Sunbeam GoHeat 804-RFL2P User manual

Sunbeam®GoHeat®
Portable Heated Patches
Refill Kit
Instruction Manual
Model: 804-RFL2P
804-RFL3P
For product questions:
Sunbeam Consumer Service
USA: 1.800.435.1250
www.sunbeam.com
©2018 Sunbeam Products, Inc. All rights reserved.
804-RFL2P_ 804-RFL3P_18EM3 P.N. 195886 Rev B
Printed in China GCDS-SUN370523-LD
Low Med Hi
STORE PATCH HERE
AFTER USE
Patches Refill Kit_804-RFL2P_804-RFL3P_18EM3.indd 2 11/6/18 10:46 AM

-1--2-
6. DO NOT USE ON AREAS OF INSENSITIVE SKIN.
7. BURNS CAN OCCUR REGARDLESS OF
CONTROL SETTING, CHECK SKIN UNDER
PATCH FREQUENTLY. STOP USE IF
SKIN BECOMES IRRITATED, BRUISED,
SWOLLEN, OR IF PAIN AND DISCOMFORT
IS EXPERIENCED. IF BURNS OCCUR, SEEK
MEDICAL ATTENTION.
8. AGE 55 OR OLDER: YOUR RISK OF BURNING
INCREASES AS YOU AGE. USE WITH
CAUTION.
9. DO NOT USE IN AN OXYGEN ATMOSPHERE.
10. DO NOT USE PINS OR OTHER METALLIC
MEANS TO FASTEN THE PATCH IN PLACE.
11. DO NOT SIT ON, AGAINST, OR CRUSH
PATCHES – AVOID SHARP FOLDS. PLACE
PATCH ON TOP OF AND NOT UNDER THE
PART OF BODY NEEDING HEAT.
12. UNPLUG CORDS WHEN NOT IN USE.
NEVER LEAVE APPLIANCE UNATTENDED,
ESPECIALLY IF CHILDREN ARE PRESENT.
13. NEVER PULL THIS PATCH BY THE CORD. DO
NOT USE THE CORD AS A HANDLE. DO NOT
PINCH CORD.
14. DO NOT TUCK IN, TRAP, FOLD, CROSS,
PINCH OR WRAP CORD OR CONTROLLER
UNDER THE PATCH OR ANY OTHER
INSULATING MATERIAL DURING USE.
IMPORTANT SAFETY
INSTRUCTIONS
DO NOT DESTROY
DANGER: TO REDUCE RISKS OF BURNS,
ELECTRIC SHOCK, FIRE, AND PERSONAL
INJURY, THIS PRODUCT MUST BE USED
IN ACCORDANCE WITH THE FOLLOWING
INSTRUCTIONS:
1. READ ALL INSTRUCTIONS BEFORE USING
THIS APPLIANCE.
2. DO NOT USE WHILE SLEEPING OR ON
SOMEONE WHO IS SLEEPING.
3. DO NOT USE ON AN INFANT OR ON AN ANIMAL.
4. THESE PATCHES ARE NOT TO BE USED
ON OR BY AN INVALID, HELPLESS OR
UNCONSCIOUS PERSON, A PERSON WITH
DIABETES, A PERSON WITH POOR BLOOD
CIRCULATION, INSENSITIVITY TO HEAT, A
PERSON INCAPACITATED BY MEDICATION
OR UNDER THE INFLUENCE OF ALCOHOL, OR
ANYONE UNDER THE AGE OF 18.
5. THIS APPLIANCE IS NOT TO BE USED ON
OR BY CHILDREN. CLOSE SUPERVISION
IS NECESSARY WHEN ANY APPLIANCE IS
USED NEAR CHILDREN. CHILDREN SHOULD
NOT PLAY WITH THE APPLIANCE.
Patches Refill Kit_804-RFL2P_804-RFL3P_18EM3.indd 1-2 11/6/18 10:46 AM

-3--4-
15. CAREFULLY EXAMINE PATCHES, CORD
AND CONTROLLER BEFORE EACH USE.
DISCARD THE PATCH IF ANY SIGN OF
DETERIORATION, WEAR OR DAMAGE. DO
NOT TAMPER WITH THIS PATCH IN ANY
WAY. IF PATCH UNIT DOES NOT FUNCTION
SATISFACTORILY, SEE WARRANTY FOR
CUSTOMER CONTACT INFORMATION.
16. LOOP CORD WHEN STORING. ALLOW TO COOL
BEFORE STORING. STORE IN THE ORIGINAL
PACKAGING, IN A COOL, DARK, DRY PLACE.
17. USE ONLY THE PROVIDED CONTROLLER,
AUTHORIZED PATCHES AND PROVIDED
POWER SUPPLY (SUNBEAM CHARGER
MODEL F06US0950050A).
18. USE THIS APPLIANCE ONLY AT RATED
VOLTAGE, AS MARKED ON THE PRODUCT.
DO NOT USE WITH GENERATORS, POWER
CONVERTERS, OR INVERTERS.
19. DO NOT USE THIS PATCH WITH LINIMENT,
SALVE OR OINTMENT PREPARATIONS. SKIN
BURNS COULD RESULT.
20. THIS APPLIANCE IS NOT INTENDED
FOR MEDICAL USE IN HOSPITALS OR
HEALTHCARE FACILITIES. ONLY USE PER
THE RECOMMENDED INSTRUCTIONS.
21. DO NOT INGEST FILLING MATERIAL,
OR ADHESIVE GEL MATERIAL, IF IT IS
INGESTED, SEEK MEDICAL ATTENTION.
22. DO NOT PLACE EXTRA PRESSURE OVER THE
PRODUCT SUCH AS HOLDING PATCH DOWN
WITH HANDS OR USE OF ADDITIONAL
ADHESIVES OR FASTENING METHODS TO
HOLD PATCH IN PLACE. REPLACE PATCH
WHEN DAMAGED OR WILL NOT ADHERE.
23. DO NOT USE ON AREAS OF BRUISING,
SWELLING OR OPEN WOUNDS.
24. STOP USE IF SKIN BECOMES IRRITATED,
BRUISED, SWOLLEN, OR IF PAIN AND
DISCOMFORT IS EXPERIENCED.
25. NEVER USE THIS APPLIANCE WITH
MALIGNANCIES, SKIN ERUPTIONS,
SWOLLEN, INFLAMED AREAS OR SIMILAR
CONDITIONS. FAILURE TO FOLLOW THIS
WARNING MAY SPREAD CONDITION TO
OTHER PARTS OF THE BODY.
26. THIS PRODUCT IS ONLY SUITABLE FOR USE
IN THE AMBIENT TEMPERATURE BETWEEN
4°C AND 40°C.
27. SAVE THESE INSTRUCTIONS.
Patches Refill Kit_804-RFL2P_804-RFL3P_18EM3.indd 4 11/6/18 10:46 AM

-5--6-
Low Med Hi
STORE PATCH HERE
AFTER USE
FCC STATEMENT
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.”
FCC CAUTION:
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures: —Reorient or relocate the receiving
antenna. —Increase the separation between the equipment and
receiver. —Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected. —Consult the dealer or
an experienced radio/ TV technician for help.
COMPONENTS INCLUDED:
1. 2 Standard Patches for Model 804-RFL2P
(Starter Kit Model 804-STR2P)
1 Deluxe patch (For Model 804-RFL3P only)
(Starter Kit Model 805-STR3P
1Standard Patches
Figure 1
1Deluxe Patch
(For Model
805-STR3P only)
KEEP DRY
(Cleaning instructions: controller do not wet / must be kept dry)
RECYCLE
Controller Contains Lithium Battery
READ INSTRUCTIONS
DISPOSE OF PROPERLY
Not for general waste disposal
This product has earned the UL Listed Mark
ULUS
C
LISTED
Heated Patch
E498509
Patches Refill Kit_804-RFL2P_804-RFL3P_18EM3.indd 5-6 11/6/18 10:46 AM

-7--8-
HOW TO USE:
Apply Patches
1. Clean skin with a soft wet washcloth. Mild soap may be used but
skin will need to be rinsed thoroughly prior to drying. Ensure skin
is completely dry before applying patch.
2. Plug the connector cords into the control unit and patches. (see
figure 2 and 3)
3. Remove initial plastic film from patch and throw away.
4. Place patches onto body with the gel side facing skin.
5. Attach belt clip to control unit and clip to pants or place into
pocket.
6. Wrap the connector cords around the control unit to remove slack.
Select Heat Setting
1. There are three heat settings,
Low, Medium, and High.
2. The High setting is a
20-minute cycle of High
Level Heat. After 20
minutes on High, the unit
automatically switches to
Medium.
3. Do not use High setting
more than once in a 2-hour
period.
i. Note: When skin is
exposed to heat, it leads
to increased blood flow
to the skin and dilation
of the capillaries. After
use, your skin may be
slightly red and warm
to touch. This redness
should fade over time.
CAUTION: If discomfort,
persistent redness or
skin irritation occurs,
discontinue use.
ii. If at any point, the temperature feels too hot, select lower
temperature setting or discontinue use.
4. There are heat-setting lights on control unit to indicate if the unit
is set to Low, Medium or High. (see figure 4 for light locations)
5. Use the control unit button to select heat settings by clicking
consecutively to scroll through each setting. (see figure 4 for
button location)
After Use
1. Place patches onto plastic films that states, “Store patch here,
after use” with the gel side facing film.
i. Each patch will last up to 10 times. Discard patch when gel no
longer sticks to skin. Refill patches sold separately. (Sunbeam
Models: 804-RFL2P and 804-RFL3P)
2. Wrap connector cords around control unit for neat and tidy storage.
3. If needed, recharge control unit prior to next use – only use the
power supply that was provided with the unit.
4. Store unit and patches in cool dry location between use.
Low Med Hi Low Med Hi Low Med Hi
Low Heat Light Medium Heat Light High Heat Light
Control Unit Button:
Control Heat Settings
Battery Light
Figure 4
Note: If all 3 Heat Setting lights are flashing, a fault has occurred.
Press the power button to shut down the control unit and try a
new patch. If flashing lights persist, discontinue use and contact
warranty services.
Patch Connector Port Patch Connector Port
Charger Port
Figure 2
Figure 3
Patches Refill Kit_804-RFL2P_804-RFL3P_18EM3.indd 7-8 11/6/18 10:46 AM

-9--10-
LIMITED WARRANTY
Sunbeam Products, Inc. (“Sunbeam”) or if in Canada, Newell Industries Canada ULC (“NIC”) warrants
that for a period of one (1) year from the date of initial retail purchase, this product will be free from
defects in material and workmanship, when used in accordance with the instructions provided.
Sunbeam (or NIC) warrants the patches and cords supplied with the unit will be free from defects in
material and workmanship for thirty (30) days from the date of initial retail purchase.
Sunbeam (or NIC), at its option, will repair or replace this product or any component of the product
found to be defective during the warranty period.
Replacement will be made with a new or remanufactured product or component. If the product is no
longer available, replacement may be made with a similar product of equal or greater value. This is
your exclusive warranty. Do NOT attempt to repair or adjust any electrical or mechanical functions on
this product. Doing so will void this warranty.
This warranty is valid for the original retail purchaser from the date of initial retail purchase
and is not transferable. Keep the original sales receipt. Proof of purchase is required to obtain
warranty performance. Sunbeam (or NIC) dealers, service centers, or retail stores selling
Sunbeam (or NIC) products do not have the right to alter, modify or any way change the terms
and conditions of this warranty.
This warranty does not cover normal wear of parts or damage resulting from any of the following:
negligent use or misuse of the product, use on improper voltage or current, use contrary to the
operating instructions, disassembly, repair or alteration by anyone other than Sunbeam (or NIC) or an
authorized Sunbeam (or NIC) service center. Further, the warranty does not cover: Acts of God, such as
fire, flood, hurricanes and tornadoes.
What are the limits on Sunbeam’s (or NIC’s) Liability?
Sunbeam (or NIC) shall not be liable for any incidental or consequential damages caused by the
breach of any express, implied or statutory warranty or condition. Except to the extent prohibited
by applicable law, any implied warranty or condition of merchantability or fitness for a particular
purpose is limited in duration to the duration of the above warranty. Sunbeam (or NIC) disclaims
all other warranties, conditions or representations, express, implied, statutory or otherwise.
Sunbeam (or NIC) shall not be liable for any damages of any kind resulting from the purchase,
use or misuse of, or inability to use the product including incidental, special, consequential or
similar damages or loss of profits, or for any breach of contract, fundamental or otherwise, or for
any claim brought against purchaser by any other party. Some provinces, states or jurisdictions
do not allow the exclusion or limitation of incidental or consequential damages or limitations on
how long an implied warranty lasts, so the above limitations or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights that vary from
province to province, state to state or jurisdiction to jurisdiction.
How to Obtain Warranty Service
In the U.S.A.
If you have any question regarding this warranty or would like to obtain warranty service,
please call 1 800 435-1250 and a convenient service center address will be provided to you.
In Canada
If you have any question regarding this warranty or would like to obtain warranty service, please
call 1 800 667- 8623 and a convenient service center address will be provided to you.
In the U.S.A., this warranty is offered by Sunbeam Products, Inc. located in Boca Raton, Florida 33431.
In Canada, this warranty is offered by Newell Industries Canada ULC, located at 20B Hereford
Street, Brampton, Ontario L6Y 0M1. If you have any other problem or claim in connection with
this product, please write our Consumer Service Department.
PLEASE DO NOT RETURN THIS PRODUCT TO ANY OF THESE ADDRESSES OR TO THE
PLACE OF PURCHASE.
WHERE TO USE:
The Sunbeam®GoHeat®Standard Patches can be used for common
muscle aches and pains.
The Sunbeam®GoHeat®Deluxe Patch can be used for common joint
pain.
HOW TO CLEAN:
1. Disconnect unit from power source and patch from control unit.
2. Do not wash or submerge in water.
3. Use a dry cloth to spot wipe the control.
4. If patch becomes wet or soiled, discard and replace.
5. Do not use chemicals to clean product.
Patches Refill Kit_804-RFL2P_804-RFL3P_18EM3.indd 9-10 11/6/18 10:46 AM
