Sunjoy L-DN1377SAL-A User manual

Made In China 1 / 11
ASSEMBLY INTRUCTION
ITEM#：L-DN1377SAL-A
D-DN1377SAL-A
L-DN1499PAL
L-DN1500PAL
This appliance complies with “ANSI Z21.97-2014/CSA 2.41-2014, Outdoor Decorative Gas Appliances.
WARNING: For Outdoor Use Only.
WARNING
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
An LP-cylinder not connected for use should not be stored in the vicinity of this or any other appliance.
DANGER CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such as a camper, tent, car or home.
Propane tank not included
AA battery needed, not included
DANGER
If you smell gas:
Shut off gas to the appliance.
Extinguish any open flame.
If odor continues, keep away from the
appliance and immediately call your gas supplier or fire
department.
WARNING: Improper installation, adjustment,
alteration, service or maintenance can cause injury or
property damage. Read the installation, operating and
maintenance instructions thoroughly before installing or
servicing this equipment.

Made In China 2 / 11
TABLE OF CONTENTS
General information
…………………………………………………………………………………..
2
Specifications
………………………………………………………………………………………..
3
Important safety information and precaution
……………………………………………………
3-4
Expanded view
………………………………………………………………………………………..
5
Parts list
……………………………………………………………………………………………….
6
Installation
……………………………………………………………………………………………
7
Location
……………………………………………………………………………………………….
8
Set up
…………………………………………………………………………………………………...
8
Gas connection
………………………………………………………………………………………….
8-9
Operation
……………………………………………………………………………………………….
9
Leak check
……………………………………………………………………………………………...
9
Ignition
…………………………………………………………………………………………………
9-10
Storage and Maintenance
…………………………………………………………………………….
10-11
Trouble shooting
……………………………………………………………………………………...
11
Limited warranty
……………………………………………………………………………………...
11
Cleaning and maintenance
………………………………………………………………………..
11
GENERAL INFORMATION
IMPORTANT
For technical assistance on assembly or replacement parts, you can call us toll-free at 1-866-578-6569 from 8 a.m. EST
to 8 PM PST. You may email to [e-mail] or visit www.sunjoyonline.com to place your order
or fax your parts replacement order form together with your purchase receipt to 1 [phone] for assistance.

Made In China 3 / 11
SPECIFICATIONS
IMPORTANT SAFETY INFORMATION AND PRECAUTION
When the appliance is for connection to a fixed piping system, the installation must conform with local codes ,or in
the absences of local codes with the National Fuel Gas Code, ANSI Z223.1/NFPA54; International Fuel Gas Code,
Natural Gas and Propane Installation Code, CSA B149.1;or Propane Storage and Handling Code,B149.2,as applicable.
The LP gas supply cylinder to be used must be:
1- Constructed and marked in accordance with the U.S. Department of Transportation (D.O.T.) Specifications
for LP-Gas Cylinders, or the Standard for Cylinders, Spheres and Tubes for transportation of Dangerous Goods
and Commission, CAN/CSA-B339 as applicable;
2- Provided with a listed overfilling prevention device;
3- Provided with a cylinder connection device compatible with the connection for the appliance.
Always place the appliance on a firm and level surface.
Solid fuels shall not be burned in this gas appliance. Burn ONLY Tempered Glass (INCLUDED).
The appliance shall be used only outdoors in a well-ventilated space and shall not be used in a building, garage or
any other enclosed area.
When in use, keep the appliance area clear and at least 40 in / 101.6 cm side clearance from combustible materials,
gasoline and other flammable liquid and vapors. Do not use the appliance under overhead combustible surfaces. Certain
items or materials, when stored under the appliance or nearby, will be subjected to radiant heat and could be damaged.
Inspect the hose assembly and burner prior to each use. If there is evidence of excessive abrasion or wear or if the
hose or burner is damaged, it must be replaced by appropriate part form the manufacturer.
Inspect the gas connections of the appliance prior to each use. Do not to operate the unit if there is a gas leak. Have the
appliance inspected annually by a qualified, service person.
The pressure regulator and hose assembly provided with the appliance must be used. The replacement part must be
Model NO.
L-DN1377SAL-A/D-DN1377SAL-A/ L-DN1499PAL
Rated Heat Input
50,000BTU/HR
Fuel
Propane-LP
Gas Supply
20 lb. LP-Gas cylinder
Manifold Pressure
11 Inches W.C.
Orifice Size (diameter)
2.18mm
Gas Supply Pressure
Max.250 PSI

Made In China 4 / 11
the same as the part specified by manufacturer.
The assembly of LP-gas and leak checking, please refer to the “Gas connection” on page 8 and “Leak Test” on page 9.
Children and adults should be alerted to the hazards of high surface temperatures and should stay away to
avoid burns or prevent clothing ignition.
Young children and pets should be carefully supervised when they are in the area of the appliance.
Any guard or other protective device removed for servicing the appliance must be replaced prior to operation.
Clothing or other flammable materials should not be hung from the appliance.
Do not use the appliance if any part has been under water. Immediately call a qualified technician to inspect the
appliance and to replace any part of the control system and any gas control which has been under water.
LP-gas supply cylinder to be used must be constructed and marked in accordance with the specifications for LP-gas
cylinders of the U.S. Department of Transportation (DOT).
The cylinder supplies system must be arranged for vapor withdrawal and the cylinder must include a collar to protect
the cylinder valve.
Use only 20 lb / 9 kg LP-Gas cylinders.
Do not burn wood or any other materials in this appliance.
The appliance must be isolated from the gas supply piping system by closing its
individual manual shutoff valve during any pressure testing of the gas supply piping
system at test pressure equal to or less than 1/2psi (3.5kPa).
Properly place the hose out of pathways where people may trip over it or in areas
where there may be subject to accidental damage.
If it is evident that the burner is damaged, the burner must be replaced prior to the appliance being put into operation.
The replacement burner must be the same as the part specified by manufacturer.
For cleaning of the appliance including the burner, please refer to “Clean and Maintenance” on page 12.

Made In China 5 / 11
EXPANDED VIEW

Made In China 6 / 11
PARTS LIST
Label
Part Number
Description
QTY
A
DN1499XXX01
Lazy Susan
1
B
DN1499XXX02
Table Top
1
C
DN1499XXX03
Main Body
1
D
DN1499XXX04
Base
1
E
LPSBLSH41
Cullet (Tempered Glass)
1 (4.1KG)
F
DN1499XXX05
Armor Plate Screen
1
G
DN1499XXX06
Windshield 1
1
H
DN1499XXX07
Windshield 2
1
I
LPDHZXY1L07
Ignition Wire
2
J
LPDHQ2W35D27
Battery Box
1
K
LPKGXN01
Control Knob
1
L
LPFB14WB14HXD
Control Valve
1
M
LPJYF070N
Pressure Regulator
1
N
DN1499XXX08
Nozzle Subassembly
1
O
LPRD07
Thermocouple
1
P
DN1499XXX09
Nozzle Support Bar
1
Q
LPFRT2421
Burner
1
R
DN1499XXX10
Fire Bowl
1
PARTS LIST
Label
Part Number
Description
QTY
Image of Part
AA
YM06015C
Bolt M6x15
4
BB
VD06C
Flat Washer M6
4
CC
TD06C
Spring Washer M6
4
DD
A04D
Spanner
1

Made In China 7 / 11
INSTALLATION
Installation will be much easier with two or more people.
Fig 1: Put Table Top (B) on Main Body (C), then use Bolt (AA) to lock them from the bottom up.
Fig 2: Put Lazy Susan (A) on Table Top (B).
If you want to replace any of the parts listed, please contact Customer Service Center: 1-866-578-6569.

Made In China 8 / 11
LOCATION
Your Gas appliance must be installed on a flat, stable surface, away from any combustible materials or construction.
SET-UP
Your Gas appliance comes assembled, ready for a Gas connection.
1- Remove the appliance from container box and place it on any level, outdoor, non-combustible surface.
NOTE: Do not place this appliance on grass or dirt area. This may prevent proper safety venting.
2- Open the gas door, put the cylinder inside.
3- Unscrew the battery box as shown in Fig 1.Insert the negative electrode side of the battery into the bottom of battery
box as shown in Fig 2. Then screw the battery box as shown in Fig 3.
Fig 1 Fig 2 Fig 3
Note: If the battery of the pulse electronic igniter runs out of power, please replace the new battery as shown above.
Gas Connection
1- Open the door, put the chain and control valve outside. See Fig 4.
2- Put the cylinder into the cylinder rack. See Fig 5.
3- Connect the regulator and the cylinder as per Fig.6. Make sure there is no leakage or damage (please refer to “Leak Test”
on page 9 and the bullet checkpoints on Page 4).
4- Secure the cylinder by the chain. See Fig 7.
Fig 7
Fig 4
Fig 5
Fig 6

Made In China 9 / 11
OPERATION
LEAK TEST
1- Make sure the control knob is on the “OFF” position.
2- Make sure the gas cylinder is correctly and securely connected to the pressure regulator, without over tightening it.
3- Turn on the gas cylinder valve. Apply a 50% soap and 50% water solution to the gas hose and connections between
the control knob and gas cylinder.
4- If something is leaking, you will see bubbles form. In case of leaks, turn off the gas supply, undo the leaking
connection, re-connect it and try again. If the leak persists, consult Customer Service Center for assistance.
5- If the connection is sound, continue to the next step.
Ignition
1- Make sure control valve is OFF.
2- Turn on gas tank valve.
3- Press in and turn control valve knob counterclockwise
to High to ignite. See the figure to the right.
4- If burner is lit, do not stop pressing in the control valve knob for
1 minute to heat the thermocouple.
5- When control valve knob is released, the burner should be lit. If not, turn control valve knob clockwise to OFF. Wait 5
minutes after completing Step 3 before attempting to re-ignite.
6- Press in and turn control valve knob to desired heat input, HIGH ~ LOW.
NOTE: While in use, the burner flame should be mainly blue in appearance with a small amount of yellow. The flame can
be identified by the following figure.
!!!WARNING!!!

Do not use an open flame to check for leaks.

Do not smoke during testing.

Do not test indoors.
A leak check must be performed whenever the gas cylinder is replaced.
Incorrect Flame
Y ELLO W T IPS
B LU E
H IG H
LO W
Correct Flame
LOW
HIGH
OFF
ON

Made In China 10 / 11
STORAGE AND MAINTENANCE
To obtain the best performance from your appliance, you must perform the following storage and maintenance activities on
a regular basis:
Allow at least 35 minutes for the appliance to cool down after use, before disconnecting and removing the gas
cylinder.
Store the gas cylinder in a dry, well-ventilated and sheltered area protected from inclement weather and dust, out of
the reach of children, and not in a building, garage or any other closed area.
The appliance may be stored indoors only if the cylinder is disconnected and removed.
Keep the appliance area clear and free from combustible materials, gasoline and other flammable vapors and liquids.
Installation and repair should be done by a qualified service person. The appliance should be inspected before
use and at least annually by a qualified service person. More frequent cleaning may be required as necessary it is
imperative that the control compartment,
burner and circulating air passageways of the appliance be kept clean.
If you disassemble the burner when cleaning the appliance, please reassemble
it according to the picture on the right to make sure the burner induction tunnel is
on and exactly cover the orifice base.
TROUBLE SHOOTING
PROBLEM OBSERVED
POSSIBLE CAUSE
CORRECTIVE MEASURES
Gas odor
—Gas leak
—See “If you smell gas:” on front cover of
manual
—Check all gas connections
Delayed ignition
—Low gas pressure
—Clogged or dirty burner ports
—Blocked orifice
—Spent battery
—Check gas supply pressure
—Clean burner ports, see manual section
—Check orifice opening
—Change a new battery
Incorrect burner flame
—Incorrect gas supply or pressure
—Blocked orifice
—Clogged or dirty burner ports
—Check gas supply pressure
—Check and clean orifice opening
—Clean burner ports
If you want to replace and of the parts listed, please contact Customer Service Center: 1-866-578-6569..

Made In China 11 / 11
LIMITIED WARRANTY
Subject to the conditions set out below, this product is warranted to the original purchaser to be free from defects in
workmanship and materials for twelve (12) months from the date of purchase.
Satisfactory proof of the purchase date must be furnished at the time of notification of the defect for any claim under
the warranty to be enforceable.
This warranty covers all parts found defective in workmanship and/or materials during the warranty period and can be
repaired or replaced at the discretion of the manufacturer at no cost to the original purchaser.
This warranty will be void if the product has not been assembled, installed or operated according to the instructions, or
subjected to abuse, improperly treated, neglected, rusted by exposure to the elements, misused and/or if any repairs,
maintenance, or service has been done by an unauthorized person.
Returns must be properly packaged and freight prepaid to the dealer from whom the product was acquired.
The manufacturer, distributor and retailer will not be liable for any incidental or consequential loss or damage arising
from the installation or operation of the product and/or the failure of any part for any reason.
There are no other express or implied warranties, except for those stipulated herein. This warranty gives specific rights
and the original purchaser may have additional rights and remedies in law.
This warranty does not cover commercial use.
CLEANING AND MAINTENANCE
To enjoy outstanding performance of your appliance for years make sure to perform the following maintenance
activities on a regular basis.
Keep exterior surfaces clean.
Use warm soapy water for cleaning. Never use flammable, corrosive or abrasive cleaners.
Clean the holes in the burner using a swab that is moistened with soapy water. Keep the holes unobstructed by using a
heavy-duty pipe cleaner. The burner must be dry before normal use. Cleaning period should be 1 year.
While washing your unit, be sure to keep the area around the burner and pilot assembly dry at all times. If the gas
control is exposed to water in any way, DO NOT try to use it. It must be replaced.
After a long break from operation, the unit should be inspected for spiders, spider webs or other insects.
Air flow must be unobstructed. Keep controls, burner and circulating air passageways clean.
Signs of possible blockage include:
—Gas odor with extreme yellow tipping of flame.
—Table does NOT reach the desired temperature.
—Table flow is excessively uneven.
—Table makes popping noises.
—Spider and insects can nest in burner or orifices.
—Compressed air may help clear away smaller particles.
WARNING: Fuels used in wood or charcoal burning appliances, and the products of combustion of such fuels, contain
chemicals known to cause cancer, birth defects or other reproductive harm.
