Sunjoy D-UM111PST User manual

January 16 Made In China 1/ 3
IMPORTANT:
1. Keep all children and pets away from assembly area. Children and pets should be supervised while product is being
assembled.
2. The assembled product should be located at least 6 feet (2 m) from any obstruction such as fence, garage, house,
overhanging branches, laundry lines or electrical wires.
3. This unit is heavy. Do not assemble this item alone. Two people are recommended for safe assembly.
4. Some parts may contain sharp edges. Wear protective gloves if necessary during assembly.
5. When assembling and using this product, basic safety precautions should always be followed to reduce the risk of
personal injury and damage to equipment. Please read all instructions before assembly and use.
6. For outdoor use only. Install on level ground.
7. Check all bolts for tightness before and during usage.
8. Please check your state and local regulations prior to purchasing. Some jurisdictions may require permits for
installation and use. Some special procedures may be valid in your area.
9. While this umbrella is manufactured to withstand strong force winds through only the supplied ground stakes, in
areas subject to frequent severe weather, securing the umbrella to a deck, concrete patio or footings should be
considered.
NOTE: The product’s structure is not guaranteed against extreme weather conditions (storms, high winds, etc.). If the
product is not dismantled for the winter, snow must be cleaned off regularly. Any damage caused by snow
accumulation is not covered by the warranty.
Care & Maintenance:
Our steel components for garden accessories and furniture are treated with rust inhibiting paint that protects it from
rusting. However, due to the nature of steel, surface oxidation (rusting) will occur once these protective coatings are
Assembly Instructions
Item# D-UM111PST

January 16 Made In China 2/ 3
scratched. This is not a defect and thus not covered by the warranty.
To minimize this condition, we recommend care when assembling & handling the product to prevent scratching the
paint. Should any scratching or damage occur, we recommend immediate touch-up with rust inhibiting paint.
Surface rust can also be easily removed with a very light application of common cooking oil. If surface oxidation
(rusting) occurs and if no measure is taken to prevent this, the oxidation may start dripping on to deck or patio and
caused damaging stains, which may be difficult to remove. This can be prevented if the above-mentioned measures are
taken to keep the product from oxidizing.
ASSEMBLY INSTRUCTIONS
Our clear, easy-to-follow, step-by-step instructions will guide you through the project from start to
finish.
All that is required is a screwdriver, a hammer and two ladders of at least 8 feet (2.5 m) high (not
included).
DO NOT assemble this item alone for your safety. Two people are necessary for smooth & safe
installation.
Item identification: For ease of identification, all parts are labeled to correspond to the Step number in
which the part is used.
Have 2 or more people helping you when assembling or moving the product.
Parts List
Part Number Description Qty Line of Drawing
A Base frame 1 1
B Base frame 2 1
C Base Tube 1
D Flat washer 4
E Bolt 6x15 4
F Umbrella 1

January 16 Made In China 3/ 3
Step 1:Attach Base frame 1 (A) to Base frame 2 (B) by cross placement as Fig. 1 show.
Step 2:Attach Base tube (C) to base frame with E and D as Fig. 2 show.
Step 3: Place Umbrella (F) to base frame and then secure it with knob pre-assembled on tube C as Fig. 3 show.
C
E
D
F
Step 4: Raise up the handle upward as Fig.4 show.
Step 5: Raise up the support post of the umbrella as Fig. 5 show.
Step 6: Upon raise up the connector post to a certain height, pull down the handle as Fig. 6 show.
Step 7: Raise up the support post as Fig. 7 show.
Step 8: Slide the tube downward and buckle into the bottom part of the tube as Fig. 8 show.
Step 9: Raise up the after end of the support post as Fig. 9 show.
A
B
