Sunjoy L-DN1123SCO-B User manual

Propane Fire Pit with 4 Chairs-Chair
Item# L-DN1123SCO-B
Congratulations on your purchase of our SUNJOY Propane Fire Pit with 4
Chairs-Chair. Our clear, easy to follow, step-by-step instructions will guide you
through the assembly process from start to finish.
WARNING:
Keep all children and pets away from assembly area. Children and pets should be
supervised when they are in the area of the Chair construction.
Keep assembly area at least 6ft/1.8m from any obstruction such as a fence, garage,
house, overhanging branches, laundry line or electrical wires.
Some parts may contain sharp edges. When assembling and using this product, basic
safety precautions should always be followed to reduce the risk of personal injury and
damage to the product. Please read all instructions before assembly and use.
Check all bolts for tightness before use, and periodically check and tighten bolts as
necessary.
Assemble on level ground.
For outdoor use only.
IMPORTANT
Please take time to read these instructions thoroughly and follow each step carefully for safe
and easy operation. Keep this manual for future reference.
For technical assistance on assembly or replacement parts, call Sunjoy Industries at
1-866-578-6569 from 8:30AM to 5:30PM EST, or email us at [email protected], or visit
www.sunjoydirect.com for assistance.

No. Description Qty
A1 Right Armrest 1
A2 Left Armrest 1
B Rear Panel 1
C Seat Board 1
D Back Cushion 1
E Seat Cushion 1
F Throw Pillow 1
AA Bolt M6x15 4
BB Bolt M6×35 9
CC Flat Washer M6
13
DD Spring Washer M6 13
EE Wrench M6 1
Step 1: Connect Seat Board (C) and
Right Armrest (A1) by Bolt (BB), Spring
Washer (DD) and Flat Washer (CC).
Insert Rear Panel (B) into Right Armrest
(A1) and lock them by Bolt (AA), Spring
Washer (DD) and Flat Washer (CC). DO
not lock tightly.
Step 2: Connect Seat Board (C) and Left
Armrest (A2) by Bolt (BB), Spring Washer
(DD) and Flat Washer (CC). Insert Rear
Panel (B) into Left Armrest (A2) and lock
them by Bolt (AA), Spring Washer (DD)
and Flat Washer (CC). DO not lock
tightly.
Parts List

Step 3: Align the hole on Seat Board (C) with
the hole on Rear Panel (B), then connect them
by Bolt (BB), Spring Washer (DD) and Flat
Washer (CC). Lock them tightly.
Step 4:Put Throw Pillow (F), Back Cushion (D)
and Seat Cushion (E) on the Rear Panel (B)
and Seat Board (C). Stick the Velcro.

Care & Maintenance
Steel components of garden accessories and furniture are treated with rust inhibiting paint.
However, due to the nature of steel, surface oxidation (rusting) will occur if this protective
coating is scratched.
To minimize this condition, it is recommended that care be taken when assembling and
handling the product, in order to prevent the paint from being scratched.
