Magnetic Mini Exercise Pedal Cycle
SF-B020026
USER MANUAL
DO NOT STAND ON THE UNIT.
IMPORTANT! Please retain owner’s manual for maintenance and adjustment instructions. Your
satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE
CONTACTED US: [email protected] or 1- 877 - 90SUNNY (877-907-8669).

1
IMPORTANT SAFETY INFORMATION
We thank you for choosing our product. To ensure your safety and health, please use this
equipment correctly. It is important to read this entire manual before assembling and using the
equipment. Safe and effective use can only be achieved if the equipment is assembled,
maintained, and used properly. It is your responsibility to ensure that all users of the equipment
are informed of all warnings and precautions.
1. Before starting any exercise program, you should consult your physician to determine if you
have any medical or physical conditions that could put your health and safety at risk or
prevent you from using the equipment properly. Your physician’s advice is essential if you
are taking medication that affects your heart rate, blood pressure, or cholesterol level.
2. Be aware of your body’s signals. Incorrect or excessive exercise can damage your health.
Stop exercising if you experience any of the following symptoms: pain, tightness in your chest,
irregular heartbeat, shortness of breath, lightheadedness, dizziness, or feelings of nausea. If
you do experience any of these conditions, you should consult your physician before
continuing with your exercise program.
3. Keep children and pets away from the equipment. The equipment is designed for adult use
only.
4. Use the equipment on a solid, flat level surface with a protective cover for your floor or carpet.
To ensure safety, the equipment should have at least 2 feet (60 CM) of free space all around
it.
5. Ensure that all nuts and bolts are securely tightened before using the equipment. The safety
of the equipment can only be maintained if it is regularly examined for damage and/or wear
and tear.
6. Always use the equipment as indicated. If you find any defective components while
assembling or checking the equipment, or if you hear any unusual noises coming from the
equipment during exercise, discontinue use of the equipment immediately and do not use
until the problem has been rectified.
7. Wear suitable clothing while using the equipment. Avoid wearing loose clothing that may
become entangled in the equipment.
8. Do not place fingers or objects into the moving parts of the equipment.
9. The equipment is not suitable for therapeutic use.
10.To avoid bodily injury and/or damage to the product or property, proper lifting and moving
are required.
11.Your product is intended for use in cool, dry conditions. You should avoid storage in extreme
cold, hot or damp areas as this may lead to corrosion and other related problems.
12.This equipment is designed for indoor and home use only; it is not intended for commercial
use!

2
EXPLODED DIAGRAM
HARDWARE PACKAGE
O
O
33
33
31
32
934
19
8L
23R
3L
463523
26
25
7R
29
6
30
16
17
22
27
16
24
38
40
39
13
44
43
24
37
37
35
23
26 25
32
23
4
20
21
45
34
24
24
24
5
7L
10
21
22
24
24
24 42
42
42 28
28
29
41
15
36
24
24
11
#49 S17-S19 1PC
12
18 47L
47R
27
24
24
8R
16
16
22
27
21 21
22 27
14
1
#48 S13-S14-S15 1PC

3
PARTS LIST
No.
Description
Spec.
Qty.
No.
Description
Spec.
Qty.
1
Main Frame
1
26
End Cap
2
2
Spindle
1
27
High Cap Nut
M8
4
3L/R
Crank
2
28
Bolt
M6*15
4
4
Magnetic Board
1
29
Nylon Nut
M6
4
5
Idler Wheel Shaft
1
30
Belt Wheel
1
6
Axle for Crank
1
31
Belt
J300
1
7L/R
Pedal
2
32
C-clip
2
8L/R
Belt Cover
2
33
Bearing
6003
2
9
Tension Control Knob
1
34
Screw
M5*15
2
10
Meter
1
35
Flat Washer
Φ8.2*Φ16*1.5
2
11
Inertial Wheel
1
36
Inductor Seat
1
12
Wave Washer
1
37
Bearing
6000
2
13
Idler Wheel
1
38
Inductor
1
14
Rear Stabilizer
1
39
Screw
M10*18*12
1
15
Magnet
2
40
Nylon Nut
M10
1
16
End Cap
4
41
Spring
1
17
Front Stabilizer
1
42
Wire Clip
3
18
Sleeve
1
43
Screw
M6*12
1
19
Spring
1
44
Flat Washer
Φ6.4*Φ12*1.2
1
20
Bolt
M8*35*15
1
45
Nut
M5
1
21
Carriage Bolt
M8*42
4
46
Washer
Φ10.2*Φ20*1.5
1
22
Washer
ID8.2*OD16*1.5
4
47L/R
Nylon Nut
M12
2
23
Nylon Nut
M8
3
48
Spanner
S13-S14-S15
1
24
Screw
ST4.2*15
15
49
Spanner
S17-S19
1
25
Flange Nut
M10
2
Ordering Replacement Parts (U.S. and Canadian Customers only)
Please provide the following information in order for us to accurately identify the part(s) needed:
✓The model number (found on cover of manual)
✓The product name (found on cover of manual)
✓The part number found on the “EXPLODED DIAGRAM” and “PARTS LIST” (found near the
front of the manual)
Please contact us at [email protected] or 1- 877 - 90SUNNY (877-907-8669).

4
ASSEMBLY INSTRUCTIONS
We value your experience using Sunny Health and Fitness products. For assistance with parts or
troubleshooting, please contact us at [email protected] or 1-877-90SUNNY (877-
907-8669).
17
22
27
22
27
21
14
22
27
22
27
21 21
1
STEP 1:
Attach Rear Stabilizer (No. 14) to the Main
Frame (No. 1) with 2 Carriage Bolts (No.
21),2Washers (No. 22),and 2High Cap
Nuts (No. 27). Tighten and secure with
Spanner (No. 48).
Attach Front Stabilizer (No. 17) to the
Main Frame (No. 1) with 2 Carriage Bolts
(No. 21),2Washers (No. 22),and 2 High
Cap Nuts (No. 27). Tighten and secure with
Spanner (No. 48).
O

5
We value your experience using Sunny Health and Fitness products. For assistance with parts or
troubleshooting, please contact us at [email protected] or 1-877-90SUNNY (877-
907-8669).
STEP 2:
NOTE: The Pedals (No. 7L & No. 7R) are
marked “L” and “R” for Left and Right.
WARNING! Read instructions carefully as
improper assembly may cause permanent
damage to your bike.
Remove the 2 Left & Right Nylon Nuts
(No. 47L & No. 47R) located on the Pedals
(No. 7L & No. 7R).
Align the Left Pedal (No. 7L) with the Left
Crank (No. 3L) at 90°. Gently insert the
Left Pedal (No. 7L) into the Left Crank
(No. 3L) and turn the Left Pedal (No. 7L)
counter-clockwise as tightly as you can
with your hand. Use Spanner (No. 48)to
tighten and secure.
Turn the Left Nylon Nut (No. 47L)
clockwise as tightly as you can with your
hand. Use Spanner (No. 48)to hold the
pedal bolt on the Left Pedal (No. 7L) and
use Spanner (No. 49) to turn the Left Nylon
Nut (No. 47L) clockwise at the same time,
until it is tightened on to the Left Crank (No.
3L).
Align the Right Pedal (No. 7R) with the
Right Crank (No. 3R) at 90°. Gently insert
the Right Pedal (No. 7R) into the Right
Crank (No. 3R) and turn the Right Pedal
(No. 7R) clockwise as tightly as you can with
your hand. Use Spanner (No. 48)to tighten
and secure.
Turn the Right Nylon Nut (No. 47R)
counter-clockwise as tightly as you can with
your hand. Use Spanner (No. 48)to hold
the pedal bolt on the Right Pedal (No. 7R)
and use Spanner (No. 49) to turn the Right
Nylon Nut (No. 47R) counter-clockwise at
the same time, until it is tightened on to the
Right Crank (No. 3R).
The assembly is complete!
47R
47L
9
3L 7L
3R
7R
3R
7R
47R
48
3R
7R
48 49
3L 7L
48
3L
7L
47L
48
49

6
BATTERY INSTALLATION & REPLACEMENT
BATTERY INSTALLATION:
1. Take out 1AAA battery from the manual bag.
2. Remove the Meter (No. 10) from Main Frame (No. 1). Then disconnect the link wire of
Inductor (No. 38) with the Meter (No. 10).
3. Install 1 AAA battery into the battery case on the back of the Meter (No .10).Pay attention to
the battery + and –poles before installing.
4. Insert the link wire of Inductor (No. 38) into the hole on the back of Meter (No. 10).
5. Attach the Meter (No. 10) onto Main Frame (No. 1).
The installation is complete!
BATTERY REPLACEMENT:
Remove the 1 old AAA battery in the battery case and install 1 new AAA battery into the battery
case on the back of the Meter (No. 10). Pay attention to the battery + and –poles before
installing.
The replacement is complete!
NOTE: Dispose battery according to your state and regional guidelines.
1BATTERY
38
BATTERY
10
10 10

7
EXERCISE METER
SPECIFICATIONS:
SPEED-------------------------------------------0.0~999.9MPH (Mile/Hour)
TIME----------------------------------------------0:00~99:59MIN
DISTANCE--------------------------------------0.0~9999M (Mile)
CALORIES--------------------------------------0.0~9999KCAL
FUNCTION KEYS:
MODE: Push down for selecting functions. If the long time holds down MODE button down for
resetting time, distance and calories.
SET:To set the values of time, distance and calories when not in scan mode.
RESET: Push down for resetting time, distance and calories.
FUNCTIONS:
SCAN: Press “MODE” button until “SCAN” appears, monitor will rotate through all the 4 functions:
Time, speed, distance, calorie. Each display will be hold 4 seconds.
TIME:
(1) Count the total time from exercise start to finish.
(2) Press “MODE” button until “TIME” appears, press “SET” button to set exercise time.
SPEED: Display current speed.
DIST:
(1) Count the distance from exercise start to end.
(2) Press “MODE” button until “DIST” appears, Press “SET” button to set exercise distance.
CALORIES:
(1) Count the total calories from exercise start to end.
(2) Press “MODE” button until “CAL” appears, Press “SET” button to set exercise calories.
NOTE:
1. Please use 1pc of battery AAA 1.5V battery as a power supply. If there is an abnormal
display on the meter, please replace the battery.
2. The meter will automatically power on when pedals are in motion or the MODE key is being
pressed.
3. The monitor will be auto-powered on when starting to exercise push button signal in.
4. The monitor will automatically start calculating when you start to exercise and will stop
calculating when you stop exercising for 4 seconds.

8
ADJUSTMENTS & USAGE GUIDE
ADJUSTING THE TENSION
Adjust the tension by rotating the Tension
Control Knob (No. 9) clockwise to
increase the level of resistance. Rotate
the Tension Control Knob (No. 9)
counterclockwise to decrease the level of
resistance.
Tension levels are set at Level 1 being the
lowest and Level 8 being the highest.
USE ONLY WHILE SITTING.
DO NOT STAND ON THE
MACHINE!
WARNING
The machine is intended to use in a sitting
position only, do not stand on the
machine.
Failure to follow all warnings and
instructions could result in serious injury
or death.
Version: 1.1
