Sunjoy L-DN1196SAL-H-T User manual

BELIZE RECTANGULAR DINING TABLE
ASSEMBLY INSTRUCTION
ITEM# L-DN1196SAL-H-T
WARNING:
_ Keep all children and pets away from assembly area. Children and pets should be
supervised when they are in the area of the table construction.
_ Keep assembly area at least 6 feet from any obstruction such as a fence, garage, house,
overhanging branches, laundry line or electrical wires.
_ Some parts may contain sharp edges. When assembling and using this product, basic
safety precautions should always be followed to reduce the risk of personal injury and
damage to the product. Please read all instructions before assembly and use.
_ Check all bolts for tightness before use. IMPORTANT - check and tighten bolts often to
keep them secure!

Part List
No#
Description
Qty
A
Cap
1
B
Table top
1
C
Leg
2
D
Support frame
1
E
Foot pad
(Pre-assembled to C)
4
AA
M6*20 Bolt
4
BB
M6 Spring washer
14
CC
M6 Flat washer
14
DD
M6*25 Bolt
8
EE
M6*35 Bolt
2
FF
M6 Wrench
1

Assembly steps
Step 1
˖
Attach support frame (D) to leg (C) by bolt (AA), spring washer (BB), and flat
washer (CC). Do not fully tighten at this stage.
Step 2: Fig.1: Connect leg (C) and table top (B) by bolt (DD), spring washer (BB), flat
washer (CC). Do not fully tighten now.
Fig.2: Connect support frame (D) and table top (B) by bolt (EE),
spring washer
(BB)
and flat washer (CC). Fully tighten all bolts by wrench (FF).

CARE & MAINTENANCE
Before using, clean the table completely with a soft dry towel. When not in use, wipe free of
dirt or loose objects, wash with a mild solution of soap and water; rinse thoroughly and dry
completely. Do not use strong detergent or abrasive cleaners. Over time nuts and bolts can
loosen. Occasionally, check nuts and bolts, re-tighten if necessary.
CUSTOMER SERVICE
Sunjoy Group warrants to the original purchaser that this item is free from defects in
workmanship and materials of your item provided the item was factory-sealed at the time
of purchase and is maintained with care and used only for personal, residential purposes.
The item is warranted to be free from defects in material or workmanship for a period of 6
months. Should any manufacturing defect arise within this warranty period, Sunjoy Group
will repair or replace (at our option) any defective merchandise upon proof of purchase;
however, transportation and delivery costs, as well as labor and material charges to
remove or replace parts, remain the responsibility of the purchaser. A purchaser of an
"open box," previously-returned, or "clearance" item, as well as original purchasers
outside of the warranty period, may obtain replacement parts from Sunjoy Group for
products in current production, at nominal cost.
If you are within the return policy that most stores have, you do have the option of
returning this item back to the store which you bought it from for an exchange of the same
item, or a refund of the purchase.
If you are within or beyond the return policy that most stores have, and need tech.
assistance or replacement parts, please call Sunjoy Group at 1(866) 578-6569 from 8:00
am EST to 8:00 pm PST or e-mail to [e-mail] or visit
www.sunjoyonline.com to place your order or fax your parts replacement order form
together with the purchase receipt to 1 [phone] for assistance.
Step 3: Put cap (A) onto table top (B).

BELIZE DINING SWIVEL ROCKER CHAIR
ASSEMBLY INSTRUCTION
Item# L-DN1196SAL-RC
CAUTION: Chair is for setting purpose only. Standing on or misuse of bench may result in
damage or injury. Not intended for commercial use. WEIGHT LIMIT 225 LBS (100 KG).
WARNING:
_ Keep all children and pets away from assembly area. Children and pets should be
supervised when they are in the area of the Chair construction.
_ Keep assembly area at least 6 feet from any obstruction such as a fence, garage, house,
overhanging branches, laundry line or electrical wires.
_ Some parts may contain sharp edges. When assembling and using this product, basic
safety precautions should always be followed to reduce the risk of personal injury and
damage to the product. Please read all instructions before assembly and use.
_ Check all bolts for tightness before use. IMPORTANT - check and tighten bolts often to
keep them secure!

Part List
Part
DESCRIPTION
QUANTITY
A
Chair 1
B
Supporter 1
C
Base 1
D
Seat cushion 1
AA
Bolt M8*40 4
BB
Bolt M8*35
( Pre-assembled )
4
CC
Spring washer M8
(Pre-assembled 4 pcs)
8
DD
Flat washer M8
(Pre-assembled 4 pcs)
8
EE
Nut M8
(Pre-assembled 4 pcs)
8
FF
Big washer
(Pre-assembled 2 pcs)
6
GG
Spring plate
(Pre-assembled˅
2
HH
Wrench M8
2

Step 1
˖
Connect supporter (B) and chair (A) by bolt (AA), big washer (FF), spring plate (GG), big washer
(FF), flat washer (DD), spring washer (CC), and nut (EE). Fully tighten by wrench (HH)
. Insert the
supporter (B) into base (C).
Step 2: Attach seat cushion (D) to the chair (A) by hook-and-loop fasteners.

Care & Maintenance
Before using, clean the Chair completely with a soft dry towel. When not in use, wipe free of any
dirt or loose objects, wash with a mild solution of soap and water; rinse thoroughly and dry
completely. Do not use strong detergent or abrasive cleaners. Over time nuts and bolts can
loosen. Occasionally, check nuts and bolts, re-tighten if necessary.
