SUPERTOOTH Bluetooth Handsfree Kit User manual

SupertoothONE 
BluetoothHandsfreeKit
HitechFeatures
VOXTechnology
MultiPointConnection
A2DPMusicStreaming and
FullDSPNoiseCancellation/EchoCancellation

2
A.ProductDescription
SUPERTOOTHONE isa Bluetooth® handsfreekit thatsupportsheadsetand
handsfree profile phones. This handsfree kitis equipped with hitech features
such as: VOX Technology, Multipoint Connection and Full DSP Noise
Cancellation/Echo Cancellation. It can also be used as speaker to stream
music fromyour phone over A2DP (Advance Audio Distribution Profile). It is
designedforeasyhandsfreeoperationandsuperiorperformance.
Don'tforget:Drivesafelyandwithinthelaw.
Checkif thenationalorlocallegislationinforceinyourcountrydoesnotlimit
the useof mobile phones while driving. It isup tothe user ofthis product to
respectthesaidlegislationintheareawherehe/shelives. 
B.ProductOverview 
1 MFBorMultifunctionButton
(poweron&off/pairing/answer/
voicedial/redial/audiotransfer)
2 VolumeDown
3 VolumeUp
4 End/RejectButton
5Microphone
6ChargerPort
7BluetoothIndicator/ChargeIndicator
8Speaker 
C.Charging 
1. Connectthecharger’splugtotheChargerPort(6)oftheSUPERTOOTH
ONE.Connectthechargertoanexternalpowersource.
ChargeIndicator(7)Status:
SteadyRed: BatteryLow
SteadyOrange: Charging
SteadyGreen: BatteryFull
2. Whenfullycharged,disconnectthecharger.

3
D.PowerOn/Off 
PowerOn: PresstheMFB(1)for1second,untiltheBluetoothIndicator(7)
turnsblinkingblue.Abeepwillbeheard.
PowerOff: Press and hold the MFB (1) for 5 seconds, until the Bluetooth
Indicator(7)turnsred.Abeepwillbeheard. 
E.PairingtoyourBluetoothMobilePhone 
PairtheSUPERTOOTHONEtoyourBluetoothmobilephonetocreatethelink
oraudioconnectionbetweenthetwo.Thepairingprocessisrequiredonlyonce
foreachphone.
1.FromOFF, press and hold the MFB (1) for 5 seconds until the Bluetooth
Indicator (7) turns blinking red/blue. The handsfree kit is now in pairing
mode.
2.While the handsfree kit is in pairing mode, access the Bluetooth menu of
your phone.  Turn on the Bluetooth function then execute a Bluetooth
search.( Seeyourphone’smanual .) 
3. WhenthephonedisplaysthelistofBluetoothdevices,select STONE. 
4.Whenthephoneasksforthepassword/pincode,enter0000andpressOk.
5.Thehandsfreekitisnowreadytouse. 
F.Installation 
1. PlacetheclipintheslotsatthebackoftheSUPERTOOTHONE.
2. Slidethecliptoitsclosedsideuntilitlocks. 
Warning:Donotforceontheswitcheswhileinsertingtheclip. 
3. The closed sideoftheclipshouldbealignedwiththetoporthebottomof
theSUPERTOOTHONE. 
Note:Theclipcanbeattachedtotheunitin2ways,tosuitanypositiononthe
sunvisor .

4
4. Place the SUPERTOOTH ONE on the sunvisor in such a way that its
microphoneisdirectedtothemouthoftheuser. 
G.BasicOperations 
IMPORTANT:
Thehandsfreekitneedstobe ‘paired’ toyourBluetoothmobilephone,before
youcanusethefollowingfunctions.  See“PairingtoyourBluetoothMobile
PhoneinSectionE”. 
MakeaCall(NormalDial):
Dialthenumberonyourphone.Audiowillautomaticallybeheardthroughthe
handsfree kit.  During an ongoing call, the Bluetooth Indicator (7) will turn
steadyblue. 
Note: With some phones, audio is always on the phone during an outgoing
call.Youwillneedtopressthe MFB(1) for1secondtotransfertheaudioto
yourhandsfreekit. 
AnsweraCall:
· To answer a call, simply press the MFB (1) for 1 second, the Bluetooth
Indicator(7)willturnsteadyblue.
· Alternatively, assuming that Voice Answer is activated ( see “Voice
AnswerActivation/DeactivationonSectionJ” ):
Accept a call by loudly and clearly saying “ACCEPT CALL”, “ACCEPT”,
“ANSWER”or“OK”afterthespecialringtone.Sayitonlyonceandwithin3
seconds emphasizing each syllable.  When a call is answered, the
BluetoothIndicator(7)willturnsteadyblue.

5
EndaCall:
PresstheEnd/RejectButton(4)for1secondtoendthecall.
VoiceDial:
Important:Beforeusingthisfeature,makesurethatthevoicedialingfunction
of your phone is activated and at least one  voice tag  is recorded on your
phone.(Kindlyrefertotheprocedureinyourphone’smanual.) 
Note:Voicedialingentriesmustbestoredinthephone’smemory,notonthe
SIMcard! 
1. PresstheMFB(1)for1second.
2. A voice dial beep will be heard on the handsfree kit prompting you to say
thevoicetagofthecontacttocallandtheBluetoothIndicator(7)willturn
steadyblue.
3. Saythevoicetagexactlyashowyourecordedit.
4. The voice tag will be played back to you and then the phone will dial the
numberautomatically.
Redial (ForHandsfreeProfilePhonesonly) :
PresstheMFB(1)for3seconds.Thelastdialednumberwillberedialed.
RejectaCall (ForHandsfreeProfilePhonesonly) :
During the ring tone, press the End/Reject Button (4) for 1 second.  The
incomingcallwillberejected.
VolumeSetting:
Increase or decrease the volume by pressing the Volume Up (3) or Volume
Down (2) button.  Press repeatedly until the desired level is reached.  The
Bluetooth Indicator (7) will turn violet as lowest and highest levels are
reached.
AudioTransfer (ForHandsfreeProfilePhonesonly) :
Duringanongoingcall,youcantransfertheaudio.
KittoPhone: PressandholdtheMFB(1)for3secondsandtheaudiowill
betransferredtothephone.
PhonetoKit: Press the MFB (1) for 1 second and the audio will be
transferredtothehandsfreekit .
Note: Forsomephones,youmayneedtoacceptaconnectionpromptonthe
phonebeforeautomatictransfertakesplace.

6
H.StreamMusicfromyourA2DPBluetoothMobilePhone: 
If a phone supports A2DP, you can stream music from your phone to the
SUPERTOOTHONE. 
Note:TheSUPERTOOTHONEneedstobe‘paired’withyourBluetoothmobile
phonebeforeyoucanusethefollowingfunctions.(See“Pairingtoyour
BluetoothMobilePhoneonsectionE”.) 
UsingA2DPMusicStreaming
ToStreamMusic:
· Gotoyourphone’smusicplayerandplayatrackviaA/Vbluetooth. (See
yourphone’smanual).
· Or DoubleShortPresstheMFB(1)toplay/pausemusicstreaming.
ToSettheVolume:
· PresstheVolumeUp(3)ordown(2)buttonrepeatedlyuntilthedesired
levelisreached. 
I.AdvancedFunctions 
a.MultiPointFunction
The SUPERTOOTHONEcansimultaneouslyconnectto2Bluetoothdevices.
Thelastconnectedphone(orthelastthathadanactivecall)issetasprimary
andtheotherphoneissetassecondary.
TheSUPERTOOTHONEisactiveonbothmobilephones.Useractions(voice
dial, redial) will control the primary phone, but anincoming call on any of the
twophonescanbeacceptedorrejectedfromtheSUPERTOOTHONE.
MultiPointPairingProcedure:
1.Turn off the handsfree kit by pressing and holding the MFB (1) until the
LEDflashesred.
2.Pair the additional phone as explained in  “Pairing to your Bluetooth
MobilePhoneonsectionE”. 
Thisphonewillnowbetheprimaryphone . 
ToSwapthePrimaryandSecondaryPhones:
Ifneeded,youcanswaptheprimaryandsecondaryphonesasfollows:
· PressandholdEnd/RejectButton(4)buttonfor5seconds,abeepwill
beheard.Thesecondaryphoneisnowsetasprimary.

7
UsingMultiPoint:
Refer to  “BASIC OPERATION on section G”  and  “Using A2DP Music
StreamingonsectionH .
Notes:
· Voice dial and redial will be done using the primary phone only. See
abovehowtoswapthephones.
· Youcanacceptorrejectcallsfromanyofthetwophones.
· Ifyouacceptacall,thatphonewillbecometheprimaryphone.
· Akeypaddialwillsetthatphoneasprimary.
Simultaneouscalls:
Youcannothearacallormusicfrom2phonessimultaneously.
If you receive a call, when you already have an ongoing call, you will hear a
specialringtone.
1.Ifyourejectthecallyoucancontinuetheongoingcall.
2.Ifyouanswerthecall,theinitialcallwillbeended. 
Note: The Voice answer function is disabled when you have an ongoing call.
Thisallowsyoutosaygoodbyebeforetoanswerthesecondcall. 
Receivingacallwhilelisteningtomusic:
Ifyoureceiveacall,themusicwillbepauseduntilyourejectorendthecall. 
Note:Onsomephonesyouwillneedtorestartthemusicplayingmanually. 
b.SwitchingConnectionsBetweenPairedPhones
The SUPERTOOTH ONE always maintains a maximum of 8 phones in its
memory.Anadditionalpairingwillautomaticallydeletethephonethathas not
beenusedforthelongesttime.Thisphoneneedstobepairedagainbeforeit
canbeused.
Youcaneasilyswitchtoanyofthepairedphonesby:
1. Disconnectingoneofthe2connectedphonesusingthe“Activedevices”
intheBluetoothmenuofthatphone.
2. Connecting to the desired phone by using the “Paired devices” in the
Bluetoothmenuofthatphone. 
Note:ReconnectiontoapairedphonecanalsobedonebypressingtheMFB
(1).However,theSUPERTOOTHONEwillattempttoconnecttothelastused

8
phoneonly.Therefore,itisrecommendedtoconnecttoanotherpairedphone
usingthephonemenu.
J.SpecialFeatures 
a.VoiceAnswerMode(VOXTechnology):
ImportantNotice:Thisfeaturemaynotperformwellinsideavehiclewithhigh
backgroundnoise.
· When activated, the user can accept a call by loudly and clearly
saying“ACCEPTCALL”,“ACCEPT”,“ANSWER”or“OK”.Emphasizeeach
syllable and say it only once and within 3 seconds after the special ring
tone.
· Whendeactivated,answeracallbypressingtheMFB(1).
TheVoiceAnswerModecanbeenabledordisabledwhenthekitisinstandby
mode(noongoingcallandcloseanymultimediaplayer).
Activation: PressandholdVolumeUp(3)Buttonfor5seconds,abeep
willbeheard.
Deactivation: Press and hold Volume Down (2) Button for 5 seconds, a
beepwillbeheard.
b.AutomaticReconnection:
· Automatic reconnection occurs when you go out of Bluetooth range for
morethan20seconds(withoutturningOFFthehandsfreekit)andthengo
back in range.  The kit will automatically search for your phone and
reconnect. 
Note:  This automatic reconnection can take up to 10 seconds after arriving
backinrange.
· Incaseofintentionaldisconnection(usingthephonemenu),thissystem
isnotactivated.

9
SUPERTOOTHONESpecifications
BluetoothCompliance: Bluetoothversion2.0specifications
SupportedBluetoothProfiles: Supportsheadsetandhandsfreeprofileswith
automaticdetection
OperatingRange: Upto10meters
Frequency: 2.4GHz
TalkTime: Upto15hours
Standbytime: Upto800hours
ChargingTime: 3hours
BatteryType: RechargeableLithiumIon
SpecialFeatures
§  FullDuplex
§  Full DSP Noise Cancellation / Echo
Cancellation
§  DigitalVolumeControl
§  VOXTechnology
§  Stream Music from A2DP Bluetooth
MobilePhone
§  MultipointFunction
§  Voice Recognition Dialing (If phone
supports)
§  LastCallRedial
§  RejectIncomingCall
§  Can also be charged directly from a PC
via USBCable(notincluded)
§  CompactSize
§  Fullautomaticreconnection
Installation: Quickfixationonsunvisorviaplasticclip
Dimensions(mm): 21x64x120
Weight: 100g

1
The  Bluetooth®  word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by EuroCB is underlicense.
Othertrademarksandtradenamesarethoseoftheirrespectiveowners.
