SUNWARD SUN-15T User manual

SUNWARDENG SUN-15T(IC,Pt,K)Controller (UserManual) Page1/4
4.HowtoConnectSensor
Tem peratureControllerSUN‐15TUserManual
Model Temperature Range Output
SUN-15T IC -50 … 125 oC
Main Relay(OUT1) /
AUX Relay (OUT2)
K type (CA) -200 … 1300oC
PT100 -200 … 400
oC
※The User Manual is provided for
preventing the damage and trouble of
product caused by carelessness and to
inform the precise usage.
~
Equipment protected throughout
by DOUBLE INSULATION of
Reinforced-Insulation
Alternating Current Supply
DisplayUnit

DisplaysCurrentTem p eratureorUser‐set
temperature

Main/Aux
Output

IndicatesthemainorauxiliaryoutputisONorOFF
SettingButton
IncreaseButton
DecreaseButton


Temp e ratureInstallerSettingButton
SettingValueincreasebutton
SettingValuedecreasebutton

▶ Power Controller for heater and cooler . Hysteresis 0.0~19.9oC for IC
sensor and PT100 models and 0~50
oC for K-Type models.0~240Sec delay
timer , Normal(heating)/ Reverse(Cooling) selection.
▶Contains general purpose digital Timer,1~999Minute.(e.g. defrosting usage)
▶ User configuration control .You can specify a valid temperature range that
user is allowed to use. You can prevent a user from changing the setting of
hysteresis, Delay timer and normal/reverse .
▶ Supply power to the controller.
It displays the current temperature.
▶ Press Set button once to set Main output
Temperature value on the display is flashing.
▶To change them, press UP or Dn Key.
If you hold UP/Dn longer than 1 sec
Increases or decreases quickly
※The selectable range might be
limited by user configuration control.
▶ If you press Set for 5 seconds,
the set Temperature will be saved.
Even if switched-off, the set value
will not be deleted.
▶The current Temperature is displayed
and controller starts to control.
▶Main output N.O. use terminals 9~10.
▶Auxiliary output use terminals 5,6 (see section13)
① sensor connection method
▶ Please connect as the right picture
If you connect with the changed
wired or use different type sensor
‘ Err ’ to be displayed.
② sensor wire extension method
▶ A Pt100 sensor line can be extended
Up to 100M . IC sensor extending
cable length limited to 30M.(Shielded
cable is advised, to prevent input noise)
③ Sensor Reading compensation
When current temperature is incorrect,
▶Hold SET key for longer than 5 sec.
When the display unit shows current temperature .
▶Release the key when diF is displayed. Select proper rSt by pressing UP
or Dn key.
▶Store the setting in memory by holding the SET key for longer than 5sec.
For example :
Current
Temperature
rSt Temperature Displayed
Temperature
20 oC +
+
-5 oC =
=
15 oC
20 oC 10 oC 30 oC

Attention ‐Manufacturerisnotresponsibleforanymisusages.
‐Itisrecommendedtouseanexcesstemperaturealarmsystemtoprotectyour
processagainsttheprobabledangers.
‐ Thisproductisintendedtobeusedastemperaturecontrolandthemanufactureris
notresponsibleforanyusesexceptthat.

‐ Foranyservicesrefertothesupplierandfortheauthorized(official)servicecenters
refertothefollowingaddress.
‐Formaintenanceandservicenotetothesection15ofthedocumenttoo
.
Ma nufacturedandsupportedby:
DPSACo.LTD,www.sunward.info,inf[email protected]fo

ITEMSpecification
SupplyVoltage 100~240VAC‐50~60Hz12~24VDC
Power MAX.3W
InputSensor
IC(‐50~125
O
C)
K‐TYPE(CA)(‐200~1300
O
C)
PT100(‐200~400
O
C)
Accuracy
IC,0.1
O
Cfortheentirerange
K‐TYPE(CA),1
O
Cfortheentirerange
PT100,(0.1
O
C:‐200~200
O
C)(1
O
C:200~400
O
C)
Hysteresis
0.1~19.9
O
CforICandPT100Sensor
1~50
O
CforK‐Typesensor
ControlOutput Relayoutput(AC250VAC,5A)
ControlOperation ON/OFF Control
IngressProtection IP55
SettingMethod DigitalmethodwithUporDownkey
etc.
SensorInputCorrection,DelayTimer,Normal/Reverse
logic,TimerOutput(defrosting)
Environment
Temp e rature:0~50
O
C
Humidity:85%orless
ICSens
TC
PT100
Auxiliary




MainPower
AC
100~
220V
OUT2OUT1
Tem p 
Sensor5A/220V

5A/220V
② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪
⑫
1
3.HowToSetMainOut
p
ut
2.CapabilitiesandApplicationsofProduct
5. External&PanelDimension
6.ProductSpecification
<Current Temperature>
Coil
< Terminals on Back >
uncun
1.DescriptionofDisplay
up
dn set
Load
AC
220V
Power
70
35
77
(unit: mm)
28+0.6
PANEL CUT OUT
70+0.6
set
up
Dn
oC
<Rear Panel terminal>
RTD
R B
W
+ - K Type TC
IC Sensor
ICSens
d

TC
Auxiliary



MainPower
AC
100~
220V
OUT2OUT1
5A/220V

5A/220V

① ②③ ④ ⑤ ⑥ ⑦ ⑧ ⑨⑩⑪
⑫
R B
W
+-
Increase
Decrease Main Output Display
Set Button
Aux Output
on1
SUNWARD
on2
OC
Maintenance
and Service

SUNWARDENG SUN-15T(IC,Pt,K)Controller (UserManual) Page2/4
▶To change hysteresis hold SET key for longer than 5 seconds . Release the
key when the display unit shows diF .
▶Set the configuration as following using UP and Dn keys.
dIF
User
Settings
InputSensorSettingDescription
PT100&IC

0.1~19.9PreventRelayVibrationFromHysteresis
K‐Type1~50
O
C
▶Store the setting in memory by holding the SET key for longer than 5 sec .
▶Description of ON/OFF control based on hysteresis value :






tyP
User
Settings
Item Setting Description
tyP C Control The Cooler (Reverse Output)
H Control The Heater ( Normal Output )
① Cooler ON/OFF control
▶When the current temperature becomes higher than a configured
temperature, the main output relay turns on.
▶You can use a delay timer to protect a compressor. (in refrigeration usage)
② Heater ON/OFF control
▶When the current temperature becomes lower than a configured temperature,
the main output relay turns on.
Note: In general, the B contact of a relay is used for reverse Output. In this
case, be cautious the contact B is ON even though the power to the unit is
turned off. (for example)
SV=50.0 ,diF=5.0 , dLt=0 , tYP=H SV=-10.0 ,diF=4.0 , dLt=0 , tYP=C
▶In order to change the delay timer setting, Hold SET key for longer than 5
seconds while the display unit shows the current temperature. Release the key
when the display unit shows diF
.
Press SET key several times to select dLt.
▶After selecting a value using Up or Dn key, press SET key to store the
setting in the memory.
Description: When the delay time expires, the output turns on.
User
Settings
Item Setting Description
dLt 0~240Sec Output Becomes ON After Specified Time
▶How the delay timer works
▶
The following diagram shows configurable items. Select an item by
pressing SET key.
▶Make a note of factory default settings before changing any one of them.
Before making any change, understand and verify the validity of your
setting(s).
▶Invalid settings may require service from the manufacturer.
7.Hysteresissetting
tyP=C
Cooling(Reverse)
tyP = H
Heating(Reverse)
47
ON
OFF
48
49
SET 50
5
1
1
48
49
SET 50
5
1
1
47
ON
OFF
9.Dela
y
TimerSettin
g

Press SET key when the display
unit shows a current temperature
Normal/Reverse Control
Hysteresis diF=2.0Hysteresis diF=1.0
ON
OFF
SET 50
51
52
53
49
SET 50
51
52
53
49
ON
OFF
8.Normal
/
ReverseOut
p
ut
Set 50
45
Heating
Action
-6.0
Set -10
Cooling
Action
The dela
y
time is 5 second=> the rela
y
turns on
after 5 sec once output signal arrives.(dLt=5)
The dela
y
time is 0 second => the rela
y
turns
on as soon as output signal arrives. (dLt=0)
10.UserConfigurableSettings
Delaytime
0~240Seconds
dLt
Hysteresis0.1~19.9
O
C(PT100&IC)
Hysteresis1~50
O
C(K‐TYPE)
DIF
Normal/ReverseSelection
C:Cooler,H:Heater
TyP
MainOutputSettingMainOutputSetting
Pro
Aux Output(Alarm) Aux Output(Alarm)
oFF
TimerOFFsetting
0~999min
On
TimerONsetting
0~999min
To go back to the top, Press SET key
Hold SET key Longer Than5
Seconds to save the configuration.
SensorInputCorrection
‐50.0~+50
O
C
r
s
t
11.UserConfi
g
urableSettin
g
s
FactorySettingItem

Turn off the power . Turn on the
power while holding SET key.
Keep holding SET key until you see
StH on the display unit . then
release it
To go back to the top , press SET
key.
Hold SET key for longer than 5sec
to save the configuration.
diF
Alarmhysteresis0.1~19.9
O
CforIC
andPT100,1~50
O
CforK‐TYPE
StH
Upperlimittemperature.Temp erature
Ran
g
eforeachSensor
LoC
LockingFunctionforuser
0:Released;1:Locked
tyP
AUXOutput:Timer/Normal/ReverseSelection
C:Cooler
(
U
pp
erAlarm
),
H:Heater
(
LowerAlarm
),
t:Timer
dLt
Delaytime
0~240Seconds
StL
Lowerlimittemperature.Temperat u re
Ran
g
eforeachSensor
(
Dismissed forTC
)

SUNWARDENG SUN-15T(IC,Pt,K)Controller (UserManual) Page3/4
①You can prevent a user from changing a pre-set configuration.
▶
Turn off the power while pressing set key. keep Holding SET key
until you see StH on the display unit you.
▶
Press SET key several times to select LoC . Set the configuration
as following using Up and Dn keys.
▶
Hold SET key for longer than 5 seconds to save the configuration.
Note: After this configuration, the main temperature can be set only
within the range of 40 to 50 degree.
②You can specify the range of temperature that a user can set .
▶Turn off the power. Turn on the power while holding SET key .Keep
holding SET key until you see StH on the display unit.
▶Press SET key several times to select StL .Set the configuration as
following using Up and Dn keys.
Factory Setting
Item Set Input Description
StH
400 /
125 Pt100, IC The highest value of temperature is 400 (Pt100) /125OC (IC)
1250 K-TYPE The highest value of temperature is
1200OC
StL -200
/-50 Pt100, IC The lowest value of temperature is -200 (Pt100) / -50OC(IC)
▶Hold SET key for longer than 5 sec to save the configuration. Note : After
this configuration ,the main temperature can be set only within above ranges.
①
Set the auxiliary relay Output to Alarm Output (timer in next section)
▶The auxiliary relay operates either as Alarm Output or as timer output .
(alarm output is factory default setting)
▶You MUST turn off power to change the factory setting.
▶Turn on the power while holding SET key. and keep holding SET key.
▶Release the set key when the display shows StH.
▶Press SET key several times until you see tyP.
▶To set the configuration as following, use Up and Dn keys.
▶
Store the setting in memory by holding the SET key for longer than 5 seconds.
②
How to set alarm output temperature.
▶When the display shows current temperature, hold SET key for longer
than 5 seconds release the SET key when the display shows diF.
▶Select Pro by pressing set key several times
.
▶If Pro is not displayed, you have to set auxiliary output as alarm state.
(refer to the item 1 above, it shows the auxiliary output set as timer)
▶To set the configuration as following, use Up and Dn keys .
▶Store the setting in memory by pressing SET key for longer than 5 sec .
③ How to set alarm high or low
▶To change the factory setting, you MUST turn off the power.
▶Turn the power ON while holding SET key. and keep holding the set key.
▶Release the key when you see StH on the display unit.
▶Select tyP by pressing SET key several times.
▶To Set the configuration as following, use Up and Dn keys .
▶
Hold set key for longer than 5 seconds to save the configuration .
④
How to disable the alarm output
▶
When you want to turn off alarm relay output, Follow the procedure
described below.
▶
Hold SET key for longer than 5 seconds(when the display shows a
current temperature) release the key when you see diF.
▶
Press SET key several times to select Pro.
▶
Select either the highest value or lowest value using Up or Dn key.
▶
Hold SET key for longer than 5 seconds to save configuration.
① How to set the auxiliary relay to the timer output
▶
The auxiliary relay select either the alarm output or timer output. As
a factory setting, the relay is set to the alarm output.
▶To change the factory setting you MUST turn off power .
▶Turn on the power while holding SET key. and keep holding SET key.
▶Release the set key when the display shows StH
▶Press SET key several times until you see tYP.
▶To set the configuration as following, use Up and Dn keys.
▶Hold SET key for longer than 5 seconds to save the configuration.
②
How to set timer value:
▶When display shows the temperature , Hold SET key for longer than 5
seconds. Release the SET key when you see diF on display .
▶Press SET key several times, to get on . if on does not appear , the auxiliary
output is not selected as the timer output .See part 1 in above paragraph .
▶Set the configuration as following using Up or Dn keys.
▶
Press SET key for longer than 5 seconds to save the configuration.
③
Description of the pulse cycle .
Note :Periodic timer is operating separated from temperature control.
▶Install the unit in an environment where
1- The temperature in relatively constant
2- There is no corrosive gas,
3- The humidity is normal, and
4- There is no excessive dust and electric noise.
▶Wire ( or line) connections
Sensor line is sensitive to noise from high-voltage power line. Use a separate
pipe for sensor wires.
▶For applications ,capable of having body injury or property damage ,it is
advised to use a double safety device.


Factory
Setting
Item Set Description
LoC 0 Unlocked (User can change setting)
1 Locked (User can’t change preset config.)
Setting
Item Set Description
Pro -50.0 /
150.0
The configuration disables the alarm
output (-50 for H and 150 for C )
Factory
Setting
Item Set Description
tYP H Auxiliary Output As Alarm Low
C Auxiliary Output As Alarm High
Example
Setting
Item Set Description
Pro 100.0 Alarm Output is set to 100OC (IC,PT100)
0.0 Alarm Output is set to 0.0OC (TC)
Factory
Setting
Item Set Description
tYP
H The output is turned on when the current
temperature becomes lower ( TC)
C The output is turned on when the current
temperature becomes higher (IC , Pt100)
Factory
Setting
Item Set Description
tYP t Use the auxiliary relay as the timer output
Example
Setting
Item Set Description
on 5 The output will be ON for 5min after a
15 min OFF period .
oFF 15 The output will be OFF for 15min after a
5 min ON period .
12.Configurationlock
13.HowtosetAlarmOutput(AuxiliaryOutput)
14.TimerSetting
5minON
15minOFF
5minON
15minOFF
Pulsecycleoutput:
ON:5min
OFF:15min
15.Installation
!

SUNWARDENG SUN-15T(IC,Pt,K)Controller (UserManual) Page4/4
3
-ﺖﺋاﺮﻗ
ﺢ
ﻴﺤﺼﺗ ورﻮﺴﻨﺳ ﺐﺼﻧ

ﻴﻐﺗﺪﻴﻠﻛ ﺎﺑ ﺮﺘﻣارﺎﭘ ﻦﻳا ﺮﻴ
Up
ﺎﻳ
Dn
دﺮﻴﮕﻴﻣ مﺎﺠﻧا.تاﺮﻴﻴﻐﺗ هدوﺪﺤﻣرﻮﺴﻨﺳ ياﺮﺑ
IC,PT100
رد
هدوﺪﺤﻣ
0.1~19.9
o
C
رﻮﺴﻨﺳ ياﺮﺑ و
K Type
،
1~50
o
C
دﻮﺑ ﺪﻫاﻮﺧ.ﺪﻴﻠﻛ ﺎﺑ
SET
ﺪﻧﺎﺳﺮﻴﻣ يرﺎﺟ ﻪﺤﻔﺻ ﻪﺑ ار ﺎﻤﺷ ﺪﻴﻠﻛ ﻦﻳا ﺪﺘﻤﻣ رﺎﺸﻓ وﺪﻴﻳﺎﻤﻧ هﺮﻴﺧذ اﺮﻧآ.
ﺘﻟﺎﺣ ردﻪﻛ ﻲتراﺮﺣﺪﻴﻠﻛ ،ﺖﺳا ﻪﺤﻔﺻ يور يرﺎﺟ
SET
زا ﺶﻴﺑ ياﺮﺑ ار 5 ﺪﻳرﺎﺸﻔﺑ ﻪﻴﻧﺎﺛ.
دﺎﻤﻧ ﻪﻛ ﻲﻧﺎﻣز
diF
ﺪﻴﻨﻛ ﺎﻫر ار ﺪﻴﻠﻛ ،ﺪﺷ ﺖﻳور.ﺪﻴﻠﻛ رﺎﺸﻓ رﺎﺑ ﺪﻨﭼ ﺎﺑ
SET
ﺶﻳﺎﻤﻧ ﺎﺑ نﺎﻣﺰﻤﻫ
دﺎﻤﻧ
dLt
ﺸﻓ ﺎﺑ ﻪﻴﻧﺎﺛ ﺐﺴﺣﺮﺑ ار ﺮﻈﻧ درﻮﻣ ﺮﻤﻳﺎﺗ دﺪﻋ ﺪﻴﻧاﻮﺗ ﻲﻣﺪﻴﻠﻛ رﺎ
Up
ﺎﻳ
Dn
بﺎﺨﺘﻧا
ﺪﻴﻨﻛ.رﺎﺸﻓ ﺎﺑ 5 ﺪﻴﻠﻛ يا ﻪﻴﻧﺎﺛ
SET
زﺎﺑ يرﺎﺟ ﻪﺤﻔﺻ ﻪﺑ وددﺮﮕﻴﻣ هﺮﻴﺧذ ﻪﻈﻓﺎﺣ رد ﻢﻗر ﻦﻳا
ددﺮﮕﻴﻣ.لﺮﺘﻨﻛ ﻪﻟر دﺪﺠﻣ ﻞﺻو ياﺮﺑ هﺎﮕﺘﺳد ﻲﻟﺮﺘﻨﻛ رﺎﻛ ﻦﻴﺣتراﺮﺣددﺮﮕﻴﻣ اﺮﺟا طﺮﺷ ود.لوا
نﺪﻴﺳرﺖﺑﻮﻃرنﺎﻣز ﻦﻴﻤﻫ نﺪﺷ ﻲﻃ مود وﺮﻈﻧ درﻮﻣ ﺪﺣ ﻪﺑ
dLt
) 240  0 (
ﺖﻟﺎﺣ ردﺪﻴﻠﻛ شﻮﻣﺎﺧ
SET
ﺑاردﺎﻤﻧ نﺪﻳد ﺎﺗ ار ﺪﻴﻠﻛ وﺪﻴﻳﺎﻤﻧ ﻦﺷور ار هﺎﮕﺘﺳد وﺪﻳرﺎﺸﻔ
STH
ﺪﻳراد ﻪﮕﻧ.ﺪﻴﻨﻛ ﺎﻫر ار ﺪﻴﻠﻛ.ﺪﻴﻠﻛ رﺎﺸﻓ رﺎﺑ ﺪﻨﭼ ﺎﺑ
SET
دﺎﻤﻧ ﻪﺑ
TyP
ﻦﻴﻴﻌﺗ ياﺮﺑ ﻪﻛ، ﻢﻴﺳر ﻲﻣ
ﻪﻟر ﻲﻟﺮﺘﻨﻛ دﺮﻛرﺎﻛ عﻮﻧمودﺖﺳا.ﻞﻤﻋ ﺮﮔاﻲﻫد تراﺮﺣزا ارمود ﻪﻟرﻢﻴﻫاﻮﺨﺑار ﺮﺘﻣارﺎﭘ ﻦﻳا
يور
H
ﻢﻴﻨﻜﻴﻣ ﻢﻴﻈﻨﺗ.ﻞﻤﻋ ﺮﮔاتدوﺮﺑﺶﻫﺎﻛ ﺎﻳتراﺮﺣمود ﻪﻟر ياﺮﺑﺪﺷﺎﺑ ﺮﻈﻧ ﺪﻣﻦﻳا ،
يور ار ﺮﺘﻣارﺎﭘ
C
ﺪﻴﻳﺎﻤﻧ ﻢﻴﻈﻨﺗ.يور ﺮﮔا
t
،ﺪﺷﺎﺑددﺮﮕﻴﻣ ﺮﻈﻧ ﺪﻣ يﺮﻤﻳﺎﺗ ﺖﻟﺎﺣ..)ﻪﻘﻴﻗد رﺎﻴﻌﻣ(
يﺮﻤﻳﺎﺗدﺮﻛرﺎﻛ ﺮﻤﻳﺎﺗ
on
ﺮﻴﺧﺎﺗ ﺮﻤﻳﺎﺗ و
Off
t
tYP

ﺖﻟﺎﺣ ﻢﻴﻈﻨﺗ
ﻲﻣرﻻآ
ﺎﭘﻢﻴﻈﻨﺗ زا ﺎﻣد ﻦﺘﻓر ﺮﺗ ﻦﻴﻳ=ﻦﺷور ﻪﻟر
H
ﻢﻴﻈﻨﺗ زا ﺎﻣد ﻦﺘﻓر ﺮﺗﻻﺎﺑ=ﻦﺷور ﻪﻟر يوﺎﺴﻣ
C
ﺪﻴﻠﻛ ﺎﺑ ﺪﻳﺎﺑ ﻢﻴﻈﻨﺗ ﻦﻳا ﺮﻴﻴﻐﺗ ياﺮﺑ
Up
ﺎﻳ
Dn
ﺮﻈﻧ درﻮﻣ دﺎﻤﻧ
H
ﺎﻳ
C
ﺎﻳ
t
وﺪﻴﻳﺎﻤﻧ ﻢﻴﻈﻨﺗ ار
ﺪﻴﻠﻛ هﺎﮕﺘﺳد ﻪﻈﻓﺎﺣ رد هﺮﻴﺧذ ياﺮﺑ
SET
ﺪﻳرﺎﺸﻔﺑ ار.
ﻪﻟرمودزا ﺮﺗ ﻦﻴﻳﺎﭘ 100 ﺟردددﺮﮕﻴﻣ ﻦﺷور ﻪ
Pro=100 tyP=H
ﻪﻟرمودزا ﺮﺗﻻﺎﺑ 100 ددﺮﮕﻴﻣ ﻦﺷور ﻪﺟرد
Pro=100 tyP=C
ﻪﻟر ندﻮﺑ شﻮﻣﺎﺧ نﺎﻣز
Off=100
ﻪﻟر ندﻮﺑ ﻦﺷور نﺎﻣز
On=100
typ=t
ﻢﻴﻈﻨﺗ هدوﺪﺤﻣ ندﺮﻛدوﺪﺤﻣ ﻦﻴﻨﭽﻤﻫ وزﺎﺠﻣ ﺮﻴﻏ داﺮﻓا يرﺎﻜﺘﺳد زا يﺮﻴﮔﻮﻠﺟ ياﺮﺑ
SET
رد ،
ﺪﻴﻠﻛ ﻪﻛ ﻲﺘﻟﺎﺣ
SET
ﺎﺸﻓﺪﻴﻳﺎﻤﻧ ﻦﺷور ار ﻢﺘﺴﻴﺳ ،ﺪﻳا هداد ر.دﺎﻤﻧ ﻪﻛ ﻲﻧﺎﻣز
StH
ﺪﻳﺪﻳد ار
ﺪﻴﻨﻛ ﺎﻫر ار ﺪﻴﻠﻛ.ﺪﻴﻠﻛ رﺎﺸﻓ رﺎﺑ ﺪﻨﭼ ﺎﺑ
SET
دﺎﻤﻧ ﻪﺑ
LoC
ﻢﻴﺳﺮﻴﻣ.يﺎﻫ ﺪﻴﻠﻛ زا ﻲﻜﻳ ﺎﺑ
Up
ﺎﻳ
Dn
ﺪﻴﻳﺎﻤﻧ ﻢﻴﻈﻨﺗ ﺮﻳز ﺐﻴﺗﺮﺘﺑ اﺮﻧآ.
ﺖﺳا زﺎﺑ ﺮﻟﺮﺘﻨﻛ تﺎﻤﻴﻈﻨﺗ
0
Loc
ﺖﺳا ﻞﻔﻗ ﺮﻟﺮﺘﻨﻛ يﺎﻬﻤﻴﻈﻨﺗ ﻪﻴﻠ
ﻛ
1
ﻪﺘﻜﻧ:ﻪﻤﻛد رﺎﺸﻓ
up
اﺮﺟا ﺖﻟﺎﺣ رد يﺎﻣد ،هﺪﺷ ﻢﻴﻈﻨﺗﺪﻫﺪﻴﻣ ﺶﻳﺎﻤﻧ ار.
- لﺮﺘﻨﻛويﺮﺘﻴﻫﺎﻳزﺎﺳ ﺎﻣﺮﮔ يﺎﻫ ﻪﺳوﺮﭘ ﺖﻬﺟ يﺮﻟﻮﻛزﺎﺳ ﺎﻣﺮﺳ ﺎﻳ
- لﺮﺘﻨﻛ ﻪﻟر ﺖﻴﺳﺎﺴﺣ
0.0
ﺎﺗ
19.9
لﺪﻣ ياﺮﺑ ﻪﺟرد
Pt , IC
و
0~50
لﺪﻣ ياﺮﺑ
TC
- يﺮﻤﻳﺎﺗ ﻪﻟر ﻪﺑ ﺰﻬﺠﻣﺎﺗ ﺮﻔﺻ 999 ﻪﻘﻴﻗد)ﺖﺳاﺮﻔﻳد ﺪﻨﻧﺎﻤﻫ ﺎﻫ دﺮﺑرﺎﻛ عاﻮﻧا ﺖﻬﺟ(
- نﺎﻜﻣاﺮﺜﻛاﺪﺣ وﻞﻗاﺪﺣﻲﻤﻴﻈﻨﺗ يﺎﻣدﺮﺑرﺎﻛ ﻂﺳﻮﺗ
-
ﻏداﺮﻓا يرﺎﻜﺘﺳد زا يﺮﻴﮔﻮﻠﺟ ياﺮﺑ ﻲﻠﺻا تﺎﻤﻴﻈﻨﺗ ﻞﻔﻗ نﺎﻜﻣازﺎﺠﻣ ﺮﻴ
-
-
ﺶﻳﺎﻤﻧ ﺮﻈﺘﻨﻣ وﺪﻴﻨﻛ ﻦﺷور ار هﺎﮕﺘﺳدتراﺮﺣﺪﻳﻮﺷ ﻪﺤﻔﺻ رد يرﺎﺟ.
- ﺪﻴﻠﻛ SET دﻮﺷ نز ﻚﻤﺸﭼ ﺪﻳﺎﺑ ﻪﺤﻔﺻ ،ﺪﻳرﺎﺸﻔﺑ رﺎﺑ ﻚﻳ ار.
-
يﺎﻫ ﺪﻴﻠﻛ ﺎﺑ
UP
ﺎﻳ
Dn
ﺪﻴﻳﺎﻤﻧ ﻢﻴﻈﻨﺗ ار ﺪﻳﺪﺟ ﺖﻨﻳﻮﭘ ﺖﺳ ﺪﻴﻧاﻮﺘﻴﻣ.ﺪﺘﻤﻣ رﺎﺸﻓ ترﻮﺻ رد
زا ﺶﻴﺑ قﻮﻓ يﺎﻫﺪﻴﻠﻛ زا ﻚﻳ ﺮﻫ 3 ﺶﻫﺎﻛ ﺎﻳ وﺶﻳاﺰﻓا ،ﻪﻴﻧﺎﺛﻪﺤﻔﺻ يور داﺪﻋا
دوﺪﺤﻣ ﺖﻳﺎﻬﻧ رد وﺪﺘﻓا ﻲﻣ قﺎﻔﺗا ﺮﺘﻌﻳﺮﺳ ﻪﺑ يﺎﻬﻤﻴﻈﻨﺗ رد ﻪﻛ ﻲﻣﺎﻗرا StL

و StH
ﺪﺷ ﺪﻫاﻮﺧ ،هﺪﻣآ.
- ﺪﻴﻠﻛ رﺎﺸﻓ ﺎﺑ SET ﺶﻳﺎﻤﻧ ار يرﺎﺟ يﺎﻣد ﺶﻳﺎﻤﻧ ﻪﺤﻔﺻ وددﺮﮕﻴﻣ هﺮﻴﺧذ ﻪﻈﻓﺎﺣ رد دﺪﻋ
ﺪﻫﺪﻴﻣ.دﻮﺧ دﺮﻛرﺎﻛ عﻮﻧ زا ﻢﻴﻈﻨﺗ زا ﻞﺒﻗ)ﻦﻛ دﺮﺳ ﺎﻳ وﻦﻛ مﺮﮔ ﻖﻄﻨﻣ(ﻮﺷ ﻦﺌﻤﻄﻣﺪﻳ.
- ﻲﻠﺻا ﻪﻟر يﺎﻫ لﺎﻨﻴﻣﺮﺗ هرﺎﻤﺷ 10 و 9 و 8 ﺖﺳا.
- ﺐﺼﻧ ياﺮﺑرﻮﺴﻨﺳ يﺎﻬﻤﺘﺴﻴﺳ رد ﺮﻳز ﻞﻜﺷ ﻪﺑ ﻪﺟﻮﺗ ﺎﺑ رﻮﺴﻨﺳ
IC
ﻪﺑ ﺰﻣﺮﻗ ﻢﻴﺳ
لﺎﻨﻴﻣﺮﺗ 1 لﺎﻨﻴﻣﺮﺗ ﻪﺑ ﻲﻜﺸﻣ ، 2 لﺎﻨﻴﻣﺮﺗ ﻪﺑ ﺪﻴﻔﺳ و 3 ددﺮﮕﻴﻣ ﻞﺼﺘﻣ.ﻪﻛ ﺪﻴﻨﻛ ﻪﺟﻮﺗ
ﺶﻳﺎﻤﻧ ﺎﻬﻤﻴﺳ ﻂﻠﻏ لﺎﺼﺗا
Err
ﻪﺑ ارﺎﺴﺧ ﺖﺳا ﻦﻜﻤﻣ ﺎﻳ دراد لﺎﺒﻧدﺪﻳﺎﻤﻧ دراو ﻲﺗار.
- ﺪﻴﻨﻛ ﻪﺟﻮﺗرﻮﺴﻨﺳ لﻮﻃلﺪﻣ
IC
ﺮﺜﻛاﺪﺣ 30 ﺪﻴﻳﺎﻤﻧ هدﺎﻔﺘﺳا ﺪﻠﻴﺷ ﻢﻴﺳ زا ﺎﻤﺘﺣ وﺮﺘﻣ.
رﻮﺴﻨﺳ ﺖﺋاﺮﻗ ﺢﻴﺤﺼﺗ ﺖﺳا ﺮﺴﻴﻣ ﺮﻳز شور ﻪﺑ نآ ﻲﻟﺎﻤﺘﺣا يﺎﻄﺧ ﺎﻳ.ﻪﻛ ﻲﻟﺎﺣ رد
راﺮﺣﺪﻴﻠﻛ، ﻢﻳراد ﺶﻳﺎﻤﻧ ﻪﺤﻔﺻ يور ار يرﺎﺟ ت
Set
ار 5 ﺪﻳرﺎﺸﻔﺑ ﻪﻴﻧﺎﺛ.زا ﺪﻌﺑﺶﻳﺎﻤﻧ
diF
،ﺪﻨﭼﺪﻴﻠﻛ رﺎﺑ
SET
ﺶﻳﺎﻤﻧ ﺎﺗ ﺪﻳرﺎﺸﻔﺑ ار
rSt
.ﺪﻴﻠﻛ ﻂﺳﻮﺗ ﻻﺎﺣ
Up
ﺎﻳ
Dn
ﻲﻣ
ﺪﻴﻨﻛ ﻢﻴﻈﻨﺗ ﻲﺸﻳﺎﻤﻧ دﺪﻋ زا ندﻮﻤﻧ ﺮﺴﻛ ﺎﻳ وندﺮﻛ ﻪﻓﺎﺿا ياﺮﺑ ار ﺮﻈﻧ درﻮﻣ دﺪﻋ ﺪﻴﻧاﻮﺗ.
رﺎﺸﻓ ﺎﺑ 5 ﺪﻴﻠﻛ يا ﻪﻴﻧﺎﺛ
SET
دﻮﺸﻴﻣ هﺮﻴﺧذ ﻪﻈﻓﺎﺣ رد دﺪﻋ.ﺪﻴﻳﺎﻤﻧ ﻪﺟﻮﺗ ﺮﻳز لﺎﺜﻣ ﻪﺑ:
ﻢﻴﻈﻨﺗ ياﺮﺑ ﺮﻟﺮﺘﻨﻛﺮﺣ،تراﺪﻨﻛ ﻲﻣ ﻞﺻو وﻊﻄﻗ ار لوا ﻪﻟر.ﻞﺻو ﺎﻳ وﻊﻄﻗ ﻪﻠﺻﺎﻓ ناﻮﺘﻴﻣاردﺪﻋ ﺎﺑ
دﻮﻤﻧ ﻦﻴﻴﻌﺗ ﺖﻨﻳﻮﭘ ﺖﺳ.ﻪﻠﺻﺎﻓ ﻦﻳاراﺮﺣﺮﺘﻣارﺎﭘ نﺎﻤﻫ ﻲﺗ
diF
ﺖﺳا.ﺪﻴﻠﻛ نآ ياﺮﺑ 
SET
ار زا ﺶﻴﺑ
5 ﺪﻳرﺎﺸﻔﺑ ﻪﻴﻧﺎﺛ دﺎﻤﻧ ﺖﻳور ﺎﺗ و diF ﺪﻳراد ﻪﮕﻧ.
OutputRange SensorTypeModel
MainandAux
OutputRelay5A
-50~125oC T ( IC)
SUN-15 -200~400oC PT (PT100)
-200~1300oC TC( K-TYPE,CA)
  
SUNWARD
1 -
ﻗ
ﻲ
ﻠﻛ يﺎﻬﺘﻴﻠﺑﺎ
2
-ﻲﺟوﺮﺧ دﺮﻜﻠﻤﻋ ﻢﻴﻈﻨﺗ
   
rSt   
20.0
oC +-5.0 oC = 15.0 oC
20.0 oC +
10.0
oC = 30.0 oC
4
لوا ﻪﻟر ﻞﺻوو
ﻊ
ﻄﻗ ﺖﻴﺳﺎﺴﺣ)ﺲﻳزﺮﺘﺴﻴﻫ(
5
-
ﻲ
ﻠﺻا ﻪﻟ
ر
د
ﺮ
ﻜﻠﻤﻋ
يﺮﻴ
ﺧﺎﺗ
ﺮ
ﻤ
ﻳ
ﺎﺗ
dLt
6
-يﺮﻤﻳﺎﺗ ﺎﻳ ﻲﻳﺎﻣد مرﻻآ ناﻮﻨﻌﺑ مود ﻪﻟر ﻢﻴﻈﻨﺗ
dIF=1 dIF=2
tYP=CtYP=H
ﺘﻴﻌﺿوﺖﻟﺎﺣرد ﻪﻛ ﻲهدﺎﻔﺘﺳا ﻦﻛ دﺮﺳ
ددﺮﮕﻴﻣ.زا ﺮﺗﻻﺎﺑ ﻪﻛ ﺎﻣد
Set
ﻪﻟر دوﺮﻴﻣ
ﻪﻠﺻﺎﻓ ﺖﻳﺎﻋر ﺎﺑ لوا
dIF
ددﺮﮕﻴﻣ ﻦﺷور
يور ﺖﺸﮔﺮﺑ رد و
Set
شﻮﻣﺎﺧ ﻪﻟر
ددﺮﮕ
ﻴ
ﻣ.
دﺮﺑرﺎﻛ ﻦﻛ مﺮﮔ لﺮﺘﻨﻛ ياﺮﺑ ﻪﻛ ﻲﺘﻟﺎﺣ
دراد.وﺎﻣد ﺶﻳاﺰﻓا ﺪﻧور رد لوا ﻪﻟر
زا رﺬﮔ
Set
ددﺮﮕﻴﻣ شﻮﻣﺎﺧ.ﺎﻣد ﻲﺘﻗو
ﻲﻳﺎﻣد ﻪﻠﺻﺎﻓ ﺖﻳﺎﻋر ﺎﺑ ،ﺪﻣآ ﻦﻴﻳﺎﭘ
dIF
ددﺮﮕ
ﻴ
ﻣﻦﺷور ﻪﻟر ﻦ
ﻳ
اهرﺎ
ﺑ
ود.
 
5A 110~220
VA C
50~60Hz
 
5A
123456 7 8 910 11 12
PT100
K-Type
=
IC  

+-
51
52
53
Set50
49
OFF
ON
49
Set50
51
48
47
OFF
ON
5
1
5
2
53
Set

50
49
OFF
ON
49
Set50
51
48
47
OFF
ON
7
ﻲﻨﻤﻳا وﺖﻇﺎﻔﺣ
LoC
