D-5382-A M3618/1100
OM-40-C-HT
Temperature
Sensors for
OM-40 Series
Data loggers
www.omega.com
e-mail: [email protected]
Shop online at
Temperature sensor enclosed:
❏Cable part number: OM-40-C-HT (6 ft.)
Range: -40°F to +212°F (-40°C to +100°C)
Accuracy: ±0.9°F at +70°F (±0.5°C at +20°C)
(insert probe 0.9" min.)
Resolution: ±0.7°F at +70°F (±0.41°C at +20°C)
Response time in air: 4.5 min. typical
Response time in stirred water: 1 min. typical
Note: Not recommended for prolonged use in water; use
in soil or rain is fine.
Logger Software is recommended for use with OM-40-C-
HT temperature sensors.
