Panasonic i-Shaper ER-GD60 User manual
Operating Instructions
(Household) AC/Rechargeable Shaving Trimmer
Model No. ER‑GD60/ER‑GD50
2
English 3
Deutsch 17
Français 33
Italiano 47
Nederlands 61
Español 75
Dansk 89
Português 103
Norsk 117
Svenska 131
Suomi 145
Polski 159
3
English
Operating Instructions
(Household) AC/Rechargeable Shaving Trimmer
Model No. ER‑GD60/ER‑GD50
Thank you for purchasing this Panasonic product.
Safety precautions..................... 6
Intended use9
9
Preparation10
Using the trimmer11
Cleaning13
Troubleshooting14
Blade life15
15
Removing the built-in rechargeable
15
16
Contents
4
English
Warning
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
•The supply cord cannot be replaced. If the cord is
damaged, the AC adaptor should be scrapped.
•Do not use anything other than the supplied AC adaptor
for any purpose.
Also, do not use any other product with the supplied AC
adaptor. (See page 9.)
5
English
•Keep the appliance dry.
The symbol on the left means “Do not wash the
product with water”.
•
power supply unit is required for connecting the electrical
appliance to the supply mains. The type reference of
power supply unit is marked near the symbol.
6
English
damage to property, always observe the following safety precautions.
The following symbols are used to classify and describe the level
of hazard, injury, and property damage caused when the
denotation is disregarded and improper use is performed.
DANGER Denotes a potential
hazard that will result in
serious injury or death.
WARNING Denotes a potential
hazard that could result
in serious injury or death.
CAUTION
Denotes a hazard that
could result in minor injury
or property damage.
The following symbols are used to classify and describe the type
of instructions to be observed.
procedure that must not be performed.
procedure that must be followed in order to operate the
unit safely.
WARNING
Do not connect or disconnect the adaptor to a
‑ Doing so may cause electric shock or injury.
Do not immerse the appliance and AC adaptor in
Do not place the appliance and AC adaptor over or
Never use the appliance if the AC adaptor is
‑
‑ Exceeding the rating by connecting too many plugs to one
electric power source matched to the rated voltage
‑
‑ Failure to do so may cause electric shock or injury.
7
English
WARNING
‑
caused by humidity.
Disconnect the adaptor and wipe with a dry cloth.
‑
•The main unit or AC adaptor is deformed or
•
•There is abnormal sound during use or charging of
‑ Immediately request inspection or repair at an authorized
service centre.
This product
‑
‑
Contact an authorized service centre for repair (battery
change, etc.).
Never disassemble except when disposing of the
‑
Preventing accidents
‑ Putting the blade, and/or oil container in the mouth may
cause accidents and injury.
vomiting, drink a large amount of water, and contact
‑ Failure to do so may result in physical problems.
CAUTION
Protecting the skin
‑ Doing so may cause skin injury.
Check that the blades are not damaged or deformed
‑ Failure to do so may cause skin injury.
8
English
CAUTION
Note the following precautions
Do not allow metal objects or trash to adhere to the
‑
circuit.
‑ Doing so may cause injury.
‑ Doing so may cause the wire in the cord to break with the
Disconnect the adaptor from the household outlet
‑
electrical leakage resulting from insulation deterioration.
holding onto the adaptor or the appliance plug
‑ Failure to do so may cause electric shock or injury.
DANGER
•
•
•Do not let the positive and negative terminals of
•
•
‑
WARNING
‑ The battery will harm the body if accidentally swallowed.
If this happens, consult a physician immediately.
9
English
WARNING
‑
contact with your eyes.
Do not rub your eyes. Wash immediately with clean water
and consult a physician.
‑
comes in contact with the skin or clothes.
Wash it off thoroughly with clean water and consult a
physician.
Intended use
• Before using an attachment, check that it has been installed
correctly. Failure to do so may cause beard to be cut too short.
• The appliance should not be used on animals.
• Before and after each use, apply oil at the marked places.
(See page 13.)
Failure to apply the oil may cause the following problems.
‑ The trimmer has become blunt.
‑ Shorter operating time.
‑ Louder sound.
• Do not use thinner, benzine, alcohol or other chemicals. Doing
so may cause failure, cracking or discoloration of the main body.
Clean the main body only with a soft cloth slightly dampened
with tap water or soapy tap water.
• Store the trimmer in a place with low humidity after use. Failure
to do so may cause malfunction due to condensation or rust.
A
1Power switch ( )
2Charge status lamp ( )
3Appliance socket
BBlade
4Mounting hook
5Cleaning lever
6Moving blade
7Stationary blade
CTrimming height comb
attachment
8Dial
9Trimming height
indication mark
D
Detail trimming attachment
ER-GD60
EAC adaptor (RE9-86)
(The shape of the power
plug differs depending on
:Adaptor
;Power plug
<Cord
=Appliance plug
Accessories
FCleaning brush
GOil
HPouch ER-GD60
Attach one of the attachments when carrying the trimmer.
10
English
Preparation
Charging the trimmer
• Make sure that the trimmer is turned off.
1 Connect the appliance plug
Plug in the adaptor into a
• Check that the charge status lamp
( ) glows.
• Charging is completed after approx.
1 hour. 1
2
3 Disconnect the adaptor when the charge status
(for safety and to reduce energy usage)
<To check if charging is completed>
If you remove and reinsert the appliance plug while charging,
the charge status lamp glows and turns off after
approximately 5 seconds.
Notes
• If there is crackling noise on radios or other devices while
charging, charge the trimmer using a different household outlet.
• When the appliance is not used for 6 months or more, the battery
once every 6 months.
•
been in use for more than 6 months, the lamp on the main body
may not glow for a few minutes, or the operating time may
shorten. Please charge it for more than 8 hours in such cases.
•
Recommended ambient temperature for charging is 0 °C – 35 °C.
The charging time may change or battery performance may
decrease outside of the recommended temperature.
• A full charge supplies enough power for approximately
50 minutes of use. (Based on dry using at 20 °C ‑ 30 °C.)
The operating time may differ depending on the frequency of
use, the operating method and the ambient temperature.
• You can charge the battery before it is completely discharged.
However, it is recommended to charge when the battery is
completely discharged. The battery life depends strongly on
factors such as how it is used and stored.
AC operation
If you connect the AC adaptor to the trimmer in the same way as
for charging, and turn on the power, you can use it.
• If the remaining battery is too low, the blades may move slowly
or stop, even with the AC operation. In this case, charge the
battery for 1 minute or more.
• The battery will be discharged, even with the AC operation.
11
English
Using the trimmer
• Check that the blades are not damaged or deformed before use.
•
Apply the oil to the blade before and after each use. (See page 13.)
• Use the appropriate attachment as needed.
(See pages 11 and 12.)
It can also be used without the attachment. (See this page.)
•
• The appliance may not operate in an ambient temperature lower
than approximately 0 °C.
How to use the trimmer
• Do not use with shaving foam applied or when the beard is wet.
to trim.
• Before trimming, comb your moustache with a comb.
Without attachment
Design precise lines
Trimming height: approx. 0.1 mm
(Fixed blade thickness is 0.1 mm)
Detail trimming attachment ER-GD60
Use the attachment for trimming narrow areas and for detailed
trimming.
12
English
Trimming height comb attachment
• Make sure that the trimmer is turned off.
• Actual beard length will be a little longer than the height you set.
• The desired results may not be achieved if beard is too long.
In this case, trim the beard to a length of about 20 mm before
using the trimmer.
• For areas with thick or dense beard growth, trim a bit at a time.
Beard sometimes gets caught or builds up in the attachment.
When this happens, clean the attachment. (See page 13.)
1 Turn the dial and adjust the
trimming height indication
mark (a
• Trimming height (estimate): 0.5 mm to 10 mm
Indicator 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5
Trimming height (mm)
(estimate) 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5
Indicator 5.5 6 6.5 7 7.5 8 8.5 9 9.5 10
Trimming height (mm)
(estimate) 5.5 6 6.5 7 7.5 8 8.5 9 9.5 10
Flat part of the comb
Removing and mounting the attachments
• Take care not to injure hands, etc., with the blade when removing
or mounting the attachment.
• Make sure that the trimmer is turned off.
Mounting the attachment
Mount the attachment to the
main body until it clicks.
• If the attachment is not
attached correctly, it may shift
and end up cutting too much
during use.
click
Removing the attachment
Hold the main body securely and
remove the attachment from the
main body.
• Hold the rib (b) part securely
and remove the detail trimming
attachment.
13
English
Cleaning
• Clean the trimmer and the blade after each use.
(If not cleaned, the motion will become poor and the sharpness
will worsen.)
• Make sure that the trimmer is turned off.
• Remove the attachment and blade. (See pages 12 and 14.)
With water
• Do not wash the appliance with water.
Doing so may cause malfunction if put in water.
Blade and the attachment
1. Clean the blade and the
attachments with running water.
• Rinse with water and shake up and
down several times to remove the
water.
2. Wipe off the water with a towel and
let it dry naturally.
3. Apply the oil to the blade after
drying. (See this page.)
With the brush
1. Brush off any hair trimmings from the
main body and from around the blade.
2. Brush off the hair trimmings from the
blade edge.
3. Brush any hair trimmings out from
between the stationary blade and the
moving blade while pressing down the
cleaning lever (c) to raise the moving
blade.
4. Apply the oil to the blade. (See this page.)
Lubrication
• Apply the oil to the blade before and after each use.
Apply a drop of the oil to each indicated
point.
Attach the blade to the main body, turn
on the power and allow to run for
approximately 5 seconds.
Failure to apply the oil may cause the
following problems due to rust, wear or
burn out.
‑ The trimmer has become blunt.
‑ Shorter operating time.
‑ Louder sound.
Replacement parts
Replacement part is available at your dealer or Service Centre
Replacement parts for ER‑GD60/
ER‑GD50 Blade WER9500
14
English
Removing and mounting the blade
Removing the blade
Hold the trimmer and push the
blade with your thumb.
Mounting the blade
Fit the mounting hook (B) into the blade mounting (A) on the
trimmer and then push in until you hear a click.
Troubleshooting
Perform the following actions.
If the problems still cannot be solved, contact the store where
you purchased the unit or a service centre authorized by
Panasonic for repair.
Problem Action
The trimmer has become
blunt.
Operating time is short.
Trimmer stopped
functioning.
Until problems are solved, please
follow each procedure as follows;
1. Charge the trimmer.
(See page 10.)
2. Clean the blade and apply oil.
(See page 13.)
3. Replace the blade.
(See pages 13 and 14.)
4. Have the battery replaced by
an authorized service centre.
Charge the battery for
approximately 8 hours
continuously to rejuvenate it.
If few uses remain even after
charging, the battery has reached
the end of its life. (Fluid may be
leaking due to degradation at the
end of battery life.)
Contact an authorized service
centre for repair.
The trimmer cannot be
charged.
Insert the appliance plug into the
Makes a loud sound.
Apply oil. (See page 13.)
attached.
15
English
Blade life
Blade life varies according to the frequency and period of use of
the trimmer.
For example, the blade life is approximately 3 years when using the
trimmer for 5 minutes 10 times a month. Replace the blades if
Battery life will vary according to the frequency and length of use.
If the battery is charged once a month, the service life will be
approximately 3 years.
the battery has reached the end of its life.
designated location if there is one.
must not be used to repair it. If you dismantle the trimmer yourself,
it may cause malfunction.
• Remove the trimmer from the AC adaptor.
• Press the power switch to turn on the power and then keep the
power on until the battery is completely discharged.
• Perform steps 1to :and lift the battery, and then remove it.
• Take care not to short circuit the positive and negative terminals
of the removed battery, and insulate the terminals by applying
tape to them.
This trimmer contains a Nickel‑Metal Hydride battery.
assigned location, if there is one in your country.
16
English
Power source See the name plate on the AC adaptor.
(Automatic voltage conversion)
Motor voltage 1.2 V
Charging time Approx. 1 hour
Airborne
Acoustical Noise 71 (dB (A) re 1 pW)
This product is intended for household use only.
Disposal of Old Equipment and Batteries
These symbols on the products, packaging, and/or
accompanying documents mean that used electrical
and electronic products and batteries must not be
mixed with general household waste.
For proper treatment, recovery and recycling of old
products and batteries, please take them to applicable
collection points in accordance with your national
legislation.
By disposing of them correctly, you will help to save
valuable resources and prevent any potential negative
effects on human health and the environment.
For more information about collection and recycling,
please contact your local municipality.
Penalties may be applicable for incorrect disposal of
this waste, in accordance with national legislation.
This symbol might be used in combination with a
chemical symbol. In this case it complies with the
requirement set by the Directive for the chemical
involved.
17
Deutsch
Bedienungsanleitung
(Haushalt) Netz‑/Akku‑Bartschneider
Modellnr. ER‑GD60/ER‑GD50
Vielen Dank, dass Sie sich für den Kauf dieses Panasonic‑Produkts entschieden haben.
Bevor Sie dieses Gerät in Betrieb nehmen, lesen Sie sich bitte diese Anleitung vollständig durch und bewahren Sie sie für ein späteres
Sicherheitsvorkehrungen .............. 20
Beabsichtigter Gebrauch
Bezeichnung der Bauteile
Vorbereitung
Verwendung des Trimmers
Reinigung
Fehlersuche
Lebensdauer der Klinge 30
Akkulebensdauer30
Entnehmen des integrierten Akkus 30
Technische Daten31
Inhalt
18
Deutsch
Warnung
• Dieses Gerät kann von Kindern ab 8 Jahren und von
Personen mit eingeschränkten physischen, sensorischen
oder mentalen Fähigkeiten verwendet werden, oder von
Personen, denen entsprechende Kenntnisse und Erfahrungen
fehlen. Voraussetzung ist, dass sie dabei beaufsichtigt
werden oder ihnen eine Einweisung gegeben wurde, wie sie
das Gerät sicher verwenden können, und sie die damit
verbundenen Risiken verstanden haben. Kinder dürfen nicht
mit dem Gerät spielen. Die Reinigung und Wartung sollte
nicht von Kindern ohne Aufsicht durchgeführt werden.
• Das Netzkabel kann nicht ersetzt werden. Wenn das Kabel
beschädigt ist, muss der Netzadapter verschrottet werden.
• Verwenden Sie keinen anderen als den mitgelieferten
Netzadapter, egal zu welchem Zweck.
Verwenden Sie auch kein anderes Produkt mit den
mitgelieferten Netzadapter. (Siehe Seite 24.)
19
Deutsch
• Halten Sie den Apparat stets trocken.
Das Symbol auf der linken Seite bedeutet „Reinigen
Sie das Gerät nicht mit Wasser“.
• Das folgende Symbol zeigt an, dass ein spezielles abnehmbares
Netzteil für den Anschluss des elektrischen Gerätes an das
Versorgungsnetz erforderlich ist. Die Typenbezeichnung des
Netzteils ist neben dem Symbol angegeben.
20
Deutsch
Sicherheitsvorkehrungen
Um das Risiko von Verletzungen, Tod, elektrischem Schlag, Brand und
Sachschäden zu reduzieren, beachten Sie immer die folgenden
Sicherheitsmaßnahmen.
Die folgenden Symbole werden verwendet, um die Größe der Gefahr,
Verletzung und Schäden am Eigentum zu beschreiben, die verursacht
werden, wenn die Beschreibung nicht beachtet wird und ein
unsachgemäßer Gebrauch erfolgt.
GEFAHR Bezeichnet eine mögliche
Gefahr, die zu ernsthaften
Verletzungen oder zum Tod
führt.
WARNUNG Bezeichnet eine mögliche
Gefahr, die zu ernsthaften
Verletzungen oder zum Tod
führen könnte.
VORSICHT
Bezeichnet eine Gefahr, die zu
kleineren Verletzungen oder
Sachschäden führen kann.
Die folgenden Symbole werden verwendet, um die Art der Anleitungen,
Dieses Symbol wird verwendet, um die Benutzer auf einen
speziellen Betriebsablauf aufmerksam zu machen, der nicht
ausgeführt werden darf.
Dieses Symbol wird verwendet, um die Benutzer auf einen
bestimmten Betriebsablauf aufmerksam zu machen, der befolgt
werden muss, um das Gerät sicher zu betreiben.
WARNUNG
Stromversorgung
Nicht den Adapter mit nassen Händen weder in die
‑
Sonst kann zu einem elektrischem Schlag oder Verletzungen
kommen.
Nicht das Gerät und den Netzadapter unter Wasser
Stellen Sie das Gerät und den Netzadapter nicht über
oder in die Nähe mit Wasser gefüllter Waschbecken oder
Benutzen Sie den Apparat auf keinen Fall, wenn der
Netzadapter beschädigt ist oder falls der Netzstecker lose
Das Netzkabel nicht beschädigen oder verändern oder
Stellen Sie auch nichts Schweres auf das Netzkabel und
‑
Ansonsten kann es durch einen Kurzschluss zu einem
elektrischen Schlag oder Brand kommen.
Nicht auf eine Art verwenden, welche die Nennleistung
‑
Wird die Nennleistung überschritten, weil zu viele Stecker in einer
Steckdose stecken, kann dies zu Brand durch Überhitzung führen.
Other manuals for i-Shaper ER-GD60
2
This manual suits for next models
1
Table of contents
Languages:
Other Panasonic Trimmer manuals
Panasonic
Panasonic ER-2403 User manual
Panasonic
Panasonic ER240 User manual
Panasonic
Panasonic ER-CNT1 User manual
Panasonic
Panasonic ES-WF20 User manual
Panasonic
Panasonic ES-2113 User manual
Panasonic
Panasonic ER-CNT1 User manual
Panasonic
Panasonic ER?GN25 User manual
Panasonic
Panasonic ER-CTN1 User manual
Panasonic
Panasonic i-Shaper ER-GD60 User manual
Panasonic
Panasonic ER2031 User manual
Panasonic
Panasonic ER-2403 User manual
Panasonic
Panasonic ES-2113 User manual
Panasonic
Panasonic ER-GB75 User manual
Panasonic
Panasonic ER-224 User manual
Panasonic
Panasonic ER-GB62 User manual
Panasonic
Panasonic ER-CTW1 User manual
Panasonic
Panasonic ER-GB37 User manual
Panasonic
Panasonic ER-SB60 User manual
Panasonic
Panasonic ES-WR50 User manual
Popular Trimmer manuals by other brands
Echo
Echo 99944200610, SRM-2100SB, SRM-2400SB, SRM-210SB, SRM-211SB, SRM-260SB, SRM-261SB, PAS-2100, PAS-2400, PAS2601, PAS-210,... Operator's manual
Weed Eater
Weed Eater FeatherLite 530086922 instruction manual
Little Wonder
Little Wonder Line Trimmer Owner's manual and safety instructions
Hitachi
Hitachi CH 50EA(ST) Handling instructions
INNOLIVING
INNOLIVING INN-615 user manual
P.Lindberg
P.Lindberg 9066898 manual
