Superfly SUPERX8 User manual

Trampolines
User Manual

[SUPERX8] Superfly X Trampoline 8ft
[SUPERX10] Superfly X Trampoline 10ft
[SUPERX12] Superfly X Trampoline 12ft
[SUPERX14] Superfly X Trampoline 14ft
[SUPERX15] Superfly X Trampoline 15ft
This manual covers the assembly, maintenance
and recommended use of the following Superfly X models.
Contact our exclusive New Zealand retailer Trade Tested
0800 800 880
[email protected]
www.tradetested.co.nz
Trampolines
For Assistance

1
Contents
1
Contents
Warranty 3
Safety and Usage 4
Trampoline Location 5
Trampoline Parts List 6
Trampoline Assembly 7
Accessory Assembly 11
Trampoline Maintenance 13
Contents 1

2

3
Superfly X
Limited Trampoline Warranty
Warranty Coverage
Trade Tested Ltd and it’s authorised service partners warrant it’s products to be free of defects in material
and workmanship under normal domestic recreational use and service conditions. The various component
parts of the trampoline are warranted against failure and defects in the workmanship as follows:
The warranty in respect of the mat and the enclosure net does not cover normal wear and tear (e.g.
stitching wear due to use), burns, cuts or snags. The warranty on the frame does not cover surface rust.
Warranty claims resulting from manufacturing defects e.g. cuts in mats, broken D-rings, tears in net,
missing parts etc must be reported within 60 days of the product being purchased.
TRADE TESTED LTD, IS NOT RESPONSIBLE OR LIABLE FOR INDIRECT, SPECIAL OR CONSEQUENTIAL
DAMAGES ARISING OUT OF OR IN CONNECTION WITH THE USE OR THE PERFORMANCE OF THE PRODUCT
OR ANY OTHER DAMAGES WITH RESPECT TO ANY ECONOMIC LOSS, LOSS OF PROPERTY, LOSS OF
REVENUE OR PROFITS, LOSS OF ENJOYMENT OR USE, COST OF REMOVAL, INSTALLATION/DISASSEMBLY
OR OTHER CONSEQUENTIAL DAMAGES. SOME STATES/TERRITORIES DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES. ACCORDINGLY THE ABOVE LIMITATIONS
MAY NOT APPLY TO YOU.
THE WARRANTY EXTENDED HEREUNDER IS IN LIEU OF ALL OTHER WARRANTIES AND ANY IMPLIED
WARRANTY OF MERCHANTABILITY, OR FITNESS FOR A PARTICULAR PURPOSE IS LIMITED IN ITS SCOPE
AND DURATION TO THE TERMS SET FORTH HEREIN. SOME STATES/TERRITORIES DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS. ACCORDINGLY THE ABOVE LIMITATIONS
MAY NOT APPLY TO YOU. THIS WARRANTY IS NOT TRANSFERABLE.
Warranty
Trampoline
FRAME: 10 YEAR WARRANTY
JUMP MAT & SPRINGS: 5 YEARS WARRANTY
SAFETY PAD & SAFETY NET: 3 YEAR WARRANTY
SUPERFLY ACCESSORY RANGE: 1 YEAR WARRANTY

4
Specific Use Limitations
Do not use trampoline without mature and knowledgable supervision.
Do not allow more than one person on the trampoline at any time.
Do not use the trampoline if it’s raining.
Do not jump onto or o of the trampoline.
Do not use a trampoline while under the influence of drugs or alcohol.
Do not allow any activity underneath the trampoline.
The trampoline must not be used in gusty or severe winds and only when
wind or air movement is calm and gentle.
Safety Instructions
Read all instructions before using the trampoline.
Allow only one person on the trampoline at any time. Use by more than one person at the same time can
result in serious injury.
Use the trampoline only with mature adult supervision at all times.
Inspect the trampoline before each use. Make sure the frame padding is correctly and securely
positioned. Replace any worn, defective, or missing parts.
Keep objects away that could interfere with the user. Maintain a clear area around, above, and under the
trampoline.
Misuse and abuse of the trampoline is dangerous and can cause serious injuries.
Climb on and o the trampoline - do not jump. Jumping from the trampoline to the ground is dangerous.
Similarly, do not run and leap onto the trampoline.
Never use springs or extension elements as ‘hand grips’.
Do not use the trampoline as a springboard to other objects. Use the trampoline only for trampoline style
bouncing.
Your clothing should allow plenty of freedom of movement, but loose clothing is discouraged.
No buckles or jewellery should be worn, as these could damage the trampoline mat and cause injury to
the jumpers.
Avoid bringing any miscellaneous items onto the trampoline.
Trampoline safety net must always be fitted to trampoline to promote safer use of the trampoline.
Trade Tested Ltd does not condone pets to be on the trampoline at any time, as sharp claws may also
cause damage to the safety netting, jumping mat, or safety padding of the trampoline.
Safety & Usage
Trampoline
1.
2.
3.
4.
5.
6.
7.
1.
2.
3.
4.
5.
6.
7.
9.
10.
11.
12.
13.
14.
8.

5
Trampoline location is vital to the safety of the jumpers
here are our safety recommendations.
Make sure you have 8m from the ground of overhead space clear of trees,
powerlines or other obstacles.
1m
8m
1m
Location
Trampoline
Always have 1m of clear space on all sides of your trampoline and ensure that your
ground anchors are securely in the ground to prevent movement.
Keep the trampoline on a level surface.
Do not keep in an exposed area during gusty or severe winds, always move
into covered areas during storms or dismantle legs and safety net.

6
1
4
3
5
6
7
8
11
10
912
13 14
2
Trampoline Parts List
Part No. Part Name 8ft
1
2
3
4
5
6
7
8
9
10
11
10ft 12ft 14ft 15 ft
Safety Pad 11111
Jump Mat 11111
Safety Net 11111
Top Rail 6 8 10 12 12
Feet 3 4 5 6 6
Lower Net Pole 6 8 10 12 12
Upper Net Pole 6 8 10 12 12
Leg 6 8 10 12 12
Nuts & Bolts 12 16 20 24 24
Net Pole Spacer 12 16 20 24 24
Spring Pull Tool 11111
12 Spring 48 64 80 84 96
13 Net Pole Screw 6 8 10 12 12
14 Bungee Cable 12 16 20 24 24
15 Ground Stake 3 4 4 4 4
15

7
2 ADULTS
4
5
8
Slot together all Top Rails into pairs
and arrange together as shown.
Congratulations on your Superfly purchase!
Please follow these assembly instructions carefully
and you’ll be up and bouncing in no time!
1HR 30MIN 2 ADULTS
8ft = 3 pairs (6 Top Rails)
10ft = 4 pairs (8 Top Rails)
12ft = 5pairs (10Top Rails)
14ft = 6pairs (12 Top Rails)
15ft = 6pairs (12 Top Rails)
Trampoline Assembly
1Join top rails
8ft = 3 feet rails
10ft = 4 feet rails
12ft = 5 feet rails
14ft = 6 feet rails
15ft = 6 feet rails
2
3
i
i
i
Join legs to feet
Attach all W bend shaped feet to the
trampoline legs . Push down the safety lock
button on the foot when inserting leg over foot, it
will pop back out when the leg is inserted correctly.
Slide both of the legs into the top rail
simultaneously for smoother assembly.
Join legs to top rail
Insert assembled legs into your top rail pairs.
Make sure the safety lock is facing outwards.
It will pop through once inserted correctly.
4
5
8

8
Safety Net Seam
Top Rail Join
With 2 people, connect up all the top rails
until the base of your trampoline is all
connected as shown in step 6.
The trampoline base will only become
secured once the springs and mat have
been attached.
5Join assembled top rails
i
DO NOT PULL BY HAND
This can result in injury
6Attach jump mat
and net to base
Attach the short hook of 2 springs
through the D-rings either side of the net
seam. Then with the spring pull tool
provided attach the long hooks of these
springs to either side of a top rail join as
shown.
Spread out the jump mat on a flat
surface and then place the safety net
on top. Go around the net inserting
the mats D-rings through the underside
of the safety net.
After you have done this drag the
mat to your desired final location
for the trampoline.
4Attach safety net
to jump mat
i
2
3
11
12
!
