Sunjoy A106005300 User manual

10x8CarterHillPergola
ITEM#：A106005300
SKU:1281022
Questions,problems,missingparts?
PleasecallSunjoyGroupat1(866)578‐6569anytime24hours/7daysaweekorvisit
www.sunjoyonline.comformoreinformationorassistance.
GENERALBESTPRACTICESFORASSEMBLY
• Pleasereadandunderstandthisentiremanualbeforeattemptingtoassembleorinstalltheproduct.
• Beforebeginningassemblyofproduct,makesureallpartsarepresent.Comparepartswithpackage
contentslistandhardwarecontentslist.Ifanypartismissingordamaged,donotattempttoassemblethe
product.
• Theassembledpergolashouldbelocatedatleast6feetfromanyobstructionsuchasfence,garage,
house,overhangingbranches,laundrylinesorelectricalwires.
• Somepartsmaycontainsharpedges.Wearprotectiveglovesifnecessary,duringassembly.
• Checkallnutsandboltsperiodicallyfortightnessand,whenrequired,tightenthemagain.
• Payattentiontothepartsorientation.

∙
WARNINGS
• Steelcomponentsforthispergolaaretreatedwithrustinhibitingpaintthatprotectsitfromrusting.
However,duetothenatureofsteel,surfaceoxidation(rusting)willoccuriftheseprotectivecoatingsare
scratched.Thisisnotadefectandthusnotcoveredbythewarranty.
• Tominimizethiscondition,itisrecommendedtousecarewhenassemblingandhandlingtheproductto
preventscratchingthepaint.Shouldanyscratchingordamageoccur,itisrecommendedtocoverthe
scratchimmediatelywithrustinhibitingpaint(notincluded).
• SurfacerustcanalsobeeasilyremovedwithaverylightapplicationofregularcookingoilorWD‐40.If
surfaceoxidation(rusting)occursandifnomeasureistakentopreventthis,theoxidationmaystart
drippingontodeckorpatioandcauseddamagingstains,whichmaybedifficulttoremove.Thiscanbe
preventediftheabove‐mentionedmeasuresaretakentokeeptheproductfromoxidizing.
• Donotusebleach,acid,orotherabrasivecleanersontherooforframeparts.
• Keepinstructionmanualforfuturereference.
• Keeptheoriginalpackagingtostorethepergola.
• Periodicallycheckandensurethatallboltsarewell‐tightenduringuse.
MAINTENANCE
• Installthepergolaonlevelground.Stakesareprovidedtosecurethepergolatotheground.
• Donotassemblethepergolaonsandy,muddyorloosesoil,asstakesdonothaveenoughanchoragein
thesetypesofsoil.
• Ifyouwishtosecurethepegolatoawooddeckorconcretesurface,useanchorssuitedtothesesurfaces.
• Snowmustbeclearedoffregularlyduringsnowydays.
• Donotleavethepergolawherethereisariskofhighwind,aspossibledamagewilloccurtothestructure.
• Anyassemblyormaintenanceoftheproductmustbecarriedoutbyadultsonly.
• Pleasecheckyourstateandlocalregulationspriortopurchasing.Somejurisdictionsmayrequirepermits
forinstallationanduse.Somespecialproceduresmaybevalidinyourarea.
• Keepallflameandheatsourcesawayfromthetentfabric.Thistentismadewithfabricthatmeets
CPAI‐84specificationsforflameresistance.Itisnotfireproof.Thefabricwillburnifrightincontinuous
contactwithanyflamesource.Theapplicationofanyforeignsubstancetothetentfabricmayrenderthe
flameresistantpropertiesineffective.
• Ifanyscratchpaint,pleasetouchuptopreventrusting.
• Foroutdooruseonly.
TOOLSNEEDED
Included

∙
EXPLODEDDRAWING

∙
PartsList
Label PartNumber Description Qty PartImage
A P000601073 TopBar1 7
B P000601074 TopBar2 7
C P000601075 LongsideSupportbar1 2
D P000601076 LongsideSupportbar2 2
E P000601077 ShortsideSupportbar1 2
F P000601078 ShortsideSupportbar2 2
G1 P000500864 CornerConnector1 2
G2 P000500865 CornerConnector2 2
H P000200342 Post 4
I P000100211 Base 4
J P006100133 BaseCover 4
K P005000289 ArcSupportFrame1 4
L P005000290 ArcSupportFrame2 4
M1 P005700309 Beam1 6
M2 P005700310 Beam2 6
M3 P005700311 Beam3 2
M4 P005700312 Beam4 2
N P000500866 RailConnector 2

O1 P005700307 Railbeam1 2
O2 P005700308 Railbeam2 2
P P005100107 Ring 16
O P006400014 Canopy 2
HardwarePack
Label PartNumber Description Qty Spare PartImage
AA H010020011BoltM6*15 1146
BB H050030001FlatWasherM6 160 5
CC H010110018BoltM6*45 14 1
DD H010110009BoltM6*15 32 2
EE H050020017SpringWasherM6 68 4
FF H070010003StakeΦ8*180 16 0
Z1 H090010017 WrenchM6 2 0

∙

∙

∙

∙

∙

∙

∙

∙

∙

∙

∙

∙
Country of Origin: China Production Number: 2021300015
