Portable Speaker System with
Bluetooth and FM-radio
PS-400
USER MANUAL

Portable Speaker System with
Bluetooth and FM-radio
ENG
2
Congratulations on your purchase of the SVEN speaker system!
COPYRIGHT
© 2021. SVEN PTE. LTD. Version 1.0 (24.09.2021).
This Manual and information contained in it are copyrighted. All rights reserved.
BUYER RECOMMENDATIONS
• Unpack the device carefully. Make sure there are no accessories left in the box. Check up the
device for damage; if the product was damaged during transportation, address the firm which
carried out the delivery; if the product functions incorrectly, address the dealer at once.
• Shipping and transportation equipment is permitted only in the original container.
• Does not require special conditions for realization.
• Dispose of in accordance with regulations for the disposal of household and computer
equipment.
•The date of manufacture of the product is indicated on the box.
APPLICATION
SVEN PS-400 portable multimedia speaker system with Bluetooth and FM-radio is designed for
operation with PC, notebooks and other mobile devices by means of data transfer via Bluetooth
protocol. It can be also used in internet telephony, during video conferences, in multimedia
applications, in interactive games, for speech recognition and foreign language teaching.
Microphone input with echo function, FM-tuner and the player with USB-flash and micro SD-cards
are included.
PACKAGE CONTENTS
• Speaker system – 1 pc
• 3.5 mm mini-jack to 3.5 mm mini-jack signal cable – 1 pc
• USB to micro USB power cable – 1 pc
• User Manual – 1 pc
• Warranty card – 1 pc
SPECIAL FEATURES
• Wired/wireless audio signal transmission (Bluetooth)
• Effective multi-colored lighting
• Wireless connection of two speakers to one source
• Built-in player for audio files from USB-flash and micro SD card
• Built-in equalizer
• Microphone input with echo function
• Built-in FM tuner
• LED display

ENG
User Manual PS-400
3
Fig.1.
Speaker system description
aMIC +/-: microphone volume control knob
bM: switching modes button: Bluetooth/Radio/Player/LINE IN
cTWS: connecting an additional speaker (short pressing in Bluetooth mode)
dTF: micro SD card slot
eDisplay
f5V: micro USB jack for charger connecting, the USB port of laptop/PC
gIndicator
h: previous track (short pressing in Player and Bluetooth mode);
Navigation on the track (long pressing in Player mode);
Previous track/station (in Radio mode);
Disconnect from device (long pressing in Bluetooth mode);
Repeat mode selection button (long pressing in Player mode):
ONE – repeats the current track;
RND – play tracks in the random order;
ALL – plays all tracks in the sequential order;
FOD - playing tracks inside a folder
iEQ: EQ mode switch button (short pressing);
Turning on/off the backlight (long pressing)
jVOL +/-: volume control knob, power button
kECH-: microphone echo adjustment knob
lECH+: microphone echo adjustment knob
mUSB: USB-flash card slot
nAUX: 3.5 mm mini-jack for audio signal connecting (phone, MP3 player, etc.)
oMIC: 6.3 mm jack microphone jack
p: previous track (short pressing in Player and Bluetooth mode);
Navigation on the track (long pressing in Player mode); Previous track/station (in Radio mode)
q: next track (short pressing in Player and Bluetooth mode);
Navigation on the track (long pressing in Player mode); Next track/station (in Radio mode)

Portable Speaker System with
Bluetooth and FM-radio
ENG
4
CONNECTION AND OPERATION
Attention! The built-in battery must be charged completely prior to the application.
Speaker system battery charging
• Connect speaker system to a USB port of PC or USB charger using micro USB to USB cable
(included). During battery charging the indicator gis red. Indicator ggoes out when the battery
is charged.
• The battery is used in the speaker system as an integral part of the device, therefore do not try
to extract or replace it, because this can result in the warranty cancellation or the device damage.
OPERATION MODES
Bluetooth mode
• Wireless data transfer via the Bluetooth protocol enables to connect speaker system to
compatible
devises. Maximum radius of action of data transfer is 10 m. Such obstacles as walls or other
electronic devices can interfere with the signal transfer.
• Turn on the speaker system Bluetooth mode – press button М bseveral times until display
shows «bt» inscription.
• It is necessary to select the search mode of devices with Bluetooth on a signal source (telephone,
notebook, smartphone, etc.). «SVEN PS-400» massage will be displayed on the screen which is to
be connected to*.
• When connection is successful, there will be a short beep and the indication of the search mode
on speaker system is over**.
Radio mode
Attention! To improve the reception quality of the radio signal, connect the 3.5 mm mini-jack cable
(included) to the AUX input nor USB-microUSB cable (included) to 5V input f.
• Turn on the speaker system – press button М bseveral times until the display shows the station
frequency. Long-term pressing button hactivates auto search mode. After scanning completion,
the first scanned radio station will start to operate automatically. With buttons pand qselect a
desired radio station.
Player mode
Attention! The file system of a micro SD carrier is FAT32. Maximum volume is 32 GB.
It is not recommended to use the micro SD Ultra Speed.
• The system will enter the Player mode automatically when a carrier (USB flash or SD card) is
connected to corresponding ports. Use button hto switch between Play/Pause modes. You can
control tracks by using buttons p(previous track) and q(next track).
The use in the wired mode (LINE IN)
• Speaker system can be used as an external device for amplifying any audio source with a 3.5 mm
output mini-jack. Connect a cable mini USB, plug 3.5 mini-jack to the audio input AUX n. Turn the
speakers to the LINE IN mode – press the M button bseveral times until «LINE» appears on the
display.
* You might have to enter «0000» code to connect some models of devices via Bluetooth.
** If the item has been already registered in the device list of a source, then the second search mode
activation is not obligatory. Choose the item name «SVEN PS-400» and the «connect» command on
the source.

ENG
User Manual PS-400
5
Connecting an additional speaker
For «SVEN PS-400» you can connect an additional speaker (Bluetooth mode only):
• Turn both speakers into Bluetooth mode.
• Connect the signal source to one of the speakers via Bluetooth (the second column should be in
search mode).
• On another speaker press button TWS.
TECHNICAL SPECIFICATIONS
Notes:
• Technical specifications given in this table are supplemental information and cannot give
occasion to claims.
• Technical specifications and package contents are subject to change without notice due to the
improvement of SVEN production.
Parameter, measurement unit Value
Frequency response, Hz 100 – 20 000
Output power (RMS), W 12
Speaker diameter, mm Ø 108
Battery capacity, mA*h 1 200
Rated current consumption, A 0.20
Power supply USB/⎓5V
Weight, g 1 400
Dimensions, mm 252 × 330 × 177
Technical support is on www.sven..
Fig. 2. Connection diagram

Portable Speaker System with
Bluetooth and FM-radio
PS-400
Model: PS-400
Importer: Tiralana OY, Office 102, Kotolahden- tie 15, 48310
Kotka, Finland.
Импортер в России: ООО «РЕГАРД», 105082, г. Москва,
ул. Фридриха Энгельса, д. 75, стр. 5.
Уполномоченная организация в России: ООО «РТ-Ф»,
105082, г. Москва, ул. Фридриха Энгельса, д. 56, стр. 1.
Условия гарантийного обслуживания смотрите в
гарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес.
Срок службы: 2 года
Производитель: «СВЕН ПТЕ. Лимитед», 176 Джу
Чиат Роуд, № 02-02, Сингапур, 427447. Произведено
под контролем «Свен Скандинавия Лимитед», 48310,
Финляндия, Котка, Котолахдентие, 15.
Сделано в Китае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road, № 02-
02, Singapore, 427447. Produced under the control of Oy
Sven Scandinavia Ltd. 15, Kotolahdentie, Kotka, Finland,
48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
