Leviton Decora True Touch TTM10-1 User manual

Single Pole (One location) or 3-Way (Multi-location)
Magnetic Low-Voltage Dimmer
Cat. No. TTM1 Ø -1
1000VA-120VAC, 60Hz
For use w/ Cat. No.TT ØØ R-1 True TouchTM Remote in Multi-Location Applications
INSTALLATION INSTRUCTIONS
WARNINGS AND CAUTIONS:
• To be installed and/or used in accordance with appropriate electrical codes and regulations.
• If you are unsure about any part of these instructions, consult a qualified electrician.
• To avoid overheating and possible damage to this device and other equipment, do not install to
control a receptacle, fluorescent lighting, a motor- or a transformer-operated appliance.
• Use with magnetic low-voltage transformers, incandescent, or 120V halogen fixtures only. Use a Leviton
electronic low-voltage dimmer to control electronic (solid state) low-voltage transformers.
• Total minimum load must exceed 40W or 40VA.
WARNINGS AND CAUTIONS:
• When a magnetic low-voltage circuit is operated at a dim level, with all lamps inoperative, excess current
may flow through the transformer. To avoid possible transformer failure due to overcurrent, use a
transformer that incorporates thermal protection or a fuse at the primary windings.
• Use only one (1) dimmer per load. For remote operation, use Leviton Remote, Cat. No. TT ØØ R-1.
Do not use a 3-way switch.
• Disconnect power at circuit breaker or fuse when servicing fixture.
• Use this device only with copper or copper clad wire. With aluminum wire use only devices marked
CO/ALR or CU/AL.
Tools needed to install your Dimmer:
Slotted/Phillips Screwdriver Electrical Tape
Pliers Pencil
Cutters Ruler
Changing the color of your Dimmer:
Your Dimmer includes two color options. The Dimmer ships with the
White frame attached. To change color of frame, proceed as follows:
When installing more than one dimmer in the same location, the side
sections of the mounting strap must be removed. Use pliers to carefully
bend side sections back and forth until they break off. The side sections
dissipate heat, so removing them requires a derating of the dimmer’s
capacity (refer to chart).
Installing Dimmer by itself or with other devices:
If installing Dimmer in a single device application, proceed with the
INSTALLING YOUR DIMMER section. If installing Dimmer in a multi-
device application, proceed as follows:
MULTI-DEVICE APPLICATION:
NOTE: You only need to remove side sections if installing with other
dimmers or if it does not fit in wall box – not when installing with
mechanical switches.
Single-Pole:
Look at the back of your switch.
If there are 2 wires connected
to two screw terminals (not
including a green or bare copper
wire used for grounding), you
have a Single-Pole switch.
3-Way:
Look at the back of your switch.
If there are 3 wires connected
to three screw terminals (not
including a green or bare copper
wire used for grounding), you
have a 3-Way switch. DO NOT
add a single-pole switch in this
location.
INSTALLING YOUR DIMMER
NOTE: Use check boxes when Steps are completed.
WARNING: To avoid fire, shock, or death; TURN OFF
POWER at circuit breaker or fuse and test that power is off
before wiring!
Step 1
Bend back and
forth to remove
side section
MAXIMUM LOAD PER DIMMER FOR MULTI-DEVICE
More than
2 Devices
Two DevicesSingleCat. No.
700VA800VATTM1
Ø -1 1000VA
/./&&
/./&&
/./&&
/./&&
/./&&
/./&&
/./&&/./&&
/./&&
/./&&
/./&&
/./&&
DI-000-TTM10-00A
Step 3
con’t
Tag Common Screw Wire
(screw is usually black and/or
marked "common")
Remove all
inner side
sections
Do not
remove
outer
side
sections
Removing existing switch: Remove existing
wallplate and switch mounting screws. Carefully pull switch
from wall box. DO NOT remove wires attached to the switch
at this time.
Identifying your wiring application (most common):
NOTE: If the wiring in the wall box does not resemble any of
these configurations, consult a qualified electrician.
Step 2
Step 3
Disconnecting switch wires and preparing wires:
• Disconnect wires from screw terminals or
Quickwire™ slots (shown).
• Pull off pre-cut insulation from Dimmer leads.
• Make sure that the ends of the wires from the
wall box are straight (cut if necessary).
• Remove 5/8" (1.6 cm) of insulation from each
wire in the wall box (shown).
• For Single-Pole Application, go to Step 5a.
• For 3-Way Application, go to Step 5b.
5/8"
(1.6 cm)
Strip Gage
Press in slot and
pull out wire
Step 4
Cut
(if necessary)
Strip 5/8"
(1.6 cm)
NOTE: Ensure cut-out for Air-Gap Switch is positioned on bottom.
Push in side at tab
to release
Line up tabs and
press in side to attach
Cut-out for Air
Gap Switch
MAXIMUM BULB WATTAGE:
Low-voltage dimmers are rated in Volt-Amps (VA). The maximum bulb
wattage is determined by the efficiency of the transformer in the low-
voltage lighting system. Transformer efficiencies will vary from different
manufacturers; consider 75% efficient as average. Use the chart to
determine maximum bulb wattage for typical transformer efficiency ratings.
MAXIMUM BULB WATTAGE AT 75% EFFICIENCY
More than
2 Devices
Two DevicesSingleRating
525W600W1000VA 750W

Connect wires per WIRING DIAGRAM as follows:
WARNING: Connect a magnetic low-voltage dimmer only to the
primary (high-voltage) side of a magnetic low-voltage transformer.
Screw wire nuts on clockwise making sure no bare conductors show below
the wire connectors. Secure each connector with electrical tape.
• Green dimmer Ground lead to Green or bare copper wire in wall box.
• Black dimmer lead to Line (Hot) wall box wire removed from old switch.
• Blue dimmer lead to remaining wall box wire (Load).
• Cap Yellow dimmer lead with appropriate size wire nut.
• Proceed to Step 6.
LIMITED 5 YEAR WARRANTY AND EXCLUSIONS
Leviton warrants to the original consumer purchaser and not for the benefit of anyone else that this product at the time of its sale by Leviton is free of defects in materials and workmanship under normal and proper use for five years from the purchase
date. Leviton’s only obligation is to correct such defects by repair or replacement, at its option, if within such five year period the product is returned prepaid, with proof of purchase date, and a description of the problem to Leviton Manufacturing Co.,
Inc., Att: Quality Assurance Department, 59-25 Little Neck Parkway, Little Neck, New York 11362-2591. This warranty excludes and there is disclaimed liability for labor for removal of this product or reinstallation. This warranty is void if this product
is installed improperly or in an improper environment, overloaded, misused, opened, abused, or altered in any manner, or is not used under normal operating conditions or not in accordance with any labels or instructions. There are no other or implied
warranties of any kind, including merchantability and fitness for a particular purpose, but if any implied warranty is required by the applicable jurisdiction, the duration of any such implied warranty, including merchantability and fitness for a particular
purpose, is limited to five years. Leviton is not liable for incidental, indirect, special, or consequential damages, including without limitation, damage to, or loss of use of, any equipment, lost sales or profits or delay or failure to perform this
warranty obligation. The remedies provided herein are the exclusive remedies under this warranty, whether based on contract, tort or otherwise. DI-000-TTM10-00A
Hot (Black)
Neutral (White)
Load
True Touch
Dimmer
Blue
Yellow
Green
Ground
Black
White
Black
Line
120VAC, 60Hz
Cap with
Wire Connector (PRIMARY SIDE OF
MAGNETIC LOW-VOLTAGE
TRANSFORMER)
}
Hot (Black)
Neutral (White)
Load
True Touch
Dimmer
Blue
Black
Yellow Yellow
Green
Ground
Green
Ground
Black
White
Black
Line
120VAC, 60Hz
Remote
TT00R-1
//
(PRIMARY SIDE OF
MAGNETIC LOW-VOLTAGE
TRANSFORMER)
}
Connect wires per WIRING DIAGRAM as follows:
WARNING: Connect a magnetic low-voltage dimmer
only to the primary (high-voltage) side of a magnetic low-
voltage transformer. Screw wire nuts on clockwise making
sure no bare conductors show below the wire connectors.
Secure each connector with electrical tape. Screw wire nuts on
clockwise making sure no bare conductors show below the wire
connectors. Secure each connector with electrical tape.
• Green dimmer Ground lead to Green or bare copper wire in
wall box.
• Black dimmer lead to tagged Line (Hot) wall box wire
identified when removing old switch.
• Blue dimmer lead to Load wall box wire.
• Yellow dimmer lead to remaining wall box wire.
Step 5b
con’t
TROUBLESHOOTING
• Lights Flickering
- Lamp has a bad connection.
- Wires not secured firmly with wire connectors.
- Lamp power is less than the 40W or 40VA.
• Light does not turn ON and ON/OFF LED does not turn ON
- Circuit breaker or fuse has tripped.
- Lamp is burned out.
- Lamp Neutral connection is not wired.
- Air gap switch is open.
• Dimmer does not operate
- Dimmer BLACK wire miswired to lamp and Dimmer BLUE wire
miswired to LINE Hot. Reverse BLACK and BLUE wires.
Air Gap
Switch
Indicator
Light
WIRE NUT / # OF COND.
COMBINATION CHART
1- #12 w/ 1 to 3 #14, #16 or #18
2- #12 w/ 1 or 2 #16 or #18
1- #14 w/ 1 to 4 #16 or #18
2- #14 w/ 1 to 3 #16 or #18
Single-Pole Wiring Application:
Step 5a
Insert wires
straight then twist
clockwise
Electrical
Tape
"LUE
9ELLOW
'REEN
"LACK
.EUTRAL
'ROUND
Insert wires
straight then twist
clockwise
"LUE
4AG
9ELLOW
'REEN
"LACK
.EUTRAL
'ROUND Electrical
Tape
3-Way Wiring Application:
Step 5b
• Restore power at circuit breaker
or fuse.
• Ensure that the Air Gap Switch is
pushed in fully.
• Carefully holding Dimmer as
shown, turn Dimmer ON by
pressing touch plate. Lights
should turn ON.
If lights do not turn ON, refer
to the TROUBLESHOOTING
section.
Air Gap Switch
Testing your Dimmer prior to mounting in wall
box:
Step 6
Dimmer Mounting:
TURN OFF POWER AT CIRCUIT BREAKER OR FUSE.
Step 7
Installation may now be
completed by carefully positioning
all wires to provide room in wall
box for dimmer. Mount dimmer
into box with mounting screws
supplied. Attach wallplate.
Restore Power: Restore power at circuit breaker or fuse.
Installation is complete.
Step 8
Air Gap Switch
NOTE: Ensure that the Air Gap Switch
is pushed in fully.
NOTE: The Green indicator light will illuminate when the Load is
OFF to facilitate access in the dark.
NOTE: If using the dimmer in a 3-way application, the lights will
turn ON at brightness set on dimmer’s touch plate. The lighting can
be controlled from either the dimmer or the remote location.
OPERATION
ON: Tap the touch plate of the dimmer. The
lights will fade ON at the brightness level last
used (LED OFF).
OFF: Tap the touch plate of the dimmer. The
lights will fade OFF (LED ON).
BRIGHTEN & DIM: Press and hold the touch
plate of the dimmer to the desired light level.
Each time the touch plate is touched, the
state of the dimmer toggles between BRIGHT
and DIM.
AIR GAP SWITCH: On the lower left corner
of the switch plate, there is an Air Gap
Switch. When servicing light fixture, pull lever
out (OFF position). This will cut the power
to the fixture. After servicing is complete,
push the lever all the way in (ON position) to
restore power.
CLEANING: To clean touch plate, wipe it with
a clean damp cloth using clean water only,
dry thoroughly.
• For technical assistance contact us at 1-800-824-3005
• Visit our website at www.leviton.com
Product Information
For non-standard wiring applications, refer to
Wire Nut and Conductor Size Chart
