Sunjoy L-BB050PCO-1 User manual

April 16 Made in China 1/ 3
Assembly Instructions
L-BB050PCO-1
Number Description Qty
A Big bird 1
B Little bird 2
C Pot 1
D Connector 1
E Crane 3
F Leg 1 3
G Leg 2 3
H Bottom base 1
Parts list

April 16 Made in China 2/ 3
Number Description Qty Image
AA Stud M6*35 6
BB Bolt M6*35 6
CC Bolt M6*20 3
DD Bolt M6*15 3
EE Wrench M6/M8 1
Number Description Qty Image
FF Nut M6 12
GG Flat washer M6 15
HH Stud M8*30 3
II Nut M8 3
JJ Flat washer M8 3
Fig.1: Put leg 2 (G) at the inner side of the crane, then connect with bolt (BB), flat washer (GG) and nut (FF); connect
leg 1 (F) in the same way.
Fig.2: Insert the end of bolt (AA) without the "-" symbols into the holes leg 1 (F)/ leg 2 (G), and lock and tighten with a
screwdriver.
Fig.3: Connect leg 1 (F)/ leg 2 (G) and bottom base (H) with bolt (AA), flat washer (GG) and nut (FF).
Fig.4: Connect connector (D) and crane (E) with bolt (CC).
Fig.5: Insert the end of bolt (HH) without the "-" symbols into the holes of pot (C), and lock and tighten with a
screwdriver.
Fig.6:Attach connector (D) to pot (C) with bolt (HH), flat washer (JJ) and nut (II).
Fig.7: Connect big bird (A) to pot (C) with bolt (DD) and flat washer (GG).
Fig.8: Connect little bird (B) to pot (C) with bolt (DD) and flat washer (GG).
Fig.9: Tighten all the bolts with wrench (EE) and self-prepared screwdriver.
Hardware list

April 16 Made in China 3/ 3
CARE AND MAINTENANCE:
To extend the life of garden cart, cover it in bad weather. Due to natural properties of steel material, if rust develops,
please clean rust area by sanding slightly, then wipe thoroughly and apply touch-up paint if possible.
Limited Warranty:
This limited warranty is extended to the original purchaser and applies to defects in materials and workmanship of your
item provided the item is maintained with care and used only for personal, residential purposes.
The item is warranted to be free from defects in material or workmanship for a period of 6 months. If any defect is
found, please call our customer service department at 1-866-578-6569 for help. The manufacturer will not cover
transportation or delivery costs, or compensate the individual or any outside party for assembling or disassembling the
product. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Service:
For technical assistance on assembly or replacement parts, please call SunNest Services at 1(866)578-6569 from 8:30
AM to 5:30 PM EST or send email to customer[email protected] or visit www.sunjoyonline.com to place your
order or fax your parts replacement order form together with your purchase receipt to 1 [phone] for assistance.
