sWaP Nova User manual
.
Nova
user guide
www.s-w-a-p.co.uk
.
1
sWaP Nova user guide www.s-w-a-p.co.uk
Contents
Welcome to your sWaP™Nova 2
Getting started 3
Inserting your SIM card 3
Charging the battery 3
Switching on and off 4
Using the stylus 4
Removing/inserting the memory card 4
Pen Calibration 4
The clock face 4
Menu map 5
Dialling a call 5
Answering a call 5
Voice activation 5
Ending a call 5
Viewing previously dialled calls 5
Using speed dial 5
In-call options 6
Call history 6
Using the wired earphones 6
Your Phone book (Contacts) 7
Adding a new entry 7
Copying entries 7
Finding an entry 7
Other Phone book options 7
Messages 8
SMS messages 8
MMS messages 10
Voice mail server 11
Broadcast message 11
Media 12
Photo album 12
Video player 12
Audio player 13
Sound recorder 14
FM radio 14
WAP 15
Settings 16
Pen Calibration 16
Organizer 16
File manager 18
Stopwatch 18
User Profiles 19
Phone Setup 19
Call Setup 20
Network Setup 20
Security Setup 21
Restore Factory Settings 21
USB link to your computer 22
Important safety information 23
Exposure to radio frequency (RF) signals 23
Operational precautions 23
Medical devices 23
Batteries 24
Vehicles 24
Specific Absorption Rate (SAR) 24
EU directives 25
FCC warning 25
contents
.
2
sWaP Nova user guide www.s-w-a-p.co.uk
Contents
Welcome to your sWaP™Nova
The most compact multifunction mobile you’ve ever owned.
Please also take a moment to read the important safety information located at the rear of this guide.
1.76” high resolution
touch screen
Speaker
Call button
End button
Power button
Microphone
Slide out
USB port
Options port
Up/down button
Things that you can do:
•Insert your SIM card page 3
•Charge the battery page 3
•Switch on page 4
•Dial/answer a call page 5
•Use the earphones page 6
•Use the phone book page 7
•Use messaging page 8
•Use multimedia applications page 12
•Access websites page 15
USB port eject button
Stylus
SIM card slot Micro SD
memory card
.
3
sWaP Nova user guide www.s-w-a-p.co.uk
Contents
0% 100%
Getting started
Inserting your SIM card
Note: Avoid touching the gold contacts of your SIM card.
1 Slide out the stylus from the side of your Nova to reveal
the recessed SIM card slot.
2 Slide your SIM card, with its gold contacts upwards and
its notched corner towards the Nova, carefully into the
slot.
3 Use the end of the stylus to push the SIM card all the
way into the slot until it clicks into place.
CLICK!
Charging the battery
You can charge your sWaP Nova using the USB port on your computer and there are two ways to connect it:
•UsingtheslideoutUSBport,or
•UsingthesuppliedUSBconnectioncable.
Your sWaP Nova can be switched on or off when it is charging.
While charging, the battery indicator on the display will show the progress:
USB
Charging using the slide out USB port
1 On the underside of your sWaP Nova, slide the USB
port button towards the base. The USB connector will
be revealed.
2 Carefully insert the USB connector into a vacant socket
on your computer. TIP: Keep your finger on the USB
port button to prevent the connector from retracting
back into sWaP Nova.
3 If your computer is not already switched on, switch it
on to start charging your sWaP Nova.
Charging using the supplied USB connection cable
1 Carefully insert the small plug of the supplied USB cable
into the Options port at the base of your sWaP Nova.
Note: Be sure to insert the plug into the correct socket
and in the correct orientation. The Options port is the
smaller socket, just above the slide USB port. It has
rounded corners on its lower side corresponding to
similar corners on the plug.
2 The other end of the cable has a standard USB plug
which you can attach to your computer.
3 If your computer is not already switched on, switch it
on to start charging your sWaP Nova.
Options
port
PC
.
4
sWaP Nova user guide www.s-w-a-p.co.uk
Contents
Switching on and off
Press and hold the upper button until the screen
responds, then release.
Using the stylus
The stylus is a slide out pointer with which you can
select items more accurately on the touch screen. It
is stored in the slot along the right side of your sWaP
Nova.
Removing/inserting the memory card
Your sWaP Nova comes with a 2 GigaByte memory
card to store all of your messages, pictures, videos and
other information. You do not normally need to remove
the memory card, however, there may the occasional
need to transfer memory content to, or from, another
similarly equipped device.
The memory card conforms to the Micro SD standard
and is cleverly hidden within the slide out USB port.
1 On the underside of your sWaP Nova, slide the USB
port button towards the base. The USB connector will
be revealed.
2 Within the underside of the USB connector you will see
the end of the concealed memory card. With a finger
nail, prise out the memory card from the connector.
To reinsert the card, ensure that it is oriented as above
and then carefully push it into the slot within the USB
connector.
The clock face
When your sWaP Nova is not engaged in other
activities, it will display a clock face (analog or digital):
saWP
14
Analog clock face
Tap here to
access the
main menu
Tap here to
access your
Phone book
Digital clock face
Name of the
current network
The chosen clock face will overlaid with the current
network name plus selectable options (in the two lower
corners). The top edge of the clock face will also show
one or more of the following status icons:
Signal level (0 to 4 bars)
Battery charge status
?
Missed call
SMS message(s) received
MMS message(s) received
GPRS data connection available
Earphones attached
Auto keypad lock is off
Auto keypad lock is on
Bluetooth function enabled
Alarm set
User profile set to use ring alert only
User profile set to use vibrate first and then ring
User profile set to use vibrate and ring alerts
User profile set to use vibration alert only
Stopwatch running
Pen Calibration
For best results, we recommend that you calibrate the
screen of your new sWaP Nova. This will ensure the
best accuracy between your stylus movements and the
reaction of the screen.
1 From the clock face, tap the Menu link in the lower left
corner of the screen.
2 Tap (twice, if necessary).
3 Tap Pen Calibration and then follow the on screen
instructions, using the stylus to tap where instructed.
TIPS:
•Whentappingonthedisplayedtouchpoints,viewthe
screen exactly as you would in normal operation.
•Forbestresults,gothroughtheproceduretwice.
•Repeattheprocedureonceamonthtokeepaccuracy
at the opimum level.
.
5
sWaP Nova user guide www.s-w-a-p.co.uk
Contents
Menu map
From the clock face, tap the Menu option (or press the lower button) and then choose one
of six icons:
SETTINGS
Pen Calibration
Organizer
Calendar
To Do List
Alarm
World Clock
Calculator
Bluetooth
File Manager
User Profiles
Phone Setup
Call Setup
Network Setup
Security Setup
MEDIA
Photo Album
Video Player
Audio Player
Sound Recorder
FM Radio
WAP
WAP
Data Account
CALL LOG
Missed Calls
Dialed Calls
Received Calls
Delete Call Log
Call Time
SMS Counter
GPRS Counter
MESSAGES
SMS
MMS
Voice Mail Server
Broadcast Message
CONTACTS
Search Entry
Add Entry
Copy All
Delete
Caller Group
Settings
Tap the Back option or press to exit from the menu and return to the clock face.
Dialling a call
1 From clock face, tap and hold the
screen for 2 seconds to show the
dial page:
2 Tap the phone number and then
press Alternatively, tap to
access your Phone book.
123
456
789
0
#
Answering a call
•Whenthecallalertsounds,press to answer.
Alternatively, to reject the call, press or tap Reject
in the lower right corner.
Voice activation
•Fromtheclockface,pressandholdthedownbutton
(located on the side of your sWaP Nova), and then say
either “CALL xyz” or “FIND xyz”, where xyz is a Phone
book contact name.
Ending a call
•Pressthe button or tap Option in the lower left
corner and then tap End.
Viewing previously dialled calls
•Press when no numbers are entered.
Using speed dial
•Tapandholdanumberbetween1and 8to dial one of
your most commonly used contacts*.
•Tapthe button to view your list of speed dial
contacts. Here you can edit an entry, delete an entry, or
call an entry (highlight the required entry and press
to place the call).
* To use speed dial, you need to first store your special
contact numbers - use the button or see Speed Dial
within the Phone Setup section.
.
6
sWaP Nova user guide www.s-w-a-p.co.uk
Contents
In-call options
During a call you can access a number of features by
tapping Option:
•Hold single call - Place the call on hold*
•End single call - End the current call
•New Call - Dial a new number*
•Phone Book - Access your Phone Book
•Message - Access your messages
•Sound Recorder - Record the call
•Call background sound - Select from a range of
sound effects to play in the background of your call.
In the call screen, you can also:
•Tap to re-display the numeric keypad.
•TapH-Free to activate the loudspeaker.
Tap H-Held to return to quiet mode.
*Network support required.
Call history
Your sWaP Nova maintains records of all incoming,
outgoing and missed calls as well as text message
quantities and data usage. You can use these records
to make calls, populate your Phone book and/or keep
track of your call charges.
1 From the clock face, tap Menu.
2 Tap (twice, if necessary) to view the Call history
options:
•MissedCalls
•DialedCalls
•ReceivedCalls
•DeleteCallLog
•CallTime
•SMSCounter
•GPRSCounter
Select the required item to view a list of related options
or details.
Using the wired earphones
The supplied earphones and microphone can be used
to listen to music/videos/FM radio as well as making
and taking calls.
1 Carefully insert the right-angle plug of the earphones
into the Options port at the base of your sWaP Nova.
The small button on the microphone pod can be used
to answer* and terminate calls.
*Within the Headset profile, if the Answer Mode
option is set to Auto, then calls will be answered
immediately - you can alter this. See the Settings
section for details.
.
7
sWaP Nova user guide www.s-w-a-p.co.uk
Contents
Your Phone book (Contacts)
Your Phone book is where you store all of your contact
details for quick access and rapid dialling.
There are two main ways to enter your Phone book
(Contacts):
•Fromtheclockface,tapContacts.
The list of Phone book contact entries will be shown.
or
•Fromtheclockface,tapMenu. Then tap (twice, if
necessary).
The main Phone book menu will be shown.
Note: When adding new entries, for best results with
voice activation, store all contact names with the first
character in capitals followed by lower case characters.
Adding a new entry
To add a new entry you need to enter the Phone book
via the Menu:
1 From the clock face, tap Menu.
2 Tap (twice, if necessary).
3 Tap Add Entry.
4 Choose where to store the entry: Tap either To SIM or
To Phone. The latter uses the sWaP Nova memory and
allows more details to be stored.
5 Use the labelled information fields to enter the relevant
details about your contact. See the note on the left.
For contacts stored within the sWaP Nova memory,
you can associate an image and/or a particular ring
tone to each person. You can also collect your contacts
into groups, such as Friends, Family, Business, etc.
These options are located lower down in the list of
information fields.
Copying entries
You can copy all of the contacts from your SIM card to
the sWaP Nova memory and vice versa.
1 From the clock face, tap Menu.
2 Tap (twice, if necessary).
3 Tap Copy All.
4 Tap either From SIM or From Phone as appropriate.
Importing contacts from another phone
The simplest way to import contacts is to use your SIM
card as a carrier.
1 Fit your SIM card into the other phone.
2 Copy the contacts from the phone memory to the SIM
card.
3 Fit your SIM card into your sWaP Nova.
4 Use the Copying entries procedure (above) to transfer
the contacts across to your sWaP Nova memory.
Finding an entry
You can find entries in two main ways: By scrolling
through the list of contacts; or by entering one or more
characters of the name to make a search.
Finding an entry by scrolling:
1 From the clock face, tap Contacts.
2 Tap the up or down arrows (or use the up/down
button) to scroll through the list.
3 When the required entry is highlighted, tap to dial or
tap Option to send a message or edit the entry.
Finding an entry by searching:
1 From the clock face, tap Menu.
2 Tap (twice, if necessary).
3 Tap Search Entry.
4 Enter one or more characters of the name and then tap
Done.
5 When the required entry is highlighted, tap to dial or
tap Option to send a message or edit the entry.
Other Phone book options
There are numerous other things that you can do
within your Phone book. Here are just a few:
•Voice activation: From the clock face, press and hold
the lower button, and then say either “CALL xyz” or
“FIND xyz”, where xyz is a contact name.
•SendSMSorMMSmessagestoacontactbystarting
from the Phone book. Enter the Phone book via
Contacts (Option: Send SMS or Send MMS).
•Duplicateanentryandtheneditthecopytosimplify
the creation of similar entries. Enter the Phone book via
Contacts (Option: Duplicate).
•Editcharacteristicsforyourcallergroupsorcreatenew
caller groups in which to collect your contacts. These
groups are particular useful when you need to regularly
send messages to more than one person. Enter Phone
book via the menu (Option: Caller Group).
•DeleteentriesindividuallyorcleartheentireSIMcard
or sWaP Nova memory. Enter Phone book via the menu
(Option: Delete).
•Checkhowmuchmemoryspaceyouhaveremaining.
Enter Phone book via the menu (Option: Settings >
Memory Status).
•Choosewhichmemoryyouprefertousetostore
contacts: SIM or Phone. Enter Phone book via the
menu (Option: Settings > Preferred Storage).
•CreateavCardcontainingyourcontactdetailswhich
you can easily send to other people, rather like an
electronic business card. You can send your vCard
either via SMS or MMS messaging, Bluetooth link or as
a file that can be downloaded to a computer via the
USB cable. Enter Phone book via the menu (Option:
Settings > My vCard).
.
8
sWaP Nova user guide www.s-w-a-p.co.uk
Contents
Messages
Your sWaP Nova enables you to stay in contact using
two different kinds of messages. SMS is the method
supported by all mobile phones which allows text
plus certain small media attachments to be sent and
received. MMS is the newer format that allows you to
send and receive larger photos, video clips and sound
recordings, in addition to text.
When an incoming message is received, your sWaP
Nova will alert you and display the sender’s number*
or their name if they are listed in your Phone book. The
clock face will also show the icon until you have
read the message.
•TapRead to go straight to the message immediately.
or
•Fromtheclockface,tapMenu. Tap (twice, if
necessary). Then tap either SMS or MMS and then
tap Inbox.
* Subject to availability.
Writing an SMS message
1 From the clock face, tap Menu.
2 Tap (twice, if necessary).
3 Tap SMS, then Compose Message.
4 Tap out or handwrite your message within the editor
page:
5 You can optionally add other elements to your
message. Tap Option:
•Insert number from your Phone book.
•Insert name from your Phone book.
•Insert object to add small images, animations or
melodies.
•Format text to change the size, style and alignment
of the characters.
•Use templates to quickly add a standard phrase to
your message.
•Insert bookmark to add internet addresses stored in
the WAP browser.
Note: Not all mobile phones are able to display or play
media attachments or show text formatting.
6 When your message is complete, tap Option and then
tap Done.
You can now choose how to send and/or save the
message: Send to one person, send to a list of people,
send to one of the your groups, or just save the
message for later.
7 Tap the required send/save option and then either enter
the phone number (or tap Search to find a Phone book
entry) or choose the group of recipients.
8 Tap OK to send/save your message.
If you chose to save your message, it will be stored in
the Outbox, which you can choose from the main
Messages menu.
Message display area - you can
also use the stylus to hand write
characters into this area.
Show/hide
punctuation
characters
Show other
characters
Space bar
Change between upper and
lower case plus numeric
characters
SMS messages
.
9
sWaP Nova user guide www.s-w-a-p.co.uk
Contents
Reading an SMS message
1 From the clock face, tap Menu.
2 Tap (twice, if necessary).
3 Tap SMS, then tap Inbox. The list of received messages
will be shown, each listed with either the phone
number or the name (if in the Phone book) of its
sender.
The prefixed envelope icon will be shown closed for
unread messages or open for previously viewed ones.
4 Tap the required message to open it.
5 Tap Option to view the range of actions available to
you:
•Reply allows you to compose and send a response to
the original message.
•Delete removes the currently opened message.
•Edit allows you to alter the message and then send it
to one or more new recipients.
•Forward allows you to send the message to one or
more new recipients without editing.
•Multi operation allows you to choose a selection of
messages and then collectively delete them or delete
all messages from a particular sender.
•Copy to ..., Move to ..., Copy All and Move All
allow you to copy or transfer messages from one
memory area to the other.
•Delete All allows you to keep your Inbox clear
of clutter.
•Use Number and Use URL are particularly useful
when there are phone numbers or website addresses
within the original message. These options allow you
to use them to make calls, save to your Phone book or
access the website, as appropriate.
SMS message settings
1 From the clock face, tap Menu.
2 Tap (twice, if necessary).
3 Tap SMS, then tap Message Settings.
•Profile Setting determines important message
delivery criteria for one or more networks.
•Report Settings allows you to request a Delivery
Report when your messages are received by the
recipients. Reply Path is a network option that is not
normally needed.
•Memory Status shows the remaining space for
messages in memory.
•Preferred Storage allows you to choose which
memory to use.
•Message Signature allows you to enter text to use as
a standard signature and append it to every message
that you send.
.
10
sWaP Nova user guide www.s-w-a-p.co.uk
Contents
MMS messages
MMS messages are structured in a similar way to slide
show presentations. Each message consists of one or
more slides, with each slide able to contain text, an
image, an audio file, a video clip, a file attachment or
any combination of these. When the message is played,
each slide and it’s contents are shown in order. You can
optionally adjust the timing of the slides, for instance,
to keep showing an image until a clip of music has
finished playing.
Note: MMS messages require a GPRS connection as
part of your service provider agreement. Also, not all
mobile phones can accept or display MMS messages.
You must also choose the correct initial settings to
match your network. Please see MMS connection
configuration at the end of this MMS section.
Writing an MMS message
1 From the clock face, tap Menu.
2 Tap (twice, if necessary).
3 Tap MMS, then tap Compose Message. A series of
blank fields will be shown. Each has a different
function:
1-To; 2-Cc (copy); 3-Bcc (blind copy); 4-Subject;
5-Edit content
Tap on a field that you want to use, and then tap Edit.
For fields 1, 2and 3you can enter any number of
phone numbers and/or email addresses.
Field 4is the message Subject and will invoke the
standard text editor.
Field 5is where you create and determine the content.
When you tap Edit content for field 5 for the first
time, you will see the text editor for the first slide.
4 Enter/edit your text and then tap Options.
To add an item to the current slide, tap Add Picture,
Add Audio, Add Video or Add Attachment.
In each case, tap Phone or Memory Card to choose
the location of the item. Your sWaP Nova applications
use Phone storage as standard, however, this can be
changed within each application (the memory card has
a much larger capacity).
You will then see the folders located within the chosen
storage area, e.g. Images, Audio, Photos, Video, etc.
Tap the appropriate folder name to view the contents.
Tap the required item to add it to your slide.
5 For each item type, repeat step 4. Remember that you
can only have one of each item type per slide. If you
add a second image to a slide, it will overwrite the first
one.
6 If necessary, add one or more new slides to
accommodate multiple items of the same type. From
the text editor, tap Options and then tap either Add
Slide Before or Add Slide After. You will now see the
blank text editor for the new slide. It is not necessary
to have text on every slide. Repeat steps 4 and 5 to
populate the new slide.
7 To change between slides, tap Options and then tap
either Previous Slide or Next Slide, as appropriate.
8 When you have completed the slides you can see how
they will play. Tap Options and then tap Preview. If
necessary, you can change the timing. Tap Options and
then tap Slide Timing. Use the editor to change the
time (in seconds) that each slide is displayed.
9 Once the message is complete, tap Options and then
tap Done. You will now see the initial group of fields
where the addressing is performed.
If not already done, enter the recipient
phone numbers and/or email addresses and then tap
Done.
10 You can now choose to Send Only, Save and Send
or Save to Drafts.
If you did not enter any recipients, the only option will
be Save to Drafts.
.
11
sWaP Nova user guide www.s-w-a-p.co.uk
Contents
Reading an MMS message
1 From the clock face, tap Menu.
2 Tap (twice, if necessary).
3 Tap MMS, then tap Inbox. The list of received MMS
messages will be shown, each listed with either the
phone number or the name (if in the Phone book) of its
sender.
The prefixed envelope icon will be shown closed for
unread messages and open for previously viewed ones.
4 Tap the required message to open it.
5 Tap Option to view the range of actions available to
you:
•Reply allows you to compose and send a response to
the original message.
•Reply by SMS allows you to contact the sender via
SMS.
•Reply All allows you to send a response to the sender
and all of the original recipients.
•Forward allows you to send the message to one or
more new recipients without editing.
•Delete and Delete All allow you to keep your Inbox
clear of clutter.
•Properties allows you to view the addressing details,
the subject name and file size of the message.
•Use Details allows you to use the addressing details
of the message.
MMS connection configuration
Before you can use MMS for the first time, you must
ensure that the MMS settings are correct for your
network connection.
1 From the clock face, tap Menu.
2 Tap (twice, if necessary).
3 Tap MMS.
4 Tap Message Settings.
5 Tap Server Profile.
6 Tap the appropriate network provider name and tap
Activate Protocol.
This process is required only once, you are now ready to
use the MMS application.
Voice mail server
This option allows you to configure the phone number
of your network service provider’s voice mail system.
These details are often set automatically by your SIM
card.
1 From the clock face, tap Menu.
2 Tap (twice, if necessary).
3 Tap Voice Mail Server.
4 Tap one of the entries and tap Edit.
5 Tap the upper entry, tap Edit and enter a name for the
network/server.
6 Tap Option and tap Done.
7 Tap the lower entry and enter a valid number for the
voice mail server, as advised by your service provider.
Tap Option and tap Done.
Listening to voice mail messages
1 Tap Voice Mail Server.
2 Tap appropriate server name.
3 Tap Call Voice Mail.
Broadcast message
These are text messages that contain information
relevant to your location, which you can choose to
receive. The messages could contain local weather
forecasts, traffic reports or special offers in local
establishments.
1 From the clock face, tap Menu.
2 Tap (twice, if necessary).
3 Tap Broadcast Message. The menu provides a number
of options:
•Receive Mode enables or disables the broadcast
messages feature.
•Read Message allows you to view any received
broadcast messages.
•Languages allow you to choose to receive all
messages or only those in English.
•Channel Setting allows you to optionally refine which
channels (0 to 999) you wish to receive. As standard,
you will receive messages from all channels.
.
12
sWaP Nova user guide www.s-w-a-p.co.uk
Contents
Media
Your sWaP Nova is a fully formed multimedia device
that can handle video and music just as smoothly as it
deals with your phone calls.
Your sWaP makes great use of its
in-built high resolution camera, which can operate as a
video camera as well as capturing still images.
Media features include:
•Photoalbum
•Videoplayer
•Audioplayer
•Soundrecorder
•FMradio
Photo album
Allows you to view, organise and do things with
your photos, such as send to friends or use them as
wallpaper on your sWaP Nova.
1 From the clock face, tap Menu.
2 Tap (twice, if necessary).
3 Tap Photo Album. Your photos will be shown, either
as a list (showing thumbnail views, filenames, dates
and sizes for each entry) or as a matrix of thumbnail
views.
4 To see options for a photo, tap on a photo entry. The
menu shows a number of options:
•View displays the selected photo. You can then tap
the left and right arrows to move through your photos.
•Browse Style allows you to change between the list
and matrix views of your photos.
•Forward allows you to assign the selected photo
for use in your sWaP Nova (as wallpaper, screensaver
or power on/off image); as the picture for a contact
in your Phone book; or send the photo to someone
either via MMS message or by Bluetooth link. The
latter option will guide you through the process of
searching for and bonding with a Bluetooth device in
your vicinity.
•Rename allows you to change the standard filename.
•Delete and Delete All Files allow you to clear away
unwanted photos.
•Sort By allows you to list your photos in order by
name, type, time or size.
Video player
1 From the clock face, tap Menu.
2 Tap (twice, if necessary).
3 Tap Video Player. A list of your videos will be shown.
4 To see options for a video, tap on an entry. The menu
shows a number of options:
•Play displays the player screen:
•Forward allows you to send the video to someone
either via MMS message or by Bluetooth link. The
latter option will guide you through the process of
searching for and bonding with a Bluetooth device in
your vicinity.
•Rename allows you to change the standard filename.
•Delete and Delete All Files allow you to clear away
unwanted videos.
•Sort By allows you to determine the order in which
the video clips are listed.
•Bluetooth Settings allows you to choose a Bluetooth
headset and redirect the audio signal to that headset.
Speaker
volume
Show full
screen
Take a
snapshot
Play/
pause
Playback
speed
Fast forward/
fast rewind
.
13
sWaP Nova user guide www.s-w-a-p.co.uk
Contents
Audio player
The audio player allows you to listen to your MP3 music
tracks or podcasts wherever you may be. The audio
player can also play .WAV and .M4A files.
Note: You can connect the wired earphones to hear
your music in stereo.
1 From the clock face, tap Menu.
2 Tap (twice, if necessary).
3 Tap Audio Player. The playback screen will be
displayed:
Selecting and playing a track
1 Tap List and then tap the required track name.
2 Tap Play to commence playback.
You can now use the playback controls at the foot of
the screen.
Tap to gain quick access to the playback settings
menu.
If a call is received (or initiated) while listening to a
track, playback will be automatically stopped. If the
Background Play option is enabled, then playback will
automatically resume after the call is completed.
Plug in the supplied wired earphones to hear playback
in stereo.
Adding or transferring audio files
There are three main ways to add or transfer audio
files:
•UseaUSBlinkwithyourcomputer.SeetheUSBlink
section later in this guide for details.
•UseBluetoothtolinkwithanotherdevice.Seethe
Bluetooth section later in this guide for details.
•UsingMMStosend/receiveaudioleattachments.See
the MMS messaging section earlier in this guide for
details.
Audio player options
Within the audio playback screen, tap List and then tap
Option to view the menu:
•Details shows information about the selected track.
•Add to Ringtones copies the track to your ringtones
list. See the Settings section for detail about using it.
•Refresh list use this when tracks have been added or
removed.
•Settings contains the following items:
List auto gen set to On to automatically update the
tracklist when changes occur.
Repeat allows you to play either a single track or your
whole collection continuously.
Shuffle when enabled, plays tracks in a random order.
Background Play when enabled, continues playing
tracks even when you leave the audio player. Playback
stops automatically when making or receiving a
call. When this option is enabled, the track will
automatically resume playing.
BT Stereo Output determines whether audio should
be redirected to a Bluetooth stereo headphone device.
This option can be enabled once you have chosen a
suitable device using the option detailed below.
BT Stereo Headset allows you to locate/choose a
suitable Bluetooth stereo headphone device to use with
the audio player.
Spectrum Display determines the appearance of the
on screen audio spectrum analyser when tracks are
playing.
Lyrics Display determines whether song lyrics (when
available) should be displayed during playback.
Show
playlist
Current track
timing, track
number and
name
View settings and
access the equalizer
Volume increase
and decrease
Playback
controls
.
14
sWaP Nova user guide www.s-w-a-p.co.uk
Contents
Sound recorder
Allows you to record face-to-face or telephone
conversations (warn the caller first) or other
soundscapes around you.
1 From the clock face, tap Menu.
2 Tap (twice, if necessary).
3 Tap Sound Recorder. A list of any existing recordings
will be shown.
To start recording: Tap Option and then tap Record.
To pause or stop recording: Tap either Pause or Stop.
As soon as you choose Stop, the screen will display an
assigned numeric name for the recording in the editor
screen.
Optionally use the editor to alter the assigned name.
Once done, tap Option and then tap Save.
The new file will be added to the list in the sound
recorder main screen.
Sound recorder options
From the list screen, tap Option:
•Record to begin a new recording.
•Play the currently selected entry.
•Append to resume recording at the end of the
currently selected entry.
•Rename to edit the name of the currently selected
entry.
•Delete and Delete All allow you to keep the list free
of clutter.
•Settings > File Format allows you to choose AMR
and WAV formats. AMR is suited to voice recording;
whereas the WAV format is supported widely on
personal computers and would be the one to choose if
you intend to transfer your recordings.
•Forward allows you to copy the entry for use as
an alert tone or send it to someone either via MMS
message or by Bluetooth link. The latter option will
guide you through the process of searching for and
bonding with a Bluetooth device in your vicinity.
FM radio
This allows you to listen to any FM radio stations available
within your vicinity. The stereo headphones must be
used uncoiled as their cable forms the radio aerial.
1 From the clock face, tap Menu.
2 Tap (twice, if necessary).
3 Tap FM Radio. The FM Radio screen will be displayed:
Finding a station
To search manually: Tap or to change the
frequency.
To choose a frequency: Tap Option and then Manual
Input. Enter the frequency and tap OK.
To auto search: Tap and then tap either or to
locate the next radio station.
To create/use a channel list entry: Tap Option and then
Channel List. Tap an existing entry to select its frequency
or tap an empty entry to add a new frequency.
General settings
Use the +and -buttons to adjust the volume or tap
to mute / unmute.
Tap to gain quick access to the settings menu.
If the Settings > Background Play option is enabled,
then the radio output will continue while you are
using other applications. Also, output will be muted
during calls and will automatically resume once a call is
completed.
Change frequency or
station search (when Auto
Search option is selected)
Mute
Current
frequency
setting
Volume increase
and decrease
Auto SearchSettings
.
15
sWaP Nova user guide www.s-w-a-p.co.uk
Contents
WAP
The WAP application brings the power of the world
wide web right to your wrist. Many websites are now
optimised for compact screens and this application
allows you to access and use them.
Note: To use WAP you must have either GSM data and/
or a GPRS connection as part of your service provider
agreement. You must also choose the correct settings
to match your network. Please see WAP connection
configuration at the end of this WAP section.
1 From the clock face, tap Menu.
2 Tap (twice, if necessary).
3 Tap WAP. The screen will show the main options:
•Homepage takes you to the web location that acts as
your starting point.
•Bookmarks provides a list of regularly used sites.
•Recent Pages gives you quick access to previously
visited locations.
•Offline Pages allows you to view previously viewed
pages that are stored within memory.
•Input Address allows you to enter a new web address.
•Service Inbox is the place where incoming WAP Push
messages are stored.
•Settings contains the following items:
Edit Profile selects the network configuration to use
Browser Options sets the page timeout period and
also whether pictures should be shown.
Service Message Settings decides whether WAP Push
messages should be received.
Clear Cache removes all stored web page data from
memory.
Clear Cookies removes all stored cookies (identification
information deposited by certain websites) from
memory.
Accessing WAP sites
Access the main WAP options list and then use any of
the first four options:
•Homepage - your portal to the web (usually a search
engine such as Yahoo, Google, etc.).
•Bookmarks - websites saved from previous visits.
•Recent Pages - a history of recently accessed websites.
•Enter Address - where you enter a new website
address.
When you have chosen a website, your sWaP Nova will
attempt to connect using either a GPRS connection or,
failing that, a GSM data connection.
If the former cannot be used, then you will be asked for
permission to use the latter (GSM connection speeds
are lower than GPRS).
If your sWaP Nova continually fails to use GPRS, then
there may be a configuration problem - see WAP
connection configuration for details.
Once a data connection is made, the website will be
located and displayed.
Note: While it is possible to access normal websites,
some will not display correctly because they are
designed only for large screens. Many organisations
offer WAP alternatives which are optimised for compact
screens.
Within each webpage you will be able to tap on
hyperlinks (usually shown in blue with or without an
underline). You can also tap within text boxes in order
to display the on-screen editor and enter alphanumeric
characters.
While browsing online, there are a couple more options
that appear within the list:
•Refresh reloads the current page.
•Set as Homepage uses the page you are viewing as
your new portal.
•Save Picture allows you to select any displayed picture
and save it to a memory location.
As mentioned above, the easiest way to create a new
homepage is to visit it, then tap Option and then tap
Set as Homepage.
You can also make a change offline from the main WAP
options list by tapping Settings, then Edit Profile, tap
your service provider’s entry, tap Edit Profile and then
edit the Homepage entry.
WAP connection configuration
In order to operate, the WAP browser requires a data
connection with your network. This can be either
using GPRS or a GSM data connection. Your contract
agreement may not include such services - check with
your network provider.
You also need to ensure that the correct network
connection details are selected:
1 From the main WAP options list, tap Settings and then
tap Edit Profile.
2 Locate your service provider’s name from the list of
operators and tap it.
3 Tap Activate Profile and then tap Yes.
If your service provider is not within the list, use a
personal computer to access the sWaP website (http://
www.s-w-a-p.co.uk). Go to the FAQs page. Download
the procedure for adding new networks to your sWaP
Nova. You will also need the following information
from your service provider:
•GSMdatadial-upnumber
•GSMdatausernameandpassword
•GSMdataDNSIPaddress
•GPRSAccessPointName(APN)
•GPRSusernameandpassword
•Authenticationtype(i.e.Normal)
Once you have these details, use the downloaded
instructions to enter them into the appropriate
locations within your sWaP Nova.
.
16
sWaP Nova user guide www.s-w-a-p.co.uk
Contents
Settings
To ensure that your sWaP Nova works the way that
suits you, the main Settings section contains plenty of
options to modify its appearance and operation. The
Settings section also includes more applications for
everyday use.
1 From the clock face, tap Menu.
2 Tap (twice, if necessary).
•Pen Calibration allows you to ensure that the touch
screen reacts accurately to stylus taps.
•Organizer contains the
following applications:
Calendar
To Do List
Alarm
World Clock
Calculator
Bluetooth
File Manager
Stopwatch
•User Profiles allow you to change all of the call and
message alert characteristics in one go, to suit your
location.
•Phone Setup is where you apply basic phone
settings, such as time and date, language, display
characteristics, etc.
•Call Setup lets you invoke call diverts, set call time
reminders, etc.
•Network Setup contains numerous network
connection options.
•Security Setup contains options such as SIM lock,
Auto keypad lock, change password, etc.
•Restore Factory Settings allows you to return all
settings back to their default configurations.
Pen Calibration
From time to time (once a month recommended), or
after a complete restore factory settings operation, you
may need to calibrate the screen to restore its accuracy.
1 From the clock face, tap Menu.
2 Tap (twice, if necessary).
3 Tap Pen Calibration.
The calibration wizard will be displayed and will take
you through the procedure. Be sure to use the supplied
stylus and view the screen exactly as you would in
normal operation as you confirm the touch points.
TIPS:
•Whentappingonthedisplayedtouchpoints,viewthe
screen exactly as you would in normal operation.
•Forbestresults,gothroughtheproceduretwice.
•Repeattheprocedureonceamonthtokeepaccuracy
at the opimum level.
Organizer
The organizer contains a number of useful applications
for everyday use.
1 From the clock face, tap Menu.
2 Tap (twice, if necessary).
3 Tap Organizer. The list of applications will be
displayed.
Calendar
This application will ensure that you never forget your
important dates again.
•AccesstheOrganizer and then tap Calendar.
When the calendar opens you will see the current
month to view and today’s date will be highlighted.
Use the left and right buttons in the top corners to
change the month back or forward.
To set a calendar reminder
1 Either tap on a day and then tap Option, or just double
tap on a day.
2 Tap View Tasks.
3 Tap Add. Within the edit page, set the time (and
change the date, if necessary).
4 Highlight Note and tap Edit to add an explanation. You
can either enter your own text and tap Option then
Save or alternatively, just tap Option and then tap Use
Template to view ready made explanations. When you
tap an explanation, it will be placed into the editor so
that you can alter it, if necessary. Tap Option and then
Save.
5 Optionally, enable the alarm and also choose whether
you would like the entry to repeat: Once, Everyday,
occur on particular Days, Weekly or Monthly.
The Days option allows you to include/exclude
particular days of the week. When a day is enclosed
within a border, it is included.
6 Tap Done and then tap Yes to confirm. The new entry
will be added to the Task List and a red border will be
placed around each date for which the reminder is
valid.
To jump to a specific date
1 Either tap on a day and then tap Option, or just double
tap on a day.
2 Tap Jump To Date and enter the required date.
3 Tap OK and the chosen date will be shown highlighted
in a month to view page.
.
17
sWaP Nova user guide www.s-w-a-p.co.uk
Contents
To Do List
•AccesstheOrganizer and then tap To Do List.
When the list opens you will see any existing reminders,
including all programmed reminders from the Calendar
application.
•TapAdd (or Option and then Add, if shown) to create
a new entry, or tap an existing entry to view its details.
Follow the procedure outlined for the Calendar (from
step 3).
•UseDelete Task or Delete All to keep the list free
from clutter.
•TapSend vCalendar to send the currently selected
entry to someone else or save it as a file. You have the
following choices:
•SendBySMS
•SendByMMS
•SendByBluetooth
•SaveasFile
In each case, the relevant application will be invoked.
Alarm
•AccesstheOrganizer and then tap Alarm.
Allows you to quickly set one or more alarms.
To set an alarm
1 In the opening page, tap a vacant alarm entry.
2 Set the alarm to On and then tap the time entry to set
the alarm time.
3 Optionally choose whether you would like the entry
to repeat: Once, Everyday, occur on particular Days,
Weekly or Monthly.
4 Optionally set a Snooze time (after which the alarm will
repeat).
5 If necessary, change the Alert Type using the
combinations of ring and vibration alerts.
6 Tap Done and then tap Yes to confirm.
Your new alarm will be ticked to show that it’s active.
World Clock
•AccesstheOrganizer and then tap World Clock.
The opening page shows a world map with cross hairs
centred on the city that is configured as your location in
the Time and Date settings.
The current time and date for the highlighted location
is shown along with either a moon or sun symbol to
indicate night and day.
•Youcaneitherusetheleftandrightbuttonstochange
to the next city or tap on the map to highlight the
nearest featured city within each timezone.
•TapOption to choose whether the Daylight Saving
Time should be switched on or off.
Calculator
•AccesstheOrganizer and then tap Calculator.
The calculator keypad and readout will be shown.
•Tapyourguresandoperand(s)andtheneithertapthe
=key or press the sWaP Nova lower button to reveal
the answer.
Bluetooth
•AccesstheOrganizer and then tap Bluetooth.
This section contains all tools required to locate, pair
and manage Bluetooth devices for use with your sWaP
Nova.
The opening page lists the main menu of options:
•Power determines whether the Bluetooth circuitry is
switched on.
•Search Bluetooth Device initiates a search for other
Bluetooth devices in the vicinity.
•My Devices shows details for all paired Bluetooth
devices, plus your sWaP Nova.
•Active Device lists all paired Bluetooth devices that are
currently active.
•Settings contains various options:
Visibility determines whether your sWaP Nova can be
seen by other Bluetooth devices that are not yet paired
with it.
Change Device Name allows you to change the
Bluetooth name by which your sWaP Nova is known.
Authentication when set to On,
allows a Bluetooth device to reconnect to your sWaP
Nova (once it has been initially authorized) without
confirmation.
Audio Path allows you to transfer all audio through
the microphone and speaker of a suitable Bluetooth
device.
FTP Setting determines where data to send and be
received should be stored in memory. It also allows
you to control whether the other device can write to
memory as well as read.
•About shows details for your sWaP Nova including
Bluetooth device name, address and supported services.
.
18
sWaP Nova user guide www.s-w-a-p.co.uk
Contents
Pairing with another device
In order to work together, Bluetooth devices must be
paired to produce a trusted bond between them. During
the pairing process, one device must search while the
other is made to be ‘visible’ and wait to be discovered.
To search for and pair with other devices
1 From the main Bluetooth menu, tap Search Bluetooth
Device. If the Bluetooth circuitry was previously Off, it
will be switched On and a search for other devices will
be carried out for up to one minute. Ensure that the
other devices have been set to be visible.
Any found Bluetooth devices will be listed in the
Discovered Device page.
2 Tap the name of the device to bond with, enter a valid
passcode and then tap OK. For most devices, there is
no fixed passcode number and a common four digit
number must be decided on between the users. The
supplied headset has a fixed passcode of 0000. Tap Yes
to confirm pairing.
To make your sWaP Nova discoverable
1 From the main Bluetooth menu, tap Settings and
check the current setting for the Visibility option.
2 If Visibility is currently Off, tap it to change its state to
On.
3 When your sWaP Nova is discovered, the other device
will initiate pairing and you will be asked to enter a
four digit passcode that matches the one entered into
the other device. Enter the code and confirm pairing.
Your sWaP Nova and the other device will now share
a common bond and can reconnect and transfer
information at any time.
To break the pairing bond
When you no longer want to use the devices together,
you can break the bond.
1 Tap My Devices and then tap the name of the other
device.
2 Tap Delete and then tap Yes to remove the pairing bond.
File manager
•AccesstheOrganizer and then tap File Manager.
Allows you to organise the memory storage areas
within your sWaP Nova. The screen will show the
Phone and Memory Card locations along with total size
and free space information.
To view folders/files within a location: Tap on a storage
location (Phone or Memory Card). If necessary, use
the scroll buttons on the right side to bring a particular
folder into view.
Tap on a folder to view its files.
Tap on a file to view a menu of options including: View,
Forward, Detail, Rename, Copy, Move, Delete, Delete
All Files and Sort.
CAUTION: The list of options available when viewing
the main locations include a Format option which will
wipe all files and folders from the storage area.
Stopwatch
•AccesstheOrganizer and then tap Stopwatch.
This application actually provides multiple stopwatches
in one.
The screen will show two options:
Typical Stopwatch and nWay Stopwatch.
The Typical Stopwatch option gives you two
variations:
•SplitTiming, where each tap of Split saves the current
elapsed time while the main counter continues. Each
subsequent tap of Split saves another elapsed time
from the very beginning up to the point at which Split
was tapped.
•LapTiming, where each tap of Lap saves the current
elapsed time since the last moment that Lap was
tapped, i.e. the counter is reset to zero each time.
The nWay Stopwatch provides a main counter and
four sub-counters of time. The main counter runs
continuously but a sub-counter is only incremented
when it is highlighted. When you tap a different sub-
counter, it begins to increment, while the previous
one is frozen. In this way the four sub-counters can
accumulate separate lots of time.
Note: If a stopwatch is left running while you use other
features, the icon will be shown on the clock face.
Leaving a stopwatch running for long periods can
shorten battery life.
.
19
sWaP Nova user guide www.s-w-a-p.co.uk
Contents
User Profiles
These allow you to change the whole nature of your
call-, key-, message- and alarm- alerts in one easy
action.
Note: Flight Mode switches off all communication
aspects of your sWaP Nova to let you use other features
without infringing ‘no mobile’ rules in certain areas.
You can also choose whether to see a Flight Mode
option whenever you first switch on.
1 From the clock face, tap Menu.
2 Tap (twice, if necessary).
3 Tap User Profiles.
A list of all profiles will be shown:
General Headset
Meeting Bluetooth
Outdoor Flight Mode
Indoor
To use a profile
•TapaproleandthentapActivate or OK. Your choice
will be confirmed.
To adjust a profile
1 Tap a profile name and then tap Customize. You can
now adjust the following:
•Tone Setup for all instances:
Incoming calls, alarms, power on and off, incoming
messages and keypad tones.
•Volume for ring tones and key tones.
•Alert Type for mixes of alert tone and/or vibration
alerts.
•Ring type to choose Single, Repeat or Ascending
alerts.
•Extra Tone to allow extra tones for warnings, errors,
etc.
•Answer Mode allows you to enable or disable any
key answering of incoming calls and also choose Auto
answering of incoming calls.
Phone Setup
Contains many configuration options to customise the
operation of your sWaP Nova.
1 From the clock face, tap Menu.
2 Tap (twice, if necessary).
3 Tap Phone Setup.
The menu options will be shown:
•Swipe Function allows you to link any of seven sWaP
Nova functions to a handwriting gesture on the clock
face. Thus, you could make an upward stroke of the
stylus on the clock face to immediately cause your
Phone Book to be shown. There are four swipe gestures
that can be defined.
•Time and Date allows you to set the current time
and date. You can also determine the time and date
formats and define your nearest major city within your
timezone.
•Schedule Power On/Off allows you to maximise your
power efficiency while you’re asleep by choosing times
to automatically switch your sWaP Nova off and on.
•Language lets you choose the appropriate language
for all menus and messages within your sWaP Nova.
•Preferred Input Method determines which on screen
keypad is displayed first when you need to enter
details.
•Display Characteristics contains numerous settings
related to the visual aspects of operation:
Wallpaper allows you to choose the image that is
displayed behind all menus. You can choose a standard
image from the System option or choose one of your
own that is stored within memory using the User
Define option.
Screen Saver allows you to choose an image that
will be displayed during periods of inactivity. You can
choose a standard image from the System option or
choose one of your own that is stored within memory
using the User Define option. You can also disable the
screen saver mode.
Power On Display and Power Off Display allow
you to choose a picture or animation to be shown
when your sWaP Nova is powered on and off. You can
choose a standard image from the System option or
choose one of your own that is stored within memory
using the User Define option.
Show Date and Time determines whether the current
data and time are shown on the clock face page.
Show Operator Name determines whether the
current network name is shown on the clock face page.
Clock Type allows you to choose the clock face design
for the standby screen.
•Speed Dial allows you to define up to eight of your
most regularly used phone numbers and associate them
with dial numbers 1 to 8. Once enabled, when you are
viewing the clock face, tap and hold as you normally
would to enter the dial page, but then tap and hold a
number between 1 and 8 to call the associated phone
number.
•Dialing Vibrator determines whether your sWaP Nova
should provide vibration feedback each time you dial a
digit.
•Disable Sleep Mode determines whether or not your
sWap Nova should enter sleep mode when idle. Setting
this option to On will affect the standby battery timing.
•Auto Update of Date and Time determines whether
the network date and time signal should be used to
update your sWaP Nova settings.
•Handwriting Setting allows you to choose a Pen
Speed and Pen Color for use in handwriting recognition
applications.
•UI Effect Settings allows you to choose the transition
effect shown when you change between different
pages within the menu.
•LCD Backlight allows you to adjust the brightness of
the touch screen backlight.
Table of contents
Other sWaP Cell Phone manuals
