Technical Handbook
Touring Caravans
Issued August 2019
Part No. 1435372

3
Contents
Basecamp specication ............................................................................................... 4
Sprite Specication .......................................................................................................... 6
Sprite Super Specication ........................................................................................... 8
Challenger / Eccles Alde Specication ...................................................................... 10
Challenger X / Eccles X Alde Specication ............................................................. 12
Elegance Specication ............................................................................................... 14
Elegance Grande Specication ................................................................................. 16
Wiring Diagrams ............................................................................................................... 18
13 Pin Socket .................................................................................................................. 29
Cable Colours .................................................................................................................. 30
Bulb Replacement ........................................................................................................... 31
Dealer Special models based on Sprite ............................................................ 32
Dealer Special models based on Sprite Super ................................................ 34
Dealer Special models based on Eccles / Challenger with Alde ................ 36
Dealer Special models based on Challenger X / Eccles X with Alde .............. 38
Dealer Special models based on Elegance ........................................................ 40
Dealer Special models based on Elegance Grande ......................................... 42
Bed make-ups ................................................................................................................... 44

4
Basecamp Specication
Masses: The masses are calculated in accordance
to EU regulation 1230/2012 and NCC code of
practice 304.
The Mass in Running Order (MRO) comprises:
1. The mass of the empty caravan as supplied by
Swift including loose items such as the hook-up
cable, kit bag, entrance step, manuals etc.
2. 10kg allowance for LPG
The MRO is calculated with the fresh water tank,


tank and the water heater the payload will reduce
accordingly.

berths and the length of the caravan and includes an
allowance of 20kg for a leisure battery.
The Maximum Technical Laden Mass (MTPLM) is
the maximum mass allowed when the caravan is
fully laden.
WARNING: Under no circumstances should the
MTPLM be exceeded
Basecamp Basecamp Basecamp Plus
Berths 2 2
Axles 1 1
 3.42m/11'3" 3.42m/11’3”
Overall Width** 2.28m/7'6" 2.28m/7’6”
Overall Height (inc. TV Aerial)** 2.58m/8'5" 2.60m/8’6”
 1.95m/6'5" 1.95m/6'5"
Overall Length** 5.10m/16’9” 5.10m/16’9”
Awning A/A dimension
Mass in Running Order
(inc. tolerance) 891kg/17.5cwt 927kg/18.2cwt
Maximum Technical Permissible
Laden Mass (Lower limit) 1002kg/19.7cwt 1038kg/20.4cwt
Maximum Technical Permissible
Laden Mass (Upper limit) 1300kg/25.6cwt 1300kg/25.6cwt
Total user Payload 111kg/2.2cwt 111kg/2.2cwt
 111kg/2.2cwt 111kg/2.2cwt
Options 0kg/0.0cwt 0kg/0.0cwt
Tyre Size 185 R14C 102 Q 185 R14C 102 Q
Tyre pressure at Lower limit MTPLM 2.7 bar / 39 psi 2.8 bar / 41 psi
Tyre pressure at Upper limit MTPLM 3.7 bar / 54 psi 3.7 bar / 54 psi
Static Load on Coupling Head 100kg 100kg
 THREE THREE
Bed Sizes
Front Double 198cm x 183cm/6'5" x 6'0" 198cm x 183cm/6'5" x 6'0"
or Front Nearside Single 183cm x 69cm/6'0" x 2'3" 183cm x 69cm/6'0" x 2'3"
 183cm x 69cm/6’0” x 2’3” 183cm x 69cm/6’0” x 2’3”
Rear Double

Side Single (nearside)

Side Bunk (nearside)
Side Fixed Lower Bunk
Side Fixed Upper Bunk

5
Bed Sizes: Please note that the front double bed

chest of drawers. The front double bed width for a

by 0.4m(1’4”) from that stated.
Awning sizes: Due to the varying awning designs
and sizes the awning sizes given are approximate

your dealer or the awning manufacturer prior to
purchase.
Est = Estimated weight or bed size
**The dimensions given are approximate due to
slight variations in suspension ride heights, loading
conditions and tyre pressures.
Customers should verify the actual dimensions of
their touring caravan before committing to anything
that could be impacted by theses dimensions
Please note:
overall payload available to the user of the caravan.
-
grade the MTPLM to the upper limit. Please contact
your caravan dealer for more information.

6
Sprite Specication
Sprite Alpine 2 Alpine 4 Major 4 SB Major 4 EB
Berths 2444
Axles 1111
 4.34m/14'3" 4.74m/15'7" 5.83m/19'2" 5.83m/19'2"
Overall Width** 2.25m/7'5" 2.25m/7'5" 2.25m/7'5" 2.25m/7'5"
Overall Height (inc. TV Aerial)** 2.59m/8'6" 2.59m/8'6" 2.59m/8'6" 2.59m/8'6"
 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5"
Overall Length** 6.05m/19'10" 6.45m/21'2" 7.54m/24'9" 7.54m/24'9"
Awning A/A dimension 8.59m/28'2" 8.99m/29'6" 10.08m/33'1" 10.08m/33'1"
Mass in Running Order
(inc. tolerance) 1052kg/20.7cwt 1094kg/21.5cwt 1241kg/24.4cwt 1275kg/25.1cwt
Maximum Technical Permissible
Laden Mass (Lower limit) 1218kg/24.0cwt 1284kg/25.3cwt 1442kg/28.4cwt 1476kg/29.1cwt
Maximum Technical Permissible
Laden Mass (Upper limit) 1250kg/24.6cwt 1300kg/25.6cwt 1500kg/29.5cwt 1500kg/29.5cwt
Total user Payload 166kg/3.3cwt 190kg/3.7cwt 201kg/4.0cwt 201kg/4.0cwt
 121kg/2.4cwt 145kg/2.9cwt 156kg/3.1cwt 156kg/3.1cwt
Options 45kg/0.9cwt 45kg/0.9cwt 45kg/0.9cwt 45kg/0.9cwt
Tyre Size 185 R14C 102Q 185 R14C 102Q 185 R14C 102Q 185 R14C 102Q
Tyre pressure at Lower limit
MTPLM 3.4 bar / 49 psi 3.6 bar / 52 psi 4.2 bar / 61 psi 4.3 bar / 62 psi
Tyre pressure at Upper limit
MTPLM 3.5 bar / 51 psi 3.7 bar / 54 psi 4.4 bar / 64 psi 4.4 bar / 64 psi
Static Load on Coupling Head 100kg 100kg 100kg 100kg
 THREE THREE THREE THREE
Bed Sizes
Front Double 202cm x 180cm/6'8" x 5'11" 202cm x 128cm/6'8" x 4'2" 202cm x 159cm/6'8" x 5'3" 202cm x 159cm/6'8" x 5'3"
or Front Nearside Single 190cm x 72cm/6'3" x 2'4" 159cm x 72cm/5'3" x 2'4" 159cm x 72cm/5'3" x 2'4"
 180cm x 72cm/5'11" x 2'4" 159cm x 72cm/5'3" x 2'4" 159cm x 72cm/5'3" x 2'4"
Rear Double 189cm x 132cm/6'2" x 4'4" 185cm x 133cm/6'1" x 4'4" 190cm x 133cm/6'3" x 4'4"

Side Single (nearside)

Side Bunk (nearside)
Side Fixed Lower Bunk
Side Fixed Upper Bunk
Masses: The masses are calculated in accordance
to EU regulation 1230/2012 and NCC code of
practice 304.
The Mass in Running Order (MRO) comprises:
1. The mass of the empty caravan as supplied by
Swift including loose items such as the hook-up
cable, kit bag, entrance step, manuals etc.
2. 10kg allowance for LPG
The MRO is calculated with the fresh water tank,


tank and the water heater the payload will reduce
accordingly.

berths and the length of the caravan and includes an
allowance of 20kg for a leisure battery.
The Maximum Technical Laden Mass (MTPLM) is
the maximum mass allowed when the caravan is
fully laden.
WARNING: Under no circumstances should the
MTPLM be exceeded

7
Major 6 Major 6 TD Quattro EW Quattro FB
6666
1122
5.60m/18'4" 5.83m/19'2" 6.27m/20'7" 6.27m/20'7"
2.25m/7'5" 2.25m/7'5" 2.25m/7'5" 2.25m/7'5"
2.59m/8'6" 2.59m/8'6" 2.59m/8'6" 2.59m/8'6"
1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5"
7.31m/24'0" 7.54m/24'9" 7.98m/26'2" 7.98m/26'2"
9.85m/32'4" 10.08m/33'1" 10.52m/34'6" 10.52m/34'6"
1259kg/24.8cwt 1307kg/25.7cwt 1385kg/27.3cwt 1405kg/27.7cwt
1478kg/29.0cwt 1528kg/30.1cwt 1610kg/31.7cwt 1630kg/32.1cwt
1500kg/29.5cwt 1550kg/30.5cwt 1800kg/35.4cwt 1800kg/35.4cwt
219kg/4.3cwt 221kg/4.4cwt 225kg/4.4cwt 225kg/4.4cwt
174kg/3.4cwt 176kg/3.5cwt 180kg/3.5cwt 180kg/3.5cwt
45kg/0.9cwt 45kg/0.9cwt 45kg/0.9cwt 45kg/0.9cwt
185 R14C 102Q 185 R14C 102Q 185/70 R14 88T 185/70 R14 88T
4.3 bar / 62 psi 4.5 bar / 65 psi 2.0 bar / 29 psi 2.0 bar / 29 psi
4.4 bar / 64 psi 4.5 bar / 65 psi 2.2 bar / 32 psi 2.2 bar / 32 psi
100kg 100kg 100kg 100kg
THREE THREE THREE THREE
202cm x 170cm/6'8" x 5'7" 202cm x 180cm/6'8" x 5'11" 206cm x 134cm/6'9" x 4'5" 202cm x 180cm/6'8" x 5'11"
190cm x 72cm/6'3" x 2'4" 180cm x 72cm/5'11" x 2'4"
180cm x 72cm/5'11" x 2'4" 190cm x 72cm/6'3" x 2'4"
194cm x 132cm/6'4" x 4'4" 192cm x 132cm/6'4" x 4'4"
180cm x 83cm/5'11" x 2'9" 180cm x 62cm/5'11" x 2'0" 180cm x 62cm/5'11" x 2'0"
180cm x 67cm/5'11" x 2'2"
176cm x 59cm/5'9" x 1'11" 176cm x 59cm/5'9" x 1'11" 176cm x 59cm/5'9" x 1'11"
176cm x 59cm/5'9" x 1'11"
183cm x 57cm/6'0" x 1'10" 183cm x 57cm/6'0" x 1'10"
183cm x 57cm/6'0" x 1'10" 183cm x 57cm/6'0" x 1'10"
Bed Sizes: Please note that the front double bed

chest of drawers. The front double bed width for a

by 0.4m(1’4”) from that stated.
Awning sizes: Due to the varying awning designs
and sizes the awning sizes given are approximate

your dealer or the awning manufacturer prior to
purchase.
Est = Estimated weight or bed size
**The dimensions given are approximate due to
slight variations in suspension ride heights, loading
conditions and tyre pressures.
Customers should verify the actual dimensions of
their touring caravan before committing to anything
that could be impacted by theses dimensions
Please note:
overall payload available to the user of the caravan.
-
grade the MTPLM to the upper limit. Please contact
your caravan dealer for more information.

8
Sprite Sprite Super Quattro DB Sprite Super Quattro FB Sprite Super Quattro EB
Berths 664
Axles 222
 6.27m/20'7" 6.27m/20'7" 6.27m/20'7"
Overall Width** 2.46m/8'1" 2.46m/8'1" 2.46m/8'1"
Overall Height (inc. TV Aerial)** 2.59m/8'6" 2.59m/8'6" 2.59m/8'6"
 1.95m/6'5" 1.95m/6'5" 1.95m/6'5"
Overall Length** 7.98m/26'2" 7.98m/26'2" 7.98m/26'2"
Awning A/A dimension 10.56m/34'8" 10.56m/34'8" 10.56m/34’8"
Mass in Running Order (inc. tolerance) 1475kg/29.0cwt 1479kg/29.1cwt 1500kg/29.5cwt
Maximum Technical Permissible Laden
Mass (Lower limit) 1700kg/33.5cwt 1704kg/33.5cwt 1705kg/33.6cwt
Maximum Technical Permissible Laden
Mass (Upper limit) 1800kg/35.4cwt 1800kg/35.4cwt 1800kg/35.4cwt
Total user Payload 225kg/4.4cwt 225kg/4.4cwt 205kg/4.0cwt
 180kg/3.5cwt 180kg/3.5cwt 160kg/3.1cwt
Options 45kg/0.9cwt 45kg/0.9cwt 45kg/0.9cwt
Tyre Size 185/70 R14 88T 185/70 R14 88T 185/70 R14 88T
Tyre pressure at Lower limit MTPLM 2.0 bar / 29 psi 2.0 bar / 29 psi 2.0 bar / 29 psi
Tyre pressure at Upper limit MTPLM 2.2 bar / 32 psi 2.2 bar / 32 psi 2.2 bar / 32 psi
Static Load on Coupling Head 100kg 100kg 100kg
 THREE THREE THREE
Bed Sizes
Front Double 225cm x 180cm/7'4" x 5'11" 225cm x 180cm/7'4" x 5'11" 225cm x 163cm/7’4” x 5’4”
or Front Nearside Single 180cm x 73cm/5'11" x 2'5" 180cm x 73cm/5'11" x 2'5" 163cm x 73cm/5’4” x 2’5”
 180cm x 73cm/5'11" x 2'5" 180cm x 73cm/5'11" x 2'5" 163cm x 73cm/5’4” x 2’5”
Rear Double 196cm x 135cm/6'5" x 4'5" 187cm x 133cm/6’2” x 4’4”
 190cm x 134cm/6'3" x 4'5" 190cm x 134cm/6'3" x 4'5"
Side Fixed Lower Bunk 182cm x 72cm/6'0" x 2'4"
Side Fixed Upper Bunk 182cm x 72cm/6'0" x 2'4"
Sprite Super Specication
Masses: The masses are calculated in accordance
to EU regulation 1230/2012 and NCC code of
practice 304.
The Mass in Running Order (MRO) comprises:
1. The mass of the empty caravan as supplied by
Swift including loose items such as the hook-up
cable, kit bag, entrance step, manuals etc.
2. 10kg allowance for LPG
The MRO is calculated with the fresh water tank,


tank and the water heater the payload will reduce
accordingly.

berths and the length of the caravan and includes an
allowance of 20kg for a leisure battery.
The Maximum Technical Laden Mass (MTPLM) is
the maximum mass allowed when the caravan is
fully laden.
WARNING: Under no circumstances should the
MTPLM be exceeded
Bed Sizes: Please note that the front double bed

chest of drawers. The front double bed width for a

by 0.4m(1’4”) from that stated.
Awning sizes: Due to the varying awning designs
and sizes the awning sizes given are approximate

your dealer or the awning manufacturer prior to
purchase.
Est = Estimated weight or bed size
**The dimensions given are approximate due to
slight variations in suspension ride heights, loading
conditions and tyre pressures.
Customers should verify the actual dimensions of
their touring caravan before committing to anything
that could be impacted by theses dimensions
Please note:
overall payload available to the user of the caravan.
-
grade the MTPLM to the upper limit. Please contact
your caravan dealer for more information.

9

10
Challenger / Eccles Specication (Alde)
Challenger (Alde heating) Challenger 480 Challenger 530 Challenger 560 Challenger 580
Eccles (Alde heating) Eccles 480 Eccles 530 Eccles 560 Eccles 580
Berths 2444
Axles 1111
 4.95m/16'3" 5.29m/17'4" 5.83m/19'2" 5.83m/19'2"
Overall Width** 2.23m/7'4" 2.23m/7'4" 2.23m/7'4" 2.23m/7'4"
Overall Height (inc. TV Aerial)** 2.61m/8'7" 2.61m/8'7" 2.61m/8'7" 2.61m/8'7"
 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5"
Overall Length** 6.66m/21'10" 7.00m/23'0" 7.54m/24'9" 7.54m/24'9"
Awning A/A dimension 9.32m/30'7" 9.66m/31'8" 10.20m/33'6" 10.20m/33'6"
Mass in Running Order
(inc. tolerance) 1262kg/24.8cwt 1325kg/26.1cwt 1389kg/27.3cwt 1362kg/26.8cwt
Maximum Technical Permissible
Laden Mass (Lower limit) 1394kg/27.4cwt 1481kg/29.2cwt 1550kg/30.5cwt 1523kg/30.0cwt
Maximum Technical Permissible
Laden Mass (Upper limit) 1500kg/29.5cwt 1500kg/29.5cwt 1550kg/30.5cwt 1550kg/30.5cwt
Total user Payload 132kg/2.6cwt 156kg/3.1cwt 161kg/3.2cwt 161kg/3.2cwt
 127kg/2.5cwt 151kg/3.0cwt 156kg/3.1cwt 156kg/3.1cwt
Options 5.0kg/0.1cwt 5.0kg/0.1cwt 5.0kg/0.1cwt 5.0kg/0.1cwt
Tyre Size 185 R14C 102Q 185 R14C 102Q 185 R14C 102Q 185 R14C 102Q
Tyre pressure at Lower limit
MTPLM 4.0 bar / 58 psi 4.3 bar / 62 psi 4.5 bar / 65 psi 4.5 bar / 65 psi
Tyre pressure at Upper limit
MTPLM 4.4 bar / 64 psi 4.4 bar / 64 psi 4.5 bar / 65 psi 4.5 bar / 65 psi
Static Load on Coupling Head 100kg 100kg 100kg 100kg
 THREE THREE THREE THREE
Bed Sizes
Front Double 202cm x 186cm/6'8" x 6'1" 202cm x 176cm/6'8" x 5'9" 202cm x 156cm/6'8" x 5'1" 202cm x 156cm/6'8" x 5'1"
or Front Nearside Single 196cm x 72cm/6'4" x 2'4" 176cm x 72cm/5'9" x 2'4" 156cm x 72cm/5'1" x 2'4" 156cm x 72cm/5'1" x 2'4"
 186cm x 72cm/6'1" x 2'4" 186cm x 72cm/6'1" x 2'4" 156cm x 72cm/5'1" x 2'4" 156cm x 72cm/5'1" x 2'4"
Rear Double 190cm x 133cm/6'3" x 4'4" 185cm x 133cm/6'1" x 4'4"
 180cm x 62cm/5'11" x 2'0"
Side Single (nearside)
 176cm x 59cm/5'9" x 1'11"
Side Bunk (nearside)
Side Fixed Lower Bunk
Side Fixed Upper Bunk
Masses: The masses are calculated in accordance
to EU regulation 1230/2012 and NCC code of
practice 304.
The Mass in Running Order (MRO) comprises:
1. The mass of the empty caravan as supplied by
Swift including loose items such as the hook-up
cable, kit bag, entrance step, manuals etc.
2. 10kg allowance for LPG
The MRO is calculated with the fresh water tank,


tank and the water heater the payload will reduce
accordingly.

berths and the length of the caravan and includes an
allowance of 20kg for a leisure battery.
The Maximum Technical Laden Mass (MTPLM) is
the maximum mass allowed when the caravan is
fully laden.
WARNING: Under no circumstances should the
MTPLM be exceeded

11
Challenger 645 Challenger 650
Eccles 645 Eccles 650
4 4
2 2
6.27m/20'7" 6.27m/20'7"
2.23m/7'4" 2.23m/7'4"
2.61m/8'7" 2.61m/8'7"
1.95m/6'5" 1.95m/6'5"
7.98m/26'2" 7.98m/26'2"
10.52m/34'6" 10.52m/34'6"
1516kg/29.8cwt 1544kg/30.4cwt
1681kg/33.1cwt 1709kg/33.6cwt
2000kg/39.4cwt 2000kg/39.4cwt
165kg/3.2cwt 165kg/3.2cwt
160kg/3.1cwt 160kg/3.1cwt
5.0kg/0.1cwt 5.0kg/0.1cwt
185/70 R14 88T 185/70 R14 88T
2.0 bar / 29 psi 2.1 bar / 30 psi
2.5 bar / 36 psi 2.5 bar / 36 psi
100kg 100kg
THREE THREE
202cm x 156cm/6'8" x 5'1" 202cm x 156cm/6'8" x 5'1"
156cm x 72cm/5'1" x 2'4" 156cm x 72cm/5'1" x 2'4"
156cm x 72cm/5'1" x 2'4" 156cm x 72cm/5'1" x 2'4"
185cm x 133cm/6'1" x 4'4" 185cm x 133cm/6'1" x 4'4"
Bed Sizes: Please note that the front double bed

chest of drawers. The front double bed width for a

by 0.4m(1’4”) from that stated.
Awning sizes: Due to the varying awning designs
and sizes the awning sizes given are approximate

your dealer or the awning manufacturer prior to
purchase.
Est = Estimated weight or bed size
**The dimensions given are approximate due to
slight variations in suspension ride heights, loading
conditions and tyre pressures.
Customers should verify the actual dimensions of
their touring caravan before committing to anything
that could be impacted by theses dimensions
Please note:
overall payload available to the user of the caravan.
-
grade the MTPLM to the upper limit. Please contact
your caravan dealer for more information.

12
Challenger X / Eccles X Specication (Alde)
Challenger X (Alde heating) Challenger X 865 Challenger X 880 Challenger X 835 Challenger X 850
Eccles X (Alde heating) Eccles X 865 Eccles X 880 Eccles X 835 Eccles X 850
Berths 4444
Axles 1122
 5.83m/19’2” 5.83m/19’2” 6.27m/20’7” 6.27m/20’7”
Overall Width** 2.45m/8’0” 2.45m/8’0” 2.45m/8’0” 2.45m/8’0”
Overall Height (inc. TV Aerial)** 2.61m/8’7” 2.61m/8’7” 2.59m/8’6” 2.59m/8’6”
 1.95m/6’5” 1.95m/6’5” 1.95m/6’5” 1.95m/6’5”
Overall Length** 7.54m/24’9” 7.54m/24’9” 7.98m/26’2” 7.98m/26’2”
Awning A/A dimension 10.20m/33’6” 10.20m/33’6” 10.52m/34’6” 10.52m/34’6”
Mass in Running Order
(inc. tolerance) 1490kg / 29.3cwt Est 1481kg/29.2cwt 1638kg/32.2cwt 1634kg/32.2cwt
Maximum Technical Permissible
Laden Mass (Lower limit) 1651kg/32.5cwt Est 1642kg/32.3cwt 1803kg/35.5cwt 1799kg/35.4cwt
Maximum Technical Permissible
Laden Mass (Upper limit) 1750kg/34.4cwt 1750kg/34.4cwt 2000kg/39.4cwt 2000.0kg/39.4cwt
Total user Payload 161kg/3.2cwt 161kg/3.2cwt 165kg/3.2cwt 165kg/3.2cwt
 156kg/3.1cwt 156kg/3.1cwt 160kg/3.1cwt 160kg/3.1cwt
Options 5.0kg/0.1cwt 5.0kg/0.1cwt 5.0kg/0.1cwt 5.0kg/0.1cwt
Tyre Size 195/70 R15C 104 R 195/70 R15C 104 R 185/70 R14 88 T 185/70 R14 88 T
Tyre pressure at Lower limit
MTPLM 4.5 bar/65 psi 4.5 bar/65 psi 2.2 bar/32 psi 2.2 bar/32 psi
Tyre pressure at Upper limit
MTPLM 4.5 bar/65 ps 4.5 bar/65 psi 2.5 bar/36 psi 2.5 bar/36 psi
Static Load on Coupling Head 100kg 100kg 100kg 100kg
 THREE THREE THREE THREE
Bed Sizes
Front Double 225cm x 159cm/7’4” x 5’3” 225cm x 159cm/7’4” x 5’3” 225cm x 159cm/7’4” x 5’3” 197cm x 127cm/6’6” x 4’2”
or Front Nearside Single 159cm x 73cm/5’3” x 2’5” 159cm x 73cm/5’3” x 2’5” 159cm x 73cm/5’3” x 2’5”
 159cm x 73cm/5’3” x 2’5” 159cm x 73cm/5’3” x 2’5” 159cm x 73cm/5’3” x 2’5”
Rear Double 187cm x 133cm/6’2” x 4’4” 187cm x 133cm/6’2” x 4’4” 187cm x 143cm/6’2” x 4’8”
 195cm x 81cm/6’5” x 2’8”
Side Single (nearside) 200cm x 81cm/6’8” x 2’8”

Side Bunk (nearside)
Side Fixed Lower Bunk
Side Fixed Upper Bunk
Masses: The masses are calculated in accordance
to EU regulation 1230/2012 and NCC code of
practice 304.
The Mass in Running Order (MRO) comprises:
1. The mass of the empty caravan as supplied by
Swift including loose items such as the hook-up
cable, kit bag, entrance step, manuals etc.
2. 10kg allowance for LPG
The MRO is calculated with the fresh water tank,


tank and the water heater the payload will reduce
accordingly.

berths and the length of the caravan and includes an
allowance of 20kg for a leisure battery.
The Maximum Technical Laden Mass (MTPLM) is
the maximum mass allowed when the caravan is
fully laden.
WARNING: Under no circumstances should the
MTPLM be exceeded

13
Bed Sizes: Please note that the front double bed

chest of drawers. The front double bed width for a

by 0.4m(1’4”) from that stated.
Awning sizes: Due to the varying awning designs
and sizes the awning sizes given are approximate

your dealer or the awning manufacturer prior to
purchase.
Est = Estimated weight or bed size
**The dimensions given are approximate due to
slight variations in suspension ride heights, loading
conditions and tyre pressures.
Customers should verify the actual dimensions of
their touring caravan before committing to anything
that could be impacted by theses dimensions
Please note:
overall payload available to the user of the caravan.
-
grade the MTPLM to the upper limit. Please contact
your caravan dealer for more information.

14
Elegance Specication
Elegance Elegance 480 Elegance 530 Elegance 560 Elegance 565
Berths 2444
Axles 1111
 4.98m/16'4" 5.45m/17'11" 5.93m/19'5" 5.93m/19'5"
Overall Width* 2.28m/7'6" 2.28m/7'6" 2.28m/7'6" 2.28m/7'6"
Overall Height (inc. TV Aerial)* 2.59m/8'6" 2.59m/8'6" 2.59m/8'6" 2.59m/8'6"
 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5"
Overall Length* 6.59m/21'7" 7.07m/23'2" 7.54m/24'9" 7.54m/24'9"
Awning A/A dimension 9.04m/29'8" 9.58m/31'5" 10.05m/33'0" 10.05m/33'0"
Mass in Running Order (inc.
tolerance) 1351kg/26.6cwt 1479kg/29.1cwt 1558kg/30.7cwt 1545kg/30.4cwt
Maximum Technical Permissible
Laden Mass (Lower limit) 1477kg/29.1cwt 1630kg/32.1cwt 1714kg/33.7cwt 1701kg/33.5cwt
Maximum Technical Permissible
Laden Mass (Upper limit) 1500kg/29.5cwt 1650kg/32.5cwt 1750kg/33.4cwt 1750kg/33.4cwt
Total user Payload 126kg/2.5cwt 151kg/3.0cwt 156kg/3.1cwt 156kg/3.1cwt
 126kg/2.5cwt 151kg/3.0cwt 156kg/3.1cwt 156kg/3.1cwt
Options 0.0kg/0.0cwt 0.0kg/0.0cwt 0.0kg/0.0cwt 0.0kg/0.0cwt
Tyre Size 185 R14C 102 Q 195/70 R15C 104 R 195/70 R15C 104 R 195/70 R15C 104 R
Tyre pressure at Lower limit
MTPLM 4.3 bar / 62 psi 4.5 bar / 65 psi 4.5 bar / 65 psi 4.5 bar / 65 psi
Tyre pressure at Upper limit
MTPLM 4.4 bar / 64 psi 4.5 bar / 65 psi 4.5 bar / 65 psi 4.5 bar / 65 psi
Static Load on Coupling Head 100kg 100kg 100kg 100kg
 THREE THREE THREE THREE
Bed Sizes
Front Double 200cm x 178cm/6'7" x 5'10" 200cm x 178cm/6'7" x 5'10" 200cm x 153cm/6'7" x 5'0" 200cm x 163cm/6'7" x 5'4"
or Front Nearside Single 188cm x 67cm/6'2" x 2'2" 178cm x 67cm/5'10" x 2'2" 153cm x 67cm/5'0" x 2'2" 163cm x 67cm/5'4" x 2'2"
 178cm x 67cm/5'10" x 2'2" 188cm x 67cm/6'2" x 2'2" 163cm x 67cm/5'4" x 2'2" 163cm x 67cm/5'4" x 2'2"
Rear Double 190cm x 133cm/6'3" x 4'4"
Rear Bunk
 180cm x 62cm/5'11" x 2'0" 172cm x 75cm/5'8" x 2'6"
Side Single (nearside) 190cm x 75cm/6'3" x 2'6"
 176cm x 59cm/5'9" x 1'11"
Side Fixed Lower Bunk
Side Fixed Upper Bunk
Masses: The masses are calculated in accordance
to EU regulation 1230/2012 and NCC code of
practice 304.
The Mass in Running Order (MRO) comprises:
1. The mass of the empty caravan as supplied by
Swift including loose items such as the hook-up
cable, kit bag, entrance step, manuals etc.
2. 10kg allowance for LPG
The MRO is calculated with the fresh water tank,


tank and the water heater the payload will reduce
accordingly.

berths and the length of the caravan and includes an
allowance of 20kg for a leisure battery.
The Maximum Technical Laden Mass (MTPLM) is
the maximum mass allowed when the caravan is
fully laden.
WARNING: Under no circumstances should the
MTPLM be exceeded

15
Elegance 580 Elegance 645 Elegance 650
444
122
5.93m/19'5" 6.36m/20'10" 6.36m/20'10"
2.28m/7'6" 2.28m/7'6" 2.28m/7'6"
2.59m/8'6" 2.59m/8'6" 2.59m/8'6"
1.95m/6'5" 1.95m/6'5" 1.95m/6'5"
7.54m/24'9" 7.98m/26'2" 7.98m/26'2"
10.05m/33'0" 10.49m/34'5" 10.49m/34'5"
1530kg/30.1cwt 1643kg/32.3cwt 1670kg/32.9cwt
1686kg/33.2cwt 1803kg/35.5cwt 1830kg/36.0cwt
1750kg/33.4cwt 2000kg/39.4cwt 2000kg/39.4cwt
156kg/3.1cwt 160kg/3.1cwt 160kg/3.1cwt
156kg/3.1cwt 160kg/3.1cwt 160kg/3.1cwt
0.0kg/0.0cwt 0.0kg/0.0cwt 0.0kg/0.0cwt
195/70 R15C 104 R 185/70 R14 88 T 185/70 R14 88 T
4.5 bar / 65 psi 2.2 bar / 32 psi 2.2 bar / 32 psi
4.5 bar / 65 psi 2.5 bar / 36 psi 2.5 bar / 36 psi
100kg 100kg 100kg
THREE THREE THREE
200cm x 163cm/6'7" x 5'4" 200cm x 153cm/6'7" x 5'0" 200cm x 163cm/6'7" x 5'4"
163cm x 67cm/5'4" x 2'2" 153cm x 67cm/5'0" x 2'2" 163cm x 67cm/5'4" x 2'2"
163cm x 67cm/5'4" x 2'2" 153cm x 67cm/5'0" x 2'2" 163cm x 67cm/5’4” x 2’2”
182cm x 133cm/6'0" x 4'4" 182cm x 133cm/6'0" x 4'4" 182cm x 133cm/6'0" x 4'4"
Bed Sizes: Please note that the front double bed

chest of drawers. The front double bed width for a

by 0.4m(1’4”) from that stated.
Awning sizes: Due to the varying awning designs
and sizes the awning sizes given are approximate

your dealer or the awning manufacturer prior to
purchase.
Est = Estimated weight or bed size
**The dimensions given are approximate due to
slight variations in suspension ride heights, loading
conditions and tyre pressures.
Customers should verify the actual dimensions of
their touring caravan before committing to anything
that could be impacted by theses dimensions
Please note:
overall payload available to the user of the caravan.
-
grade the MTPLM to the upper limit. Please contact
your caravan dealer for more information.

16
Elegance Grande Specication
Elegance Elegance Grande 835 Elegance Grande 845 Elegance Grande 850
Berths 446
Axles 222
 6.36m/20'10" 6.36m/20'10" 6.36m/20'10"
Overall Width* 2.45m/8'0" 2.45m/8'0" 2.45m/8'0"
Overall Height (inc. TV Aerial)* 2.59m/8'6" 2.59m/8'6" 2.59m/8'6"
 1.95m/6'5" 1.95m/6'5" 1.95m/6'5"
Overall Length* 7.98m/26'2" 7.98m/26'2" 7.98m/26'2"
Awning A/A dimension 10.49m/34'5" 10.49m/34'5" 10.49m/34'5"
Mass in Running Order (inc. tolerance) 1745kg/34.3cwt 1710kg/33.7cwt 1740kg/34.3cwt
Maximum Technical Permissible Laden
Mass (Lower limit) 1905kg/37.5cwt 1870kg/36.5cwt 1900kg/37.4cwt
Maximum Technical Permissible Laden
Mass (Upper limit) 2000kg/39.4cwt 2000kg/39.4cwt 2000kg/39.4cwt
Total user Payload 160kg/3.1cwt 160kg/3.1cwt 160kg/3.1cwt
 160kg/3.1cwt 160kg/3.1cwt 160kg/3.1cwt
Options 0.0kg/0.0cwt 0.0kg/0.0cwt 0.0kg/0.0cwt
Tyre Size 185/70 R14 88 T 185/70 R14 88 T 185/70 R14 88 T
Tyre pressure at Lower limit MTPLM 2.3 bar / 33 psi 2.3 bar / 33 psi 2.3 bar / 33 psi
Tyre pressure at Upper limit MTPLM 2.5 bar / 36 psi 2.5 bar / 36 psi 2.5 bar / 36 psi
Static Load on Coupling Head 100kg 100kg 100kg
 THREE THREE THREE
Bed Sizes
Front Double 218cm x 153cm/7'2" x 5'0" 218cm x 153cm/7'2" x 5'0" 194cm x 121cm/6’4” x 4’0”
Side Double
or Front Nearside Single 153cm x 70cm/5'0" x 2'4" 153cm x 70cm/5'0" x 2'4"
 153cm x 70cm/5'0" x 2'4" 153cm x 70cm/5'0" x 2'4"
Rear Double 184cm x 133cm/6'0" x 4'4" 184cm x 133cm/6'0" x 4'4" 189cm x 143cm/6’2” x 4’8”
Rear Bunk
Side Fixed Lower Bunk Single (nearside)
Side Fixed Upper Bunk Single (nearside)
Masses: The masses are calculated in accordance
to EU regulation 1230/2012 and NCC code of
practice 304.
The Mass in Running Order (MRO) comprises:
1. The mass of the empty caravan as supplied by
Swift including loose items such as the hook-up
cable, kit bag, entrance step, manuals etc.
2. 10kg allowance for LPG
The MRO is calculated with the fresh water tank,


tank and the water heater the payload will reduce
accordingly.

berths and the length of the caravan and includes an
allowance of 20kg for a leisure battery.
The Maximum Technical Laden Mass (MTPLM) is
the maximum mass allowed when the caravan is
fully laden.
WARNING: Under no circumstances should the
MTPLM be exceeded

17
Bed Sizes: Please note that the front double bed

chest of drawers. The front double bed width for a

by 0.4m(1’4”) from that stated.
Awning sizes: Due to the varying awning designs
and sizes the awning sizes given are approximate

your dealer or the awning manufacturer prior to
purchase.
Est = Estimated weight or bed size
**The dimensions given are approximate due to
slight variations in suspension ride heights, loading
conditions and tyre pressures.
Customers should verify the actual dimensions of
their touring caravan before committing to anything
that could be impacted by theses dimensions
Please note:
overall payload available to the user of the caravan.
-
grade the MTPLM to the upper limit. Please contact
your caravan dealer for more information.

18
Wiring Diagrams - Road Lighting
Basecamp

19
Option
FB4
FB3
O
R
U
G
Fuse Unit part number C44
NY
B
W
Copyright Sargent Electrical Services Ltd. 2017 allrightsreserved. Subjecttochangewithout priornotice.
FC1
Pin3 Negative W
Road Lighting
Swift Caravans
SARGENT ELECTRICAL SERVICES LTDIssue 2 14/06/18
HIGH
LEVEL
BRAKE
L1 L2
L3
L4
Brake lamp
O/SIndicator lamp
O/STaillamp
O/SFogllamp
Seeseparatesheet for cablecolour chart
Dual coloured cables show in primary colour
Whitecablesshown in Black
FC1is the rear panelconnector
FC2isthe alarmconnector
Not alllights are fittedsome models
LED LED
LED
LED
L5
L6
L7
L8
Reverselamp
Brake lamp
N/SIndicatorl lamp
LED
N/S Tail lamp
LED
LED
LED
L9
L11
FoglampLED
Number plate lamp LED
L12 L13
Number plate lamp LED
N/S rearmarker lamp LED
L14
L15
O/S rear marker lamp LED
N/Sfront marker lamp LED
L16LED L17
O/S front marker lamp
LEDHigh level brake lamp
1
35
7
42
11446Plug
Connector
98
13
6
10
12
11
FB6
WUY GBRN
FB7
W/R
O
S
W/B
K
AS310
ALARM
SYSTEM
ALKO
ATC
FB5
W/O
N/G
FB1
FB2
ALKO ATC
R
G
M
ATC
ALKO
ATC
Status Ind
W
B
N
L19-22 LEDN/SSidemarker lamp
L23-26 LED
O/SSide marker lamp
W/G
PSU X5 -1
L19 L20L21 L22
L24 L25L26
L23
N/P
PSU E4 -10
L17
L14 L13
NUMBER PLATE
L12L11
O/SLIGHT CLUSTER
L5
L4
L3
L2
L1
STOP
INDICATORFOG
TAIL REVERSE
N/SLIGHT CLUSTER
L10
L9
L8
L7
L6
STOP
INDICATORFOG
TAIL REVERSE
Option
L10Reverselamp LED
L15 L16
B
N
W
Wiring Diagrams - Road Lighting
Sprite, Sprite Super, Challenger, Eccles, Challenger X, Eccles X, Elegance
& Elegance Grande

20
Wiring Diagrams - Consumer Circuits
Basecamp

21
Option
B/R
Option
Heating
Copyright SargentElectricalServicesLtd.2017all rights reserved. Subjecttochange withoutprior notice.
Consumer Circuits – Floorwith Combi
SwiftCaravans
SARGENTELECTRICALSERVICES LTD Issue 02 14/06/18
PSUpart numberEC602
E1 9 WAY
Pin13NegativeW/O
Electronic
oven/hob
W/O
Y/G
M
Pressure
switch
Pump
Internal Water
z
Y/W
12v socket
W/O
Y/W
12vsocket
P/B
W/O
Y/W
E3 6 WAY
Combiheater
W/O
M
Seeseparatesheet forcable
colour chart
Dual colouredcablesshowin
primary colour
Whitecables showninBlack
12vsocketpositions dependanton
layout
W/O
Singleswitch
W/O W/O
E2 12 WAY
S
Option
K
Singleswitch
W/O
M
Toilet
switch
P
E4 12WAY
W/O
WalkwaySwitchWalkwaySwitch
M
CIBusCIBus CIBusCIBus
ATC
ALKO
B/R
W/O
Combiheater
control
T
Y
Thermostat
Y
RJ12
Coupler
RJ12
Coupler
S/OK/N
WL19 WL21
WL20 WL22
LED
WL19-20 WL21-22
Walkwayfront lamp
Walkwayrear lamp
USBSocket
Wiring Diagrams - Consumer Circuits
Floor with Combi heating:
Sprite and Sprite Super
