Sunjoy S-DN121-2-C2 User manual

Sierra 6 PC Dining Chair-Stationary Chair
Instruction Manual
Item#: S-DN121-2-C2
SKU #: 810325099
CAUTION:Chair is for setting purpose only. Standing on or misuse of bench may result in
damage or injury. Not intended for commercial use. WEIGHT LIMIT 225 LBS (100 KG).
WARNING:
_ Keep all children and pets away from assembly area. Children and pets should be
supervised when they are in the area of the Chair construction.
_ Keep assembly area at least 6 feet from any obstruction such as a fence, garage, house,
overhanging branches, laundry line or electrical wires.
_ Some parts may contain sharp edges. When assembling and using this product, basic
safety precautions should always be followed to reduce the risk of personal injury and
damage to the product. Please read all instructions before assembly and use.
_ Check all bolts for tightness before use. IMPORTANT - check and tighten bolts often to
keep them secure!

Part
Description
Qty
A
Back
1
B
Left armrest
1
C
Right armrest
1
D
Seat board
1
E
Back cushion
1
F
Seat cushion
1
AA
Bolt M6×20
10
BB
M6 Spring washer
10
CC
M6 Flat washer
10
DD
Cap
8
EE
Hex key M6
1
FF
Foot pad
(pre-assembled)
4
Step 1: Attach seat board (D) to back (A) by bolt (AA), spring washer (BB), flat washer
(CC) and hex key (EE). Do not lock tightly. Put on cap (DD) after locking all bolts tightly.
Parts List

Step 3: Put bolt (AA) through
spring washer (BB), flat washer
(CC), attach armrest (B, C) to
back (A) by hex key (EE). Do not
lock tightly.
Step 4: Put seat cushion (F) onto seat
board, stick hook-and-loop fasteners,
put back cushion (E) on back.
Step 2: Attach armrest (B, C) to seat board (D)
by bolt (AA), spring washer (BB), flat washer
(CC) and hex key (EE). Lock all bolts tightly.
Then put on cap (DD).

Care & Maintenance
Before using, clean the Chair completely with a soft dry towel. When not in use, wipe free of
any dirt or loose objects, wash with a mild solution of soap and water; rinse thoroughly and dry
completely. Do not use strong detergent or abrasive cleaners. Over time nuts and bolts can
loosen. Occasionally, check nuts and bolts, re-tighten if necessary.
Exclusions:
Items used for commercial, contract, or other non-residential purposes, or items damaged due
to acts of nature, vandalism, misuse, or improper assembly are not covered. Corrosion or
rusting of hardware is not covered. Proof of purchase (dated register receipt) is required for
warranty claims. Warranty is to the original purchaser and is non-transferable. Any
replacement of warranted items will be in the original style and color, or a similar style and
color if the original is unavailable or has been discontinued. As some states do not allow
exclusions or limitations on an implied warranty, the above exclusions and limitations may not
apply. This warranty gives you specific rights, and you may also have other rights, which vary
from state to state.
CUSTOMER SERVICE
Sunjoy Group warrants to the original purchaser that this item is free from defects in
workmanship and materials of your item provided the item was factory-sealed at the time of
purchase and is maintained with care and used only for personal, residential purposes. The
item is warranted to be free from defects in material or workmanship for a period of 1 year.
Should any manufacturing defect arise within this warranty period, Sunjoy Group will repair or
replace (at our option) any defective merchandise upon proof of purchase; however,
transportation and delivery costs, as well as labor and material charges to remove or replace
parts, remain the responsibility of the purchaser. A purchaser of an "open box,"
previously-returned, or "clearance" item, as well as original purchasers outside of the warranty
period, may obtain replacement parts from Sunjoy Group for products in current production, at
nominal cost.
If you are within the return policy that most stores have, you do have the option of returning
this item back to the store which you bought it from for an exchange of the same item, or a
refund of the purchase.
If you are within or beyond the return policy that most stores have, and need tech. assistance
or replacement parts, please call Sunjoy Group at 1(866) 578-6569 from 8:00 am to 8:00 pm
eastern standard time or e-mail to [email protected] or fax your parts replacement
order form together with the purchase receipt to 1 [phone] for assistance.

Sierra 6 PC Dining Chair-Swivel Chairs
Instruction Manual
Item#: S-DN121-2-C2
SKU #: 810325099
CAUTION:Chair is for setting purpose only. Standing on or misuse of bench may result in
damage or injury. Not intended for commercial use. WEIGHT LIMIT 225 LBS (100 KG).
WARNING:
_ Keep all children and pets away from assembly area. Children and pets should be
supervised when they are in the area of the Chair construction.
_ Keep assembly area at least 6 feet from any obstruction such as a fence, garage, house,
overhanging branches, laundry line or electrical wires.
_ Some parts may contain sharp edges. When assembling and using this product, basic
safety precautions should always be followed to reduce the risk of personal injury and
damage to the product. Please read all instructions before assembly and use.
_ Check all bolts for tightness before use. IMPORTANT - check and tighten bolts often to
keep them secure!

Part#
Description
Qty
A
Back
1
B
Left armrest
1
C
Right armrest
1
D
Seat board
1
E
Base
1
F
Back cushion
1
G
Seat cushion
1
AA
Bolt M6×20
10
BB
M6 Spring washer
10
CC
M6 Flat washer
10
DD
Screw M8*40
4
EE
Screw M8*35
(pre-assembled)
4
FF
M8 Nut( pre-assembled 4)
8
GG
M8 Spring washer
( pre-assembled 4)
8
HH
M8 Flat washer
( pre-assembled 4)
8
II
Big washer
(pre-assembled 2)
6
JJ
Spring steel plate
(pre-assembled)
2
KK
Cap
8
LL
Wrench M8
2
MM
Hex key M6
1
NN
Foot pad
(pre-assembled on E)
6
Step 1: Attach seat board (D) to back (A) by bolt (AA), spring washer (BB), flat washer
(CC) and hex key (MM). Do not lock tightly. Put on cap (KK) after locking all bolts tightly.
Parts List

Step 3: Put bolt (AA) through spring washer
(BB), flat washer (CC), attach armrest (B, C) to
back (A) and hex key (MM). Do not lock tightly.
Step 2: Attach armrest (B, C) to seat board (D) by bolt (AA), spring
washer (BB), flat washer (CC) and hex key (MM). Put on cap (KK) after
locking all bolts tightly.

Step 5: Put seat cushion (G) onto seat board, stick hook-and-loop fasteners, put
back cushion (F) on back.Assembly finished.
Step 4: Put hole of base (E) and hole of assembled frame A (BCD) on the same line, put screw
(DD) through big washer (II), spring steel plate (JJ), big washer (II), flat washer (HH), spring
washer (GG), attached nut (FF) by wrench (LL). Lock all bolts tightly by wrench (LL).

Care & Maintenance
Before using, clean the Chair completely with a soft dry towel. When not in use, wipe free of
any dirt or loose objects, wash with a mild solution of soap and water; rinse thoroughly and dry
completely. Do not use strong detergent or abrasive cleaners. Over time nuts and bolts can
loosen. Occasionally, check nuts and bolts, re-tighten if necessary.
Exclusions:
Items used for commercial, contract, or other non-residential purposes, or items damaged due
to acts of nature, vandalism, misuse, or improper assembly are not covered. Corrosion or
rusting of hardware is not covered. Proof of purchase (dated register receipt) is required for
warranty claims. Warranty is to the original purchaser and is non-transferable. Any
replacement of warranted items will be in the original style and color, or a similar style and
color if the original is unavailable or has been discontinued. As some states do not allow
exclusions or limitations on an implied warranty, the above exclusions and limitations may not
apply. This warranty gives you specific rights, and you may also have other rights, which vary
from state to state.
CUSTOMER SERVICE
Sunjoy Group warrants to the original purchaser that this item is free from defects in
workmanship and materials of your item provided the item was factory-sealed at the time of
purchase and is maintained with care and used only for personal, residential purposes. The
item is warranted to be free from defects in material or workmanship for a period of 1 year.
Should any manufacturing defect arise within this warranty period, Sunjoy Group will repair or
replace (at our option) any defective merchandise upon proof of purchase; however,
transportation and delivery costs, as well as labor and material charges to remove or replace
parts, remain the responsibility of the purchaser. A purchaser of an "open box,"
previously-returned, or "clearance" item, as well as original purchasers outside of the warranty
period, may obtain replacement parts from Sunjoy Group for products in current production, at
nominal cost.
If you are within the return policy that most stores have, you do have the option of returning
this item back to the store which you bought it from for an exchange of the same item, or a
refund of the purchase.
If you are within or beyond the return policy that most stores have, and need tech. assistance
or replacement parts, please call Sunjoy Group at 1(866) 578-6569 from 8:00 am to 8:00 pm
eastern standard time or e-mail to [email protected] or fax your parts replacement
order form together with the purchase receipt to 1 [phone] for assistance.
