SunnCamp ULTIMA ASPIRE 260 User manual

ULTIMA ASPIRE AWNING
Erection Instructions
Thank you for choosing the SunnCamp ‘Ultima Aspire’.
Before attempting to fit this awning to your caravan, please ensure you have fully read and understood this instruction sheet. Should there be anything that is unclear to you, then please refer to
your supplier for additional instruction. If you follow these instructions when erecting and dismantling, packing and storing then you should enjoy many years of trouble free use.
It is essential that you check that all parts
listed above are present BEFORE leaving
home. It is also strongly recommended to
have a trial set up at home prior to proper
use. Failure to do so could affect your
warranty.
Unpack all the parts of your awning and
ensure that everything is present. Make
sure that the carry bag is put away
somewhere safe.
All poles are in sections which are pre
linked together. Take each pole in turn
and slot the sections together, inserting
the fibreglass section fully into the steel
ferrule. Ensure that the swagged sections
of the steel poles are fully inserted to the
wider ‘shoulder’. These adjustable steel
poles are in two pieces, the adjustable
ends need to be slid onto the main poles
with the Quick Lock Brackets open.
Unfold the awning’s flysheet and locate
the rear edge fitted with beading strip
(there are two diameters of beading fitted
to the awning one narrow & one wider). If
fitting directly to a caravan use the larger
diameter, if attaching to a wind out
canopy then use the smaller diameter.
Slide the beaded rear edge into the
caravan or canopy’s awning channel.
Take a fibreglass pole, one end is fitted
with a plastic ‘bung’. Insert the pole, bung
end first, into one of the flysheet’s external
sleeves. The pole’s end should locate
firmly into the reinforced pocket at the top
of the awning’s roof, the other end should
now locate onto a ‘ring & pin’ at the base
of the awning to bring the pole under
tension and into a curved shape. The ring
to which the pin is attached is fitted to the
awning by means of an adjustable
webbing strap, this can be loosened to
make fitting of the pole easy and then fully
tensioned to ensure a tight fit (this ring is
also used later as one of the pegging
points for the awning). Repeat this
process with the remaining fibreglass
poles. Bring the awning to an upright
position by pegging the corner guy lines,
these may need to be repegged at a later
stage.
To aid the awning’s rigidity it is supplied
with two sets of steel Roof Support Bars,
these are adjustable in length. Firstly
loosen the ‘Quick Lock Bracket’ using the
simple lever action & from inside the
awning insert the flattened end of the
pole’s fixed length into the webbing
retainer pocket at one side of the awning.
Lift the pole up and extend so that the
adjustable section’s flattened end can
slide into the retaining pocket at the
opposite side, bring the pole under
tension and secure by pressing the Quick
Lock Bracket’s lever fully down. Once in
place tie the ribbons in the middle of the
awning around the pole to hold it in place
to prevent any sagging (two ribbons on
the 390 model and one on the 260).
Repeat this process with the second Roof
Support Pole.
You can now start to peg your awning out,
all pegging points MUST be used what
ever the weather conditions Pegs should
always be inserted at a 45 degree angle,
pointing away from the awning, for
greatest strength. Please note that the
awning is fitted with ‘Ladder Band’
pegging points to allow height variation,
always peg at a point on the ladder that
applies tension to the flysheet but do not
over stress. The ladder bands are a
perishable component of your awning
and should you need replacements,!are
available to purchase from your dealer.
Start by pegging the two points closest to
the caravan ensuring that the line of the
side walls are vertical and close to the
caravan’s side to achieve a snug fit. Next
peg the two front corners keeping a
straight line, achieving tension in all three
walls of the awning. Finally peg all
remaining points around the awning
including those inside where the flysheet
returns along the wall of the caravan.
Never use your foot to push a peg into the
ground, always use a suitable mallet/
hammer for the type of peg being used.
ALL guy ropes must also be secured,
each with it’s own peg at a suitable
distance from the awning, tighten each
guy rope equally using the sliding guy line
runner to bring the flysheet into shape
and under tension. Do NOT overtighten!
Remember that the guylines pegged at
the beginning of the process may now
need repositioning to achieve the best
results. Following the pegging and guying
process, the flysheet should now be tight
and under tension.
The awning is fitted with two front
‘eyebrow’ canopies to help give the
doorways extra protection. Insert the
small fibreglass support pole into the
sleeving on the front edge. The ends of
the pole locate into two webbing pockets,
these have velcro openings for ease of
fitting, ensure they are firmly closed once
the poles are inserted.
The two rear vertical support poles fit into
reinforced pockets at the top rear corners
of the awning. Extend the pole and
tension with the lever action Quick Lock
Brackets to create a seal between the
rear pads and the caravan wall, secure to
the flysheet with the velcro fastenings.
PARTS LISTING
Flysheet
1
Adjustable Steel Roof Support
Pole (in two parts)
2
Adjustable Steel Rear Support
Poles (in two parts)
2
Shock Corded Fibreglass Poles
(390 Model)
4
Shock Corded Fibreglass Poles
(280 Model)
3
Fibreglass Canopy Support Pole
2
Peg Bag
1
Carry Bag
1
ULTIMA ASPIRE 260 ULTIMA ASPIRE 390
www.sunncamp.com Sunnflair Ltd, Brentwood, Essex, CM13 1QD
BEFORE YOU START
POLES
FLYSHEET
ROOF SUPPORT POLES
PEGGING
GUY ROPES
FRONT CANOPIES
REAR SUPPORT POLES

www.sunncamp.com Sunnflair Ltd, Brentwood, Essex, CM13 1QD
•General wear and tear
•Defects arising from neglect, misuse or unauthorised modifications.
•Damage caused by storms, winds or other inclement weather conditions
•Damage caused by abuse, misuse, dropping or other similar damage caused by, or as a result of, failure to follow storage or erection instructions.
•Moisture appearing on the inside of the flysheet, this is caused by condensation and is not a leak.
•Leakage through the seams of the tent due to excessive abrasion and damage to the seam sealant tape.
•Seams coming apart as a result of over tensioning.
•Broken or damaged zips caused by undue force , jamming or incorrect pegging
•Broken buckles if they have been subject to undue force.
•Damaged carry bag if due to being overloaded, incorrect packing of tent or general misuse
•ALL pole breakages – These are a perishable part of your tent and are regarded as ‘Fair wear and tear’. They are normally due to undue stress in the erection or
dismantling procedures and are easily replaced and readily available from your retailer.
•Collateral damage arising from a pole breakage (Such as ripped pole sleeve or flysheet)
•Damage caused by the incorrect pitching or dismantling of the tent/awning
•Any damage sustained due to cooking inside the tent/awning.
•Damage caused due to UV degradation.
•Unauthorised alterations, additions or repairs.
•Transportation or shipment costs to and from the Manufacturer or their recognised agents, for repair or assessment against a warranty claim.
•Awnings/tents used on permanent sites or displays or commercial use by rental companies.
THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS.
The Manufacturer and/or their recognised agents, directors, employees or insurers will not be held liable for consequential or other damages, losses or expenses in
connection with or by reason of or the inability to use the awning for any purpose.
NOTE; Any claim(s) arising due to missing parts or faulty goods MUST be made before use. The manufacturer will not be responsible for any claims regarding missing
parts or faulty items where the product has not been checked by the user prior to use.
In the event of a faulty extension being returned, it must be sent in a completely dry and clean condition. Failure to do so will affect your warranty.
The following items are NOT COVERED by the products Manufacturers Warranty:
WARRANTY
Your new SunnCamp awning is covered by the Manufacturer’s Warranty against any manufacturing defect for a twelve month period from the date of purchase. During
this period the Company undertakes to replace or repair, free of charge, any defect which the Company considers to be due to faulty workmanship or material. Please
ensure you retain your receipts and proof of purchase for this period.
The awning is fitted with a weather skirt at
the base. Make sure this is neatly and
correctly laid and pegged out to help any
water to be shed away from your awning.
All windows are fitted with internal
curtains for privacy. When opening the
curtains, they can simply be rolled out of
the way and secured with the toggle and
loop fixings. When closed the curtains
can also be secured in place with similar
fixings.
The awning’s front entrances (two on the
260 model and three on the 390) are
single skinned and can be unzipped and
rolled up out of the way and secured in
place with toggle and loop fixings. These
doors can also be used as a canopy with
the addition of a Canopy Pole Set which is
available from your dealer as an optional
accessory.
The awning’s two side doors have a
secondary mesh panel allowing the door
to be open to provide ventilation whilst
keeping insects out. Both the solid outer
door and the inner mesh door can
independently be rolled to the side and
secured with toggle and loop fixings.
When closing any of the doors ensure that
the the zips are fully secured and the
protective flap is in place and secured by
the velcro tabs to prevent water ingress.
When not in use doors should also be
fully pegged.
The awning is not supplied with a
groundsheet. Many types are available on
the market but we do recommend using a
breathable option. There is an optional,
made to measure, breathable PE
groundsheet/underlay for this awning
available from your SunnCamp dealer.
When taking the awning down simply
reverse the set up procedure. Ensure that
you take all parts with you and that they
are clean and dry. Place the poles and
pegs in the bags provided before packing
the awning away in it’s carry bag. Please
also to refer to, and take notice of, the
‘Care’ section on this page.
It is always advisable when camping to
have a ‘Fire Bucket’ filled with water in
case of emergencies. Please be aware
that your awning is flame retardant but
NOT fire proof. Do not smoke, cook or use
a naked flame in or near this awning.
Try to keep your awning well ventilated to
reduce condensation. Moisture collecting
on the inside of the flysheet is
condensation and NOT a sign of leakage.
All the main seams of this awning are hot
air taped to help reduce any leakage, any
other seams, or where taping has become
damaged, should be treated with a seam
sealant.
Should you have to pack the product
away when wet or damp, the awning and
all parts (including guy ropes) MUST be
dried out fully as soon as possible and
not left packed wet for extended periods.
Failure to do so will result in damage to
your awning which is not covered under
your warranty.
The flysheet should only be cleaned using
fresh clean water and a clean coth. Do
not use detergents or chemical cleaners
as these will affect the waterproofing of
your awning.
Repairs to the awning should only be
made by SunnCamp’s recommended
agents. Repairs made by an unauthorised
third party will make the manufacturer’s
warranty void.
Prolonged exposure to UV can weaken
the flysheet’s fabric and reduce the tent’s
life. If possible try and camp in shaded
areas.
It is important to remember that carbon
monoxide can kill. Your awning is of
course well ventilated and does not
feature a sewn in groundsheet, however
still never use a fuel-burning appliance
inside your awning. Even a warm
barbecue can be lethal.
WEATHER SKIRT
UV DETERIORATION
DISMANTLING
WINDOWS
FRONT DOORS
SIDE DOORS
GROUNDSHEET
SAFETY
VENTILATION
SEAMS
CARE
CARBON MONOXIDE
