sunjoe 24V-ST14 User manual

© 2021 by Snow Joe®, LLC
All rights reserved. Original instructions. SAVE THESE INSTRUCTIONS
1
A Division of Snow Joe®, LLC
OPERATOR’S MANUAL
Model 24V-ST14 Form No. SJ-24V-ST14-880E-M
RCORDLESS TRIMMER + EDGER
24V MAX* | 4.0 Ah | 12-INCH
EN
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Read all the instructions contained in this manual. Keep this
manual in a safe place, so that the information is available at
all times. If you give the equipment to another person, make
sure to provide these operating instructions. Basic safety
precautions should always be followed to reduce the risk of
re, electric shock, and personal injury.
mDANGER! This indicates a hazardous situation, which,
if not followed, will result in serious injury or death.
mWARNING! This indicates a hazardous situation, which,
if not followed, could result in serious injury or death.
mCAUTION! This indicates a hazardous situation, which,
if not followed, could result in minor or moderate injury.
Improper use of the machine will invalidate the warranty,
relieve the manufacturer from all liabilities. The user will
consequently be liable for all and any damage or injury to
himself/herself or others.
mDANGER! The cordless trimmer + edger should only
be used for cutting lawns and for trimming along the borders
of ower beds. Other uses of the trimmer + edger that are
not indicated in these instructions could damage the unit or
seriously injure the operator.
General Safety
1. Avoid dangerous environments – Do not use appliances
in damp or wet locations. Do not use in rain.
2. Keep children and bystanders away – Children and
other spectators, including pets, should be kept at least
50 feet (15 meters) away from the work area. When the
grass is cut, stones and debris contained in the grass can
be picked up by the trimmer + edger and dispersed into
the air. These ying projectiles can cause blindness or
other bodily injury.
3. Dress properly – Always wear suitable clothing when
using the trimmer + edger to prevent head, hand, or feet
injuries. Do not wear loose clothing or jewelry. They can
get caught in moving parts.
4. Use safety glasses – Also use safety footwear, snug-
tting clothing, protective gloves, hearing and head
protection.
5. Use the right tools – Do not use tools for any job except
that for which they are intended.
6. Avoid unintentional starting – Do not carry the tool with
nger on the trigger. Make sure the switch is o before
inserting the battery.
7. Do not force the tool – It will do the job better and with
less likelihood of injury if it is used at the rate for which it
was designed.
8. Do not overreach – Keep proper footing and balance at
all times.
9. Stay alert – Watch what you are doing. Use common
sense. Do not operate the trimmer + edger when you are
tired, or under the inuence of alcohol or drugs.
10. Disconnect the tool – Turn the trimmer + edger o and
remove the battery when: the unit is not in use; it is left
unattended; it is being examined because it is not working
correctly; the cutting line is being removed or changed;
or when the trimmer is being moved from one place to
another.
11. Store idle tools indoors – When not in use, tools should
be stored indoors in a dry and high or locked-up place out
of the reach of children.
12. Maintain tools with care – Keep cutting lines sharp
and clean for best performance and to reduce the risk of
injury. Follow instructions for maintenance and changing
accessories. Repair the trimmer + edger only at an
authorized service facility. Keep handles dry, clean, and
free from oil and grease.
13. Checked for damaged parts – Before continuing to
use the trimmer + edger, a guard or other part that is
damaged should be carefully checked to determine that
it will operate properly and perform its intended function.
Check for the alignment of moving parts, binding of
moving parts, breakage of parts, mounting, and any other
condition that may aect the tool’s operation. A guard or
other part that is damaged should be properly repaired or
replaced by an authorized service center unless indicated
elsewhere in this manual.
mCAUTION! The safety guard is critical to the safety of
the operator and the safety of people standing within a safe
distance of the trimmer + edger. The safety guard keeps the
unit in good working order and must always be in place during
operation. Failure to have the guard in place during operation
is dangerous and will void the warranty.

2
14. Keep away from the cutting line – It can seriously injure
the skin.
15. Do not try to stop the cutting device with your hands –
Always let it come to a stop by itself.
16. Stay alert – Watch what you are doing. Use common
sense. Do not operate the trimmer + edger when you are
tired or under the inuence of drugs, alcohol, or other
medication.
mCAUTION! The trimmer line spool will continue to rotate
after turning the trimmer OFF. Wait until the trimmer line spool
has completely stopped before making contact.
• Only use the same type of line originally provided with the
tool.
• Do not use the unit to cut grass that is not in contact with
the ground.
• Do not switch the trimmer + edger ON in enclosed or poorly
ventilated spaces or in the presence of ammable and/or
explosive substances such as liquids, gases, and powders.
• The user of the trimmer + edger is responsible for any
damage sustained by third parties that has been caused by
the trimmer + edger within the working area.
• Only cut during broad daylight or with adequate articial
light.
• Do not cross roads or gravel paths while the unit is still
running.
• When the trimmer + edger is not in use, store it in a dry
place and out of the reach of children.
• The trimmer + edger must be operated in a vertical position,
perpendicular to the ground.
• Check regularly that all screws are properly secured.
Battery + Charger
Safety Instructions
We pay a great deal of attention to the design of every battery
pack to ensure that we supply you with batteries that are safe,
durable and have a high energy density. The battery cells have
a wide range of safety devices. Each individual cell is initially
formatted and its electrical characteristic curves are recorded.
This data is then used exclusively to be able to assemble the
best possible battery packs.
Despite all the safety precautions, caution must always be
exercised when handling batteries. The following points must
be obeyed at all times to ensure safe use. Safe use can only
be guaranteed if undamaged cells are used. Incorrect handling
of the battery pack can cause cell damage.
IMPORTANT! Analyses conrm that incorrect use and poor
care of high-performance batteries are the main factors
responsible for personal and/or product damage.
mWARNING! Use only approved replacement batteries;
other batteries may damage the power tool and cause it to
malfunction, which can lead to serious personal injury.
mWARNING! Do not use a battery pack or appliance that
is damaged or modied. Damaged or modied batteries may
exhibit unpredictable behavior resulting in re, explosion or risk
of injury.
Do not modify or attempt to repair the appliance or the battery
pack except as indicated in the instructions for use and care.
Have your battery pack serviced by a qualied repair person
using only identical replacement parts. This will ensure that the
safety of the battery pack is maintained.
mCAUTION! To reduce the risk of injury, charge the
Sun Joe®24V lithium-ion battery pack only in its designated
Sun Joe® lithium-ion charger. Other types of chargers present
risk of re, personal injury and damage. Do not wire a battery
pack to a power supply plug or car cigarette lighter. Such
misuse will permanently disable or damage the battery pack.
• Avoid dangerous environments – Do not charge the
battery pack in rain, snow or in damp or wet locations.
Do not use the battery pack or charger in the presence of
explosive atmospheres (gaseous fumes, dust or ammable
materials) because sparks may be generated when inserting
or removing the battery pack, which could lead to a re.
• Charge in a well-ventilated area – Do not block the
charger vents. Keep them clear to allow for proper
ventilation. Do not allow smoking or open ames near a
charging battery pack. Vented gases may explode.
NOTE: The safe temperature range for the battery is 41°F –
105ºF (5°C – 40.5°C). Do not charge the battery outside in
freezing weather; charge it at room temperature.
• Maintain charger cord – When unplugging the charger, pull
the plug, not the cord, from the receptacle to reduce the
risk of damage to the electrical plug and cord. Never carry
the charger by its cord or yank it by the cord to disconnect
it from the receptacle. Keep the cord away from heat, oil
and sharp edges. Make sure the cord will not be stepped
on, tripped over or subjected to damage or stress when the
charger is in use. Do not use the charger with a damaged
cord or plug. Replace a damaged charger immediately.
• Do not use an extension cord unless it is absolutely
necessary – Using the wrong, damaged or improperly
wired extension cord poses a risk of re and electric shock.
If an extension cord must be used, plug the charger into a
properly wired 16 gauge or larger extension cord with the
female plug matching the male plug on the charger. Make
sure that the extension cord is in good electrical condition.
• Charger 24VCHRG-QC is rated for 120 volt AC only
– The charger must be plugged into an appropriate
receptacle.
• Use only recommended attachments – Use of an
attachment not recommended or sold by the battery

3
charger or battery pack manufacturer may result in risk of
re, electric shock or personal injury.
• Unplug charger when not in use – Make sure to
disconnect battery pack from unplugged charger.
mWARNING! To reduce the risk of electric shock,
always unplug the charger before performing any cleaning
or maintenance. Do not allow water to ow into the charger.
Use a Ground Fault Circuit Interrupter (GFCI) to reduce shock
hazards.
• Do not burn or incinerate battery pack – Battery pack
may explode, causing personal injury or damage. Toxic
fumes and materials are created when battery packs are
burned.
• Do not crush, drop or damage battery pack – Do not use
the battery pack or charger if they have sustained a sharp
blow, been dropped, run over or have been damaged in any
way (i.e. pierced with a nail, hit with a hammer, stepped on,
etc.).
• Do not disassemble – Incorrect reassembly may pose
a serious risk of electric shock, re or exposure to toxic
battery chemicals. If the battery or charger are damaged,
contact an authorized Snow Joe®+ Sun Joe®dealer or
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563) for assistance.
• Battery chemicals cause serious burns – Never let a
damaged battery pack contact the skin, eyes or mouth.
If a damaged battery pack leaks battery chemicals, use
rubber or neoprene gloves to safely dispose of it. If skin
is exposed to battery uids, wash the aected area with
soap and water and rinse with vinegar. If eyes are exposed
to battery chemicals, immediately ush with water for 20
minutes and seek medical attention. Remove and dispose
of contaminated clothing.
• Do not short circuit – When battery pack is not in use,
keep it away from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal objects
that can make a connection from one terminal to another.
Shorting the battery terminals together may cause burns or
a re.
• Store your battery pack and charger in a cool, dry
place – Do not store the battery pack or charger where
temperatures may exceed 105ºF (40.5ºC), such as in direct
sunlight or inside a vehicle or metal building during the
summer.
Information about the battery
1. The battery pack supplied with your cordless trimmer +
edger is only partially charged. The battery pack has to
be charged completely before you use the tool for the rst
time.
2. For optimum battery performance, avoid low discharge
cycles by charging the battery pack frequently.
3. Store the battery pack in a cool place, ideally at 77°F
(25°C) and charged to at least 40%.
4. Lithium-ion batteries are subject to a natural aging
process. The battery pack must be replaced at the latest
when its capacity falls to just 80% of its capacity when
new. Weakened cells in an aged battery pack are no
longer capable of meeting the high power requirements
needed for the proper operation of your cordless trimmer
+ edger, and therefore pose a safety risk.
5. Do not throw the battery pack into an open re as this
poses a risk of explosion.
6. Do not ignite the battery pack or expose it to re.
7. Do not exhaustively discharge batteries. Exhaustive
discharge will damage the battery cells. The most
common cause of exhaustive discharge is lengthy storage
or non-use of partially discharged batteries. Stop working
as soon as the performance of the battery falls noticeably
or the electronic protection system triggers. Place the
battery pack in storage only after it has been fully charged.
8. Protect the battery and the tool from overloads. Overloads
will quickly result in overheating and cell damage inside
the battery housing even if this overheating is not apparent
externally.
9. Avoid damage and shocks. Immediately replace batteries
that have been dropped from a height of more than
3 feet (1 meter) or those that have been exposed to violent
shocks, even if the housing of the battery pack appears to
be undamaged. The battery cells inside the battery may
have suered serious damage. In such instances, please
read the waste disposal information for proper battery
disposal.
10. If the battery pack suers overloading and overheating,
the integrated protective cuto will switch o the
equipment for safety reasons.
IMPORTANT! Do not press the power supply button any
more if the protective cut-o has been activated. This may
damage the battery pack.
11. Recharge only with the charger specied by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of re when used with
another battery pack.
12. Use appliances only with specically designated battery
packs. Use of any other battery packs may create a risk of
injury and re.
13. Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally occurs,
ush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause
irritation or burns.
14. Do not use a battery pack or appliance that is damaged
or modied. Damaged or modied batteries may exhibit
unpredictable behavior resulting in re, explosion or risk of
injury.
15. Do not expose a battery pack or appliance to re or
excessive temperature. Exposure to re or temperature
above 265ºF (130°C) may cause explosion.
16. Follow all charging instructions and do not charge the
battery pack or appliance outside of the temperature
range specied in the instructions. Charging improperly
or at temperatures outside of the specied range may
damage the battery and increase the risk of re.

4
Information about the charger and the
charging process
1. Please check the data marked on the rating plate of the
battery charger. Be sure to connect the battery charger
to a power supply with the voltage marked on the rating
plate. Never connect it to a dierent mains voltage.
2. Protect the battery charger and its cord from damage.
Keep the charger and its cord away from heat, oil and
sharp edges. Have damaged cords repaired without delay
by a qualied technician at an authorized Snow Joe®+
Sun Joe®dealer or call the Snow Joe®+ Sun Joe®
customer service center at 1-866-SNOWJOE
(1-866-766-9563).
3. Electrical plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
grounded appliances. Unmodied plugs and matching
outlets will reduce the risk of electric shock.
4. Keep the battery charger, battery pack and the cordless
tool out of the reach of children.
5. Do not use the supplied battery charger to charge other
cordless tools.
6. During periods of heavy use, the battery pack will become
warm. Allow the battery pack to cool to room temperature
before connecting with the charger to recharge.
7. Do not overcharge batteries. Do not exceed the maximum
charging times. These charging times only apply to
discharged batteries. Frequent insertion of a charged or
partially charged battery pack will result in overcharging
and cell damage. Do not leave batteries in the charger for
days on end.
8. Never use or charge the battery if you suspect that it has
been more than 12 months since the last time they were
charged. There is a high probability that the battery pack
has already suered dangerous damage (exhaustive
discharge).
9. Charging batteries at a temperature below 41°F (5°C) will
cause chemical damage to the cells and may cause a re.
10. Do not use batteries that have been exposed to heat
during the charging process, as the battery cells may have
suered dangerous damage.
11. Do not use batteries that have suered curvature or
deformation during the charging process or those that
exhibit other atypical symptoms (gassing, hissing,
cracking, etc.).
12. Never fully discharge the battery pack (maximum
recommended depth of discharge is 80%). A complete
discharge of the battery pack will lead to premature aging
of the battery cells.
Protection from environmental inuences
1. Protect your cordless tool and the battery charger from
moisture and rain. Moisture and rain can cause dangerous
cell damage.
2. Do not use the cordless tool or the battery charger near
vapors and ammable liquids.
3. Use the battery charger and cordless tools only in dry
conditions and at an ambient temperature of 41ºF – 105°F
(5°C – 40.5°C).
4. Do not keep the battery charger in places where the
temperature is liable to reach over 105°F (40.5°C). In
particular, do not leave the battery charger in a car that is
parked in the sunshine.
5. Protect batteries from overheating. Overloads,
overcharging and exposure to direct sunlight will result
in overheating and cell damage. Never charge or work
with batteries that have been overheated – replace them
immediately, if possible.
6. Store the charger and your cordless tool only in dry
locations with an ambient temperature of 41ºF – 105°F
(5°C – 40.5°C). Store your lithium-ion battery pack in a
cool, dry place at a temperature of 77°F (25°C). Protect
the battery pack, charger and cordless tool from humidity
and direct sunlight. Only place fully charged batteries in
storage (charged to at least 40%).
7. Prevent the lithium-ion battery pack from freezing. Battery
packs that were stored below 32°F (0°C) for more than 60
minutes must be discarded.
8. When handling batteries, be wary of electrostatic
charge. Electrostatic discharges can damage the
electronic protection system and the battery cells. Avoid
electrostatic charging and never touch the battery poles.

5
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all
instructions on the machine before attempting to assemble and operate.
READ THE OPERATOR'S
MANUAL(S) – Read, understand,
and follow all instructions in the
user manual(s) before attempting
to assemble and operate.
SAFETY ALERT – Indicates
a precaution, a warning, or
a danger.
DANGER! Beware of thrown objects to bystanders. Keep bystanders at least
15 m (50 ft) away from the machine.
WARNING! Do not expose the unit
to rain or wet conditions.
WEAR EYE AND HEARING
PROTECTION – For protection
against injury, wear ear defenders
and safety goggles.
Keep bystanders and children
a safe distance away.
Symbols SymbolsDescriptions Descriptions
Wear protective gloves when
using the machine and handling
debris.
Beware of ying objects and
debris.
Indoor use only. Only use
battery charger indoors.

6
Know Your Cordless Trimmer + Edger
Read the owner’s manual and safety instructions carefully before operating the cordless trimmer + edger. Compare the illustration
below to your cordless trimmer + edger in order to familiarize yourself with the location of the various controls and adjustments.
Save this manual for future reference.
1
2
3
4
5
6
7
8
9
10
11
12
13
14151617
18
19
20
21
22
23
24
1. Battery compartment
2. Handle grip
3. Trigger switch
4. Safety lock button
5. Upper pole
6. Auxiliary handle
7. Auxiliary handle lock
8. Telescoping locking coupler
9. Lower pole
10. Trimmer/edger head
locking button
11. Multi-angle head
adjustment button
12. Safety guard
13. Edger guide wheel
14. Spool housing
15. Cutting line
16. Edger guide + ower guard
17. Line cutter
18. Motor housing
19. iON+ 24V lithium-ion battery
(24VBAT) featuring exclusive
EcoSharp®technology
20. Push lock button (2)
21. Battery indicator
22. Push button for battery indicator
23. 24V iON+ lithium-ion quick
charger (24VCHRG-QC)
24. Charger plug

7
Technical Data
Motor .............................................................................. 250 W
Battery Voltage Max* .................................................. 24V D.C.
Battery Capacity ............................................................. 4.0 Ah
Battery Runtime Max ...................................................... 35 min
..................................................(trims up to 2800 sq ft of grass)
Charger Input ........................................ 120V AC, 60 Hz, 75 W
Charger Output .................................................... 26V DC, 2.2A
Charge Time Max ................................................... 1 hr 50 min
Cutting Width Max .............................................. 12 in. (30 cm)
Trimmer Line Length ............................................. 16.4 ft. (5 m)
Trimmer Line Diameter ................................ 0.063 in. (1.6 mm)
Cutting Speed ..................................................6500 ± 10% rpm
Telescoping Pole Length ....................................... 5 ft — 5.8 ft
(1.5 m – 1.8 m)
Multi-Angle Head .......................................... 0° , 15° , 30° , 45°
Spool Advance .......................................................... Auto feed
Net weight ......................................................... 6.2 lbs (2.8 kg)
*Initial no-load voltage, when fully charged, peaks at 24 volts; nominal voltage
under typical load is 21.6 volts.
Unpacking
Carton Contents
• Cordless trimmer + edger
• Safety guard
• Safety guard screws (2)
• Auxiliary handle
• Edger guide wheel
• Edger guide + ower guard
• iON+ 24V lithium-ion battery
• iON+ 24V lithium-ion battery charger
• Manual with registration card
1. Carefully remove the cordless trimmer + edger and check
to see that all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you nd damaged or
missing parts, DO NOT return the unit to the store. Please
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use the cordless trimmer
+ edger. The packaging is made of recyclable materials.
Properly dispose of these materials in accordance with
local regulations or save the packaging for long-term
product storage.
IMPORTANT! The equipment and packaging material are not
toys. Do not let children play with plastic bags, foils, or small
parts. These items can be swallowed and pose a suocation
risk!
Battery Pack Operation
The equipment is powered by a lithium-ion battery. The battery
pack is completely sealed and maintenance free.
Battery Charge Level Indicator
The battery pack is equipped with a push button for checking
the charge level. Simply press the push button to read o the
battery charge level from the LEDs of the battery indicator:
• All 3 level monitoring LEDs are lit: Battery charge level is
high.
• 2 level monitoring LEDs are lit: Battery charge level is
decreasing. Turn o the cordless trimmer + edger as soon
as possible.
• 1 level monitoring LED is lit: Battery is at. Turn o the
cordless trimmer + edger IMMEDIATELY and charge the
battery. Otherwise the battery’s service life will be greatly
shortened.
NOTE: If the charge level button does not appear to be
working, insert the charger and charge as needed.
NOTE: Immediately after using the battery pack, the charge
level button may display a lower charge than it will if checked
a few minutes later. The battery cells “recover” some of their
charge after resting.
Charger Operation
mWARNING! Charge only Sun Joe®24V lithium-ion
battery pack with its compatible Sun Joe®24V lithium-ion
charger. Other types of batteries may cause personal injury
and damage.
To reduce the risk of electric shock, do not allow water to ow
into the charger's AC/DC plug.
Charge level button
The battery is at 30% capacity
and requires charging
The battery is at 60% capacity
and requires charging soon
The battery is at full capacity
Light IndicatorsLights

8
When to Charge the iON+ 24VBAT
Lithium-Ion Battery
NOTE: The iON+ 24VBAT lithium-ion battery pack does
not develop a "memory" when charged after only a partial
discharge. Therefore, it is not necessary to run down the
battery pack before charging.
• Use the battery indicator lights to determine when to charge
your iON+ 24VBAT lithium-ion battery pack.
• You can "top-o" your battery pack's charge before or after
a long day of use.
Charging the Battery
1. Push the push lock buttons on the battery to pull the
battery pack out from the battery compartment (Fig. 1).
2. Check that the mains voltage is the same as that marked
on the rating plate of the battery charger. Then, insert the
charger's plug into the electrical wall outlet. When you
plug in the charger, the top right green light will illuminate
and stay green (Fig. 2).
3. Place the battery pack into the charger by sliding the
pack to lock it into position. When you insert the battery
into the charger, the top right green light will go o, and
the top left red light will illuminate to indicate that the
battery is charging (Fig. 3).
4. When the charger light turns green, the battery is fully
charged (Fig. 3).
NOTE: A fully discharged pack with an internal
temperature in the normal range will fully charge in 1 hr 50
mins (between 32ºF/0ºC and 113ºF/45ºC).
5. If the light indicators do not come on at all, check that
the battery pack is fully seated into the bay. Remove
the battery pack and reinsert. If the problem persists,
contact an authorized Snow Joe®+ Sun Joe®dealer or
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563) for assistance.
6. When charging is complete, remove the battery from the
charger by pressing the push lock buttons and sliding the
battery backward to unlock it from the charger.
Assembly
mWARNING! Do not insert the battery until assembly is
complete. Failure to comply could result in accidental starting
and possible serious personal injury.
Fitting the Safety Guard
mWARNING! The safety guard must be properly installed.
The guard provides the operator and other bystanders with
some protection from thrown objects.
1. Remove the battery pack from the trimmer + edger.
2. Slide the tabs of the safety guard into the slots on the
trimmer head. Push to make sure the safety guard clicks
into position (Fig. 4).
Fig. 1
Battery lock button
Battery compartment
Fig. 2
Charger
green
Power on
Fig. 3 Battery pack
Charger
red
Charging
green
Fully
Charged

9
3. Lay the trimmer on the ground with the trimmer head
facing upward then secure the safety guard to the trimmer
head with the screws provided (Fig. 5).
NOTE: Never use the tool unless the safety guard is properly
installed.
Fitting the Edger Guide Wheel
1. Mount the edger guide wheel by sliding it from above as
shown (Fig. 6). Firmly press the edger guide wheel into
place.
Fitting the Edger Guide + Flower Guard
1. Lightly spread the edger guide + ower guard by hand
while approaching the motor housing.
2. While lightly spreading the edger guide + ower guard, t
the curved parts into the slot on the motor housing, and
release (Figs. 7 & 8).
Fitting the Auxiliary Handle
1. Flip the auxiliary handle lock up to release the handle lock.
(Fig. 9).
Fig. 4
Safety guard
Tabs
Slots
Fig. 5 Safety guard screws
Fig. 6
Edger guide
wheel
Edger guide +
ower guard
Fig. 7 Slots
Edger guide +
ower guard
Slot
Fig. 8
Fig. 9
Upper pole
Flip up to
unlock
Auxiliary
handle lock

10
2. Slide the auxiliary handle onto the base plate. Make sure
the tabs on both sides of the auxiliary handle slide into the
slots on the base plate. Push until it clicks into position
(Fig. 10).
3. Adjust the auxiliary handle to a comfortable working
position. Lock the auxiliary handle by ipping the handle
lock down (Fig. 11).
Operation
Starting + Stopping
Before you start the unit, make sure the trimmer is not
contacting with any object.
1. Slide the battery pack in the battery compartment until it
snaps into position (Fig. 12).
IMPORTANT! Make sure that the battery pack is secured
to the tool before beginning operation.
2. To turn the trimmer + edger ON, press and hold the safety
lock button with your thumb, then squeeze the ON/OFF
trigger switch with your ngers. Once the machine powers
on, you can release the safety lock button and proceed
with operation (Fig. 13).
3. To switch OFF, release the trigger switch. Remove the
battery from the battery compartment (Fig. 13).
mWARNING! Always remove the battery pack from the
trimmer + edger during work breaks and after nishing work.
Telescoping Pole Adjustment
1. Disconnect the trimmer + edger by removing the battery
pack.
2. Turn the telescoping locking coupler clockwise to unlock
the telescoping pole (Fig. 14).
Fig. 10
Auxiliary
handle
Base plate
TabSlot
Fig. 11
Auxiliary
handle lock
Flip down
to lock
Fig. 12
Battery compartment
Battery pack
Fig. 13
Safety lock button
Trigger switch
Fig. 14
Telescoping
locking coupler

11
3. Adjust the pole to the desired length (Fig. 15).
NOTE: Push poles toward each other to shorten the pole
or pull them away from each other to lengthen the pole.
Only extend the pole to the minimum length needed.
4. Lock the telescoping pole in position by turning the
telescoping locking coupler counter-clockwise. (Fig. 14)
Trimming
• Wear non-slip gloves for maximum grip and protection.
Hold the trimmer + edger with your right hand on the rear
handle while the right arm slightly bent, and your left hand
on the front auxiliary handle with the left arm straight. The
trimmer + edger should be held at a comfortable position
with the rear handle about hip height. The trimmer head
should be parallel with the ground and easily contacts the
material to be cut without the operator having to bend over
(Fig. 16).
• For the best cutting action against walls, fences, and in
high grass, move the trimmer + edger slowly so grass is cut
with the tip of the high speed nylon line. Do not force the
trimmer. Cutting with more than the tip will reduce cutting
eciency and may overload the motor.
• Avoid dragging the trimmer + edger and string spool hub in
contact with the ground.
• Trim only when grass and weeds are dry.
• Cut tall grass from top down. This will prevent grass from
wrapping around the shaft housing and string head which
may cause damage from overheating.
• If grass becomes wrapped around the string head:
–Stop the trimmer.
– Remove the battery.
– Remove the grass.
mWARNING! Always hold the trimmer away from body.
Any contact with the trimmer + edger cutting head while
operating can result in serious personal injury.
• The life of your nylon line is dependent upon following
instructions for proper use, as well as what is being cut,
and where the cutting is being done.
mWARNING! Remove stones, loose pieces of wood, and
other objects from the cutting area. The cutting line continues
to rotate for a few seconds after switching o the trimmer. Let
the motor come to a complete stop before resuming operation.
Do not rapidly switch the trimmer o and on.
mCAUTION! Always wear eye protection.
1. The correct angle for the cutting attachment is parallel to
the ground.
2. Slowly swing the trimmer from side to side (Fig. 17).
Fig. 15
Telescoping pole
Fig. 16
Fig. 17
Swing
Trimming with tool

12
3. Do not overload your trimmer; instead, take small “bites”
of grass, working from the top to the bottom. This will
keep the machine operating at high speed and will greatly
improve its cutting eciency (Fig. 18).
Adjusting Multi-Angle Trimming Head
1. Press the multi-angle head adjustment button to adjust
the trimmer head in four positions (0º, 15º, 30º and 45º)
(Fig. 19).
Edging
1. To convert from trimming to edging, turn OFF the tool and
remove the battery.
2. Remove the edger guide + ower guard if it prevents the
cutting line from contacting the soil.
3. Press trimmer/edger head locking button then turn the
trimmer head to 90 degree (Figs. 20 & 21).
4. Reinstall the battery. Press the safety lock button and then
the trigger.
5. Hold the trimmer in a comfortable position with right hand
on the rear handle and left hand on the front auxiliary
handle (Fig. 22). Slowly walk with the tool, holding it with
your arms steady. Moving your body instead of your arms
will ultimately make the cut on the grass much straighter.
6. Move the unit in a backwards direction when trimming
around edges to avoid damage.
Fig. 18
Fig. 19 Multi-angle head
adjustment
button
0º to 45º
Fig. 20
Trimmer/edger
head locking
button
Fig. 21
Turn trimmer
head to 90º
Fig. 22 Edging with the tool

13
mWARNING! Do not trim near electrical wires.
Advancing Cutting Line
NOTE: Your trimmer + edger uses 0.063 in. (1.6 mm) diameter
nylon line to cut grass and weed quickly and easily. In time,
the tip of the nylon line will become worn and the auto-feed
mechanism will automatically feed and trim a fresh length of
line. The cutting line will wear faster if the cutting is done along
sidewalks or other abrasive surfaces or heavier weeds are
being cut.
The trimmer + edger is equipped with an auto-feed head.
Bumping the head to try to advance the cutting line will
damage trimmer.
1. With the unit running, release the ON/OFF trigger switch.
2. Wait two seconds, and press the ON/OFF trigger switch.
NOTE: The cutting line will extend approximately 1/4 in.
with each stop and start of the switch trigger until the
cutting lines reach the length of the safety guard.
3. Resume the trimming + edging.
mWARNING! Do not operate the grass trimmer + edger
in a tree, on a ladder, or on a scaold; this is extremely
dangerous.
mWARNING! Do not bump the unit on ground in attempt
to feed line or for any other purpose.
Maintenance
mWARNING! Make sure to remove the battery before
inspecting its parts.
mWARNING! Always wear protective gloves during
maintenance tasks. Do not carry out maintenance when the
motor is running or hot.
• Your cutting line can dry out over time. To keep your line in
top condition, store spare pre-wound spools or bulk line in a
plastic resealable bag with a tablespoon of water.
• Never use water or chemical cleaners to clean your trimmer
+ edger. Wipe it clean with a dry cloth.
• Plastic parts may be cleaned by using mild soap and a
damp rag.
• Always store your trimmer + edger in a dry place. Do not
allow any liquid to get inside it.
• Keep the motor ventilation slots clean.
IMPORTANT! To ensure product safety and reliability, repairs,
maintenance, and adjustments to this power tool should be
performed only with identical replacement parts. Contact your
authorized Snow Joe®+ Sun Joe®dealer or call the Snow Joe®
+ Sun Joe® customer service center at 1-866-SNOWJOE
(1-866-766-9563) for assistance.
Replacing the Spool + Clearing Jams
and Tangled Lines
mWARNING! Remove the battery from the battery
compartment before changing the cutting line.
mWARNING! Never use metal-reinforced line, wire,
or rope, etc. These can break o and become dangerous
projectiles.
NOTE: 16.4 ft. (5 m) single-line replacement spool
(model 24V-ST14-SPOOL) is available for use with the
24V-ST14 trimmer + edger. Visit snowjoe.com to purchase
this accessory online. Always use the recommended nylon
cutting line with diameter no more than 0.063 in. (1.6 mm).
Using line other than that specied may cause the trimmer +
edger to overheat or become damaged.
1. Press together both release tabs on the line spool cover
and remove the cover by pulling it straight o
(Figs. 23 & 24).
Fig. 23
Spool releasing tab
(on both sides)
Spool cover
Fig. 24 Spool cover

14
2. Lift and remove the spool out of the hub (Fig. 25) and
clean out the remaining cutting line, remove any jams, or
dirt and grass residue.
3. Re-insert the spool into the spool hub as follow, or insert a
new pre-wounded spool (Fig. 25).
4. Insert each line end through its respective eyelet on each
side of the hub and gently press the spool down (Fig. 26).
5. Reinstall the spool cover by depressing the release tabs
into their slots in the hub, and push down until the spool
cover clicks into place (Fig. 27).
IMPORTANT: Only use original replacement parts specied for
this machine.
You can purchase a replacement pre-wound spool (Model
24V-ST14-SPOOL) and other genuine replacement parts
by visiting us online at sunjoe.com or calling our toll-free
customer service helpline at 1-866-SNOWJOE (1-866-766-
9563). The use of parts that do not meet the original equipment
specications may lead to improper performance of the grass
trimmer, may compromise operator safety and will void the
manufacturer's warranty.
Winding the Line
NOTE: Should you wish to wind the line yourself, the
instructions are provided below. Self-winding, however, is NOT
recommended because if the line is not wound properly it can
cause the trimmer’s auto feed system to malfunction. For this
reason, users are strongly urged to purchase the pre-wound
spool.
1. Turn o and remove the battery. Make sure the spool has
come to a complete stop.
2. To remove the spool from the trimmer hub, follow steps
1 and 2 from the section "Replacing the Spool + Clearing
Jams and Tangled Lines" beginning on page 13.
3. Measure and cut a 16.4 ft (5 m) piece of new cutting line.
Insert the end of the cutting line into the small hole located
inside of the spool (Fig. 28).
4. Bend the cutting line 180 degree around the hole, secure
the bending part with your left hand thumb, and use your
right hand to wind the line according to the arrows on the
spool (Figs. 29 & 30). Use slight tension to make sure the
line is tight around the spool.
Fig. 25 Spool cover
Spool
Spool hub
Fig. 26
Eyelet
Spool hub
Cutting
line
Fig. 27
Spool cover
Release tabs
Slots
Fig. 28
Spool
Cutting line
Fig. 29
Bend the cutting line

15
5. Re-install the spool as instructed in steps 3 to 5 of
"Replacing the Spool + Clearing Jams and Tangled Lines".
mCAUTION! Catapulted pieces of nylon line may cause
injury.
mWARNING! Pay attention to the winding direction.
NOTE: Always replace the spool with a new pre-wound spool.
Visit sunjoe.com to purchase the pre-wound spool
(model 24V-ST14-SPOOL) for this cordless trimmer + edger.
Storage
Follow these recommendations for storing the trimmer + edger.
• Clean the trimmer + edger thoroughly before storing.
• Store the trimmer + edger in a stable and safe position out
of the reach of children. Keep the trimmer + edger in a dry
place where the temperature is not too hot or too cold.
• When storing the trimmer + edger, do not rest it against the
oor. Hang it by the upper handgrip so that the guard does
not touch anything. If the guard rests against a surface, its
shape and dimensions could be permanently altered, and
could render the machine unsafe to use.
Battery Caution + Disposal
Always dispose of your battery pack according to federal,
state, and local regulations. Contact a recycling agency in your
area for recycling locations.
mCAUTION! Even discharged battery packs contain
some energy. Before disposing, use electrical tape to cover
the terminals to prevent the battery pack from shorting, which
could cause a re or explosion.
mWARNING! To reduce the risk of injury or explosion,
never burn or incinerate a battery pack even if it is damaged,
dead, or completely discharged. When burned, toxic fumes
and materials are emitted into the surrounding atmosphere.
1. Batteries vary according to device. Consult your manual
for specic information.
2. Install only new batteries of the same type in your product
(where applicable).
3. Failure to insert batteries in the correct polarity, as
indicated in the battery compartment or manual, may
shorten the life of the batteries or cause batteries to leak.
4. Do not mix old and new batteries.
5. Do not mix Alkaline, Standard (Carbon-Zinc), or
Rechargeable (Nickel Cadmium, Nickel Metal Hydride, or
Lithium-Ion) batteries.
6. Do not dispose of batteries in re.
7. Batteries should be recycled or disposed of as per state
and local guidelines.
Service and Support
If your Sun Joe®24V-ST14 cordless trimmer + edger requires
service or maintenance, please call the Snow Joe®+ Sun Joe®
customer service center at 1-866-SNOWJOE
(1-866-766-9563).
Model and Serial Numbers
When contacting the company, reordering parts, or arranging
service from an authorized dealer, you will need to provide the
model and serial numbers, which can be found on the decal
located on the housing of the unit. Copy these numbers into
the space provided below.
Fig. 30
Record the following numbers from the housing or handle of your
new product: Model #:
Serial #:
2 4 V - S T 1 4

16
Troubleshooting
Problems Possible Cause Possible Solution
The motor does not
run or the tool runs
slowly.
• Battery is not inserted well or is at.
• Spool housing cannot rotate freely.
• Cutting line does not protrude.
• Check to make sure the battery is charged and inserted
well.
• Remove the spool and clean the slots; carefully remove
any grass and weeds or other debris.
• Cut the spool line o so that it just reaches the line
trimming blade.
• Contact your authorized Snow Joe®+ Sun Joe®dealer
or call Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563) if the trimmer does
not start after completing these checks.
• Contact your authorized Snow Joe®+ Sun Joe®dealer
or call Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563).
• Rewind or trim line to line cutter.
• Line cutter in guard is covered,
damaged, or missing.
• Line extends past guard.
Line fails to cut o.

17
Optional Accessories
mWARNING! ALWAYS use only authorized Snow Joe®+ Sun Joe® replacement parts and accessories. NEVER use
replacement parts or accessories that are not intended for use with this cordless trimmer + edger. Contact Snow Joe®+ Sun
Joe®if you are unsure whether it is safe to use a particular replacement part or accessory with your cordless trimmer + edger.
The use of any other attachment or accessory can be dangerous and could cause injury or mechanical damage.
iON+ 24V 2.0 Ah Lithium-Ion Battery
Battery Runtime Max: 18 min (trims up to 1500 sq ft of grass)
iON+ 24V 2.0 Ah Lithium-Ion Battery
Battery Runtime Max: 11 min (trims up to 910 sq ft of grass)
iON+ 24V 2.5 Ah Lithium-Ion Battery
Battery Runtime Max: 22 min (trims up to 1750 sq ft of grass)
iON+ 24V 4.0 Ah Lithium-Ion Battery
Battery Runtime Max: 35 min (trims up to 2800 sq ft of grass)
iON+ 24V 2.5 Ah Lithium-Ion Battery
Battery Runtime Max: 13 min (trims up to 1050 sq ft of grass)
iON+ 24V 5.0 Ah Lithium-Ion Battery
Battery Runtime Max: 44 min (trims up to 3360 sq ft of grass)
24VBAT-LTE
24VBAT-LTW
24VBAT-LT
24VBAT-LTX
24VBAT
24VBAT-XR
ModelAccessories Item
3
1
4
2
5
6

18
NOTE: Accessories are subject to change without any obligation on the part of Snow Joe®+ Sun Joe®to provide notice of such
changes. Accessories can be ordered online at snowjoe.com or via phone by contacting the Snow Joe®+ Sun Joe®customer
service center at 1-866-SNOWJOE (1-866-766-9563).
Grass Trimmer Single-Line Replacement Spool
iON+ 24V lithium-ion Battery Quick Charger
iON+ 24V lithium-ion Dual Port Battery Charger
24V-ST14-SPOOL
24VCHRG-QC
24VCHRG-DPC
ModelAccessories Item
7
8
9

R4_01282020
SNOW JOE®+ SUN JOE®CUSTOMER PROMISE
OUR WARRANTY:
Snow Joe warrants new, genuine, powered and non-powered Products to be free from defects in material or workmanship when used
for ordinary household use for a period of two years from the date of purchase by the original, end-user purchaser when purchased
from Snow Joe or from one of Snow Joe’s authorized sellers with proof of purchase. Because Snow Joe is unable to control the quality
of its Products sold by unauthorized sellers, unless otherwise prohibited by law, this Warranty does not cover Products purchased from
unauthorized sellers. If your Product does not work or there’s an issue with a specic part that is covered by the terms of this Warranty,
Snow Joe will elect to either (1) send you a free replacement part, (2) replace the Product with a new or comparable product at no
charge, or (3) repair the Product. How cool is that!
This Warranty gives you specific legal rights, and you may also have other rights which vary from State to State.
PRODUCT REGISTRATION:
Snow Joe strongly encourages you to register your Product. You can register online at snowjoe.com/register, or by printing and
mailing in a registration card available online from our website, or calling our Customer Service Department at 1-866-SNOWJOE
(1-866-766-9563), or by e-mailing us at [email protected]. Failure to register your Product will not diminish your warranty
rights. However, registering your Product will allow Snow Joe to better serve you with any of your customer service needs.
WHO CAN SEEK LIMITED WARRANTY COVERAGE:
This Warranty is extended by Snow Joe to the original purchaser and original owner of the Product.
WHAT IS NOT COVERED?
This Warranty does not apply if the Product has been used commercially or for non-household or rental applications. This Warranty also
does not apply if the Product was purchased from an unauthorized seller. This Warranty also does not cover cosmetic changes that do
not aect performance. Wearing parts like belts, augers, chains and tines are not covered under this Warranty, and can be purchased
at snowjoe.com or by calling 1-866-SNOWJOE (1-866-766-9563).
ABOVE ALL ELSE, Snow Joe, LLC (“Snow Joe”) is dedicated to you, our customer. We strive to make your experience as pleasant as
possible. Unfortunately, there are times when a Snow Joe®, Sun Joe®, or Aqua Joe®product (“Product”) does not work or breaks under
normal operating conditions. We think it’s important that you know what you can expect from us. That’s why we have a Limited Warranty
(“Warranty”) for our Products.
19
EN
