Leisure UNITY FX 2023 User manual

2023 MANUAL
FX

MODEL SPECIFIC MANUAL TABLE OF CONTENTS
REV September 22, 2022 i
TABLE OF CONTENTS
1. INTRODUCTION
Supplemental Manual 11
Motorhome Information Kit 12
Options and Equipment 12
Service Assistance 12
Reporting Safety Defects 13
2. GENERAL INFORMATION
Floor Plan 21
Exterior Equipment Location 23
Beds and Seating 25
Leisure Lounge Seating 25
Lowering the Murphy Bed 26
Raising the Murphy Bed 26
TV Location 26
3. SCHEMATICS
Electrical 31
12 volt Electrical Reference 31
120 Volt Electrical Reference 32
Electrical Schematic 33
Plumbing 39
Water lines schematic 39
Drain line schematic 310
Entertainment 311
Satellite Pre-wire 312

MODEL SPECIFIC MANUAL 1. INTRODUCTION
REV September 22, 2022 11
1. INTRODUCTION
Congratulations! Thank you for selecting a Leisure
Travel Vans Motorhome.
Welcome to the exciting world of motorhome travel
and camping, with all the comforts of home with you,
while you travel and enjoy the outdoors.
Your motorhome has been designed and manufactured
to enhance your travel and camping experience and
to provide you with safe, ecient and trouble-free
operation.
Before your first drive, become familiar with the
operation of the vehicle chassis and all functions and
operations of the motorhome. Spend adequate time
with your dealer when you take delivery to learn all
you can about your new motorhome.
SUPPLEMENTAL MANUAL
This manual was prepared to aid the operator and
occupants in the operation and care ofthe motorhome
by giving specic information about your model. There
are many options to Leisure Travel Vans, so ensure
that you are familiar with your motorhome’s systems
and equipment. All operators and occupants of the
motorhome should read, understand and follow
the instructions in this manual, the vehicle chassis
manual &the information contained in the Motorhome
Information Kit provided with your new motorhome.
Your motorhome contains a number of systems,
components, equipment, and appliances manufactured
by vendors that supply components for Triple E RV.
These vendors are unrelated to Triple E RV.
Before operating the motorhome for the rst time –
even if an experienced motorhome operator – read
and become familiar with all of the relevant manuals
to your motorhome, components, equipment and
appliances provided in the Motorhome Information
Kit. Your familiarity with the detailed operation of
your motorhome will assist in your safe, ecient and
trouble-free motorhome operation.
KEEP the Motorhome Information Kit within your
motorhome for readily available reference.
PASS this manual, the Chassis Operation Manual and
the Motorhome Information Kit to any subsequent
operator or owner.
For clarication or further details on any of the enclosed
information, please contact:
Your Leisure Travel Vans Dealer orTriple E RV Customer
Service at:
Email: [e-mail]
Toll Free: 8779929906
Telephone: 2043254361
Fax: 2043255241

1. INTRODUCTION MODEL SPECIFIC MANUAL
12 REV September 22, 2022
MOTORHOME INFORMATION KIT
The Motorhome Information Kit includes but isn’t
limited to information on the components, equipment
and appliances listed below (based on options
selected).
•Refrigerator
•Stove top
•Furnace
•Electrical Panel
•Toilet
•Water Heater
•Water Pump
•Water Filtration
•Vent (roof)
•Fire Extinguisher
•Smoke Detector
•Thermostat
•CO Detector
•Propane Detector
•Gas Regulator
•TV Antenna
•TV/DVD
•Chassis
•Air Conditioner
•Generator
•Stabilizers/Leveling Jacks
•Rear View Monitor
•Inverter
•Entertainment System
•Safety
•Flooring and Countertops
•Electric Step
•Solar Panel
•Surge Protector
•Safe
•Awning
OPTIONS AND EQUIPMENT
Leisure Travel Vans are available in various sizes
and floor plan configurations and with differing
optional equipment. The equipment, accessories and
components described in this manual may not apply
in all respects to your motorhome. Read the material
and manuals provided in the Motorhome Information
Kit for detailed instructions regarding the equipment
specic to your motorhome.
SERVICE ASSISTANCE
Your dealer will assist you with any additional
information you need and will answer any questions
you have about the operation of your motorhome.
When it’s time to service the vehicle, remember
that your dealer knows your motorhome best and is
dedicated to your satisfaction. Your dealer will provide
quality maintenance and assistance during your period
ownership. Triple E RV strongly recommends that you
follow a regular maintenance schedule to keep your
motorhome functioning at its best.
Call the following numbers if you require warranty
assistance while traveling:
Triple E RV: 1-877-992-9906
Canada Sprinter Customer Service:
1-800-387-0100 www.thesprinter.ca
US Sprinter Customer Service:
1-877-762-8267 www.mbsprinterusa.com
Canada Ford Customer Service:
1-800-565-3673 www.ford.ca
US Ford Customer Service:
1-800-392-3673 www.ford.com
Emergency Roadside Service* Call:
1-877-219-3831
4287 Beltline Road, Box 198
Addison, Texas 75001
*This Emergency Roadside Service is available to
owner of the motorhome during the rst two years
after purchase.

MODEL SPECIFIC MANUAL 1. INTRODUCTION
REV September 22, 2022 13
REPORTING SAFETY DEFECTS
If you suspect your motorhome has a safety defect
that could cause injury or death, immediately contact
Triple E RV. Also, contact the National Highway Trac
Safety Administration (NHTSA) in the US or Transport
Canada to report your concern.
NHTSA will investigate the concern if there are a
number of similar complaints. NHTSA has the authority
to order a recall and repair campaign depending on
the nature and severity of the problem.
You can reach the NHTSA by calling the Auto Safety
Hot-line at 18004249393 (2023660123 in the
Washington, DC, area) or by writing to NHTSA, US
Department ofTransportation, Washington, DC 20590.
The hot-line also will provide you with additional
information on motor vehicle safety.
In Canada, call 18003330510 or write to Transport
Canada and Road Safety, 2780 Sheeld Road, Ottawa,
Ontario K1B 3V9.

MODEL SPECIFIC MANUAL
REV September 22, 2022 21
2. GENERAL INFORMATION
FLOOR PLAN
U24FX
123
4
5
6
7
89
10
11
12
13
14
15
16
46
17
18
20
21
27
28
43 26
22
29
32 33
34
30
31
2324
35
36
37 38
39
40
42
41
19
25 4544 25
48
49
7
50
51
52
1Macerator Option Under Floor
2Utility Center Under Floor
3Shore Power Plug
4Sewer Hose Under Slide Out
5ULounge Dinette
6Generator Option Under Floor
7USB Plug
8Propane/CMD Alarm
9
Chassis Battery Under Cab Floor
10 100Amp Fuse Location
11 12 Volt plug/ USB Plug
12 Swivel Seats
13 Smoke Alarm on Ceiling
14
Awning Switches and Relay
Under Seat
15 DC/DC Charger Under Seat
16 Wardrobe
17 Fire Extinguisher
18
Battery Disconnect Switch on
Cabinet Wall
19 Breaker Panel
20 Step, slideout 5amp, and option
Battery heat 2amp fuses Behind
Breaker Panel
21 Inverter In Compartment Under
Floor
22 Water Heater Under Galley
23 Furnace Under Sofa
24 Egress Window
25
Exterior BBQ Connection Under
Floor
26 TV
27
Coach Battery’s Under Floor
(Solar panel 15/30amp fuse behind)
28 Galley
29
Slide Out Control Module Under
Galley
30 Pantry
31 Sofa
32
Water Tank/Drain and Water
Pump Under Floor
33
Generator Transfer Switch Under
Sofa
34 Surge Protector Under Sofa
35 Propane Tank Under Floor
36
Tank Flush Non Return Valve
Behind Bedroom Shelf
37 USB Plug Below O/H Cabinet
38 Shower
39 Water Filter in Vanity
40 Toilet
41 Wardrobe
42 Fridge(2amp fuse behind vent)
43 Microwave
44
Solar Controller, Inverter Remote,
and Water Heater Dial above
Entrance Door
45
Satellite Option Prewire and
Component Connection Plate in
Overhead Cabinet
46
BluRay Player and HDMI Switcher
TV Antenna Booster/WIFI Switch
in Overhead cabinet
47 Seatbelt
48
MultiPlex G12 Panel Above Pantry
49 MultiPlex Display
50 Murphy Bed
51 Ottoman
52
Battery Power and Ignition Fuses
under Driver Seat

2. GENERAL INFORMATION MODEL SPECIFIC MANUAL
22 REV September 22, 2022

MODEL SPECIFIC MANUAL
REV September 22, 2022 23
EXTERIOR EQUIPMENT LOCATION
PASSENGER SIDE VIEW
1Light
2
Inverterand Storage Compartment
3External Receptacle
4Awning
5Generator Compartment
6BBQ Hook-Up
7Storage Compartment
8Entrance Step
9Furnace Exhaust
10 Water Heater
11 Ladder (Optional)
1
2
3
4
6
67
75 8
9
10
11
DRIVER SIDE VIEW
1Refrigerator Vents
2Awning
3Diesel Fill
4Storage Compartment
5Sewer Hose (Behind Doors)
6Shore Power Connection
7Utility Center
8Slide Out Room
9Sewer Termination
11
2
3 44
567
8
9

2. GENERAL INFORMATION MODEL SPECIFIC MANUAL
24 REV September 22, 2022
TOP VIEW
1Solar Panels (Optional)
2Roof Vent
3Skylight
4Stack Vent
5Satellite (Optional)
6A/C
7TV/WiFi Antenna
11
11 2
2
3
3
4
4
56 7

MODEL SPECIFIC MANUAL
REV September 22, 2022 25
BEDS AND SEATING
LEISURE LOUNGE SEATING
1. Bench conguration 1.
1
2. Seats with table conguration 2.
2
3. Seats pulled out (Pull out seats before lowering
Murphy bed) 3.
3
4. Bed down with the headboard tilted out as
backrest 4.
4
5. Rear seating (lock ottoman to prevent movement
while the vehicle is in motion) 5.
5
6
ᘐCAUTION
Lock ottoman
6
in its storage position to prevent
movement while operating motorhome.

2. GENERAL INFORMATION MODEL SPECIFIC MANUAL
26 REV September 22, 2022
LOWERING THE MURPHY BED
RAISING THE MURPHY BED
TV LOCATION
In the Unity FX, the TVs are located in the bedroom area
4, and in the front of the couch beside the entrance
door
5
. They are locked in position when traveling.
To unlock the front TV, ip up the release latch
7
and
reposition.
4 5
7
NOTE: It is possible to position the front TV so it can
be viewed from the forward coach living area.
To store the TV, fold the TV back to stored position
and secure with the latch.
NOTE: When traveling, ensure the TV is latched in the
stored position.

MODEL SPECIFIC MANUAL 3. SCHEMATICS
REV September 22, 2022 31
3. SCHEMATICS
ELECTRICAL
12 VOLT ELECTRICAL REFERENCE
U24FX 12V ELECTRICAL WIRING SCHEMATIC
PLEASE REFER TO FUSE PANEL LABELS FOR EXACT LAYOUT
*BATTERY HEAT SWITCH ONLY AVAILABLE WITH LITHIUM BATTERIES **LVD ONLY REQUIRED WITH AGM BATTERIES
120V
CIRCUIT
BREAKERS
20
30
30 30
1515 15 15
120V
SUBPANEL
1
2
7
9
6
10
4
4
327
8
11
12
13
14
16
19
20
21
22
24
15
5
23
26
18
1Macerator Pump (Optional)
2Water Pump
3Water Heater
4
Power Roof Vent (Washroom/Galley)
5Multiplex System
6Winegard Connect 2.0
7Satellite Dish (Optional)
8Furnace
9Fridge
10 DC Fuse Panel
11 Air Conditioner
12 USB Chargers
13 Light Circuits
14 Inverter
15 120V AC Power Input
16 AGM Low Voltage Disconnect
17 RV Batteries
18 Solar Charge Controller
19 DC/DC Charger
20 Chassis Battery
21 Awning
22 Battery Disconnect
23
Lithium Battery Heat Enable Switch
(Optional)
24
Solar Panels (200W or 400W
Optional)
25 Generator (Optional)
26 Leveling Jacks (Optional)
27 Slide Module

3. SCHEMATICS MODEL SPECIFIC MANUAL
32 REV September 22, 2022
120 VOLT ELECTRICAL REFERENCE
U24FX 30 AMP 120V ELECTRICAL WIRING SCHEMATIC
PLEASE REFER TO BREAKER PANEL LABELS FOR EXACT LAYOUT
10
11
14
9
13
2
6
7
8
5
4
1
3
12
12
11
14
15
16
1AC Distribution Panel
2Air Conditioner
3Inverter/Charger
4Fridge
5Microwave
6Surge Protector
7Transfer Switch
8Generator
9
Generator Current Switch (Diesel
Option)
10 Lower Galley Receptacle
11 TV Receptacle
12 Lounge Receptacle
13 Washroom Receptacle
14 Entertainment Receptacle
15 Bed Receptacle
16 Exterior Receptacle

MODEL SPECIFIC MANUAL 3. SCHEMATICS
REV September 22, 2022 33
ELECTRICAL SCHEMATIC
PANEL GROUND CHASSIS GROUND
A
DOOR
SWITCH
ENTRANCE
STEP
OVERRIDE
A
BATTERY IGNITION
FUSE
#4
FUSE
#24
ENGINE
RUNNING
MERCEDES POWER SUPPLY
UNDER DRIVER SEAT
SPRINTER
ROOF
ANT
REAR
VIEW CAM
BATTERY
DISCONNECT
MANUAL
250A
COURTESY
LIGHTS
DR
PS
ENTRANCE
DOOR
ACTUATOR
PSM MODULE
IN DRV.
PEDESTAL
21 PIN PLUG
PSM
EXTENSION
12V COACH BATTERY
12V CHASSIS BATTERY
OPTIONAL
EQUALIZER
AUTO-LEVEL
SYSTEM
A
PARKBRAKE
SWITCH
21 PIN PLUG
PSM
EXTENSION
SPRINTER
ROOF
ANT
PANELGROUND
BATTERY
HEAT SW OPT.
PANEL
GROUND
SOLAR PANEL
OPT. 200W OPT. 400W
ROOF CAP
SOLAR CONTROLLER
B
G
H
DY
F
22-18AWG
#10
22-18AWG
#10
E
E
18 AWG YEL
1707
12 AWG ORG
1701
1701
12 AWG ORG
1700
12 AWG WHT
TO SHEET 1
18 AWG WHT
GREEN
YELLOW
BROWN
5702
16 AWG ORG
1 AWG WHT
1705
RED
WHITE 16 AWG ORG
1703 1701A
STEP
ELECTRIC
PURPLE
16 AWG ORG
5702
16 AWG ORG
5A 5A
FAC TO RY
RADIO
FAKRA "A" BLACK ANTENNA EXTENSION
6001 8AWG RED
1/0 AWG RED
2/0 AWG RED
1701
12 AWG ORG
6 AWG WHITE
6 AWG RED
4 AWG RED
20 AMP AUTO RESET
TYPE I
STEP BREAKER
2/0 AWG RED (DIESEL)
6 AWG RED
6 AWG WHITE
2/0 AWG RED
2/0 AWG BLK
16 AWG ORG
2602
16 AWG WHT
2600
16 AWG ORG
7804
16 AWG ORG
7803
PIN 5
PIN 3
PIN 20
4 AWG RED
4 AWG RED
4 AWG BLK
FAKRA "C" BLUE GPS EXTENSION
FAKRA "E" GREEN EXTENSION
CONNECTION IN DRIVER PEDESTAL
CONNECTION BEHIND CAB READING LT'S
VENDOR WIRE-IGN SIGNAL
18 AWG PINK
VENDOR WIRE-PARKBRAKE SIGNAL
VENDOR WIRE-PARKBRAKE SIGNAL
18 AWG BLK/YEL
18 AWG WHT
FAKRA "D"TEL BORDEAUX
CONNECTION BEHIND REAR CAMERA
CAMERA PWR & CANBUS
COAX 50 OHM LMR-100A
1/0 AWG BLK
6 AWG WHITE
2/0 AWG BLK (DIESEL)
DIESEL REMOTE MANUFACTURER
HARNESS
DIESEL GEN OPT
INVERTER/CHARGER
XANTREX
FREEDOM
XC 2000W
6 AWG WHT
4 AWG RED
INOUT
REM
ALARM
GND
PROG
4 AWG RED
LVD GND
BLK FACTORYSUPPLIED
VICTRON LVD BP/100DVCDV
STD. N./RWITH LITHIUM BATT.
18 AWG YEL
8601
COACH BATTERIES
2/0 AWG BLACK
2/0 AWG RED
AGM
6 VOLT
AGM
6 VOLT
STANDARD AGM
OPT. LITHIUM
BBGC2H
LITHIUM
12
VOLT
BATTERRY
BBGC2H
LITHIUM
12
VOLT
BATTERRY
18 AWG YEL
8602A
18 AWG YEL
8602
18 AWG YEL
8602
6000 8AWG WHT
AMP/
VOLT
BATTERY
TYPE
HOLDFOR3 SEC.
FORSETTINGS
SOLARCHARGE
CONTROLLER
30AMP
12/24VOLT
CHARGINGSTATUS BATTERY CONDITION
ZS-30A
ZAMPSOLAR
6011 8AWG RED
6010 8AWG WHT
REDARC
RED
YELLOW
CAP AND TAPE
BLACK
BROWN
BLUE
GREEN
ORANGE
C6-B
0702
C6-C
C6-F
0701
0703
SHEET 3
GENERATOR
SHEET 3
0716
WHITE
TO SHEET 3
SHEET 3
5 Amp
FUSE
SHEET 3
18 AWG YEL
0706
18 AWG YEL
8901
5701
16 AWG ORG
1700A
SHEET 1
18 AWG YEL
1701A
SHEET 1
ELECTRIC STEP SAFETY SWITCH
JACKS SAFETY RETRACT
FRIDGE D+
AWNING SAFETY RELAY
DC/DC CHARGER
G12 CHASSIS VOLTAGE
80A
100A 100A 200A 100A
30A OPT
FACTORYSUPPLIED
F150/4

3. SCHEMATICS MODEL SPECIFIC MANUAL
34 REV September 22, 2022
!GENTITLE-RU!GENTITLE-MAX
HEATING PAD
GREY TANK
127-9307
HEATING PAD
BLACK TANK
127-9307
HEATINGPAD
FRESH TANK
127-9311
HEATINGPAD
FRESH TANK
127-9311
M M
SLIDE
SWITCH
12V COACH BATTERY FUSE BLOCK
12V CHASSIS BATTERY
PANEL GROUND
CHASSIS GROUND
A
VA
IGNITION
SHUT OFF
RELAY
M
CONTROL MOD.
AWNING
AWNING
SWITCH
WATER
HEATER
TRUMA
STANDARD
LED
WIFI
PWR
SW.
ANT
PWR
SW.
CT
PD
W
16 AWG YEL
8401
7.5A
GRAYTANK SW
4901 GRAY
10 AWG YEL
4903 GRAY
10 AWG YEL
4900 GRAY
10 AWG WHT
15A
BLACK TANK
SW
4901 BLACK
10 AWG YEL
4904 BLACK
10 AWG YEL
4900 BLACK
10 AWG WHT
15A
SLIDE READING LT
#43x2
SLIDE READING LT
16 AWG WHT
8400
FRESH TANK
SW
4901 FRESH
10 AWG YEL
4902 FRESH
10 AWG YEL
4900 FRESH
10 AWG WHT
15A
1 Amp 2.1 Amp 1 Amp 2.1 Amp 1 Amp 2.1 Amp
FRONT PILLAR BED ARMREST
SOFA
SLIDE HARNESS
SLIDE HARNESS
10 AWG WHT
5500
18 AWG YEL
5505
18 AWG YEL
5504 10 AWG YEL
5501
18 AWG YEL
5506
SLIDE OUT
CONTROL MODULE
5 Amp
FUSE
30 Amp AUTO RESET
TYPE I
0100
18 AWG WHT
18 AWG YEL
0101
8AWG RED
1301
1300
REFRIGERATOR
TO SHEET 1
16 AWG ORG
5702
0105
PROPANESHUT OFF
8AWGWHT
2 Amp
FUSE
20A5A
16 AWG YEL
8101
10 AWG YEL
8100
10 AWG WHT
MACERATOR
OPT.
20 Amp AUTO RESET
TYPE I
16 AWG WHT
7401A
14 AWG YEL
5700B
15A
7405 (EXT)
16 AWG YEL 7409 (COM)
18 AWG YEL
RED
BLACK
7402
12 AWG YEL
7401
12 AWG YEL
7408 (RET)
18 AWG YEL
7406 (EXT)
18 AWG YEL
7400
12 AWG WHT
16 AWG WHT
1100 BLACK 1101
16 AWG YEL
RED
7.5A
OFF
Eco
Clean
0601
18 AWG YEL
0600
18 AWG WHT
3A
TV1
OUTPUT
FRONTVIEW
WINEGARD
CONNECT
2.0
0600A
18 AWG WHT
0602
18 AWG YEL
WINEGARD
CONNECT 2.0
4G LTE+ WIFI EXTENDER with
TV/FM ANTENNA
COOK TOP
8801
18 AWG YEL
8800
18 AWG WHT
1A
5600
14 AWG WHT
7.5A
FURNACE
5601
12 AWG YEL
18 AWG YEL
5603 SHEET 3
PROPANE DETECTOR
PASSENGERSIDE WARDROBE LIGHT
0501
10 AWG YEL
TOILET
0500
10 AWG WHT
25A
FLOATSW GND
16 AWG WHT
3402
16 AWG YEL
BLACK TANKFLOAT SW
DRIVER SIDE WARDROBELIGHT
OPTIONAL HEATING PADS
87 30
86 85
87A

MODEL SPECIFIC MANUAL 3. SCHEMATICS
REV September 22, 2022 35
!GENTITLE-RU!GENTITLE-MAX
CHASSIS GROUND PANEL GROUND
12V CHASSIS BATTERY
12V COACH BATTERY FUSE BLOCK
P
PANEL GROUND
F
UTILITY SW
B
PANELGROUND
Y
M M
W
SeeLeveL
SOUL
708-RVC
B
D
SHOWER LIGHT
7407
16 AWG YEL
7400A
16 AWG WHT
16 AWG YEL
1017
16 AWG YEL
3101
16 AWG WHT
3100
LP GAS
SENDING UNIT
WINEGARD
RoadTrip
T4
8500
14 AWG WHT
G12 MULTIPLEX UNIT
LPG TANK
LPG GND
J4 HIGH CURRENT OUTPUTS
1
2 3
4
5 6 7 8
9
10
11
12 13
14
15
AWNING LIGHT 2A
UTILITY/STORAGE LIGHT 4A
ASSIST HANDLE/STEP LIGHT 4A
INVERTER LOCKOUT (CONSTANT) 4A
SHOWER LIGHT (ON ATSTART UP) 4A
SAT DISH POWER 6A
J3 HIGH CURRENT OUTPUTS
1
2 3
4
5 6 7 8
9
WASHROOM CEILING 4A
FRONT CEILING 6A
REAR LOUNGE CEILING 4A
GALLEY/DINETTE TRACK 4A
BED/BED D/S TRACK 4A
ACCENT LIGHTS 6A
BED P/S TRACK RTB/FTB ONLY4A
PORCH LIGHT 4A
16 AWG YEL
1004
1707
16 AWG YEL
14 AWG YEL
1602
8502
14 AWG YEL
OPTIONAL
18 AWG YEL
1012
16 AWG YEL
1002
1007
16 AWG YEL
9102
5701
SHEET 1
16 AWG YEL
1008
18 AWG YEL
1006
16 AWG YEL
1009
16 AWG YEL
1015
x2 x9
16 AWG ORG
16 AWG WHT
0100
INVERTER
14 AWG WHT
1600
0100A
16 AWG WHT
1018
18 AWG YEL
0100
18 AWG WHT
16 AWG WHT
0100
16 AWG WHT
0100(x)
16 AWG WHT
0100(x)
16 AWG WHT
0100(x)
16 AWG WHT
0100(x)
16 AWG WHT
0100(x)
16 AWG YEL
1005
16 AWG WHT
0100(x)
LOUNGE TRACKRL'S ONLY 4A 16 AWG YEL
1021
16 AWG WHT
0100(x)
J13 LPG
1
2 4 3 5
6
CHASSIS VOLTAGE GEN RUN INPUT
WATER PUMP 10A
1600
18 AWG WHT
1603
18 AWG YEL
J6 POWER (M8 BOLT)
J5 INPUTS
1
0702
0701
J12 THERMISTORS
1 THERMISTOR 1 PWR
7 THERMISTOR 1 GND
J10 HALF BRIDGES
1 10 GEN START (DIESEL; UNITY'S ONLY) 11 GEN START 12 GEN STOP
18 AWG YEL
5603
SHEET 1
AC
TOUCH
SCREEN
8901
5605
5604
16 AWG ORG 16 AWG ORG
18 AWG YEL
1001
8 AWG RED
1000
8 AWG WHT
18 AWG WHT
18 AWG YEL
RVC NETWORK CABLE
RVC NETWORK CABLE
MIRA
BLUETOOTH
RVC NETWORK CABLE
SHEET 1
J17
REAL TIME CLOCK (RTC) INPUT
WATER PUMP
J7 GND (M6 BOLT)
BATH POWER VENT
GALLEY POWER VENT
0300
14 AWG WHT
1
2 3
4
5 6 7 8
J8 VENTS
GALLEY FAN SPEED GALLEY FAN UP GALLEY FAN DOWN
BATH FAN SPEED BATH FAN UP BATH FAN DOWN
0302
18 AWG YEL
0303
18 AWG YEL
0304
18 AWG YEL
0312
18 AWG YEL
0313
18 AWG YEL
0314
18 AWG YEL
RVC 3M NETWORK PORTS
RVC MINIFIT JR INPUT
40A AUTO RESET
TYPE I
RVC NETWORK CABLE
SHEET 2
FRESH TANK
18 AWG YEL
3201
RED +12V MAIN PWR
BLUE SENDERS
PURPLE CAN-Hi
YELLOW CAN-Lo
BLACK GND
GREEN LPG
GRAYTANK
BLACK TANK
BLACK
BLUE
18 AWG WHT
3500
18 AWG YEL
3501
18 AWG WHT
3300
18 AWG YEL
3301
18 AWG WHT
3400
18 AWG YEL
3401
BLACK
BLUE
BLACK
BLUE
18 AWG YEL
3200
16 AWG WHT
0100(x)
16 AWG WHT
0100(x)
WHT
BLU
BLK
RED
NOT USED
FURNACE CONTROL 4A
0703A
SHEET 1
16 AWG ORG
DIESEL GEN PROPANE GEN
CURRENT SENSOR
SHEET 1
0703
0706
TV O/H LIGHT W24FL ONLY 4A
BED STEP ACCENT W24RTB ONLY

3. SCHEMATICS MODEL SPECIFIC MANUAL
36 REV September 22, 2022
12V CHASSIS BATTERY
12V COACH BATTERY FUSE BLOCK
PANEL GROUND CHASSIS GROUND
12V CHASSIS BATTERY
12V COACH BATTERY FUSE BLOCK
PANEL GROUND CHASSIS GROUND
CHASSIS CONNECTOR
DRIVER SIDE
CHASSIS CONNECTOR
PASSENGER SIDE
FRONT UPPER
CLEARANCE LIGHTS
127-0406
16 AWG ORG
16 AWG WHT
1201
16 AWG ORG
2001L
16 AWG ORG
2804
16 AWG ORG
3601
1200
DRIVER SIDE
SIDE
CLEARANCE
127-0406
16 AWG WHT
18 AWG ORG
2001R
18 AWG ORG
2803
18 AWG ORG
3601R
1200
1
REAR UPPER
CLEARANCE LIGHTS
127-0498
18 AWG ORG
1201E
18 AWG ORG
1200E
16 AWG ORG
1201FR
16 AWG WHT
1200FR
1201
16 AWG ORG
1201A
16 AWG WHT
1200A
16 AWG ORG
ABBREVIATION
BR BROWN
GY GREY
DG DARK GREEN
WHT WHITE
DB DARK BLUE
BLK BLACK
RD RED
SIDE
CLEARANCE
127-0406
TAIL/BRAKE
127-0792
LEFT TURN
127-0793
REVERSE
127-0794
BROWN (GROUND)
RED (BRAKE LIGHT)
WHT/DK BLUE (REVERSE)
BLACK (LEFT SIGNAL)
1234567
GRAY (CLEARANCE LIGHTS)
GY/BR (FOG LT)
GY/DG (LICENSE LT)
LICENSE PLATE LIGHT
127-0857
TAIL/BRAKE
127-0792
RIGHT TURN
127-0793
REVERSE
127-0794
BROWN (GROUND)
WHT/DK BLUE (REVERSE)
GRAY (CLEARANCE LIGHTS)
BLACK (RIGHT SIGNAL)
DARK GREEN (LICENSE)
PASANGER SIDE
234567
GY/BR (FOG LT)
RED (BRAKE LIGHT)
