Sunjoy 3PC OPEN WEAVE WICKER CHAT SET A202012100 User manual

3PC OPEN WEAVE WICKER CHAT SET
ASSEMBLY INSTRUCTIONS
ITEM#: A202012100
SKU#：810502657
INeed help? We are here for you! 1(866)578 – 6569 24/7 • Toll Free

WARRANTY:
WARNINGS:
MAINTENANCE
GENERAL BEST PRACTICES FOR ASSEMBLY:
WHAT IS COVERED?
The limited warranty is extended tothe original purchaser and applies to material and manufacturer’s defect provided
the item is maintained with care and used only for personal, residential purposes.
Warranty: 12 months
•Please read and understand this entire manual before attempting to assemble or install the product.
• Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and
hardware contents list. If any part is missing or damaged, do not attempt to assemble the product.
• Do not place theproduct on a damp or conductive subsurface.
•Standing on or misuse of this chair may result in damage and injury.Read and follow mfg. assembly and use instructions. Not
intended for commercial use.
•Keep all children and pets away from assembly area.
•Check all bolts for tightness before use. IMPORTANT -check and tighten bolts often to keep them secure!
•Weight limit is 250lbs per chair.
• Before using, clean the chair completely with asoft dry towel.
• Do notuse harsh abrasives or cleaners.
•When not in use, store in a cool, dry area and for best results always cover the chair with an outdoor cover.
2/7

EXPLODED DRAWING
3/7

PARTS LIST
HARDWARE LIST
Label Part Number Description Qty Part Image
A P007700039 1
B P005400525 Front Leg 2
C P005400526 Back Leg 2
D P001800178 Cushion 1
E P002000002 Pillow 1
JFoot pad
Pre-assembled 2
K P005300069 Foot pad
Pre-assembled 2
Label Part Number Description Qty Add Part Image
H1 Bolt M6*15 12 2
H2 H050010025 Flat washer
M6 12 2
HW H090030002 Wrench M6 1 0
4/7

HELPFUL HINTS
• Separating parts before starting
How many people are needed for the installation
5/7
Provided in hardware pack

STEP 1
Assembled View:
1x
2x
12x 12x
2x
6/7
Attached Chair back(A) to Front Leg
(B) and Back Leg(C) with Bolt H1 and
Flat washer H2, tighten all the Bolt to
100% depth with Wrench(EE).

STEP 2
Assembled View:
1x 1x
7/7
Put the Cushion (D) and Pillow (E)
on the Chair back(A), the product
assembly is completed.
