Supermicro SC826TQ-R800LPV User manual

SC826 SerieS ChaSSiS
USer’S MaNUaL
Revision 2.0a
SC826BE1C-R920LPB SC826BE1C-R920WB
SC826BE2C-R920LPB SC826BE2C-R920WB
SC826BA-R1K28LPB SC826BA-R1K28WB
SC826BE26-R1K28LPB SC826BE26-R1K28WB
SC826BE16-R1K28LPB SC826BE16-R1K28WB
SC826E26-R1200LPB SC826E26-R1200UB
SC826E16-R1200LPB SC826E16-R1200UB
SC826A-R1200LPB SC826A-R1200UB
SC826BA-R920LPB SC826BA-R920UB
SC826BA-R920WB SC826BE26-R920LPB
SC826BE26-R920UB SC826BE26-R920WB
SC826BE16-R920LPB SC826BE16-R920UB
SC826BE16-R920WB
SC826TQ-R800LPV(B) SC826TQ-R800UB
SC826TQ-R500LPB SC826E16-R500LPB

ii
Manual Revision 2.0a
Release Date: October 30, 2015
The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our web site at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and
documentation, is the property of Supermicro and/or its licensors, and is supplied only under a
license. Any use or reproduction of this product is not allowed, except as expressly permitted by
the terms of said license.
IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all
claims will not exceed the price paid for the hardware product.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.
Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2015 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America

iii
Preface
Preface
About This Manual
This manual is written for professional system integrators and PC technicians. It
provides information for the installation and use of the chassis. Installation and
maintenance should be performed by experienced technicians only.
This document lists compatible parts available when this document was published.
Refer to the Supermicor web site for updates on supported parts and congurations.

SC826 Chassis Manual
iv
Contents
Chapter 1 Introduction
1-1 Overview ......................................................................................................... 1-1
1-2 Models............................................................................................................. 1-1
1-3 Features .......................................................................................................... 1-3
Drives .............................................................................................................. 1-3
System Power................................................................................................. 1-3
Front Control Panel......................................................................................... 1-3
Cooling System............................................................................................... 1-3
1-4 Contacting Supermicro.................................................................................... 1-4
1-5 Returning Merchandise for Service................................................................. 1-5
Chapter 2 Standardized Warning Statements for AC/DC Systems
Warning Denition ........................................................................................... 2-1
Installation Instructions.................................................................................... 2-4
Circuit Breaker ................................................................................................ 2-5
Power Disconnection Warning ........................................................................ 2-6
Equipment Installation..................................................................................... 2-8
Restricted Area................................................................................................ 2-9
Battery Handling............................................................................................ 2-10
Redundant Power Supplies .......................................................................... 2-12
Backplane Voltage ........................................................................................ 2-13
Comply with Local and National Electrical Codes........................................ 2-14
Product Disposal........................................................................................... 2-15
Hot Swap Fan Warning................................................................................. 2-16
DC Power Supply ........................................................................................ 2-18
DC Power Disconnection .............................................................................. 2-20
Hazardous Voltage or Energy Present on DC Power Terminals.................. 2-21
Chapter3 System Interface
3-1 Overview ......................................................................................................... 3-1
3-2 Control Panel Buttons ..................................................................................... 3-2
3-3 Control Panel LEDs ........................................................................................ 3-2
Overheating..................................................................................................... 3-3
Overheat Temperature Setting ................................................................... 3-3
Responses.................................................................................................. 3-4
3-4 Drive Carrier LEDs.......................................................................................... 3-4
3-5 Power Supply LEDs ........................................................................................ 3-4

v
Preface
Chapter 4 Chassis Setup and Maintenance
4-1 Removing Power from the System ................................................................. 4-1
4-2 Removing the Chassis Cover ......................................................................... 4-2
4-3 Installing Hard Drives...................................................................................... 4-3
Removing a 3.5" Hard Drive Carrier............................................................... 4-3
Installing 3.5" Hard Drives .............................................................................. 4-4
Installing the Rear 2.5" Hard Drive Cage (SC826B Only).............................. 4-6
Installing the Rear Drives Into Carriers (SC826B Only)................................. 4-8
4-4 Installing the Motherboard ............................................................................. 4-9
Riser Card Bracket (W or U Models only)...................................................... 4-9
I/O Shield ........................................................................................................ 4-9
Permanent and Optional Standoffs............................................................... 4-10
Installing the Motherboard .............................................................................4-11
4-5 Installing Expansion Cards .......................................................................... 4-12
Expansion Cards for an LP Model Chassis.................................................. 4-12
Expansion Cards for a W or U Model Chassis............................................. 4-12
4-6 Installing the Air Shroud................................................................................ 4-15
Checking the Airow ..................................................................................... 4-16
4-7 System Maintenance..................................................................................... 4-17
System Fans ................................................................................................. 4-17
Power Supply ............................................................................................... 4-19
Power Distributor........................................................................................... 4-20
Optional Front Bezel ..................................................................................... 4-21
Chapter 5 Rack Installation
5-1 Unpacking the System .................................................................................... 5-1
5-2 Preparing for Setup......................................................................................... 5-1
Choosing a Setup Location............................................................................. 5-1
5-3 Warnings and Precautions .............................................................................. 5-2
Rack Precautions............................................................................................ 5-2
General Server Precautions............................................................................ 5-2
Rack Mounting Considerations ....................................................................... 5-3
Ambient Operating Temperature ................................................................ 5-3
Sufcient Airow ......................................................................................... 5-3
Circuit Overloading..................................................................................... 5-3
Reliable Ground ......................................................................................... 5-3
5-4 Installing the System into a Rack ................................................................. 5-4
Identifying the Sections of the Rack Rails...................................................... 5-4
Releasing the Inner Rail ................................................................................. 5-5

SC826 Chassis Manual
vi
Installing the Inner Rails on the Chassis ........................................................ 5-6
Installing the Outer Rails onto the Rack......................................................... 5-7
Sliding the Chassis onto the Rack Rails......................................................... 5-8
Appendix A SC826 Chassis Cables
Appendix B SC826 Power Supply Specications
Appendix C BPN-SAS-826TQ Backplane Specications
Appendix D BPN-SAS-826A Backplane Specications
Appendix E BPN-SAS2-826EL Backplane Specications
Appendix F BPN-SAS3-826EL Backplane Specications

Chapter 1: Introduction
1-1
Model HDD I/O Slots Power Supply
SC826BE1C-R920LPB 12xSAS3/SATA +2 opt. SAS3
12Gb/s 1x expander 7x LP 920W Redundant (Platinum Level)
SC826BE1C-R920WB 2xSAS3/SATA +2 opt SAS3
12Gb/s 1x expander 4x FH, 3x LP 920W Redundant (Platinum Level)
SC826BE2C-R920LPB 2xSAS3/SATA +2 opt SAS3
12Gb/s 2x expander 7x LP 920W Redundant (Platinum Level)
SC826BE2C-R920WB 2xSAS3/SATA +2 opt SAS3
12Gb/s 2x expander 4x FH, 3x LP 920W Redundant (Platinum Level)
SC826BA-R1K28LPB 12x SAS/SATA + 2 opt. 7x LP 1280W Redundant
(Platinum Level)
SC826BA-R1K28WB 12x SAS/SATA + 2 opt. 4x FH, 3x LP 1280W Redundant
(Platinum Level)
SC826BE26-R1K28LPB 12x SAS/SATA + 2 opt.dual
expander SAS2 backplane 7x LP 1280W Redundant (Platinum Level)
SC826BE26-R1K28WB 12x SAS/SATA + 2 opt.dual
expander SAS2 backplane 4x FH, 3x LP 1280W Redundant (Platinum Level)
SC826BE16-R1K28LPB 12x SAS/SATA + 2 opt.single
expander SAS2 backplane 7x LP 1280W Redundant (Platinum Level)
SC826BE16-R1K28WB 12x SAS/SATA + 2 opt.single
expander SAS2 backplane 4x FH, 3x LP 1280W Redundant (Platinum Level)
SC826E16-R1200LPB 12x SAS/SATA 7x LP 1200W Redundant
(Gold Level)
SC826E16-R1200UB 12x SAS/SATA 4x FF (1x UIO),
3x LP
1200W Redundant
(Gold Level)
SC826E26-R1200LPB 12x SAS/SATA 7x LP 1200W Redundant
(Gold Level)
Chapter 1
Introduction
1-1 Overview
Supermicro's SC826 chassis maximizes the storage capacity of a 2U form factor
by offering twelve hot-swappable hard drive bays. It is ideal for data storage
applications. The chassis design optimizes every aspect of interior space, without
compromising superior cooling and is equipped with a redundant power supply.
1-2 Models
Visit the Supermicro web site for the latest models and parts lists at www.supermicro.
com. A complete list of safety warnings is provided on the Supermicro web site at
www.supermicro.com/about/policies/safety_information.cfm.

SC826 Chassis Manual
1-2
SC826E26-R1200UB 12x SAS/SATA 4x FF (1x UIO),
3x LP
1200W Redundant
(Gold Level)
SC826A-R1200LPB 12x SAS/SATA 7x LP 1200W Redundant
(Gold Level)
SC826A-R1200UB 12x SAS/SATA 4x FF (1x UIO),
3x LP
1200W Redundant
(Gold Level)
S826BA-920LPB 12x SAS/SATA +2 opt. 7x LP 920W Redundant
(Platinum Level)
SC826BA-R920UB 12x SAS/SATA +2 opt. 4x FH, 2x LP 920W Redundant
(Platinum Level)
SC826BA-R920WB 12x SAS/SATA +2 opt. 4x FH, 3x LP 920W Redundant
(Platinum Level)
SC826BE26-R920LPB 12x SAS/SATA +2 opt., dual
expander SAS2 backplane 7x LP 920W Redundant (Platinum Level)
SC826BE26-R920UB 12x SAS/SATA +2 opt., dual
expander SAS2 backplane 4x FH, 2x LP 920W Redundant (Platinum Level)
SC826BE26-R920WB 12x SAS/SATA +2 opt., dual
expander SAS2 backplane 4X FH, 3x LP 920W Redundant (Platinum Level)
SC826BE16-R920LPB 12x SAS/SATA +2 opt., single
expander SAS2 backplane 7x LP 920W Redundant (Platinum Level)
SC826BE16-R920UB 12x SAS/SATA +2 opt., single
expander SAS2 backplane 4X FH, 2x LP 920W Redundant (Platinum Level)
SC826BE16-R920WB 12x SAS/SATA +2 opt., single
expander SAS2 backplane 4x FH, 3x LP 920W Redundant (Platinum Level)
SC826TQ-R800LP(V)
(B) 12x SAS/SATA 7x LP 800W Redundant
SC826TQ-R800UB 12x SAS/SATA 4x FF (1x UIO),
3x LP 800W Redundant
SC826TQ-R500LPB 12x SAS/SATA 7x LP 500W Redundant
(Platinum Level)
SC826E16-R500LPB 12x SAS/SATA 7x LP 500W Redundant
(Platinum Level)
Legend:
LP: Low prole
FF: Full-height, full-length
FH: Full-height, half-length

1-3
Chapter 1: Introduction
1-3 Features
Drives
The chassis allows twelve 3.5" hot-swap SAS3/SATA hard disk drives. Some models
support two optional 2.5" hot-swap drives for OS mirroring.
System Power
Different models offer redundant power supply modules of several different watt-
ages.
Front Control Panel
The control panel provides a monitoring and control interface. LEDs indicate system
status and buttons control system power.
Cooling System
The system includes three 80mm hot-swap fans

SC826 Chassis Manual
1-4
1-4 Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Web Site: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Web Site: www.supermicro.nl
Asia-Pacic
Address: Super Micro Computer, Inc.
3F, No. 150, Jian 1st Rd.
Zhonghe Dist., New Taipei City 235
Taiwan (R.O.C)
Tel: [phone]
Fax: [phone]
Email: [email protected]
Web Site: www.supermicro.com.tw
