SuperLightingLED S1-B+R11 User manual

Operation temperature
Environment
Ta: -30
O
C ~ +55
O
C
Technical Parameters
Safety and EMC
EMC standard (EMC) ETSI EN 301 489-1 V2.2.3
ETSI EN 301 489-17 V3.2.4
Radio Equipment(RED) ETSI EN 300 328 V2.2.2
Certication CE,EMC,LVD,RED
EN 62368-1:2020+A11:2020
Safety standard(LVD)
1
User Manual Ver 1.0.0
Features
Model No.: S1-B+R11
AC Triac RF + Push Dimmer Kit
RF dimming/Leading edge or trailing edge/Min brightness settable/Push Dim/Wall junction box mounting
● RF + Push AC phase-cut dimmer, 1 channel output.
● To dim and switch single color dimmable LED lamps,
traditional incandescent and halogen lights.
● Leading edge dimming or trailing edge dimming set by dip switch.
● Min brightness can be set by key.
● Light on/off fade time 3s selectable.
● Connect with external push switch to achieve on/off and dimming function.
● Easy to be inserted into standard 86*86mm wall box. LVD
Output current Max 1.5A
Input voltage AC100-240V
Output voltage AC100-240V
Triac Dimmer’s Input and Output
Output power 150-360W
Dimming range
RF 2.4GHz + Push Dim
30m(Barrier-free space)
256 levels
0-100%
Dimming signal
RF Control distance
Dimming level
Working current ＜5mA
Output signal RF(2.4GHz)
Working voltage 3VDC(CR2032)
Standby time
LED Remote’s Input and Output
Standby current ＜10μA
＜1 years
Mechanical Structures and Installations
AC L input
AC N input
AC N output
AC L output
DIP switch for Leading edge
or trailing edge phase-cut select
Match / Min brightness set key
OUTPU T IN P U T
L N L N
ON
Mat ch
Min s et
A2 A1
Pus h
Swi tch
100-240
VAC
ACPushswitch
52.00 mm
52.00 mm
26.00 mm Typical Wall Junction Box Mounting
36.00 mm
139.00 mm
11.00 mm
Back holder with magnet
Remote function
Bright touch slide
On/Off
LED indicator
1%
100%
50%
Compatible Load Types
Load Type Maximum Load Remarks
Due to variety of LED lamp designs, maximum number of LED lamps
is further dependent on power factor result when connected to dimmer.
Maximum permitted number of drivers is 200W divided by driver nameplate
power rating, and make sure the surge current is no more than 2 times 65A.
Dimmable LED lamps
Triac Dimmable
LED drivers
Incandescent lighting,
HV Halogen lamps
200W @ 220V
100W @ 110V
400W @ 220V
200W @ 110V
200W @ 220V
100W @ 110V

2
User Manual Ver 1.0.0
Wiring diagram
Caution: Please carefully ensure all wire connections and polarities are correct and secure before applying power, otherwise this dimmer will be damaged.
LED light
Triac Dimmable
LED Driver
Push Switch Push Switch
A2
S1-B
OUTPUT IN P UT
L N L N
A1
Pu sh
Sw it ch
ON
100-240
VAC
Ma tc h
Mi n se t
Push Switch Push Switch
Dimmable LED light
A2
S1-B
OUTPUTI NP UT
LNL N
A1
Pu sh Sw it ch
ON
100-240
VAC
Ma tc h
Mi n se t
Connect with Triac dimmable LED driver
Connect with dimmable LED light
Note: When calculating the maximum number of load lamps or drivers, the input power or input current parameters of a single lamp or driver must be used,
the output power parameters can not be used.
In addition, the maximum surge current of the dimmer is 65A, the sum of surge current of multiple dimmable LED drivers should not exceed 2 times. otherwise,
the product will be overloaded and damaged.
Leading edge or trailing edge dimming setting
Reverse-phase
Forward-phase
Select leading edge(forward-phase) dimmer or trailing edge(reverse-phase) dimmer according to dimmable LED light or driver.
Caution: before power on, you must confirm the selection of dip switch.
O N
Long press Min set key for 2s, the light blink 2 times, ready for min brightness set, then short press Min set key 1-6 times,
to get 6 min brightness: 5%, 10%, 15%, 20%, 25% or 30%, the light will output the current min brightness immediately,
Long press Min set key for 2s or wait 8s, quit min brightness set, the light will output 100% brightness automatically.
Min brightness setting
Long press Match key 5s, then short press Match key 3 times, the light on/off time will be set to 3s, the indicator light blink 3 times.
Light on/off fade time
Long press Match key 10s, restore factory default parameter, the light on/off time also restore to 0.5s.
Match Remote Control (two match ways)
Use the controller’s Match key
Match:
Short press Match key, immediately press on/off key of the remote.
Use Power Restart
Match:
Switch off the power, then switch on power, repeat again.
Immediately short press on/off key 3 times on the remote.
The light blinks 3 times means match is successful.
Delete:
Switch off the power, then switch on power, repeat again.
Immediately short press on/off key 5 times on the remote.
The light blinks 5 times means all matched remotes were deleted.
Delete:
Press and hold Match key for 5s to delete all match,
The light blinks 5 times means all matched remotes were deleted.
End user can choose the suitable match/delete ways. Two options are offered for selection:
