SVAGO SV-395 Manual

Maintenance service manual
Model: 7100

8: Guidance of change the side board and armrest.
A: Insert the screw driver into the side board and lever the side board gently, then we can take off the
side board. ( As pictures bellowing show.)
B: Slacken and remove the 3pcs socket headed screws and 1pcs pan-head screw which secure the inner
side board. Then we can detach the inner side board. ( As pictures bellowing show. )
C: Slacken and remove 1pcs socket headed screw and 1pcs pan-head screw which secure the armrest.
Then we can detach the armrest. ( As pictures bellowing show. )
Locate the 3pcs socket
headed screw.
Locate the 1pcs
pan-head screw.
Locate the screws which secure the
armrest.
The armrest has been detached.
Lever the side board at here.
The side board has been taken off.
The inner side board has been taken off.
