Sven MS-2000 User manual

www.sven.fi
OPERATION
MANUAL
2.1 Hi-Fi Multimedia
Speaker System
MS-2000

Congratulations on your purchase of the Sven speaker system!
COPYRIGHT
© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some discrepancies may occur. The
information in this Manual is given on “as is” terms. The author and the publisher do not bear any
liability to a person or an organization for loss or damage which has arisen from the information
contained in this Manual.
CONTENTS
1. BUYER RECOMMENDATIONS ..................................................
.............
2. PACKAGE CONTENTS............................................................. ............
3. SAFETY PRECAUTIONS .................................................. ...................
4. TECHNICAL DESCRIPTION .................................................... ................
5. PREPARATION AND OPERATION ..........................................
......................
6. OPERATION MODES .................................
...............................................
7. TROUBLESHOOTING................................. ...............................................
8. TECHNICAL SPECIFICATIONS .................................................... ...........
1
2
2
2
5
6
8
8
1. BUYER RECOMMENDATIONS
•Unpack the device carefully. Make sure there are no accessories left in the box. Check up the
device for damage; if the product was damaged during transportation, address the firm which
carried out the delivery; if the product functions incorrectly, address the dealer at once.
•Check up the package contents and availability of the warranty card. Make sure the warranty
card has a shop stamp, a legible signature or the seller’s stamp and purchase date, and the goods
number corresponds to that in the warranty card.
• Do not switch on the speaker system immediately after you bring it into a room from environment
with negative temperature! After unpacking, the speaker system should be kept in conditions of
room temperature for at least 4 hours.
•Before installing and using the speaker system, read this Manual carefully and keep it for future
reference.
Technical support is on www.sven.fi.
ENG
1
Operation Manual MS-2000

2. PACKAGE CONTENTS
• Subwoofer – 1 pc
• Satellites – 2 pcs
• Remote control (RC) – 1 pc
•Audio cables – 2 pcs
•2RCA to mini-jack signal cable – 1 pc
• AAA type batteries – 2 pcs
•Antenna wire – 1 pc
• Satellite wall-mounting sets – 2 pcs
• Operation manual – 1 pc
• Warranty card – 1 pc
3. SAFETY PRECAUTIONS
•To avoid electric shock, do not open the MSS and do not perform repairs by yourself. Service and
repairs should be performed only by qualified specialists in an authorized service center. The list of
authorized service centers is available on www.sven.fi
•Do not allow the circuit of wires (including the grounded ones) between the speakers, on the
power amplifier or the ground, for it causes damage to the power amplifier output stage.
•Do not touch the MSS power cord plug pins for 2 seconds after unplugging it from the mains.
•Do not put foreign objects inside the holes of the MSS.
•Protect the MSS from high humidity, water and dust.
•Protect the MSS from heating: do not place it closer than 1 m from a heat source. Do not expose
it to direct sunlight.
•Do not place any open flame sources on or close to MSS.
•Do not place the MSS in poorly ventilated areas. Leave an air gap of 10 cm or more. When
operating the MSS, do not put any devices on it, do not cover it with cloth or other objects pre-
venting it from cooling.
•Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.
4. TECHNICAL DESCRIPTION
MS-2000 2.1 Multimedia Speaker System (MSS) is designed to play music and sound games,
movies, etc. The MSS has a built-in power amplifier and audio cables allowing to connect it to
virtually any audio source (CD/DVD-player, TV, PC, etc.) without using an additional power
amplifier. The MSS has a built-in FM radio, audio player and a clock. Remote control is included.
Special features
•Speaker system is compatible with PCs, DVD/Media-players, mobile devices and other sound
sources
• Built-in FM radio and clock
•Digital LED display
•Built-in player for audio files from external storage devices
•USB flash port and SD card slot
•Two switchable inputs
Caution! High voltage inside! To avoid the risk of electric
shock do not open or touch elements inside.
ENG
2
2.1 Hi-Fi Multimedia
Speaker System

Fig. 2. Subwoofer side panel
•Remote control
•StandBy, Mute and Sleep modes
•Adjustable display brightness
Subwoofer control panels
aLED display
bINPUT: input switch, PC/AUX/FM/MP3 mode
switch (pressed short)
cVOL-/СН-/ : previous track (pressed short in
the Player mode);
previous station* (pressed short in the Tuner
mode);
volume/timbre down (pressed long)
dTIMBRE: bass/treble selection (pressed
short in any mode)
eST-BY/AUTO/ : play/pause (pressed short in
the Player mode);
start/stop auto scan (pressed short in the Tuner
mode);
Standby mode (pressed long in any mode)
fVOL+/СН+/ : next track (pressed short in
the Player mode);
next station* (pressed short in the Tuner mode);
volume/timbre up (pressed long)
gSD/MMC CARD: slot for SD/MMC cards**
containing МР3 audio files
hU DISK: slot for a USB flash device** con-
taining МР3 audio files
iON/OFF: power switch (see Fig. 3)
jPower cord
kRADIO ANT: radio antenna input jack
lPC AUDIO INPUT: PC input jack
mAUX AUDIO INPUT: line input jack
nAUDIO OUTPUT: satellite output terminals
Remote control (see Fig. 4)
aSD: MP3 player mode switch-on button
(playing MP3 files from an SD card**)
bUSB: MP3 player mode switch-on button
(playing MP3 files from a USB flash device**)
cAUTO: start auto scanning and memorizing
stations in FM band (in the Tuner mode)
dTUNE+/-: manual band scanning (in the Tuner
mode)
Fig. 1. Subwoofer control panel
TRE BASS SLEEP PC
MP3 FM AUX IR
++VOL- CH VOL CH-
TIMBRE
ST.BY///AUTO
bacdef
g
h
SD/MMC
CARD
U DISK
ENG
3
Operation Manual MS-2000

FM
ANT
k
l
m
n
j
i
AUX
PC
R
R
L
L
OFF
ON
AUDIO OUTPUT
RA DIO A NT
AUDIO INPUT
R
L
POWER SWITCH
a
n
c
d
d
e
f
h
j
k
g
b
p
r
t
s
f
w
y
x
v
u
q
BASS
EBLE
SLEEP
-
SET
CLOCK
100- 100+ 10- 10+
TR - TREBLE +BASS+
VOL
SW
12 3
456
987
EQ- EQ+ DISP- DISP+
+
-
+
-
+
SLEEP- TUNE-
TUNE+
CH+
CH-
SA EV
AOUT
USB FM AUX PC
MU ET
SD
0RESET
REPEAT
i
l
om
i
26
eCH-/ : previous track (pressed short in the Player
mode*)
previous station* (pressed short in the Tuner mode)
fSLEEP+/-: Sleep mode switch-on time setting
gTREBLE+/-: treble level up/down
hSW+/-: subwoofer volume control
i10+/-, 100+/-: track number multiplier
j0-9: numeric pad
kREPEAT: player operation mode selection
lEQ+/-: equalizer mode selection but- ton (in the
Player mode only)
mFM: enter the Tuner mode
n: On/Offswitch
oAUX: AUX input selection button
pMUTE: sound on/off
qPC: PC input selection button
rSAVE: memorize selected frequency
(in the Tuner mode)
s: Play/Pause (in the Player mode)
tCH+/ : next track (pressed short in the
Player mode)
next station* (pressed short in the Tuner
mode)
uBASS+/-: bass level up/down
vSET: time setting (in the ST-BY mode)
Fig. 3. Subwoofer rear panel
Fig. 4. Remote control
ENG
4
2.1 Hi-Fi Multimedia
Speaker System

ENG
5
Operation Manual MS-2000
wVOL+/-: volume control
xCLOCK: show current time
Battery Installation
• Open the battery compartment on the back of the remote control.
• Insert the included AAA batteries.
• Close the battery compartment.
Notes:
• Use the RC at an angle no more than 30° at a distance of no more than 7 meters.
• Direct the remote control at the LED display on the subwoofer.
• If the remote control does not work, check the batteries or replace the discharged
batteries with new ones.
• Remove the batteries from the RC if you don’t intend to use it for a long time.
* The frequencies are switched if there are stations preset in the memory.
** The storage device must be formatted as FAT, FAT32. Connecting devices other than USB flash drive is
not recommended. Connection of HDDs and other devices can cause damage to the MSS.
5. PREPARATION AND OPERATION
Speaker placement
•Place the speakers symmetrically to the listener at least one meter away. The subwoofer emits
non-directional sound, therefore it can be located in any place of the room where it sounds the best.
•Place MSS far away from monitors and TV sets, as insignificant image distortion in these super-
sensitive devices is possible.
Installation and operation
MS-2000 speaker system can be connected to virtually any audio devices: DVD/CD players, PCs,
laptops, etc. (see connection diagram in Fig. 5).
• Before making any connections, make sure the MSS is offand unplugged. Then connect speakers
to the subwoofer AUDIO OUTPUT L/R nterminals with the help of included audio cables. Observing the
polarity connect the right speaker to the subwoofer AUDIO OUTPUT R with the audio cable and the left
speaker – to the AUDIO OUTPUT L. Pay attention that the plus (red) cable wires of speakers must be
connected to the subwoofer plus terminals (+ →+) and the minus ( black) cable wires of speakers – to the
subwoofer minus terminals (– →–) (see connection diagram in Fig. 5).
Note. Check the reliable fixation of wires in the terminals, polarity of connection and
absence of contact of the bared wires with each other and the metal parts of the hardware.
• To connect the MSS to a PC, МР3/CD player, use a 2RCA to mini-jack signal cable (included).
Insert the RCA jacks of the signal cable into the L and R jacks of the PC AUDIO INPUT l, and the
mini-jack of the signal cable – into the LINE OUT port of your PC sound card or an audio output of
your МР3/ CD player, as shown in Fig. 5.
• To connect the MSS to a TV or DVD/CD player, use a 2RCA to 2RCA signal cable (not included).
Insert the RCA jacks of the signal cable into the L and R jacks of the PC AUDIO INPUT l, and the
other RCA jacks – into your TV or DVD/CD player audio output jacks, as shown in Fig. 5.
•Connect the subwoofer to the mains outlet with the power cord j.
•Turn on the MSS power supply using the ON/OFF switch (i, ON) on the subwoofer rear panel.
26
yRESET: return to default settings
DISP+/-: adjust display brightness

CD
PC
DVD
Player
FM
ANT
Right
speaker
FM antenna
2RCA to 2RCA
signal cable
2RCA to mini-jack
signal cable
AUX
PC
R
R
L
L
OFF
ON
Left
speaker
SD/MMC
CARD
U DISK
USB/SD-card
connection
SD
USB
CD player
AUDIO OUTPUT
RA DIO A NT
AUDIO INPUT
R
L
POWER SWITCH
Fig. 5. Connection diagram
• Turn on the MSS with button eon the front panel or button non the remote control.
• Select a signal source using the INPUT bbutton on the control panel or remote control buttons:
SD a, USB b, AUX o, PC q, FM m.
• Adjust the master volume as desired with VOL- cand VOL+ fbuttons on the control panel or
with the VOL+/- wbutton on the remote control.
• Adjust the bass and treble level using the TIMBRE dand c, fbuttons on the
control panel or the BASS+/- uand TREBLE+/- gbuttons on the remote control.
• To adjust the subwoofer volume, use the SW+/- hbuttons on the remote control.
• To listen to the radio, connect the antenna to the RADIO ANT kjack (see Fig. 5) and adjust it for
better reception.
• After using the MSS, mind to switch it offusing the ON/OFF switch (i, OFF position) and unplug
the power cord jfrom the socket.
6. OPERATION MODES
Player Mode
• The system will automatically enter the Player mode when a USB device is connected to the USB
port hor an SD card is inserted into the corresponding slot g; or press the INPUT bbutton on
the front panel or the SD a/USB bbuttons on the remote control. The display awill show the
selected mode, then the number of the tracks found and the number of the track played, and then
the playback time elapsed. The files will automatically start playing. The playing device symbol will
show on the display as well.
* Please observe the polarity connecting the satellites.
ENG
6
2.1 Hi-Fi Multimedia
Speaker System

• To select the track, you can enter its number on the remote control using the numeric pad but-
tons jor select it using buttons cand fon the front panel. The display will show the track
number for a short moment, and then the playback time elapsed.
• You can select a playback mode using the remote control REPEAT kbutton («ONE» – repeat the
playing track; «RND» – play random tracks; «ALL» – play all tracks available).
• In the Player mode, Equalizer feature is available. To select a preset mode, use the EQ lbutton
on the remote control.
* The MSS operation may be incorrect if an SD card of 512 Mb capacity or lower is used. If a USB
flash device of 8 Gb capacity or more is used, command processing time may be extended.
Tuner Mode
• To switch to the Tuner mode, use the INPUT bbutton on the front panel or the FM mbutton on
the remote control. The subwoofer display awill show the FM inscription.
• To auto scan and memorize the found stations, press button eon the front panel or the AUTO c
button on the remote control short. To stop auto scanning, press this button again before the
scanning is over. The display dwill show the frequency being scanned. When the channel is being
memorized, the display shows its number for a short moment.
• For manual scanning, use buttons TUNE-/+ don the remote control (up/down the frequency
range). To save the selected station, press the SAVE rbutton on the remote control and then,
using buttons cand fon the front panel or buttons eand ton the remote control, assign the
station its number and press the SAVE button again. When the station has been memorized, the
display awill write “Good”.
• If preset stations are available in the memory, you can switch from one to another by short pressing
buttons c, fon the front panel or buttons e, ton the remote control. You can also enter the
frequency or the number of the preset station with the remote control numeric pad buttons. The
display will show the station number for a short moment and then its frequency.
The radio will tune to the set frequency within 2-3 seconds.
AUX/PC Mode
• To switch to the AUX/PC mode, press the INPUT bbutton on the front panel or buttons q
PC/oAUX on the remote control, the MSS switched on. The display awill show AUX or PC.
Clock Mode
• When the MSS is in the ST-BY mode, the display ashows the current time. When the system is in
a different mode, to see the time, use the CLOCK xbutton on the remote control. The current time
will show for 3-5 seconds.
• To set the current time, go to the ST-BY mode by pressing button eon the front panel or button n
on the remote control long. To enter the time setting mode, press the SET vbutton on the remote
control (the corresponding position will start blinking on the display a). Set the minutes and hours
directly from the RC numeric pad or using buttons c, fon the front panel or e, ton the RC. To
switch between setting hours/minutes and to exit the setting mode, press the RC SET vbutton
short.
ST-BY Mode
• To enter/exit this mode, press and hold down button eon the front panel or button non the RC.
When the MSS is in the ST-BY mode, the display ashows the current time.
MUTE Mode
• To enter the MUTE mode, press button pon the remote control. To exit the MUTE mode, press
this button again.
ENG
7
Operation Manual MS-2000

Notes:
•Technical specifications given in this table are supplemental information and cannot give
occasion to claims.
•Technical specifications and package contents are subject to change without notice due
to the improvement of SVEN production.
Parameter, measurement unit
Output power (RMS), W:
subwoofer
satellites
Frequency response, Hz:
subwoofer
satellites
Speaker diameter, mm:
subwoofer
satellites
Power supply, V/Hz
Dimensions, mm:
subwoofer
satellites (one speаker)
Weight, kg
8. TECHNICAL SPECIFICATIONS
Value
40 (18 + 2 × 11)
18
2 × 11
50 – 150
150 – 20,000
Ø 133
full-range Ø 80
~220/50
140 × 273 × 280
95 × 152 × 95
4.3
If none of the above methods can solve the problem, please seek professional advice at your
nearest service center. Never attempt to repair the product yourself.
Note. Due to the constant development of the software, the actual MSS operation may differ
from that described in this manual. The most recent version of the manual is available at
www.sven.fi.
Problem
The MSS does not
turn on.
No sound or the
sound is too quiet.
Distortion of sound.
The remote control
is not working.
Cause
The MSS isn’t connected to a mains
outlet.
The power switch is off.
Volume level is set at minimum value.
Improperly connected audio source.
Large amplitude of the input signal.
The batteries are discharged.
Solution
Check the connection.
Turn on the switch.
Adjust the volume control knob.
Connect the audio sources correctly.
Turn down the source volume
and the MSS volume.
Replace the batteries with new ones.
7. TROUBLESHOOTING
ENG
8
2.1 Hi-Fi Multimedia
Speaker System

2.0 Multimedia Speaker System
Automatic Voltage Regulator
Стабилизатор напряженияСтабилизатор напряжения
Automatic Voltage Regulator
2.0 Multimedia Speaker System2.0 Multimedia Speaker System
SPS-619
Модель: MS-2000
Импортер вРоссии: ООО «СКАНДИТРЕЛ»,
111024, РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация вРоссии: ООО «РТ-Ф»,
105082, г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
вгарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес.
Срок службы: 5 лет.
Производитель: «СВЕН ПТЕ. Лимитед», 176
Джу Чиат Роуд, №02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка, Котолахдентие, 15.
Сделано вКитае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,
№02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland. MS-2000
2.1 Hi-Fi Multimedia
Speaker System
