljo naslednji možnosti:
ð na pogonski sistem namestite samo pogonsko kolo (a) ali
ð na pogonski sistem namestite obroč (b) in pogonsko kolo (c).
2] Izmerite dolžino (L) med notranjim robom pogonske glave in koncem
pogonskega kolesa.
1]
2]
L
L = …
Ø Ø Ø Ø
ab c
2.1.2.Priprava cevi
POZOR
Namestite pogonski sistem v cev s premerom najmanj 0,5 mm in gladko notranjo površino: brez varjenja, stiskanja,
pregibanja itd. znotraj cevi.
1] Odrežite cev na želeno dolžino glede na motorizirano napravo.
2] Posnemite robove cevi in odstranite ostružke.
3] Pri gladkih ceveh naredite zarezo z naslednjimi merami:
d e
Ø 40 x 1 6 mm 8,5 mm
Ø 40 x 1,5 7 mm 8,5 mm
1]
3]
2]
d e
2.1.3.Sestava sklopa pogonskega sistema in cevi
1] Pogon potisnite v cev. Gladke cevi morate namestiti, tako da je zareza na
obroču.
2] Kolo mora biti zablokirano, tako da preprečite pomikanje v cevi.
•
To lahko dosežete bodisi s pritrditvijo cevi na kolo s 4 kniping vijaki Ø 5 mm ali 4 jeklenimi slepimi kovicami Ø 4,8
mm, nameščenimi 5–15 mm od zunanjega roba kolesa, ne glede na vrsto cevi.
POZOR
Vijaki ali slepe kovice ne smejo biti nameščeni na pogonski sistem, temveč le na kolo.

SL Sunea 40 Solar io
20 Copyright© 2022 SOMFY ACTIVITES SA. All rights reserved.
2.1.4.Montaža sklopa cevi in pogonskega sistema
POZOR
Motorizirana naprava ne sme biti stisnjena med nosilci.
1] Po potrebi na glavo pogonskega sistema (f) privijte adapter nosilca.
2] Sklop pogonskega sistema s cevjo namestite in pritrdite na končni nosilec (g)
ter na nosilec pogonskega sistema (h).
1]
2]
f
gh
POZOR
Preverite, da je sklop pogonskega sistema in cevi pritrjen na končni nosilec. S tem preprečite, da bi se sklop
pogonskega sistema in cevi iztaknil s priklopa končnega nosilca.
2.1.5.Namestitev antene
Za doseganje najboljšega radijskega sprejema priporočamo, da je antena pogonskega
sistema najmanj 10 cm zunaj ohišja motorizirane naprave in vsaj 1 cm oddaljena od
vseh kovinskih površin.
Za pritrditev antene pogonskega sistema v najustreznejšem položaju priporočamo
uporabo pribora Somfy MOUNTED ANTENNA BRACKET.
≥1 cm
≥10 cm
x
i
POZOR
• Ne navijajte in ne krajšajte antenskega vodnika. Radij upogiba (i) naj ne bo manjši od 9 mm.
• Ne potiskajte antenskega vodnika ob strani (obstaja nevarnost prerezanja antene)!
2.2.Kabelska napeljava
OPOZORILO
• Zaradi zagotavljanja električne varnosti je treba pogonski sistem razreda III uporabljati skupaj z virom varnostne
zelo nizke napetosti (SELV).
• Neustrezna uporaba baterijskega sklopa lahko povzroči pregrevanje, požar ali eksplozijo in povzroči hude telesne
poškodbe ali smrt.
• Pogonskega sistema ali baterije ne izpostavljajte izrednim temperaturam.
• Obstaja nevarnost kratkega stika med kovinskimi predmeti in baterijskim pogonskim sistemom ali baterijo.
PREVIDNO
• Kabli, speljani skozi kovinsko steno, morajo biti zaščiteni in izolirani s plaščem ali obojko.
• Kable je treba pritrditi tako, da se ne morejo stikati s pomičnimi deli.
• Če pogonski sistem uporabljate na prostem in če je napajalni kabel tipa H05-VVF ali PVC, morate kabel speljati
skozi kanal, ki je odporen na UV-žarke, kot je na primer kanal glavnega voda.
• Kabla pogonskega sistema ni mogoče odstraniti. Če se kabel poškoduje, pogonski sistem pošljite v servisni center.
POZOR
• Kabel med pogonskim sistemom in akumulatorsko baterijo ne sme biti daljši od 2,5 m (pri čemer presek žice ni
manjši od 0,75 mm²). Pri dolžinah, daljših od 2,5 m, priporočamo uporabo podaljševalnega kabla z večjim presekom
žice.
• Pustite prost dostop do napajalnega kabla pogonskega sistema: njegova zamenjava mora biti preprosta.
• Na napajalnem kablu vedno naredite upogib, da preprečite vdor vode v pogonski sistem.
