Sunmi T2s LITE User manual

This Manual shall be read carefully before use and remain in safe hands.
T2s LITE
POS User Manual
13119046-00

“Take main screen as sample”
Three options for sub screen of intelligent POS machine
15.6〃main screen only
（L571）
15.6〃main screen+10.1〃
customer screen
（L572）
15.6〃main screen+15.6〃
customer screen
（L573）
1. Rotate the display to horizontal 2. Open the port cover
3. Connect the power interface of the
adapter
to the power port at the
bottom of the mainframe. And insert
the other side of the adapter to electric
supply sockets
4. Press the power button for
two seconds to turn on
Quick Installation Guide

“Take main screen as sample”
Product Introduction
Display
Metal Base
USB interface
Power, Pilot Light
Card slot cover
USB Interface
For external keyboard, mouse and USB drive.
Display
For the touch screen used by the operator.
Metal Base
For supporting the display when put on the
desktop.
Able to be replaced with the VESA suspension
bracket.
Slot reader interface
For external MSR/NFC POS
Card slot is an optional part which may not
be available in all configurations.
TF card slot
For external TF card.
Micro USB debug port, debug key
For device debugging only.
Cash drawer interface
For external cash drawer with 120ms electric
pulse output. No continuous power is
supplied. This system only supports 24V/1A
cash drawers. Connecting a 12V drawer may
result in hardware failure.
Slot reader interface
Interface cover
TF card slot
Micro USB debug port
Port cover
Debug key
Power
port
Headset
jack
Cash drawer
interface
LAN
interface
USB
interface
Serial
interface
USB
interface
GND
RXD
TXD
5V
Power
In the state of power off, a short press turns on the
POS machine.
When powered on, press on the power button for
two or three seconds to choose power off or restart.
If the system is frozen, press the power button for
11 seconds to power off.
Pilot Light
The light will be blue when the power is on. When
the power is off, the light is off.
15.6”

Installation Steps for the VESA Bracket
Remove the base
1. Put the display flat on the desktop
with its face down.
2. Rotate the metal base to vertical.
3. Remove the lower cover of the bracket.
Remove the base
4. Rotate the metal base to horizontal.
5. Remove the upper cover of the bracket.
Remove the base
6. Unscrew the four M4 screws with a
screwdriver and complete the removal
of base.
Install VESA accessories
1. Place the VESA bracket aligning the four screw
holes according to directions.
2. Use the four M4 screws removed from the base
to fix the VESA bracket.
3. Install the bracket on the wall or desk
in accordance with VESA bracket instructions
to complete the installation.
1
3
2
6
4
5
Note: This machine only supports the installation for VESA
MIS-D (100×100mm) suspension bracket. The VESA
bracket is an optional accessory which needs to be
purchased by the user.
“Single screen configuration only”

Basic Specifications
Operating system
Processor
Display resolution
Storage
Touch screen
Wi-Fi
Bluetooth
Loudspeaker
External interface
External storage card
VESA(limited main screen only)
Item dimension
AC adapter
Android 9.0
Qualcomm snapdragon Qcta-core processor
15.6’’ resolution HD 1920 x 1080
32GB ROM + 3GB RAM or 64GB ROM + 4GB RAM
Multi-touch capacitive display
Support 802.11b/g/n/AC 2.4GHz/5GHz
Support Bluetooth 3.0/4.0/5.0 and iBeacon
Single 1.2W voice reaches 90db
5 x USB Type A interfaces, 1x RJ11 serial interface,
1 x RJ12 24V cash drawer interface, 1x RJ45 LAN interface,
1 x headset jack, 1x power port, 1x Micro-USB debug interface
MicroSD (TF), 64G maximum
In accordance with VESA MIS-D 100×100mm Standard
H 35cm × W 38cm × T 17cm
Configurations and parameters listed in this page are indicative and actual products on the market shall prevail.
Input:AC 100~240V,50/60Hz,1.5A Output:DC 24V,1.5A
Minimal Settings
How to download/use the application
Please read the built-in Help APP for more help.
Only a few steps to turn on the intelligent business equipment.
Press the power button and the screen will power on. Enter the first start-up screen and
follow the prompts. Two options for Internet access are available.
Wi-Fi setting.
· Press [Setting] and start WLAN. Enter the searching interface of WLAN, waiting for WLAN
network available;
· Click on the WLAN to be connected. A password is required for access if an encrypted
network is chosen.
Setting of LAN
1
2
3
This POS machine is suitable for cashier environment of business customers of different industries
including Chinese and Western foodservice industry, exclusive department store, convenience
store, the banking service industry, consulting station, interactive multimedia and advertisement
broadcast system, etc. Relevant apps can be scanned, downloaded and installed in the
application store with access to the internet.
Display resolution 10.1’’ resolution HD 1024 x 600
Specification of 10.1” customer display（optional）
Specification of 15.6” customer display（optional）
Display resolution 15.6’’ resolution HD 1920 x 1080
Touch screen
Touch screen
Multi-touch capacitive display
Multi-touch capacitive display

Precautions
Warning Important Safety Instructions
Recommendation
· Please insert the AC plug into the AC outlet accord
ing to the identifying input on the power adapter;
· It is prohibited to use the device in any places with
potential explosive gases;
· Nonprofessionals shall not open the power adapter
anyhow so as to avoid dangers;
· The device is a Grade A product. In living environ
ment,the product may cause radio interference.
Therefore,users may be required to take practical
measures against the interference.
· About the battery replacement:
1. It may cause explosion with wrong type battery
2. Old battery which is replaced should be handled
by repair man, do not put it in fire!
· Adapter shall be installed near the equipment and
shall be easily accessible.
· The operating temperature of the device between
0℃to 45℃.
· The device complies with RF specifications when
the device used at 20cm from your body.
· This product can be used across EU member states.
Statement
Disclaimer
· Avoid installing or using during
thunder and lightning,other wise
lightning stroke may occur;
· Cut off the power immediately if
there is abnormal smell, overheating or
smog!
The company is not responsible for the
following behaviors:
· Damages caused by using and maintaiing
the device without following the User Guide;
· Damages or problems caused by selection
of objects or Consumables (products which
are not the initial ones provided or recognized
by the company).
In this case, the company will not undertake
any responsibility.
· No one is entitled to modify or change the
product unless permitted by the company.
Discrepancies between the product and the
file concerning details may raise due to
product updates. Please be subject to the
material object. The company reserves the
right to interpret the file and the right to
revise this manual without prior notices.
Please make sure the temperature for
adapter will be from -10 ℃to 40 ℃.
Please make sure the temperature for
device will be from -10 ℃to 40 ℃.
· Do not use the device near water or in humid
environment.Keep liquid from falling onto the
terminal;
· Do not use the device in extremely cold and hot
environment, e.g. around fire or lighted cigarettes;
· Do not smash, throw or bend the device;
· Use the device in clean and dustfree environ
ment as much as possible and keep small items
from falling into the terminal;
· Do not use it near medical devices unless
permitted.
Package content
1× main machine
1× user manual
1× power adapter
Room 505, KIC Plaza, No.388 Song Hu Road, Yang Pu District, Shanghai, China
Manufacture
Name and content of toxic and harmful substances
contained in this product are shown in the following table
Name of parts
Circuit board
（Pb）(Hg) (Cd) (Cr(VI)） (PBB) (PBDE)
Toxic and harmful substances and elements
For products that have reached or passed the service years for environmental protection, they should be recycled
according to Measures for Control and Management of Electronic Information Products and should not be thrown
away at will.
:It indicates that the content of toxic and harmful substances in all homogeneous materials of this part is below the limit specified
in SJ/T11363-2006.
:It indicates that the content of toxic and harmful substances is higher than the limit specified in SJ/T11363-2006 in at least one
homogeneous material of this part; however, the the reason why the toxic substance of that part exceeds the limit is that there is
no applicable material to replace it currently.
Shell

Technical features and characteristic
the product includes the following features and characteristics�
EU Regulatory Conformance
FCC Regulations:
This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does
not cause harmful interference.
This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiated radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communica-
tions. However, there is no guarantee that interference will not occur in a particular installation If this
equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct theinterference by one or more of
the following measures:
· Reorient or relocate the receiving antenna.
· Increase the separation between the equipment and receiver.
· Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
· Consult the dealer or an experienced radio/TV technician for help.
Caution: Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
Hereby, Shanghai Sunmi Technology Co., Ltd. declares that the radio equipment type is in compliance with
Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address: www.sunmi.com
Notice: Observe the national local regulations in the location where the device is to beused. This device may
be restricted for use in some or all member states of the European Union (EU).
Adapter shall be installed near the equipment and shall be easily accessible.
The operating temperature of the device between 0� to 45�.
The device complies with RF specifications when the device used at 20cm from your body
This product can be used across EU member states.
2402MHz-2480MHz
2402MHz-2480MHz
BT
Operation Frequency
Transmitted
BLE
WIFI
Operation Frequency
Transmitted
Transmitted
Operation Frequency
1dBm±1dBm
2412MHz-2462MHz
17dBm±1dBm
2dBm±1dBm
