Country of Origin: China Production Number: XXXXXXXXXX
ASSEMBLY INSTRUCTION
Item No.: A304001200


WE HAVE YOU IN MIND, LET US SERVE YOU!
Questions? Issues?
CONTACT US
24 hours / 7 days a week
www.sunjoyonline.com
1-(866)-578-6569
[email protected]

2/ 7

Country of Origin: China
Warning! Pleasereadandunderstandthisentiremanualbeforeattemptingto
assembleoroperatethisproduct.
Caution!Somepartsmaycontainsharpedges.Pleasewearprotectiveglovesduring
Caution！
 Properplacementofyourfirebowlisessential.
 Keepchildrenawayduringassembly.
 Thisproductcontainssmallpartswhichcanbeswallowedbychildren.
 Keepfingersawayfromtheplaceswheretheycanbepinchedortrapped.
 Pleasewearprotectiveglovesduringassembly.
 Donotattempttoassemblethefirebowlifanypartsaremissing.











• Thisfireplaceisintendedforoutdooruseonly.NEVERLEAVEAFIREUNATTENDED.
• DONOTusethefireplacetocookfood.Thefireplaceisnotdesignedforgrillingfood.
• DONOTallowchildrenorpetsnearthefireplacewithoutsupervision.
• DONOTtouchthesurfaceofthefireplacewhileinuseasitmaycauseburns.
• NEVERburninvehicles,tentsorindoors.CARBONMONOXIDEHAZARD.
• Useapokerand/orheat‐resistantglovestoopen/closethemeshcoverwhileinuse.
• DONOTusewatertoextinguishasthisisdangerousandcancausedamage.
• Burnonlyuntreatedwoodlogsinthisfirebowl.
• DONOTusegasolineorkerosenetostartthefireinthisfirebowl.
• DONOTusethisfireplaceonawooddeck,longordrygrass,leaves,oracombustiblesurface.
• DONOTattempttomovethefireplacewhileitishotorinuse.
• Placethefireplacenocloserthan8ft.fromwallsorcombustiblesduringuse.
• Adequatefireextinguishingmaterialshouldbereadilyavailable.
• Thepokerhandlemaybecomehotduringandafteruse.
• Checklocalfireregulationsandmunicipalby‐lawsforinformationregardingthesafeuseofthisfirepit.









Placeallpartsfromtheboxinaclearedareaandpositionthemonthefloorinfrontofyou.Removeall
packingmaterialsandplacethembackintothebox.Donotdisposeofthepackingmaterialsuntilassembly
iscompleted.Readeachstepcarefullybeforebeginninganyassemblyandmakesureyouunderstandeach
step.



Important Safety Instructions

3/ 7

Country of Origin: China
A
B
C
D
G1
F1
I
J
K
H










Exploded Drawing

4/ 7

Country of Origin: China







Label Part Number Description Qty Part Image
A
P000900085
Chimney 1
B
P000300048
Top 1
C
P007900044
Body 1
D
P002800026
Grate 1
G1
P003000013
Base 1
F1
P000100284
Ash Tray 1
H
P002700035
Porker 1

I
P000100287
Side Table Top 2
J
P000100285
Upper Side Base 2
K
P000100286
Lower Side Base 2
Parts List

5/ 7

Country of Origin: China




Label Part Number Description Qty Part Image
AA H02015C11 Bolt M6*15 8
BB H19001C11 Flat washer M6 8
CC H00001C12 Wrench M6 1
Hardware Pack
Fig.2:PlaceBody(C)ontobase(F1)
Fig.1:PutGrate(D)inAshtray(G1),theninsert
theAshtray(G1)intoBase(F1).            
Assembly Steps

6/ 7
Country of Origin: China
Fig.3:Puttop(B)onbody(C)andchimney
(A)ontop(B)inorderasFig.3
Fig.4: Attach upper side base (J) and lower
sidebase(K)withbolt(AA)andflatwasher
(BB),asFig.4
Fig.5:Inserttheassembledsidebase(K)into
Body(C).
Fig.6:Putthesidetabletop(I)onassumedside
base(J&K).(Note:Thetabletopsidewithoutstone
shouldfacethebody).UsePoker(H)asnecessary.
Now,yourfireplaceisreadyforuse.
Fi
g
.6

7/ 7
Country of Origin: China
Lighting
• Makesurethereisonlyasmallamountofashinthebottomofthebowl.
• Placealayerofdryseasonedhardwoodthatcoversnomorethan3/4ofthebowl.
• Useamatchtolightkindlingorfirestarter.
• Usethepokerthatisprovidedtooperate.Pleasewearheat‐resistantglovesduringuse. 

Extinguishing
• Allowfire toburnitselfout.
• DONOTusewatertoextinguishasthisisdangerousandcandamagethisfireplace. 

Cleaning
• Thisfireplaceshouldbecleanedonaregularbasistopromotesaferexperienceandlongproductlife.
• DONOTattempttocleanthisfireplaceuntilthefireisCOMPLETELYoutandcooltotouch.
• DONOTuseovencleanerorabrasivecleanerasthiswilldamagethefirebowl. 

Storage
• DONOTmoveorstorethisfireplaceuntilthefireisCOMPLETELYoutandcooltotouch.
• Storethefireplaceinadrylocationtomaximizeproductlife.
• Storeassembledfireplaceinalocationawayfromchildrenandpets.




Thislimitedwarrantyisextendedtotheoriginalpurchaserandappliestodefectsinmaterialandworkmanship
ofyouritemprovidedtheitemismaintainedwithcareandusedonlyforpersonal,residentialpurposes.The
manufacturerSunjoyGroupwarrantsthisitemisfreeofdefectsinmaterialandworkmanshipforaperiodof
ONEYEAR.Ifanydefectisfound,pleasecallourSunjoyGroupcustomerservicedepartmentat1‐866‐578‐6569
oremailat[email protected]forhelp.ThemanufacturerSunjoyGroupwillnotcover
transportationordeliverycostsorcompensatetheindividualoranyoutsidepartyforassemblingor
disassemblingtheproduct.
Caution!
Checkallscrewsandnutsperiodicallyfortightness,fasteningthemagainasrequired.
LIMITED WARRANTY
Cleanin
g
and Maintenance
