SureShot MGI Ai Series User manual

Quick Start Guide
VERSION 1.1
MGIG_2075 - GBL - Navigator Ai Quick User Manual_FINAL 1.1.indd 1MGIG_2075 - GBL - Navigator Ai Quick User Manual_FINAL 1.1.indd 1 26/05/2023 4:06:39 PM26/05/2023 4:06:39 PM

MGI Ai NAVIGATOR GPS+Quick Start Guide 1.1 3
2
WHAT’S INCLUDED:
MGI Ai Navigator GPS+
2 x Front Wheels
2 x All-terrain Rear Wheels
High Performance Lithium Battery
MGI Pouch
– O Rings
– Axle Lubrication Cloth
– Battery Charger Manual
– USB Lead
– Remote Holder
– Remote Control
MGI Ai Navigator GPS+User Manual (online)
Battery Charger and Manual
THANK YOU FOR
LEADING THE WAY AND
PURCHASING AN MGI Ai
NAVIGATOR GPS+
For future reference, please record the serial
number of your Ai Navigator GPS+below.
This can be located on the aluminium shaft in
the battery tray of the Ai Navigator GPS+.
Please keep your receipt as proof of purchase.
To register you Ai Navigator GPS+please have
Wi-Fi available.
YOUR SERIAL NUMBER:
Reading this information will ensure you get the most positive
experience rst time.You are also strongly advised to properly
read the User Manual which is located on the website
mgigolf.com
1. INITIAL SETUP
When powering your Ai Navigator GPS+ on, please note it will
take a few moments to boot.
The Ai Navigator GPS+will need to be connected to a Wi-Fi
network to allow user registration and complete the latest
rmware updates.
If an update is required, the Ai Navigator GPS+ will prompt you
to update rmware – MGI recommends the Ai Navigator GPS+
is always up to date prior to usage.
2. HOW BEST TO UNFOLD YOUR Ai NAVIGATOR GPS+
1: Ensure both rear
wheels are attached.
4: The handle will
naturally unfold as
you lift.
MGIG_2075 - GBL - Navigator Ai Quick User Manual_FINAL 1.1.indd 2MGIG_2075 - GBL - Navigator Ai Quick User Manual_FINAL 1.1.indd 2 26/05/2023 4:06:40 PM26/05/2023 4:06:40 PM

MGI Ai NAVIGATOR GPS+Quick Start Guide 1.1 3
WHAT’S INCLUDED:
MGI Ai Navigator GPS+
2 x Front Wheels
2 x All-terrain Rear Wheels
High Performance Lithium Battery
MGI Pouch
– O Rings
– Axle Lubrication Cloth
– Battery Charger Manual
– USB Lead
– Remote Holder
– Remote Control
MGI Ai Navigator GPS+User Manual (online)
Battery Charger and Manual
THANK YOU FOR
LEADING THE WAY AND
PURCHASING AN MGI Ai
NAVIGATOR GPS+
Reading this information will ensure you get the most positive
experience rst time.You are also strongly advised to properly
read the User Manual which is located on the website
mgigolf.com
1. INITIAL SETUP
When powering your Ai Navigator GPS+ on, please note it will
take a few moments to boot.
The Ai Navigator GPS+will need to be connected to a Wi-Fi
network to allow user registration and complete the latest
rmware updates.
If an update is required, the Ai Navigator GPS+ will prompt you
to update rmware – MGI recommends the Ai Navigator GPS+
is always up to date prior to usage.
2. HOW BEST TO UNFOLD YOUR Ai NAVIGATOR GPS+
1: Ensure both rear
wheels are attached.
4: The handle will
naturally unfold as
you lift.
2: Depress blue locking
toggle.
5: Position handle
to desired height.
3: Lift the top bag rest
vertically.
6: Push bag support
forward until it clicks
into place. At the same
time, the lower handle
will lock into place.
MGIG_2075 - GBL - Navigator Ai Quick User Manual_FINAL 1.1.indd 3MGIG_2075 - GBL - Navigator Ai Quick User Manual_FINAL 1.1.indd 3 26/05/2023 4:06:43 PM26/05/2023 4:06:43 PM

4
4. BATTERY
CONNECTING BATTERY
Position battery on the chassis of the Ai Navigator GPS+with
the red indicator closest to the handle.Then slide the switch
into position so you can see green. Once connected your Ai
Navigator GPS+will automatically turn on and commence
start up mode.
This slide switch should be cleaned regularly especially when
playing on sandy or dusty courses.
BATTERY CHARGING
Before using your Ai Navigator GPS+for the rst time you
must fully charge the battery overnight. Keep on charge in
between use.
• Lift the charging port cover on the side of the battery and
insert the charger lead, ensuring the small semicircle is
facing upwards. Plug the charger into a wall socket.
• The LED on the charger will change from green to red to
indicate charging.
• A solid green light indicates full charge.
• Your battery should be charged after every use. Do not
leave your battery in an uncharged state.
For more information about battery charging please
reference the Battery Charger manual.
LITHIUM BATTERY CARE
Your lithium battery casing and connections should be
regularly inspected for damage and wear. If your connections
are in need of repair or replacement, please contact your
local MGI repair centre for assistance immediately. Under
no circumstances should a Lithium Battery that has been
dropped, damaged or immersed – partially or fully in water,
be connected to an Ai Navigator GPS+ or charger. By doing
so, the battery will become a re hazard and may cause
the Lithium cells to combust. Please contact the MGI Service
Centre to arrange a replacement.
STRONG BATTERY WARNING
Under no circumstances should a lithium battery that has been
dropped, damaged or immersed in water be connected to an Ai
Series or charger.
It is not covered under warranty and you will need to
purchase another battery.Your Ai Navigator GPS+is designed
to be used in all conditions however a level of caution is
required when operating your Ai Navigator GPS+ in wet
conditions.When playing in wet conditions, we recommend
carrying a hand towel to wipe away any excessive water from
the top box. Keep your Ai Navigator GPS+ on the fairway and
paths when possible and avoid boggy terrain and puddles.
Your Ai Navigator GPS+is designed to be as resistant to wet
conditions as possible however they are not waterproof.
Under no circumstances should you clean your Ai Navigator
GPS+using a pressure washer or hose. MGI recommends
cleaning away excess debris with a brush and wiping the Ai
Navigator GPS+ down with a damp cloth.
Ingress of water or moisture into the battery will void all
stipulated warranties on the battery.
5.CHARGING YOUR REMOTE CONTROL
Before using your Ai Navigator GPS+you
must fully charge your remote control.
Charge time is approximately 6 hours.
To charge the remote, plug in the USB
cord into the USB port on the base of
the remote.The cable can be plugged
into your PC or Laptop for charging;
alternatively, plug the cable into an AC
adapter (not included).
Whilst charging, the LED will ash. Once
fully charged, the LED will remain solid.
It is recommended to charge your remote control after every
use.
3.THE 5TH REAR WHEEL
Your Ai Navigator GPS+comes
standard with a 5th foldable rear
wheel (please see images to unfold
your 5th wheel).The 5th wheel MUST
be unfolded and in use on the Ai
Navigator GPS+. If you do not engage
the 5th wheel, your Ai Navigator GPS+
might tip backwards if travelling
uphill.Any damage caused to the Ai
Navigator GPS+ due to this will not
be covered under warranty.The 5th
wheel should be cleaned regularly
with a cloth to ensure it can be
folded as required for storage.
The grey latch as seen
in the photo is the way
to unfold the 5th wheel.
MGI Ai NAVIGATOR GPS+Quick Start Guide 1.1 5
MGIG_2075 - GBL - Navigator Ai Quick User Manual_FINAL 1.1.indd 4MGIG_2075 - GBL - Navigator Ai Quick User Manual_FINAL 1.1.indd 4 26/05/2023 4:06:45 PM26/05/2023 4:06:45 PM

4. BATTERY
CONNECTING BATTERY
Position battery on the chassis of the Ai Navigator GPS+with
the red indicator closest to the handle.Then slide the switch
into position so you can see green. Once connected your Ai
Navigator GPS+will automatically turn on and commence
start up mode.
This slide switch should be cleaned regularly especially when
playing on sandy or dusty courses.
BATTERY CHARGING
Before using your Ai Navigator GPS+for the rst time you
must fully charge the battery overnight. Keep on charge in
between use.
• Lift the charging port cover on the side of the battery and
insert the charger lead, ensuring the small semicircle is
facing upwards. Plug the charger into a wall socket.
• The LED on the charger will change from green to red to
indicate charging.
• A solid green light indicates full charge.
• Your battery should be charged after every use. Do not
leave your battery in an uncharged state.
For more information about battery charging please
reference the Battery Charger manual.
LITHIUM BATTERY CARE
Your lithium battery casing and connections should be
regularly inspected for damage and wear. If your connections
are in need of repair or replacement, please contact your
local MGI repair centre for assistance immediately. Under
no circumstances should a Lithium Battery that has been
dropped, damaged or immersed – partially or fully in water,
be connected to an Ai Navigator GPS+ or charger. By doing
so, the battery will become a re hazard and may cause
the Lithium cells to combust. Please contact the MGI Service
Centre to arrange a replacement.
STRONG BATTERY WARNING
Under no circumstances should a lithium battery that has been
dropped, damaged or immersed in water be connected to an Ai
Series or charger.
It is not covered under warranty and you will need to
purchase another battery.Your Ai Navigator GPS+is designed
to be used in all conditions however a level of caution is
required when operating your Ai Navigator GPS+ in wet
conditions.When playing in wet conditions, we recommend
carrying a hand towel to wipe away any excessive water from
the top box. Keep your Ai Navigator GPS+ on the fairway and
paths when possible and avoid boggy terrain and puddles.
Your Ai Navigator GPS+is designed to be as resistant to wet
conditions as possible however they are not waterproof.
Under no circumstances should you clean your Ai Navigator
GPS+using a pressure washer or hose. MGI recommends
cleaning away excess debris with a brush and wiping the Ai
Navigator GPS+ down with a damp cloth.
Ingress of water or moisture into the battery will void all
stipulated warranties on the battery.
5.CHARGING YOUR REMOTE CONTROL
Before using your Ai Navigator GPS+you
must fully charge your remote control.
Charge time is approximately 6 hours.
To charge the remote, plug in the USB
cord into the USB port on the base of
the remote.The cable can be plugged
into your PC or Laptop for charging;
alternatively, plug the cable into an AC
adapter (not included).
Whilst charging, the LED will ash. Once
fully charged, the LED will remain solid.
It is recommended to charge your remote control after every
use.
3.THE 5TH REAR WHEEL
Your Ai Navigator GPS+comes
standard with a 5th foldable rear
wheel (please see images to unfold
your 5th wheel).The 5th wheel MUST
be unfolded and in use on the Ai
Navigator GPS+. If you do not engage
the 5th wheel, your Ai Navigator GPS+
might tip backwards if travelling
uphill.Any damage caused to the Ai
Navigator GPS+ due to this will not
be covered under warranty.The 5th
wheel should be cleaned regularly
with a cloth to ensure it can be
folded as required for storage.
MGI Ai NAVIGATOR GPS+Quick Start Guide 1.1 5
MGIG_2075 - GBL - Navigator Ai Quick User Manual_FINAL 1.1.indd 5MGIG_2075 - GBL - Navigator Ai Quick User Manual_FINAL 1.1.indd 5 26/05/2023 4:06:46 PM26/05/2023 4:06:46 PM

6
SAFETY FEATURES – YOUR Ai NAVIGATOR GPS+WILL HALT IF
ANY OF THE BELOW CONDITIONS ARE MET
• It becomes out of range of the remote.
• If there is more than 2 minutes between commands from
the remote.
6. REAR WHEEL POSITIONS
The Ai Navigator GPS+ is designed to allow the rear wheels to
be in two positions.The position is determined by where the
wheel is locked on the axle in either of the two grooves (see
picture at the top of the next page).The drive position is used
during the normal operation of the Ai Navigator GPS+.The free
wheel position is used to push the Ai Navigator GPS+ freely, if
required.
i. Drive position – Lock the wheel into the inner groove.To do
so, press the black release toggle on the wheel hub, push the
wheel onto the axle as far as possible and gently pull back
until you hear a click.To test for drive position try rolling the
wheel backwards. If you feel resistance then the wheel is now
in drive position and ready to use. Repeat for both wheels.
ii. Free wheel – Lock the wheel into the outer groove.To do
this, press the black release button on the wheel hub, push
the wheel on to the axle and push the release button onto
the groove.To test for free wheel position try rolling the wheel
backwards.The wheel should spin freely with no resistance.
Repeat for both wheels.
7. LUBRICATE AXLES
To avoid wear on the Ai Navigator GPS+ axles and wheels,
apply some petroleum jelly to the exposed shaft (included
in MGI pouch).This will need to be cleaned and re-
applied monthly. Please refer to the user manual for further
information.
8. ENGAGING THE MOTOR BRAKE
The Ai Navigator GPS+features a motor brake to prevent it
from rolling away on uneven surfaces when idle.
Free wheel position
Drive position
To activate the brake, stop the Ai Navigator GPS+and turn
the speed control on the top box anticlockwise past 0 until
you hear a click. The brake will be activated and a P will be
displayed.The brake can also be activated using the remote
by stopping the Ai Navigator GPS+and then clicking the park
brake button located in the top right corner of the remote.
You will hear a click and a P will be displayed. Release the
brake by starting the Ai Navigator GPS+from the Top Box or
Remote.
9. LOAD-BEARING LIMITATION
The Ai Navigator GPS+ is designed to transport one golf bag,
14 clubs, accessories and other paraphernalia. It is not to be
used as an aid to help users traverse up/down hills or slopes.
Doing so will cause damage to the drive system of the Ai
Navigator GPS+and, as such, will void all stipulated warranties
on parts affected.
MGI Ai NAVIGATOR GPS+Quick Start Guide 1.1 7
MGIG_2075 - GBL - Navigator Ai Quick User Manual_FINAL 1.1.indd 6MGIG_2075 - GBL - Navigator Ai Quick User Manual_FINAL 1.1.indd 6 26/05/2023 4:06:46 PM26/05/2023 4:06:46 PM

SAFETY FEATURES – YOUR Ai NAVIGATOR GPS+WILL HALT IF
ANY OF THE BELOW CONDITIONS ARE MET
• It becomes out of range of the remote.
• If there is more than 2 minutes between commands from
the remote.
6. REAR WHEEL POSITIONS
The Ai Navigator GPS+ is designed to allow the rear wheels to
be in two positions.The position is determined by where the
wheel is locked on the axle in either of the two grooves (see
picture at the top of the next page).The drive position is used
during the normal operation of the Ai Navigator GPS+.The free
wheel position is used to push the Ai Navigator GPS+ freely, if
required.
i. Drive position – Lock the wheel into the inner groove.To do
so, press the black release toggle on the wheel hub, push the
wheel onto the axle as far as possible and gently pull back
until you hear a click.To test for drive position try rolling the
wheel backwards. If you feel resistance then the wheel is now
in drive position and ready to use. Repeat for both wheels.
ii. Free wheel – Lock the wheel into the outer groove.To do
this, press the black release button on the wheel hub, push
the wheel on to the axle and push the release button onto
the groove.To test for free wheel position try rolling the wheel
backwards.The wheel should spin freely with no resistance.
Repeat for both wheels.
7. LUBRICATE AXLES
To avoid wear on the Ai Navigator GPS+ axles and wheels,
apply some petroleum jelly to the exposed shaft (included
in MGI pouch).This will need to be cleaned and re-
applied monthly. Please refer to the user manual for further
information.
8. ENGAGING THE MOTOR BRAKE
The Ai Navigator GPS+features a motor brake to prevent it
from rolling away on uneven surfaces when idle.
GETTING YOUR
MGI AiNAVIGATOR GPS+
ON THE GOLF COURSE.
FULL USER MANUAL
To view our full user manual, scan the QR
code below or visit our website mgigolf.com
For customer support, please contact MGI directly
for immediate and professional advice by visiting
mgigolf.com
To activate the brake, stop the Ai Navigator GPS+and turn
the speed control on the top box anticlockwise past 0 until
you hear a click. The brake will be activated and a P will be
displayed.The brake can also be activated using the remote
by stopping the Ai Navigator GPS+and then clicking the park
brake button located in the top right corner of the remote.
You will hear a click and a P will be displayed. Release the
brake by starting the Ai Navigator GPS+from the Top Box or
Remote.
9. LOAD-BEARING LIMITATION
The Ai Navigator GPS+ is designed to transport one golf bag,
14 clubs, accessories and other paraphernalia. It is not to be
used as an aid to help users traverse up/down hills or slopes.
Doing so will cause damage to the drive system of the Ai
Navigator GPS+and, as such, will void all stipulated warranties
on parts affected.
MGI Ai NAVIGATOR GPS+Quick Start Guide 1.1 7
MGIG_2075 - GBL - Navigator Ai Quick User Manual_FINAL 1.1.indd 7MGIG_2075 - GBL - Navigator Ai Quick User Manual_FINAL 1.1.indd 7 26/05/2023 4:06:46 PM26/05/2023 4:06:46 PM

mgigolf.com
MGI AUSTRALIA
Service Email: [e-mail]
Live Chat: visit mgigolf.com
Toll Free within Australia: 1300 644 523 (excludes mobiles)
Western Australia/ Internal phone [phone]
Local Service Centres: visit mgigolf.com
to locate your local service centre.
MGI USA
Service Email: [e-mail]
Live Chat: visit mgigolf.com
Telephone: [phone]
MGI CANADA
Service Email: [e-mail]
Live Chat: visit mgigolf.com
Telephone: [phone]
MGI GLOBAL
Sales Email: [email protected]
Service Email: [e-mail]
Live Chat: visit mgigolf.com
Follow us on
NOTE: This quick start guide was correct at time of printing.The online version is the
most up-to-date and must be referred to as the correct version.To download the most
current user manual please visit mgigolf.com. Images shown throughout this manual
may not be of the particular model you have purchased. MGIG_2075 05/23.
MGIG_2075 - GBL - Navigator Ai Quick User Manual_FINAL 1.1.indd 8MGIG_2075 - GBL - Navigator Ai Quick User Manual_FINAL 1.1.indd 8 26/05/2023 4:06:48 PM26/05/2023 4:06:48 PM
