Sur-e slice SSG350S User manual

16
Ref. Descripon Code
- SYDNEY KEYPAD CONTR.ASS.Y 19702030
604 GASKET FOR ROUND CONTROL PANEL 19563034
608 KEYPAD HOUSING FOR SIDNEY KEYPAD 19563124
610 ON/OFF DECAL FOR SIDNEY KEYPAD 19420163
612 S/S BUTTON 19410135.10
614 S/S BUTTON W/LAMP 19410136.10
620A PRINTED CIRCUIT BOARD 230-110 V 19411102
620B PRINTED CIRCUIT BOARD 400 V 19411103
Drawing nr. 5/5
SERVICE CENTRE
AUTHORISED DEALER
1
Service Manual
Professional slicer CE
mod. SSG350STR
Ed. 04/2011

2 15
Drawing nr. 5/5

14
Ref. Descripon Code
626 CAPACITOR FOR SLICER 10UF 19410307
632 WIRE WAY HOUSING FOR SLICER 19563127.09
640 SUPPORT,TERMINAL BLOCK FOR GALILEO 19541742.07
642 TERMINAL BLOCK KADO2/5 FOR SLICER 19410800
644A CORD + TERMINAL KADO 1-PH 19410541
644B CORD + TERMINAL KADO 3-PH 19410542
648A MOTOR - SLICER 350-370 230V, 50HZ 19400109
648B MOTOR 350 380V-50HZ 19400409
652 GROUNDING PLATE FOR SLICER 19420177
658 GROUND WIRE UL FOR SLICER 300-385 19410739
664 MICROSWITCH SINGLE-PHASE 19410201
668 MOTOR ROD FR SLICER GALILEO 350-385 19540564
670 MOTOR TIE ROD STUD BOLT M8 F.SLICER 19336022
676 SUPPORT, MOTOR FOR SLICER GALILEO 19540364
680 WIRE WAY HOUSING COVER FOR SLICER 19563148.09
684 BOTTOM ENCL.PANEL LEONARDO 350-385 19563154
690 UPPER HEX ROD FOR COVER LEONARDO 19540752.07
Drawing nr. 4/5
692 HEX ROD FOR COVER_SLICER 19540754
3
115 V. ELECTRICAL DIAGRAM - 230V. SINGLE-PHASE - 230V.
THREE-PHASE - 400V. THREE-PHASE, PUSH-BUTTON
Fig. n°21
115 V. tension selection
Single-phase 230 V. tension selection

4
Three-phase 230 V. tension selection
Three-phase 400 V. tension selection
13
Drawing nr. 4/5

12
Ref. Descripon Code
402 SHARPENER HOUSING_LEON/PALL 300-385 19511252C
404 SHARPENER RED KNOB FOR LEONARDO/PLD 19522652R
406 BUTTON SCREW _ SLICER 250-370 19335025
409 DEBURRING PUSH BUTTON FOR SLICER 19550208
410 SHARPENER PINS SPRING FOR SLICER 19390309
412 DEBURRING PIN FOR SLICER 330-370 19540709
414 BUSHING_LEONARDO/PALL.USA 19540718
416 DEBURRING STONE D.50 H.8 F.8 19300209
424 SHARPENING STUD FOR SLICER 330-370 19540708
430 VIBRATION DAMPER FOR LEONARDO 19560152
432 THUMB SCREW SHARPENER LNR 19335023
436 BOTTOM ENCLOSURE_LEONARDO 300-385 19511253C
437 CONICAL SCREW FOR RING_SLICER 19336055.09
442 SHARPENER ROD _ LEONARDO 300-385 19540452
444 LOCK BOLT FOR SHARPENER_LEONARDO 19336056.09
456 SHARPENER FOR LEONARDO 300-385 19021352
470 SHARPENING STONE D.48 H15 Y10 19300108C.10
Drawing nr. 3/5
5
Drawing nr. Ref. SSG350STR
5/5 620A
620B Pc board
5/5 - On/Off touch panel
3/5 416
470 Grinding stones (couple)
1/5 24 Belt
1/5 03
04 Feet (4x)
2/5 294 Plexi hand-guard
Page
15
15
11
6
6
8
Recommended Spare Parts

6
Drawing nr. 1/5
11
Drawing nr. 3/5

10
Drawing nr. 2/5
Ref. Descripon Code
278 PUSHER BUFFER D8,5XH36 19563206
280 MEAT PRESSER 19511764
282 PIVOT MEAT PRESSER GLL 350 19531324
287 HANDGUARD SPACER 19562345
288 FLAT HEAD SCREW_HAND GUARD_GALILEO 19335064
288C SCREW FOR CARRIAGE LOCKING+BS2 NUOVO 19335045
290A NUT HANDGUARD LOCKING 19533764
292A NUT COVER 19533765
294C HAND GUARD (CARRIAGE) FOR GALILEO 350-385 19562344.09
302 SPACER GLL 350-385 19522638
306 SPACER GLL 350-385 OSS 19522634
308 RED HANDLE GUARD FOR SLICER LEONARDO 19522640R
310 PRODUCT PUSHER RED HANDLE LEONARDO 19522645R
312 SUPPORT PIN FOR PRESSER GALILEO 350 19533766
314 BUMPER,END WEIGHT D8XHT6 FOR SLICER 19563200
320 BOLT FOR CARRIAGE HANDLE 19525052
7
Drawing nr. 1/5
Ref. Descripon Code
02 BASE FOR SLICER GALILEO 350-385 19510164
03 FOOT BUFFER '05 LEONARDO 350-385 19560156.05
04 FOOT ASSEMBLY '05 LEONARDO 350-385 19522620.05
05 FOOT PLATE LNR 350 FROM 05 19540656.05
06 BLADE COVER Y08 SLICER 350 19510257
08 KNOB FOR SLICE DEFLECTOR_SLICER 19021156
14 TIE ROD LOCK NUT FOR SLICER 19530909
15 GUARD RING FOR SLICER GALILEO 195621364
16 GB BLADE 350 - 57/4/280 CE 18350574280GF
18 BLADE RIM GUARD 350 GLL 19513064
20 KNIFE RIM GUARD SUPPORT FOR GALILEO 19534074
22 PULLEY GALILEO 350-385 19700364
24 BELT TB2 430 X 12 19310264
28 MICROSWITCH HOLDER RING 19540909
32 TIE ROD GALILEO 350-385 19530564
34 TIE ROD KNOB 19522610R
36 SLICE DEFLECTOR/SCRAPER FOR GALILEO 19531057A
38 BLADE COVER KNOB FOR SLICER 19021110
39 S/S PRONG SHOULDER SCREW FOR SLICER 19335011
40 GAUGE GALILEO 350 19510364
41 PRONG SHOULDER SCREW FOR SLICER 19336052
42 PLATE FOR SLICER GALILEO 350 19540648
44 SQUARE STUD TQ 8X38 FOR SLICER 350 19335007
48 TABLE SUPPORT FOR SLICER GALILEO 19510764
52 COVER, TABLE SUPPORT FOR GALILEO 19512264
56 KNOB, COVER FOR SLICER LEONARDO 19335021
62 GASKET FOR TABLE SUPPORT FR GALILEO 19563064
63 STUD BOLT F.SLICER LEONARDO/PALLADI 19563156
64 THICKNESS PLATE SLIDE LEONARDO 350 19500160
66 SLIDE GUIDE FOR SLICER LEONARDO 350 19540654.07
76 SPRING FOR SLICER LEONARDO 350-385 19390756
80 BUSHING SUPPORT 19500164
84 STUD BOLT 6X25 FOR SLICER 19337002
90 PIN, INDEX CAM FOR SLICER LNR 19336074
92 CAM+SLIDE ROD D.12_LEONARDO/GALILEO 19563574
96 CORRUGATED SPRING WASHER 19 19342006
98 KNOB WASHER LEONARDO 350 19562154
99 BUSHING 18.20.20 19324108
102 GRADUATED RED KNOB LEONARDO 350-385 19522600R
106 RING FOR SLICER 300-385 19534066
120 BLADE EXTRACTOR TOOL 350 19702512
124 SHAFT,TABLE SLIDE FR SLICER GALILEO 19530766
140 OIL BOTTLE 19563008

8
Drawing nr. 2/5
9
Drawing nr. 2/5
Ref. Descripon Code
002 MEAT PRESS ASSEMBLY GALILEO CE 19801264
202 PLATE FOR SLICER 19533200
204 "T"PLATE,CARRIAGE RELEASE F.SLICER 19533254
206 PUSH ROD _ SLICER 300-385 CE 19565001
210 BEARING PIVOT 350 19540808
212 CARRIAGE SLIDE F.SLICER GALILEO/LEO 19500556
214 SPRING,SLIDE BUMPER FOR SLICER LEO 19390754
216 PISTON,SLIDE BUMPER FOR SLICER LEO 19531356
220 STUD BOLT M8 FOR SLICER LEONARDO 19337054
223 HEX ROD,CARRIAGE RELEASE F.SLIC.LEO 19534038
224 CARRIAGE RELEASE SPRING FOR SLICER 19390601
225 SPACER FOR SLICER LEONARDO 350-385 19346056
226 RELEASE BUSHING FOR LEONARDO 350-85 19534026
227 BEARING ROD FOR LEONARDO 350-385 19540807
228 LOCKRING(EXT THREADING)FOR SLICER 19534030
232 CARRIAGE PLATE SLICER 350-370 19533009
234 BUSHING FOR SLICER LEONARDO 350-385 19538054
236 BEARING FOR SLICER 6000 2RS R11 19320154
240 WASHER FOR SLICER LEONARDO 350 19346054
242 CARRIAGE ROUND RAIL FOR LEONARDO 19530654
246 SLIDE BUMPER LEONARDO 350-385 19560154
248 SQUARE RAIL FOR LEONARDO 350-385 19540154
252 S/S PLATE LNR 350-385 19530854X
254 SUPPORT,ROUND RAIL FOR LEONARDO 19541745
256 CARRIAGE LOCKING RED KNOB FOR LEONARDO 19522615R
257 STUD BOLT FOR SLICER M10 19336038
258 CARRIAGE LOCKING ARM 19510664
259 S/S ARM BUSHING LEONARDO 350-385 19534023
260 SQUARE STUD TQ 8X38 FOR SLICER 350 19335007
261 BUSHING FOR SLICER 300-370 CE 19534016
264C CARRIAGE CORT. 09 350-385 19510465.09
265 BOLT /CARRIAGE GLL 350 OSS 19525066
267 STUD BOLT 19531364
268 NYLON SPACER CARRIAGE BS2 FR.SLICER 19563254
269 THUMB SCREW FOR LEONRDO BS2 350-385 19335256
270 PLATE BAR GLL 350-385 19530464
272 BLOCK FOR PLATE BAR 19525064
274 BUSHING 16,18,20 FOR SLICER 19324107
