Sunjoy 1203060011-W User manual


CountryofOrigin:ChinaProductionnumber:20181682





































ASSEMBLY INSTRUCTION
ITEM#：1203060011-W
Ifyouhaveanyissueswiththeproduct,donotreturn
theproductbacktothestore
Foranyquestionsorissuesaboutourproduct
CallSunjoyCustomerService
1(866)578‐6569
8:00AMEST–8:00PMPST
Forfurtherassistance,pleasewritetousat
[e-mail]


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
2/17




































Safety Information
Two people are required for this assembly.
Some parts may contain sharp edges. Wear
protective gloves.
When assembling and using this product,
basic safety precautions should always be
followed to reduce the risk of personal
injury and damage to equipment. Please read
all instructions before assembly and usage.

Thelimitedwarrantyisextendedtotheoriginalpurchaserandappliestomaterialandmanufacturer’sdefectprovided
theitemismaintainedwithcareandusedonlyforpersonal,residentialpurposes.
Warranty: 1 Year
WHAT IS COVER?
IMPORTANT
KEEPTHISINSTRUCTIONMANUALFORFUTUREREFERENCE.
CAUTION: Do not climb on top of the
gazebo. Falling off the gazebo can
result in serious injury.
NOTICE: For indoor use only.
DANGER: This unit is heavy! Do not assemble
this item alone.
WARNING: Do not leave the gazebo where there
is a risk of high wind, as possible damage will
occur to the structure.
WARNING: Keep all flame and heat sources
away from this gazebo fabric. This Gazebo is
made with fabric that meets CPAI-84
specifications for flame resistance. It is not fire
proof. The fabric will burn if left in continuous
contact with any flame source. The application
of any foreign substance to the gazebo fabric
may render the flame-resistant properties
ineffective.
IMPORTANT
How many people needed for the installation work


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
3/17
VC
EXPLODED DRAWING


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
4/17
PartsList
Label Part Number Description Qty Part Image
#1 P21313B10011 Left Drawer Panel 2
#2 P21306D10011
Back Drawer Panel 2
#3 P21314B10011
Right Drawer Panel 2
#4 P21306C10011
Bottom Drawer Panel 2
#5 P21309A10011
Drawer Front Panel 2
#6 P20616A10011 Bottom Panel 1
#7 P11719A10011 Shelf1
1


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
5/17
#8 P02405A10011 Riser Plate 1
#9 P21217A10011 Back Panel 1 1
#10 P21218A10011 Back Panel 2 1
#11 P11847A10011 Support Brace 1 1
#12 P11848A10011 Support Brace 2 1
#13 P21125A10011 Right Side Panel 1
#14 P21126A10011 Left Side Panel 1
#15 P03001A10011 Wine Rack 1 2



CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
6/17
#16 P03002A10011 Wine Rack 2 3
#17 P11849A10011 Support Brace 3 1
#18 P11850A10011 Support Brace 4 1
#19 P11720A10011 Shelf 2 1
#20 P20917A10011 Door 1
#21 P02105A10011 Tower Bar Holder 2
#22 P02105B10011 Tower Bar 1
#23 P12317A10011 Table Top 1



CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
7/17
HardwarePack

Label Part Number Description Qty Add Part Image
AA P90103A01002 Cam Bolt M6*35 202

BB P90103B01002 Cam Ø 15 202
CC P90404A10000 Dowel Ø8*30 122

DD H11030J12 Screw M4*30 81
EE H06060C12 Bolt M6*60
101

FF P90602A01002 Multi Fit Ø 10*10 101

GG H09018A12 Bolt M4*18 61

HH H11012P15 Screw M3*12
354
JJ H11040J12 Screw M4*40 122

KK H11035J12 Screw M4*35 51

A
ctual Size
A
ctual Size
A
ctual Size
A
ctual Size
A
ctual Size
A
ctual Size


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
8/17
LL H10014U15 Screw M2.5*14 21

MM H08050K12 Screw M5*50 41

NN P90008A02000 Handle 30

PP P90201C02000 Table Hinge 40

QQ P90201D01002 Door Hinge 20

RR P90310A01002 Castor Wheel
With Lock 20

SS P90310B01002 Castor Wheel 20

TT P91103A01002 Magnetic Touch1 10
UU P91103A01002 Magnetic Touch2 10

WW P90504A01002 Bulkhead Pin 41

XX H00002C13 Allen Key Site 6 10
YY H00001D13 Wrench M8 10


A
ctual Size
A
ctual Size


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
9/17


STEP1:Connect the Left Drawer Panel and Back Drawer
Panel ,Right Drawer Panel and Bottom Drawer Panel
P21313B10011
2x
STEP2:Connect the Drawer Front Panel and Handle
8x
2x
2x 2x
P21314B10011
P21306D10011
H11030J12
P21306C10011
4x
2x
2x
8x 8x 2x 4x
H11030J12
P21309A10011
P90103B01002
P90103A01002
P90008A02000
H09020A12
2x
2x
P90103B01002
P90103A01002
P90008A02000
H09020A12


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
10 /17

STEP3:Connect the Bottom Panel , Riser Plate ,Shel
f
1 ,Magnetic
Touch1
P11847A10011
4x
1x 1x
1x
1x 2x 2x 2x
P20616A10011
STEP4:Connect the Support Brace 1 and 2, Right Side Panel
1x 4x
1x
1x
1x
P02405A10011
P11719A10011
P90103B01002
P90103A01002
2x 2x
P90404A10000
P91103A01002
H11040J12
H10014U15
P90103B01002
H11040J12
P90404A10000
H10014U15
P21125A10011
P11848A10011
H06060C12
H11035J12
P90602A01002
H11035J12
H06060C12
P90602A01002
1x
1x
1x
2x
1x


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
11 /17


STEP5:Connect the Back Panel 1and Right Side Panel
STEP6:Connect the Left Side Panel, Tower Bar Holder, Tower Bar
P21126A10011
P21217A10011
1x
1x 2x 1x
1x
2x
1x
4x
P90404A10000
H06060C12
H06060C12
P90602A01002
P90602A01002
H08050K12
P02105B10011
P02105A10011
H08050K12
1x
1x


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
12 /17


STEP7:Connect the Left Side Panel and Back Panel 1
STEP8:Connect theWine Rack 1 and Wine Rack 2
P03001A10011
3x
H06060C12
2x 2x
5x 2x 2x 5x
2x
10x
P90103B01002
P90103A01002
P90602A01002
P90404A10000
H11035J12
H06060C12
P90404A10000
P90602A01002
P90103A01002
H11035J12
P03002A10011
H11040J12
H11040J12
1x
1x
1x
1x


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
13 /17


STEP9:Connect the Castor Wheel With Lock and Castor Wheel
STEP10:Connect theBack Panel 2
P21218A10011
1x
P90310B01002
2x 2x 1x
P90310A01002
H00001D13
P90310A01002
P90310B01002
1x
H11012P151
2x
1x


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
14 /17


STEP11:Connect the Support Brace 3, Support Brace 4
STEP12:Connect the Table Top
P12317A10011
1x
P11850A10011
1x
1x
4x 24x
8x 6x 8x
P11849A10011
P90201C02000
H11012P151
H11012P151
P90201C02000
P90103A01002
P90103B01002
P90404A10000
P90103A01002 P90404A10000
3x
2x
P90103B01002
H11035J12
H11035J12
2x
1x
2x


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
15 /17

 
STEP13:Connect the Left Drawer and Right Drawer
STEP14:Connect the Shelf 2
P11720A10011
4x
2x
1x
P90504A01002
P90504A01002
2x
2x



CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
16 /17


STEP15:Connect the Magnetic Touch2 , Door Hinge on the Door
STEP16:Connect the Doo
r
,Door Hinge andHandle
H09020A12
2x
P20917A10011
1x 5x
1x
2x
1x
1x
4x
H11012P15
P91103A01002
H11012P15 P91103A01002
H11012P15
P90201D01002
P20917A10011
P90008A02000
P90201D01002
H09020A12
P90008A02000
H11012P15
1x
2x
P90201D01002
P90201D01002



CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
17 /17

Woodisanaturalmaterial.Theappearanceofthewoodwillagewithtimewhenitisexposedtoextreme
weather.Asurfacecoatingisvitaltoprotectitfromprematureagingorsplitting.
Thefinishshouldberegularlymaintainedtoensurethatthewoodisprotectedfrommoistureandthe
furniturecontinuestolookitsbest
Applywoodoilontheproductsurfacewithacleanclothevery6weeksorearlierdependingonweather
conditions.
Treatallsurfacesoftheproductincludingthe‘hardtogetto’andhiddensurfaceswithextraattentiongiven
tothejointsandendgrains.
Protectthisproductfromsevereweatherandstoreitundercoverduringwinterwithaliberalcoatofwood
oil.
Beforeusing,cleantheproductcompletelywithsoft,drytowel.Whennotinuse,wipefreeofanydirtor
loosedust,washwithamildsolutionofsoapandwater;rinsethoroughlyanddrycompletely.
Donotusestrongdetergentorabrasivecleaners
Moistureandheatcandamageanywoodfinish.Protectyourfurnituresurfacebyusingcoastersandtrivets.
Alwayswipeupmoisturepromptlyanddrywithasoftcloth.
Protectingfurniturefromnaturalelements.Whennotinuse,protectioncoveringarehighlyrecommended.
Avoiddraggingsharporroughobjectsacrossthesurfaceofyourwoodfurniture.Useadhesivefeltpads,
trivets,coastersandplacematstohelppreventscratches.
Woodwillexpandandcontractwithseasonalhumiditychanges.
Overtime,airandsunlightwillchangethecolourofnaturalwood.Occasionallyrotatetheitemsplacedon
yourwoodfurnituretoallowamoreuniformcolourtodevelop.
Careforyourwoodfurnitureaccordingtoitsfinish.
Cleanwithdampclothwhenevernecessary.
Periodicallycheckandensurethatallboltsarewell‐tightenduringuse
Shouldanyscratchingordamageoccur,werecommendimmediatetouch‐upoilorappropriatetouch‐up
paint.


SunjoyGroupwarrantstotheoriginalpurchaserthatthisitemisfreefromdefectsinworkmanshipandmaterialsfora
periodof1Yearfromthedateofpurchase,providedtheitemwasfactory‐sealedatthetimeofpurchaseandis
maintainedwithcareandusedonlyforpersonal,residentialpurposes.Shouldanymanufacturingdefectarisewithin
thiswarrantyperiod,SunjoyGroupwillreplace(atouroption)anydefectivemerchandiseorpartsuponproofof
purchase;however,transportationanddeliverycosts,aswellaspaymentstoathirdpartyforassemblyordisassembly
oftheitem,remaintheresponsibilityofthepurchaser.Apurchaserofan"openbox,"previously‐returned,or
"clearance"item,aswellasoriginalpurchasersoutsideofthewarrantyperiod,mayobtainreplacementpartsfrom
SunjoyGroupforproductsincurrentproduction,atnominalcost.
Itemsusedforcommercial,contract,orothernon‐residentialpurposes,oritemsdamagedduetoactsofnature,
vandalism,misuse,orimproperassemblyarenotcovered.Corrosionorrustingofhardwareisnotcovered.Proofof
purchase(datedregisterreceipt)isrequiredforwarrantyclaims.Warrantyistotheoriginalpurchaserandis
non‐transferable.Anyreplacementofwarranteditemswillbeintheoriginalstyleandcolor,orasimilarstyleand
coloriftheoriginalisunavailableorhasbeendiscontinued.Assomestatesdonotallowexclusionsorlimitationsonan
impliedwarranty,theaboveexclusionsandlimitationsmaynotapply.Thiswarrantygivesyouspecificrights,andyou
mayalsohaveotherrights,whichvaryfromstatetostate.
Limited Manufacturer’s Warranty
Exclusions:
Care and Maintenance
