LS SV-iG5H Series User manual

Thank you for purchasing LS Variable Frequency Drives!

ii
Safety Information
SAFETY INSTRUCTIONS
Always follow safety instructions to prevent accidents and potential hazards fromoccurring.
In this manual, safety messages are classified as follows:
Improper operation mayresult in serious personal injury or death.
Improper operation may resultin slight to medium personal injury or property damage.
Throughout this manual we use the following two illustrations to make you aware ofsafetyconsiderations:
Identifies potential hazards under certain conditions.

Read the message and follow the instructions carefully.

Identifies shock hazards under certain conditions.

Particular attention should bedirected because dangerous voltage may be

present.
Keep operating instructions handy for quick reference.
Read this manual carefully to maximize the performance of SV-iG5H series inverter andensure its safe use.

iii
Safety Information
Do not remove the cover whilepower is applied or the unit is in operation. Otherwise,

electric shock could occur.
Do not run the inverter with the front cover removed. Otherwise, you may getan electric

shockdue to high voltage terminalsor charged capacitor exposure.
Do not remove the cover except for periodic inspections or wiring, even if the input power is

not applied. Otherwise, you may access the charged circuits and get an electric shock.
Wiring and periodic inspections should be performed at least 10 minutes afterdisconnecting

the inputpower and after checking the DC link voltage is discharged with a meter (below DC
30V). Otherwise, you may get an electric shock.
Operate the switches with dry hands. Otherwise, you mayget an electric shock.

Do not use the cable when its insulating tube is damaged. Otherwise, you may get an

electric shock.
Do not subject the cables to scratches, excessive stress, heavyloads orpinching.

Otherwise, youmay get an electric shock.
Install the inverteron a non-flammable surface. Do not place flammablematerial nearby.

Otherwise, fire could occur.
Disconnect the inputpower if the inverter getsdamaged. Otherwise, it could result in a

secondary accident and fire.
After the input power is appliedor removed, the inverter will remain hot for a couple of

minutes. Otherwise, you maygetbodilyinjuries such as skin-burn or damage.
Do not apply power to a damaged inverter or to an inverter with parts missing even if the

installation is complete. Otherwise, electric shock could occur.
Do not allowlint, paper, wood chips, dust,metallic chips or other foreign matter into the

drive. Otherwise,fire or accident could occur.

iv
Safety Information
OPERATING PRECAUTIONS
(1) Handling and installation
Handle according to the weight of the product.Do not stack the inverter boxes higher than the number recommended.Install according to instructionsspecified in this manual.Do not open the cover during delivery.Do not place heavy items on the inverter.Check the inverter mounting orientationis correct.Do not drop the inverter, or subject it to impact.Follow your national electrical code for grounding. Recommended Ground impedancefor 200 V Class is below 100 ohm and for 400V class below 10 ohm.
iG5H series contains ESD (Electrostatic Discharge) sensitive parts. Take protectivemeasuresagainst ESD before touching the pcb for inspection or installation.
Use the inverter under the following environmental conditions:
Environment
Surrounding temperature
- 10 - 50 ℃(non-freezing)
Relative humidity
90% RH or less (non-condensing)
Storage temperature
- 20 - 65 ℃
Location
Protected from corrosive gas, combustible gas,
oil mist or dust
Altitude,Vibration
Max. 1,000m above sea level, Max. 5.9m/sec2
(0.6G) orless
Atmospheric pressure
70 - 106 kPa
(2) Wiring
Do not connect a power factor correction capacitor, surge suppressor, or RFI filter totheoutput of the inverter.
The connection orientation of the output cables U, V, W to the motor will affect thedirection of rotation of the motor.
Incorrect terminal wiring could result in the equipment damage.Reversing the polarity(+/-) of theterminals could damage the inverter.Only authorized personnel familiar with LS inverter should perform wiring andinspections.
Always install the inverter before wiring. Otherwise, youmay get an electricshock orhave bodily injury.
(3) Trial run
Check all parameters during operation. Changing parameter values might berequireddepending on the load.
Always apply permissible range of voltage to the each terminal as indicated in thismanual. Otherwise, it could leadto inverter damage.

v
Safety Information
(4) Operation precautions
When theAuto restart function is selected, stay away from the equipment as a motorwill restart suddenly after an alarm stop.
The Stop key on the keypad is valid only when the appropriate function setting hasbeen made. Prepare an emergency stop switch separately.
If an alarm reset is made with the reference signal present, a sudden start will occur.Check that the reference signal is turned off in advance. Otherwise an accident could
occur.
Do not modify or alter anything insidethe inverter.Motor might not be protected by electronic thermal function of inverter.
Do not use a magnetic contactor on the inverter input for frequent starting/stopping ofthe inverter.
Use a noise filter to reduce the effect of electromagnetic interference. Otherwise nearbyelectronic equipment may be affected.
In case of input voltage unbalance, installACreactor. Power Factor capacitors andgenerators may become overheated and damaged due to potential high frequency
noise transmitted from inverter.
Usean insulation-rectified motor or take measures to suppressthe micro surge voltagewhen driving 400V class motor with inverter.Amicro surge voltage attributable to wiring
constant is generated at motor terminals, and may deteriorate insulation and damage
motor.
Before operating unit and prior to user programming, reset user parameters to default
settings.
Inverter can easily be set to high-speed operations, Verify capability of motor ormachinery prior to operating unit.
Stopping torque is not produced when using the DC-Break function. Install separateequipment when stopping torque is needed.
(5) Fault prevention precautions
Provide a safety backup such as an emergency brake which will prevent the machineand equipment from hazardous conditions if the inverter fails.
(6) Maintenance, inspection and parts replacement
Do not conduct a megger (insulation resistance) test on the control circuit of the inverter.Refer to 12.4.2 Periodic inspection (parts replacement).
(7) Disposal
Handle the inverter as an industrial waste when disposing of it.
(8) General instructions
Many of the diagrams and drawings in this instruction manual show the inverter withouta circuit breaker, a cover or partially open. Never run the inverter likethis.Alwaysplace
the cover with circuit breakers and follow this instruction manual when operating the
inverter.

vi
Safety Information
Important User Information
The purpose of this manual is to provide the user with the necessary information toinstall, program, start up and maintain the SV-iG5H series inverter.
To assure successful installation and operation, the material presented must bethoroughlyread and understood before proceeding.
This manual contains.
Chapter
Title
Description
1
Basic information &
precautions
Provides general information and precautions for safe
use of the SV-iG5H series inverter.
2
Installation &Wiring
Provides instructions on howtoinstall and wiring for
power source & signal terminal of SV-iG5H inverter.
3
Basic configuration
Describes how to connect the optional peripheral
devices to the inverter.
4
Programming keypad
& Basic operation
Illustrates keypad features and display & Provides
instructions forquick start of the inverter.
5
Function list
Parameter values are listed.
6
Control block diagram
Shows control flow to help users easily understand
operation mode.
7
Basic functions
Provides information for basic functions in the SV-iG5H
8
Advanced functions
Indicates advanced functions used for system
application.
9
Monitoring
Gives information on the operating status and fault
information.
10
Protective functions
Outlines protective functions of the SV-iG5H.
11
RS 485
Provides specification of RS485 communication.
12
Troubleshooting &
maintenance
Definesthe various inverter faults and the appropriate
action to take as well as general troubleshooting
information.
13
Specifications & Option
Gives information on Input/Output rating, control type
andmore detailsof the SV-iG5H inverter.
Explains options including Remote keypad, Conduit,
EMC filter, DB resistor.

vii
Table of Contents
Table of Contents
1Basic information & precautions.....................................................................1
1.1 Important precautions ...............................................................................1
1.2 Product Details..........................................................................................2
1.3 Product assembling & disassembling......................................................3
2Installation & Wiring ..........................................................................................4
2.1 Installation precautions.............................................................................4
2.2 Dimensions................................................................................................6
2.3 Terminal wiring (Control I/O).....................................................................9
2.4 Specifications for power terminal block wiring....................................... 11
2.5 Control terminal specification..................................................................14
2.6 PNP/NPN selection and connector for communication option.............16
2.7 Terminating Resistor selection................................................................17
3Basic configuration..........................................................................................18
3.1 Connectionof peripheral devices to the inverter...................................18
3.2 Recommended MCCB............................................................................19
3.3 Recommendable Fuse, Reactors..........................................................20
4Programming Keypad & Basic operation....................................................21
4.1 Keypad features......................................................................................21
4.2 Alpha-numeric view on the LED keypad ...............................................22
4.3 Moving to other groups...........................................................................23
4.4 How to change the codes in a group.....................................................26
4.5 Parameter setting....................................................................................28
4.6 Monitoring of operation status................................................................31
Output current display................................................................314.6.1
Fault display................................................................................324.6.2
Parameter initialize.....................................................................334.6.3
4.7 Frequency Setting and Basic Operation................................................34
Frequency Setting via keypad & operating via terminals.........344.7.1
Frequency Setting via potentiometer & operating via terminals4.7.2 ....................................................................................................35

viii
Table of Contents
Frequency setting via potentiometer & operating via the Run4.7.3 key..............................................................................................36
5Function list.......................................................................................................38
5.1 Drive Group .............................................................................................38
5.2 Function group 1 .....................................................................................40
5.3 Function group 2 .....................................................................................46
5.4 Input/output group...................................................................................55
5.5 Application Group....................................................................................63
6Control Block Diagram....................................................................................67
6.1 Frequency setting....................................................................................68
6.2 Drive command setting...........................................................................70
6.3 Accel/Decel setting and V/F control.......................................................71
7Basic Functions................................................................................................72
7.1 Frequency mode.....................................................................................72
Keypad Frequency setting 1......................................................727.1.1
Keypad Frequency setting 2......................................................727.1.2
Frequency setting via –10 - +10[V] input...................................737.1.3
Frequency setting via 0 - 10 [V] input or Terminal Potentiometer7.1.4 ....................................................................................................74
Frequency setting via 0 - 20 [mA] input.....................................757.1.5
Frequency setting via -10 - +10[V] voltage input + 0 - 20[mA]7.1.6 input............................................................................................75
Frequency setting via0 - 10[V] + 0 - 20[mA] input...................767.1.7
Frequency setting via RS 485 communication.........................767.1.8
Frequency setting via Digital Volume (up-down)......................777.1.9
Analog Hold.................................................................................777.1.10
7.2 Multi-Step Frequency setting..................................................................78
7.3 Operating command setting method......................................................79
Operation via keypad RUN key and STOP/RSTkey...............797.3.1
Operating command via FX, RX terminal1..............................797.3.2
Operating command via FX, RX terminal2..............................807.3.3
Operating command via RS485 communication......................807.3.4
Rotating direction select via –10 - +10[V] input of V1 terminal 817.3.5

ix
Table of Contents
FX/RX Run Disable....................................................................817.3.6
Power On Start select.................................................................827.3.7
Restart after fault reset...............................................................827.3.8
7.4 Accel/Decel time and pattern setting .....................................................83
Accel/Decel time setting based on Max frequency..................837.4.1
Accel/Decel time setting based on Operating Frequency........847.4.2
Multi-Accel/Decel time setting via Multi-function terminals......857.4.3
Accel/Decel pattern setting ........................................................867.4.4
Accel/Decel Disable....................................................................877.4.5
7.5 V/F control................................................................................................88
Linear V/F pattern operation ......................................................887.5.1
Square V/F pattern .....................................................................887.5.2
High starting torque pattern........................................................897.5.3
User V/F pattern operation.........................................................897.5.4
Output voltage adjustment.........................................................907.5.5
Manual torque boost...................................................................90
7.5.6
Auto torque boost .......................................................................917.5.7
7.6 Stop method select .................................................................................92
Decel to stop...............................................................................927.6.1
DC braking to stop......................................................................927.6.2
Free run stop...............................................................................927.6.3
7.7 Frequency limit........................................................................................93
Frequency limit using Max Frequency and Start Frequency...937.7.1
Frequency command limit using High/Low limit.......................937.7.2
Skip frequency............................................................................947.7.3
8Advanced functions.........................................................................................95
8.1 DC brake..................................................................................................95
Stopping motor by DC brake .....................................................958.1.1
Starting DC brake.......................................................................968.1.2
DC brake ata stop......................................................................978.1.3
8.2 Jog operation...........................................................................................98
Terminal jog operation................................................................988.2.1
Terminal JOG FX/RX operation.................................................998.2.2

x
Table of Contents
8.3 UP-DOWN Operation ...........................................................................100
Up-down storage function........................................................1008.3.1
Up-down mode select...............................................................1018.3.2
8.4 3-Wire.....................................................................................................103
8.5 Dwell operation......................................................................................104
8.6 Slip compensation.................................................................................104
8.7 PID control.............................................................................................106
PID control diagram..................................................................1078.7.1
Sleep & Wake-up......................................................................1098.7.2
Sleep Boost...............................................................................1098.7.3
Pre-PID......................................................................................1108.7.4
8.8 Multi Step PID........................................................................................ 111
8.9 MMC.......................................................................................................112
8.10 MMC(Auto Change)..............................................................................114
8.11 MotorAlternation...................................................................................116
8.12 Relay On/Off Delay...............................................................................117
8.13 Relay On/Off Control.............................................................................118
8.14 Power On Run Delay............................................................................118
8.15 RegenerationAvoidance Function.......................................................119
8.16 Auto-tuning.............................................................................................120
8.17 Factory default by motor ratings...........................................................121
8.18 Energy-saving operation.......................................................................122
8.19 Speed search ........................................................................................122
8.20 Auto restart try.......................................................................................125
8.21 Operating sound select (Carrier frequency change)...........................127
8.22 2nd motor operation................................................................................127
8.23 Frequency setting and 2nd drive method select...................................128
8.24 Stall Prevention and Power Braking....................................................131
8.25 DRAW Operation...................................................................................132
8.26 2 Phase PWM Operation......................................................................134
8.27 Cooling fan control ................................................................................134
8.28 Operating mode select when cooling fan trip occurs..........................135
8.29 Accel/Decel Change Frequency ..........................................................136

xi
Table of Contents
8.30 Fire Mode...............................................................................................137
8.31 Parameter read/write.............................................................................138
Parameter read.........................................................................1388.31.1
Parameter write.........................................................................1388.31.2
8.32 Parameter Initialize / Lock.....................................................................139
Parameter initialize...................................................................1398.32.1
Password register.....................................................................1398.32.2
9Monitoring.......................................................................................................141
9.1 Operating status monitoring .................................................................141
Output current...........................................................................1419.1.1
Motor RPM................................................................................1419.1.2
Inverter DC Link Voltage..........................................................1429.1.3
User display select....................................................................1429.1.4
Power on display ......................................................................1429.1.5
9.2 Monitoring the I/O terminal ...................................................................143
Input terminal status monitoring...............................................1439.2.1
Output terminal status monitoring............................................1449.2.2
9.3 Monitoring fault condition......................................................................145
Monitoring current fault status..................................................1459.3.1
Fault History Monitoring............................................................1469.3.2
9.4 Analog Output........................................................................................147
9.5 Multi-function output terminal Relay 1 and Relay 2 ............................148
9.6 Output terminalselect at loder communication error..........................158
10 Protective functions.......................................................................................159
10.1 Electronic Thermal................................................................................159
10.2 OverloadWarning and trip....................................................................161
Overload warning......................................................................16110.2.1
Overload trip..............................................................................16110.2.2
10.3 Stall prevention......................................................................................162
10.4 Output phase loss protection................................................................164
10.5 External trip signal.................................................................................164
10.6 Inverter Overload...................................................................................165
10.7 Speed command loss...........................................................................165

xii
Table of Contents
10.8 DB Resistor Enable Duty setting..........................................................168
10.9 Under Load Protection..........................................................................169
10.10Broken Belt Protection..........................................................................171
10.11Pipe Broken...........................................................................................172
10.12Over Pressure .......................................................................................173
11 RS485 communication..................................................................................174
11.1 Introduction............................................................................................174
11.2 Specification...........................................................................................175
11.3 Installation..............................................................................................175
11.4 Operation...............................................................................................176
11.5 Communication protocol (MODBUS-RTU) .........................................177
11.6 Communication protocol (LS BUS)......................................................177
11.7 Parameter code list <Common area>...............................................181
11.8 Troubleshooting.....................................................................................187
11.9 Miscellaneous........................................................................................188
12 Troubleshooting & Maintenance.................................................................189
12.1 Protective functions...............................................................................189
12.2 Fault remedy..........................................................................................191
Overload Protection..................................................................19412.2.1
12.3 Precautions for maintenance and inspection......................................195
12.4 Check points..........................................................................................195
Daily inspections.......................................................................19512.4.1
Periodic inspection....................................................................19512.4.2
12.5 Part replacements.................................................................................196
13 Specifications.................................................................................................197
13.1 Technical data........................................................................................197
Input & output ratings:Three Phase 200V Class...................19713.1.1
Input & output ratings:Three Phase 400V Class...................19813.1.2
Control.......................................................................................19813.1.3
Operation...................................................................................19913.1.4
Protective function....................................................................19913.1.5
Environment..............................................................................20013.1.6
13.2 Temperature Derating Information.......................................................200

xiii
Table of Contents
13.3 Remote Option......................................................................................201
Parts...........................................................................................20113.3.1
Installation .................................................................................20213.3.2
13.4 Conduit Kit .............................................................................................203
Installation .................................................................................20313.4.1
Conduit Kit.................................................................................20413.4.2
13.5 Braking resistor......................................................................................205

1
Basic information & precautions
Basic Info.
1 Basic information & precautions
1.1 Important precautions
Unpackingand
inspection
Inspect the inverter for any damage that may have occurred during

shipping.To verify the inverter unit is the correct one for the application
you need,check the inverter type, output ratings on the nameplate and
the inverter is intact.
SV
075
iG5H
-
2
LS Inverter
Motor rating
Series Name
Volt Range
004
0.4 [kW]
iG5H
2
Three Phase 200-230[V]
008
0.75 [kW]
015
1.5 [kW]
022
2.2 [kW]
037
3.7 [kW]
4
Three Phase 380-480[V]
040
4.0 [kW]
055
5.5 [kW]
075
7.5 [kW]
Accessories

If you havefound any discrepancy, damage, etc., contact your sales
representative.
Preparations of
instruments
andparts
required for
operation
Instruments and parts to be prepared depend on how the inverterisoperated.
Prepare equipmentand parts as necessary.
Installation
To operate the inverter with high performance for a long time, install the
inverterin a proper place in the correct direction and with proper clearances
Wiring
Connect the power supply, motor and operation signals (control signals) to the
terminal block. Note that incorrectconnection may damage the inverter and
peripheral devices

2
Basic information & precautions
1.2 Product Details
Appearance
Inside view after front cover is removed
Refer to “1.3 Product assembling & disassembling”for details.
Front cover:
Removed when
wiring
Bottom cover:
Removed when
wiring input
power and a
motor
Status LED Display
Inverter
nameplate
4-Waybutton for
parameter setting
(Up/Down/Left/Right)
Control signal
Terminal
NPN,PNP
SelectSwitch
[ENT] button
STOP/RESET
button
Inverter Ground
Terminal
RUN button
Power terminal
Cooling fan

3
Basic information & precautions
Basic Info.
1.3 Product assembling & disassembling
To remove the front cover: Press the both indented sides of the cover lightly and pull up.
To change the inverter fan: Press the both sides of bottom cover lightly and pull out to your
side
.

4
Installation & Wiring
2 Installation & Wiring
2.1 Installation precautions
Handle the inverterwith care to prevent damage to the plastic components. Do not hold

the inverter by the front cover. It may fall off.
Install the inverterin a place where it is immune to vibration (5.9 m/s2or less).

Install in a location where temperature is within the permissible range (-10-50 oC).

<Ambient Temp Checking Location>
The inverter will be very hot during operation. Install it on a non-combustible surface.

Mount the inverter on a flat, vertical and level surface. Inverter orientationmust be vertical

(top up) for proper heat dissipation.Also leave sufficient clearances around the inverter.
Protectfrom moisture and direct sunlight.

Ventilatingfan
Coolingair
5cm
Min
10cm Min
5cm
Min
10cm Min
Leave space enough to allow
cooled air flowing easily
between wiring duct and the
unit

5
Installation & Wiring
Installation
Donot install the inverterin anyenvironment where itis exposed to waterdrops, oil mist,

dust, etc. Install the inverter in a clean place or inside a “totallyenclosed”panel any
suspended matter is not entered.
When two or more inverters are installed or a cooling fan is mounted in a panel, the

inverters and fan must be installed in proper positions with extreme care to keep the
ambient temperature below the permissible range.
Installed the inverter using screws or bolts to insure the inverter is firmlyfastened.

< For installing multiple inverters in a panel>
Take caution on proper heat ventilation when installinginverters and fans in a panel.
Heat (NG)

6
Installation & Wiring
2.2 Dimensions
SV004iG5H-2 /SV008iG5H-2
SV004iG5H-4 /SV008iG5H-4
SV015iG5H-2 / SV015iG5H-4
