sunjoe SPX-FC34 User manual

RSPX-FC34 ASSEMBLY QUICK GUIDE
FOR USE WITH
SPX3000/SPX4000/SPX9000 SERIES:
1.If not already done, detach your spray wand from your trigger gun.
2.Attach the transfer adapter to your trigger gun.
3.Take the foam cannon and align the two tabs with the transfer adapter.
4.Once aligned, insert the tip of the locking collar on the foam cannon into the transfer adapter, twist counter clockwise to lock into place.
5.Adjust the foam cannon if needed. After any adjustment is made, use the locking collar to lock the attachment into place. and twist to lock.
SPX2000/SPX6000/SXP7000 Series
Trigger gun Locking collar
SPX3000/SPX4000/SPX9000 Series
Trigger gun Transfer adapter Locking collar
SPX200/SPX1000 Series
Trigger gun Locking collarMiddle wand

FOR USE WITH
SPX2000/SPX6000/SPX7000 SERIES:
1.If not already done, detach your spray wand from your trigger gun.
2.Take the foam cannon and align the two tabs with the trigger gun.
3.Once aligned, insert the tip of the locking collar on the foam cannon into the trigger gun, twist counter clockwise to lock into place.
4.Adjust the foam cannon if needed. After any adjustment is made, use the locking collar to lock the attachment into place.
FOR USE WITH SPX200/SPX1000 SERIES:
1.Disconnect your spray wand assembly so that only the middle wand remains attached to your trigger gun.
2.Take the foam cannon and align the two tabs with the middle wand.
3.Once aligned, insert the tip of the locking collar on the foam cannon into the middle wand and twist counter clockwise to lock into place.
4.Adjust the foam cannon if needed. After any adjustment is made, use the locking collar to lock the attachment into place and twist to lock.
NOTE:
1.There is a soap knob on the top of your SPX-FC34. Turn it clockwise to release soap, and counter clockwise to stop.
2.You can adjust the amount of soap you would like to release by turning the front part of your SPX-FC34. Turn
clockwise for a larger spray, and counter clockwise for a pin point spray.
Only use detergents specifically recommended for use with pressure washers, such as Sun
Joe® HOUSE + DECK WASH (SPX-HDC1G), Sun Joe® SNOW FOAM AUTO WASH (SPX-
FCS1G), or Sun Joe® HEAVY DUTY CLEANER (SPX-APC1G).
DO NOT USE household detergents, acids, alkaline solutions, bleaches, solvents, flammable
material, or industrial grade solutions. These can damage the pump.
