SUPRENT HC596 User manual

HC596 | SUPRENT Hair Clipper

Components 1 Parameters
Use the Rechargeable Mode
Bottom blade
Top blade
Blade lever
ON/OFF switch
Professional
Hair Clipper
Specific Adaper
Motor
Battery
Operating voltage: 3V
High perform ance motor
2500mAH Li-ion battery
Charging time: about 3 hours
Operating time with full charge: about 5 hours
Input: 100-240V~50/60Hz
Output: 5V 1000mA
1. lnsert the charger into the tail of clipper, connect to the power to
start charging.
2. When the charging indicator lights up, it starts charging;when the
red light changes to the green (blue) light fully charged.
3. Cord and cordless are available
Combs Brush
Standard 5V/US
charging port
2

Fixed-length Function Cutter Assembly and Disassembly
A: Use of Limit Comb: Cropped hair and hair trim
Feature: [1.5, 3, 4.5, 6, 10 & 13mm] six lengths adjustment to
control the hair length.
1. To determine the length of haircut
2. To select the appropriate limit comb
3. To fine-tune the cutter
Adjust the cutter by rotating the adjusting
ring from forward to downward.
ount the limit comb:
1. Align the limit comb with the blade edge
2. Slightly forward push to mount it.
Disassemble the limit comb: Just pull hard the
limit comb.
The sketch shows how the bottom blade holes
are larger than the shanks of the blades
screws.When the blade screws are loosened the
bottom blade can be aligned with tight after the
blade is aligned.
2.Extreme left-hand tooth of the top blade must be covering or be to
the left of the first small tooth of the bottom blade.
3.Extreme right-hand tooth of the top blade must be touching the big
tooth on the bottom blade.
1.End of the top blade teeth should be 1/32" to
1/16,0.79mm to 1.59mm back from the bottom
blade.This is important so that the clipper
doesn’t cut too close or allow the moving cutter
to touch the skin.
Taper Lever
Some clippers are equipped with an adjustable
taper lever that changes the closeness of your
cut.When the lever is in the uppermost position,
the blades will give the closest cut.Pushing the
lever downward gradually increases the cutting
length.
1.5 mm 3 mm 4.5 mm
6 mm 10 mm 13 mm
3 4

Cutter Cleaning and Maintenance Precautions For Use
Blade Alignment
Cutter Maintenance
.Your clippers were carefully examined to ensure that the blades
were oiled and aligned before leaving our factory.
.Blades must be realigned if they have been removed for cleaning or
replacement
.To realign the blades,simply match the upper and bottom blades
teeth up, point for point.(End of top blade teeth should be
approximately 0.5-1.0mm back from the bottom blade.Compare your
clipper blades with the sketch)
.If blade alignment is incorrect,add a few drops of oil to the
blade,turn the clipper on for a few moments,turn off and
unplug.Loosen screws slightly and adjust.
Tighten screws after the blade is aligned
1.Please do not disassemble the product.
2.The hair clipper can not be washed.
Please keep it away from wet conditions.
3.The product can only be cleaned by cloth with little water or mild
soap solution.
4.Do not charge the product under environment above 40℃or below
o°C.
※The product can produce little heat duringusing or charging,
which is normal.
※Please remove the battery safely and return it to the specified
places when the battery runs out.Never discard it casually.
To maintain your clipper in peak condition,the
blades should be oiled every few haircuts.
To oil it properly,the unit should be held so the
blades are in a downward position.With the clipper
blade running,dispense 2-3 drops of oil across the
top blade.
5 6

Warranty Card
Following Guarantees Provided For the Product
1.The product is produced through strict quality management and
inspection.
2.lf malfunction occurred in fair use, the consumer can enjoy free
warranty service according to the warranty card in the purchasing
store or our repair center.
(The battery and blade belong to consumables, not coverd by
warranty but provided with fee)
3.No free services for the following situations:
A.Damages caused by repair or reformation not approved
by our company.
B. Damages caused by false or neglectful use, or by accidents.
C. Damages caused by natural disasters or abnormal voltage.
D. Damages caused by ignoring attentions provided with in the
product specification.
4.The product is only guaranteed when provided the warranty
card instead of the invoice.
Product Name Professional Hair Clipper
Month Date Year
Warranty Period
To Month Date Year
One year from the
purchasing date
Product Model
Purchasing Date
Customer Address
Address
Name
Name
Name
Phone
Number
Phone
Number
Point of
Sale
7
