USER MANUAL
Portable Speaker System
with Bluetooth and FM-radio
pS-192
pS-195

ENG
2
Portable Speaker System
with Bluetooth and FM-radio
Congratulations on your purchase of the SVEN speaker system!
COPYRIGHT
© 2020. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some discrepancies may
occur. The information in this Manual is given on “as is” terms. The author and the
publisher do not bear any liability to a person or an organization for loss or damage
which has arisen from the information contained in this Manual.
BUYER RECOMMENDATIONS
•Unpack the device carefully. Make sure there are no accessories left in the box. Check up
the device for damage; if the product was damaged during transportation, address therm
which carried out the delivery; if the product functions incorrectly, address thedealer at once.
•Check up the package contents and availability of the warranty card. Make sure
thewarranty card has a shop stamp, a legible signature or the seller’s stamp and pur-
chase date, and the goods number corresponds to that in the warranty card. Remem-
ber: in case of warranty card loss or discrepancy of numbers you forfeit the right for
warranty repairs.
•Before installing and using the speaker system, read this Manual carefully and keep
it for future reference.
•Shipping and transportation equipment is permitted only in the original container.
•Does not require special conditions for realization.
•Dispose of in accordance with regulations for the disposal of household and computer
equipment.
APPLICATION
SVEN PS-192, PS-195 portable multimedia speaker systems with Bluetooth and FM-radio
is designed for operation with PC, notebooks and other mobile devices by means of data
transfer via Bluetooth protocol. It can be also used in Internet telephony, during video
conferences, in multimedia applications, in interactive games, for speech recognition and
foreign language teaching. FM-tuner and the player with USB-flash and micro SD-cards
are included.
PACKAGE CONTENTS
•Speaker system — 1 pc
•3.5 mm mini-jack to 3.5 mm mini-jack signal cable — 1 pc
•USB to micro USB power cable — 1 pc
•User Manual — 1 pc
•Warranty card — 1 pc
Technical support is on www.sven..

ENG
3
User Manual PS-192
PS-195
SPECIAL FEATURES
•Bluetooth wireless signal transmission
•Fast Bluetooth connection via NFC
•Wireless connection of two speakers to one source
•Built-in audio files player from USB-flash and microSD card storage devices
•Built-in FM tuner
•Wired connection
Speaker system description
a: Switch mode button: Bluetooth/FM/Player/LINE (short pressing);
POWER button (long pressing)
b: Play/Pause (short pressing in Player and Bluetooth mode);
Mute (short pressing in Radio and LINE mode);
Disconnecting from the sound source (long pressing in Bluetooth mode);
Automatic scan of radio stations (long pressing in Radio mode);
Connecting an additional speaker (long pressing)
c: Next track (in Player and Bluetooth mode); Next station (in Radio mode)
d: Next track (in Player and Bluetooth mode); Next station (in Radio mode)
e: Volume decrease
f: Volume increase
g3.5 mm mini-jack for audio signal connecting (phone, MP3 player, etc.)
hUSB flash connector
iMicro SD card slot
jIndicator
kMicro USB jack for connecting speakers to the charger, the USB port of laptop/PC
CONNECTION AND OPERATION
Attention! The built-in battery must be charged completely prior to the application.
Speaker system battery charging
•Connect speaker system to a USB port of PC or USB charger using micro USB to USB
cable (included). When charging, the indicator jlights up in red. Indicator jgoes out
if the battery is charged.
•The battery is used in the speaker system as an integral part of the device, therefore
do not try to extract or replace it, because this can result in the warranty cancellation
or the device damage.
Fig. 1.

ENG
4
Portable Speaker System
with Bluetooth and FM-radio
OPERATION MODES
Bluetooth mode
•Wireless data transfer via the Bluetooth protocol enables to connect speaker system to
compatible devises. Maximum radius of action of data transfer is 10 m. Such obstacles as
walls or other electronic devices can interfere with the signal transfer.
•Turn on the speakers in Bluetooth mode – press the button arepeatedly until the
іndicator jblinks blue short.
•It is necessary to select the search mode of devices with Bluetooth on a signal source
(telephone, notebook, smartphone, etc.). «SVEN PS-192/195» massage will be displayed
on the screen which is to be connected to*.
•When connection is successful, there will be a short beep and the indication of the search
mode on speaker system is over**.
Connecting to the speaker via Bluetooth using NFC
Attention! To connect the speaker to a smartphone, the smartphone must be equipped
with an NFC chip. It must be enabled in the wireless settings.
•Turn on the speakers in Bluetooth mode – press the button arepeatedly until the
іndicator jblinks blue short.
•Hold the phone close to the NFC mark on the top panel and wait for a short beep to
confirm a successful speaker connection.
Note. You need to allow connections on the phone (depending on the phone’s operating
system).
Radio mode
To improve radio reception, connect USB-microUSB cable (included) to the input kor
signal cable to the input g.
•Turn on the speaker system – press button aseveral times until, the radio mode
will turn on. Long-term pressing button bactivates auto search mode. After scanning
completion, the first scanned radio station will start to operate automatically. With
buttons cand dselect a desired radio station.
МР3 player mode
Attention! The file system of a micro SD or USB flash carrier is FAT32. Maximum volume
is 32 GB. It is not recommended to use the micro SD Ultra Speed.
•Insert the USB flash or micro SD carrier into appropriate slot. If the speaker system is
in turned on position, the playback will start automatically. Playback/Pause modes are
switched over with the help of the button b. Tracks can be controlled by buttons c
(previous track) and d(next track).
Connecting an additional speaker
It is poddible to connect an additional speaker to the model «SVEN PS-192/195»
(Bluetooth mode only):
Attention! Before connecting an additional speaker, disconnect both speaker from
signal source.
* You might have to enter «0000» code to connect some models of devices via Bluetooth.
** If the item has been already registered in the device list of a source, then the second
search mode activation is not obligatory. Choose the item name «SVEN PS-192/195» and
the «connect» command on the source.

ENG
5
User Manual PS-192
PS-195
The use in the wired mode (AUX)
•Speaker system can be used as an external device for amplifying any audio source
with a 3.5 mm output mini-jack. To do this, connect a cable 3.5 mini-jack – 3.5 mini-jack
to the audio output AUX g.
TECHNICAL SPECIFICATIONS
Parameter, measurement unit Value
Frequency range, Hz 100-20000
Output power (RMS), W 16 (2 × 8)
Membrane, mm Ø 45
Radius of operation Bluetooth, m up to 10
Battery capacity, mA*h 2400
Power supply USB / 5 V
Weight, g 850
Dimensions, mm 238 × 76 × 84
Notes:
• Technical specifications given in this table are supplemental information and cannot
give occasion to claims.
• Technical specifications and package contents are subject to change without notice
due to the improvement of SVEN production.
•Turn on both speakers (long press button a) and select Bluetooth mode. On both
speakers іndicator jwill flash white flashes.
•On one of the speakers, press and hold the button buntil a beep sounds, then release it.
The speakers will connect with each other.
Note. At the subsequent inclusion of both speakers, they will be connected
automatically.
Fig. 2. Connection diagram

Portable Speaker System
with Bluetooth and FM-radio
pS-192
pS-195
Models: PS-192, PS-195
Импортер вРоссии: OOO «Регард»,
105082,г.Москва, ул.ФридрихаЭнгельса,
д. 75,стр.5.Уполномоченная организация
вРоссии:ООО «РТ-Ф», 105082,г. Москва,
ул. Фридриха Энгельса, д. 56, стр. 1.
Условиягарантийного обслуживаниясмо-
тритевгарантийном талонеили на сайте
www.sven.fi.Гарантийный срок: 12 мес.
Срокслужбы: 2 лет.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, №02-02, Сингапур,
427447.Произведено под контролем
«Свен Скандинавия Лимитед», 48310,
Финляндия, Котка, Котолахдентие, 15.
Сделано в Китае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat
Road, № 02-02, Singapore, 427447.
Produced under the control of Oy Sven Scan-
dinavia Ltd.15,Kotolahdentie, Kotka, Finland,
48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
