Swisscom Aton CL114 User manual

/ Schweiz de / Cover_front_151x195.fm / 12.07.2012
Aton CL114
User manual

1
Aton CL114 / Swisscom / A31008-M2402-F151-1-2X19 / Leerseite.fm / 12.07.2012
Template Bali, Version 1, 16.02.2012

1
Aton CL114 / Swisscom EN / A31008-M2402-F151-1-2X19 / Bali.fm / 13.07.2012
Template Bali, Version 1, 16.02.2012
Aton CL114
The handset at a glance
1 Charge status of the batteries
2 Signal strength
3Displaykeys
4 End call key and On/Off key
5 Talk key/Handsfree key
6Control key (p)
ªAudio settings
INT Internal call
âDirectory
|Muting during a call
7Key 1 
network mailbox
8Star key 
Ringers on/off (press and hold);
with an open connection:
switch from pulse dialling to
tone dialling (press briefly)
9Key 0/recall key
Consultation call (flash): press
and hold
10 Hash key
Keypad lock on/off (press and
hold); toggles between upper/
lower case and digits; inserts a
dialling pause (press and hold)
11 Microphone
Handset display keys:
Pressing a key launches the function
that appears above that key in the dis-
play.
Please note
New messages in the calls list/net-
work mailbox list are indicated in
the display by the message New
messages, the left display key
flashes (if set ¢page 8).
Display Function when pressed
’Open calls list (¢page 8).
§Menu§ Open main/submenu
(see menu overview
¢page 16).
” Go back one menu level.
YScroll up/down or adjust vol-
ume with q.
X Move cursor to left/right
with r.
ÜBackspace deletes one
character at a time.
§OK§ Confirm menu function or
save entry.
ÐU
INT 1
23.04. 10:53
‘Menu
The base station at a glance
Registration/paging key: 
Search for handsets (press
briefly, paging ¢page 9)
Register handsets (press and
hold ¢page 9).
ECO DECT
During a call, the transmission power is automatically adjusted to the distance
between handset and base station, the smaller the distance, the lower the
transmission power (radiation). In idle status the transmission power of the
handset is switched off. Only the base station ensures contact with the hand-
set using low radio signals.
Your phone offers you the opportunity to further reduce the transmission
power:
1) Reducing transmission power (eco mode)
If the setting Max. Range is switched to off (menu tree ¢page 16), the trans-
mission power in standby mode and during a call is reduced up to 80% at half
range.
2) Deactivating transmission power (eco mode+)
With the setting No Radiation (menu tree ¢page 16), you turn off the trans-
mission power of the base station in standby mode completely. Please note:
◆All registered handsets must support this feature.
◆For quick connection of incoming calls the handset repeatedly switches
to reception mode for short periods. This increases energy consumption
and therefore reduces the standby and talk times.
1
2
3
4
5
6
7
8
9
10
11

2
Aton CL114 / Swisscom EN / A31008-M2402-F151-1-2X19 / Bali.fm / 13.07.2012
Template Bali, Version 1, 16.02.2012
Safety precautions
First steps
Check the package contents
Base station and handset package: One handset, one Aton CL114base station, one mains adapter, one phone cord, two
batteries, one battery cover, one user guide.
Handset and charging cradle package: One handset, one charging cradle with mains adapter, two batteries, one bat-
tery cover, one user guide.
If you have purchased a model with multiple handsets, the package should contain two batteries, a battery cover and
a charging cradle with mains adapter for each additional handset.
Setting up the base station and charging cradle (if included)
The base station and charging cradle are designed for use in enclosed dry rooms with a temperature range of +5 °C to
+45 °C.
¤Set up the base station at a central location on a flat, non-slip surface in your house or apartment. You can also
mount the base station and charging cradle on the wall.
The phone's feet do not usually leave any marks on surfaces. However, due to the multitude of different varnishes and
polishes used on today's furnishings, the occurrence of marks on the surfaces cannot be completely ruled out.
Care: Wipe down the base station, the charging cradle and the handset with a damp cloth (no solvents) or an antistatic
cloth. Never use a dry cloth. This can cause static.
Warning
Read the safety precautions and the user guide before use.
Explain their content and the potential hazards associated with using the device to your children.
Use only the power adapter indicated on the device.
Use only rechargeable batteries that correspond to the specification (see "Technical Data"). Never use a con-
ventional (non-rechargeable) battery or other battery types as this could result in significant health risks and
personal injury. Rechargeable batteries, which are noticeably damaged, must be replaced.
Using your telephone may affect nearby medical equipment. Be aware of the technical conditions in your parti-
cular environment, e.g., doctor's surgery.
If you use a medical device (e.g., a pacemaker), please contact the device manufacturer. They will be able to
advise you regarding the susceptibility of the device to external sources of high frequency energy (for the spe-
cifications of your product see "Technical Data").
Do not hold the rear of the handset to your ear when it is ringing or when speaker mode is activated. Otherwise
you risk serious and permanent damage to your hearing.
Your device is compatible with the majority of digital hearing aids on the market. However, perfect function with
all hearing aids cannot be guaranteed.
The phone may cause interference in analogue hearing aids (humming or whistling) or cause them to overload.
If you require assistance, please contact the hearing aid supplier.
The devices are not splashproof. For this reason do not install them in a damp environment such as bathrooms
or shower rooms.
Do not use the devices in environments with a potential explosion hazard (e.g., paint shops).
If you give your device to a third party, make sure you also give them the user guide.
Remove faulty devices from use or have them repaired by our Service team, as these could interfere with other
wireless services.
Please note
◆The device cannot be used in the event of a power failure. It is also not possible to transmit emergency calls.
◆Emergency numbers cannot be dialled if the keypad lock is activated!
Please note
Pay attention to the range of the base station. This is up to 300 m in unobstructed outdoor areas and up to 50 m
inside buildings.

3
Aton CL114 / Swisscom EN / A31008-M2402-F151-1-2X19 / Bali.fm / 13.07.2012
Template Bali, Version 1, 16.02.2012
Please note:
◆Never expose the telephone to the influence of heat sources, direct sunlight or other electrical devices.
◆Protect your Aton from moisture, dust, corrosive liquids and vapours.
Connecting the base station
Connecting the charging cradle (if included)
Setting up the handset for use
The display is protected by a plastic film. Please remove the protective film!
Inserting the batteries and closing the battery cover
¤First connect the mains adapter 1.
¤Then connect the telephone jack 2and insert the
cables into the cable ducts.
Please note:
◆The mains adapter must always be connected, as the
phone will not operate without mains connection.
◆Only use the mains adapter and phone cord supplied.
Pin connections on telephone cables can vary.
Warning
Use only the rechargeable recommended batteries (¢page 13), i.e., never use conventional (non-rechargeable)
batteries as this could result in significant health risks and personal injury. For example, the batteries could explode.
The phone could also malfunction or be damaged as a result of using batteries that are not of the recommended
type.
1
2
1
1
¤Connect the flat plug from the power
supply 1.
¤Plug the mains adapter into the plug
socket 2.
If you need to disconnect the plug from the
charging cradle, press the release button 3
and disconnect the plug 4.
1
2
3
4
¤Insert the batteries
with the polarity in the
correct direction.
The polarity is indicated in
the battery compartment.
¤Insert the battery cover from
the top.
¤Then slide the cover upwards
until it clicks into place.
To open the battery cover, for instance to
replace the batteries:
¤Reach into the notch at the top of the
cover and slide the cover down-
wards.

4
Aton CL114 / Swisscom EN / A31008-M2402-F151-1-2X19 / Bali.fm / 13.07.2012
Template Bali, Version 1, 16.02.2012
Initial charging and discharging of the batteries
The correct charge status can only be displayed if the batteries are first fully charged and discharged.
Changing the display language
Change the display language if you do not understand the language currently set:
§Menu§ ¤421 (press the keys one after the other) ¤q(select language) ¤§OK§ (‰= current language)
¤Press and hold the end call key ato return to idle status.
Setting the date and time
Set the date and time so that the correct date and time can be assigned to incoming calls, and so that the alarm can be
used.
§Menu§ ¤q Settings ¤§OK§ ¤Date/Time ¤§OK§ ¤Date ¤~(enter the day, month and year in 6-digit format)
¤§OK§ ¤Time ¤~(enter hours and minutes in 4-digit format) ¤§OK§ (display message: Saved)
¤a(press and hold to return to idle status).
You can move the position of an entry to the left or right by pressing the control key left or right r.
Please note
◆Base station and handset package: The handset is pre-registered with the base station. If you have purchased
a model with multiple handsets, all handsets will already be registered with the base station. You do not need
to register the handset again. 
However, if a handset is not registered with the base station (Register HS or Put into base is displayed), please
register the handset manually (¢page 9).
Handset and charging cradle package: please register the handset manually (¢page 9).
◆After the first battery charge and discharge, you may place your handset in the charger after every call.
◆Always repeat the charging and discharging procedure if you remove the batteries from the handset and rein-
sert them.
◆The batteries may warm up during charging. This is not dangerous.
◆After a while, the charge capacity of the batteries will decrease for technical reasons.
Please note
If your phone receives the date and time during calling line display (e.g., via your network provider, a router or
PABXs), you can specify whether this data should be copied to your phone:
¤Press the key sequence: §Menu§ ¤P#Q5#MI
The following is displayed; the current setting flashes:
¤Press one of the following keys to specify, when this data should be copied to your
phone:
QNever
or 1Once, in case the date/time is not set on your phone 
or 2Always
Your selection is displayed (e.g., 2):
¤Press the display key §OK§.
6 h ¤Charge the handset in the base station/charging cradle
for 6 hours.
¤After charging, remove the handset from the base sta-
tion/charging cradle and only replace it when the batter-
ies are fully discharged.
Please note
The handset must only be placed in the designated base
station or charging cradle.
973 SET : [0]
973 SET: [2]

5
Aton CL114 / Swisscom EN / A31008-M2402-F151-1-2X19 / Bali.fm / 13.07.2012
Template Bali, Version 1, 16.02.2012
Display in idle status
Once the phone is registered and the time set, the idle status is shown as in this example.
Screen display
◆Reception between the base station and the handset:
- Good to poor: Ð ¨ § ¦
- No reception: ¥
◆Battery charge status:
-UCharged over 66%
-VCharged between 34% and 66%
-eCharged between 11% and 33%
-=Charged less than 11%
-=Flashes: batteries almost empty (less than 10 minutes talktime)
-= e V UBatteries are charging
If No Radiation mode (¢page 16) is activated, the ½icon is displayed in the top left.
Activating/deactivating the handset
Press and hold the akey to activate or deactivate the handset. If you place a deactivated handset in the base station
or charging cradle, it will automatically activate after approx. 30 seconds.
Your phone is now ready for use.
If you have any questions about using your phone, please read the tips on troubleshooting ("Faults and self-help with
troubleshooting", ¢page 14) or contact our Customer Care team ¢page 14.
Menu guidance
Your telephone's functions are accessed via a menu consisting of several levels (menu overview ¢page 16).
Main menu (first menu level)
¤When the handset is in idle status, press the display key §Menu§ or right on the control key vto open the main menu.
The functions in the main menu are shown by means of an icon and the function's name.
Selecting a function:
¤You can scroll between functions using the control key q. The function is shown in the display.
¤Press the display key §OK§ or the right control key vto select the displayed function. This opens the corresponding
submenu and the first entry is displayed.
If you press the display key ”or briefly the end call key a, the display returns to idle status.
Submenus
The functions in the submenu are indicated by name.
Selecting a function:
¤You can scroll between functions using the control key q. The function is shown in the display.
¤Press the display key §OK§ to select the displayed function. This opens the corresponding submenu and the first entry
is displayed.
If you press the display key ”or briefly the end call key a, the display returns to the previous menu level or you cancel
the operation.
Any settings you have not confirmed by pressing the display key §OK§ are lost.
Reverting to idle status
From any point in the menu:
¤Press and hold the end call key aor
¤Do not press any key: after 2 minutes, the display will automatically revert to idle status.
ÐU
INT 1
23.04. 10:53
‘Menu

6
Aton CL114 / Swisscom EN / A31008-M2402-F151-1-2X19 / Bali.fm / 13.07.2012
Template Bali, Version 1, 16.02.2012
Making calls
Making external calls and ending calls
External calls are calls using the public telephone network.
~(Enter the phone number) ¤c.
The phone number is dialled. (Or you can firstpress and hold talk key c[dial tone] and then enter the number.) During
the call you can adjust the earpiece volume using tand set the volume with q.
End the call/cancel dialling: Press the end call key a.
You can automatically insert a network provider dialling code before any phone number (¢page 6).
Accepting a call
The handset indicates an incoming call by ringing and by a display on the screen.
Press the talk key cto accept the call.
When Auto Answer is activated (see menu overview ¢page 16), simply remove the handset from the base station/
charging cradle.
Calling Line Identification
When you get a call, the caller's number will be displayed on your handset; the caller's name will be displayed if it is
stored in the directory.
Prerequisites:
1 You have asked your network provider for the caller's number (CLIP) to be displayed on your handset screen.
2 The caller has asked the network provider for his number to be identified (CLI).
External Call appears in the display if you have not requested CLIP, Unavailable appears if the caller has withheld CLI or
if CLI has not been requested.
External Call appears in the display if you have not requested CLIP, Withheld appears if the caller has withheld CLI, and
Unavailable appears if CLI has not been requested.
Handsfree operation
In handsfree mode, you activate the loudspeaker so that you can hear the caller without having to hold the handset to
your ear. During a callyou can activate or deactivate handsfree mode by pressing the handsfree key d.
During the call in handsfree mode you can adjust the handsfree volume by pressing tand set the volume with q.
Muting
You can deactivate your handset's microphone during a call. Press the right control key vto mute the handset. Press
the control key vagain to reactivate the microphone.
Automatic network provider preselection
You can store a call-by-call number (preselection number), which is automatically placed in front of numbers when you
dial them. If, for example, you wish to make international calls via special network providers, you can save the relevant
dialling code here.
In the "With Preselect" list, specify the dialling codes or the first digits of the dialling codes that you wish to assign to the
preselection number.
In the "Without Presel." list, enter any exceptions to the "With Preselect" list.
Enter preselection number via menu (¢page 16). 
Permanently deactivating preselection: Delete the preselection number with Ü.
Temporarily cancelling preselection:
(press and hold) ¤§Menu§ ¤qPreselect off ¤§OK§ ¤~(enter number) or s(use number from directory) ¤The
number is dialled without Preselection.
Example:
Presel. Number 0999
With Preselect 08
Without Presel. 081
084
Phone number Dialled number
07112345678 ¤07112345678
08912345678 ¤0999 08912345678
08412345678 ¤08412345678
All numbers that start with 08, except
for 081 and 084, are dialled with the
preselection number 0999.
c

7
Aton CL114 / Swisscom EN / A31008-M2402-F151-1-2X19 / Bali.fm / 13.07.2012
Template Bali, Version 1, 16.02.2012
Using the directory and lists
Directory
To open the directory: press control key s.
You can save up to 100phone numbers (max. 22 digits) with corresponding names (max. 16 characters). 
Enter letters/characters ¢page 13.
Storing the first number in the directory
s¤New Entry? ¤§OK§ ¤~(enter number) ¤§OK§ ¤~ (enter name) ¤§OK§
Storing further numbers in the directory
s¤§Menu§ ¤New Entry ¤§OK§ ¤~(enter number) ¤§OK§ ¤~ (enter name) ¤§OK§
Selecting a directory entry
Open the directory with s.You have the following options:
◆Use qto scroll through the entries until the required name is selected.
◆Enter the first character of the name and scroll to the entry with q, if required.
Dialling with the directory
s¤q(select entry) ¤c
Using other functions
s¤q(select entry) ¤§Menu§
The following functions can be selected with q:
Using shortcut keys
You can assign directory entries to the keys 2–9:
s¤q(select entry) ¤§Menu§ ¤qShortcut ¤§OK§
¤q(select key) ¤§OK§ or ~(press the key you want to assign the entry to)
To dial, press and hold the required shortcut key.
Sending the directory to another handset
Prerequisites:
◆The sending and receiving handsets must both be registered to the same base station.
◆The other handset and the base station can send and receive directory entries.
s¤q(select entry) ¤§Menu§ ¤qSend Entry / Send List ¤§OK§
¤q(Select the internal party) ¤§OK§ or ¤~(enter the internal number of the receiving handset)
New Entry Save new phone number.
Show Number Display the phone number.
Show Name Display the name.
Edit Entry Edit selected entry.
Use Number Edit the number or open the directory by pressing the control key sto insert a number from the
directory at the current position. Then dial or use other functions with §Menu§.
Delete Entry Delete selected entry.
Send Entry Send a single entry to another handset (¢page 7).
Delete List Delete all directory entries.
Send List Send the complete list to another handset (¢page 7).
Shortcut For shortcuts, assign the current entry to a key.

8
Aton CL114 / Swisscom EN / A31008-M2402-F151-1-2X19 / Bali.fm / 13.07.2012
Template Bali, Version 1, 16.02.2012
Last number redial list
This list contains the ten last dialled numbers.
Dialling from the last number redial list
c(press briefly) ¤q(select entry) ¤c
Managing entries in the last number redial list
c(press briefly) ¤q(select entry) ¤§Menu§
You can select the following settings:
Calls list/network mailbox list
Press the display key ’, to open the list overview. If you have new messages, only lists with new messages are dis-
played. Scroll through the lists by pressing q.
An advisory tone sounds as soon as a new entry appears in the calls list/network mailbox list. By default the left display
key flashes and the message New messages appears on the display. You can change this behaviour by using the follow-
ing procedures:
¤Press the key sequence: §Menu§ ¤P#Q5#M
The following is displayed:
¤Press one of the following keys to select the message type:
5for missed calls
or Mfor messages on the network mailbox
Your selection is displayed (e.g., 5for missed calls); the current setting flashes:
Press key Qor 1, to set the behaviour for new messages:
QThe presence of new messages is displayed (default setting).
or 1The presence of new messages is not displayed.
Your selection is displayed (e.g., 1):
¤Press the display key §OK§.
Settings will only be changed once a new message has been received.
Calls list
Prerequisite: CLIP (¢page 6)
Depending on the type of list set, the calls list contains (¢page 16):
◆Answered calls
◆Missed calls
Depending on the type of list set, all numbers of the last 25 incoming calls are saved or just the missed calls are saved.
Open the calls list
’¤qCallsList
The calls list is displayed as follows:
Number of new entries + number of old, read entries 
Press §OK§ to open the list.
The last incoming call is displayed. If necessary, use qto select another entry.
Using other functions
q(select entry) ¤§Menu§
Use Number Edit the number or open the directory by pressing the control key sto insert a number from the
directory at the current position. Then dial or use other functions with §Menu§.
Copy to Dir. Copy an entry to the directory.
Delete Entry Delete selected entry.
Delete List Delete all entries.
Please note
When calls are saved in the network mailbox, you will receive a message if the appropriate settings have been made
(depending on your network provider).
97
975 SET: [0]
975 SET: [1]
CallsList 01+02

9
Aton CL114 / Swisscom EN / A31008-M2402-F151-1-2X19 / Bali.fm / 13.07.2012
Template Bali, Version 1, 16.02.2012
The following functions can be selected with q:
Calling back a caller from the calls list
’¤qCallsList 01+02 ¤§OK§ ¤q(select entry) ¤c
Network mailbox list
You can use these lists to listen to messages on the network mailbox (¢page 9).
New messages can only be deleted during playback of message body.
Setting a different language
You can change the language for the voice prompt and default announcement.
§Menu§ ¤qAnswer Machine ¤§§OK§§ ¤qLanguage ¤§§OK§§ ¤q(select language) ¤§OK§
Network mailbox
The network mailbox is the answering machine in your provider's telephone network. More information is available from
your provider. You cannot use the network mailbox unless you have requested it from your provider.
In order to use the network mailbox quickly and easily via the network mailbox list (¢page 8), the menu (¢page 16)
and to use fast access (¢page 1), you will need to enter the number in your phone:
§Menu§ ¤qAnswer Machine ¤§OK§ ¤qNet Mailbox ¤~(enter number) ¤§OK§
Locating a handset (paging)
You can locate your handset using the base station.
¤Briefly press the registration/paging key on the base station (¢page 1).
All handsets will ring at the same time (paging), even if the ringers are switched off.
Ending paging: Briefly press the registration/paging key on the base station (¢page 1) or press the talk key cor the
end call key aon the handset.
Registering handsets manually
You can register up to four handsets on your base station. Each additional handset must be registered on the base sta-
tion in order for it to work properly!
Registration takes approx. 1 minute. Once the registration process has been completed successfully, the display briefly
shows HS registered and returns to idle status. Handsets are assigned the lowest available internal number (1-4). If the
internal numbers 1–4 are already assigned to other devices, the number 4 will be overwritten.
De-registering handsets
You can de-register all other registered handsets from each of the registered Aton handsets.
§Menu§ ¤qSettings ¤§OK§ ¤qHandset ¤§OK§ ¤qDe-register HS ¤qSelect the internal party you wish to de-
register. The handset you are currently using is indicated by <. ¤§OK§ ¤Enter the base station system PIN (default setting:
0000) ¤§OK§
Delete Entry Delete current entry.
Copy to Dir. Copy an entry to the directory.
Date/Time Call date and time (if set).
Status New Call: new missed call. Old Call: entry already read.
Delete List Warning! All old and new entries will be deleted.
1) On the handset
§Menu§ ¤qSettings ¤§OK§ ¤qHandset ¤§OK§ ¤qRegister HS ¤Enter the base station system PIN (default set-
ting: 0000) ¤§OK§ ¤Registering is displayed.
2) On the base station
Within 60 seconds, press and hold the registration/paging key on the base station (¢page 1) for approx. 3 seconds.

10
Aton CL114 / Swisscom EN / A31008-M2402-F151-1-2X19 / Bali.fm / 13.07.2012
Template Bali, Version 1, 16.02.2012
Using multiple handsets
Making internal calls
Internal calls are free calls to other handsets that are registered to the same base station.
2 handsets are registered
Press the control key u, the other handset is called.
More than 2 handsets are registered
Calling a specific handset
u¤~(1...4, enter internal number of the handset) or
u¤q(Select the internal party) ¤§OK§ or c¤the handset is called.
Calling all handsets (group call)
Press and hold u or u¤P or u¤qCall all ¤§OK§ or c¤all handsets are called.
When a participant answers you can speak to him. To end the call, press a.
Internal consultation call/connecting a call
You are in conversation with an external participant. Press the control key uand call one or all handsets. The external
participant hears the hold music. When the internal participant answers: Announce the external call, if necessary.
Either
press the end call key a. The call is transferred to the internal participant,
or
press the display key ”. You are reconnected with the external participant.
When transferring a call you can also press the end call key abefore the internal participant answers.
Listening in to an external call
You are conducting an external call. An internal participant can listen in on this call and take part in the conversation
(conference). Prerequisite: The Listening in function must be activated.
Activating/deactivating listening in
§Menu§ ¤qSettings ¤§OK§ ¤qBase ¤§OK§ ¤qListening in ¤§OK§ (‰= on)
Internal listening in (conference)
You want to listen in to an existing external call. Press and hold the c key. You can listen in to the call. All participants
hear a signal tone.
To end:press the end call key a. All participants hear a signal tone.
If the first internal participant presses the end call key a, the handset that has "listened in" remains connected to the
external participant.
Setting the alarm clock
Activating/deactivating the alarm clock
§Menu§ ¤qAlarm Clock ¤§OK§ ¤Activation ¤§OK§ (‰= on)
When activated: ¤~(Set the wake-up time) ¤§OK§
When the alarm clock rings, press any key to switch it off for 24 hours. If the alarm clock is set, the wake-up icon lwill
appear on the screen and the wake-up time will be displayed instead of the date.
Setting the wake-up time
§Menu§ ¤qAlarm Clock ¤§OK§ ¤qWake-upTime ¤§OK§
Enter the wake-up time in hours and minutes, then press §OK§.

11
Aton CL114 / Swisscom EN / A31008-M2402-F151-1-2X19 / Bali.fm / 13.07.2012
Template Bali, Version 1, 16.02.2012
Phone settings
For details on activating/deactivating advisory tones and battery low tones, see menu tree (¢page 16).
For details on setting the display contrast and large dialling numbers, see menu tree (¢page 16).
For details on how to set the system PIN on the base station, see the menu overview (¢page 16).
Changing the display language
§Menu§ ¤qSettings ¤§OK§ ¤qHandset ¤§OK§ ¤qLanguage ¤§OK§ ¤q(select language) ¤§OK§
The current language is indicated by ‰.
If you accidentally choose a language you do not understand:
§Menu§ ¤421 (press the keys one after the other) ¤q(select language) ¤§OK§
Changing the handsfree/earpiece volume
In idle status:
t¤Handset Volume ¤§OK§ ¤qEarpiece/Speaker ¤§OK§ ¤q(set the volume level 1 to 5)
¤§OK§ (‰= selected)
During a conversation via the earpiece or in handsfree mode:
t¤q(set the volume level 1 to 5)
The setting will automatically be saved after approximately 3 seconds or press the display key §OK§.
You can also set the handsfree/earpiece volume using the menu Audio Settings (¢page 16).
Setting the sound of the earpiece
Adapt the sound of the earpiece to your needs.
◆Low: Standard setting.
◆High: High frequencies are emphasized.
In idle status:
t¤qHandset Sound ¤§OK§ ¤qLow/High ¤§OK§ (‰= selected)
You can also set the sound of the earpiece using the menu Audio Settings (¢page 16).
Setting ring tones of the handset
Setting the ringer volume
In idle status:
t¤qRinger Volume ¤§OK§ ¤q(set the volume level 1 to 5 or "Crescendo")¤§OK§ (‰= selected)
You can also set the call volume using the menu Audio Settings (¢page 16).
Setting the ringer melody
Set different ringer melodies for External Calls, Internal Calls and the Alarm Clock.
In idle status:
t¤qRinger Melody ¤§OK§ ¤qExternal Calls / Internal Calls / Alarm Clock ¤§OK§ ¤q(select melody)
¤§OK§ (‰= selected)
You can also set the call volume using the menu Audio Settings (¢page 16).
Time Control (day/night mode)
You can specify a time period when you do not want the telephone to signal external calls e.g., during the night.
Activating Time Control:
§Menu§ ¤qSettings ¤§OK§ ¤qHandset ¤§OK§ ¤qTime Control ¤§OK§ ¤Activation ¤§OK§ (‰= activated)
Setting time period:
§Menu§ ¤qSettings ¤§OK§ ¤qHandset ¤§OK§ ¤qTime Control ¤§OK§ ¤qSettings ¤§OK§
¤Off from: ~(Enter time in 4-digit format) ¤§OK§ ¤Off until: ~(Enter time in 4-digit format) ¤§OK§
Anonymous calls silent
You can set your handset so that it doesn't ring for calls where Calling Line Identification has been withheld. The call will
only be signalled on the display.
§Menu§ ¤qSettings ¤§OK§ ¤qHandset ¤§OK§ ¤qAn.Call Silent ¤§OK§ (‰= activated)
Activating/deactivating the ringer
Deactivating/reactivating the ringer permanently
In idle status, press and hold the star key P. If the ringer is deactivated, the Úicon appears in the display.

12
Aton CL114 / Swisscom EN / A31008-M2402-F151-1-2X19 / Bali.fm / 13.07.2012
Template Bali, Version 1, 16.02.2012
Deactivating the ringer for the current call
§Menu§ ¤Silent ¤§OK§
Activating/deactivating music on hold
You can set that your external participant hears music in case of internal recall and during call transfer.
§Menu§ ¤P#Q5#1M ¤The number for the current setting flashes: 0= off; 1= on ¤enter number ¤§OK§.
Repeater mode
With a repeater, you can increase the range of your base station. You will need to activate repeater mode (¢page 16).
Repeater mode and No Radiation mode (¢page 16) cancel each other out.
Resetting the handset
You can reset individual settings and changes that you have made. Entries in the directory, the calls list and the handset's
registration to the base station will be retained.
§Menu§ ¤qSettings ¤§§OK§§ ¤qHandset ¤§§OK§§ ¤qReset Handset ¤§§OK§§ ¤Reset? ¤§§OK§§
Restoring the base station
When restoring factory settings:
◆Individual settings are reset.
◆All lists are deleted.
◆The No Radiation mode is deactivated.
The date and time are retained.
Resetting the base station via the menu
When resetting via the menu
◆Handsets are still registered.
◆The system PIN is not reset.
§Menu§ ¤qSettings ¤§OK§ ¤qBase ¤§OK§ ¤qBase Reset ¤§OK§ ¤Reset? ¤§OK§
Resetting the base station using the key on the base station
When resetting the base station using the key on the base station
◆All handsets are de-registered and
◆The system PIN is reset to the original code 0000.
Carry out the following steps: Remove the mains cable from the base station. Hold down the registration/paging key
on the base station (¢page 1) and reconnect the power cable to the base station at the same time. Hold the key down
for at least 5 seconds.
Operating the base station on the PABX/router
Operating on the router
When operating on an analogue port of a router, you can reduce problems with echoing by activating the XES Mode
(¢page 16). If you have no problems with echoing, this function should be deactivated.
Operating on the PABX
The following settings are only necessary when your PABX requires them, see the user guide for your PABX.
When entering the digits, enter them slowly one after the other.
Changing the dialling mode
§Menu§ ¤P#Q5#1N ¤The number for the set dialling mode flashes: 0 = touch tone dialling (DTMF);
1= dial pulsing (DP) ¤enter number ¤§OK§.
Setting recall
§Menu§ ¤P#Q5#1Q ¤The number for the current recall flashes: 0= 80 ms; 1= 100 ms; 2= 120 ms;
3= 400 ms; 4= 250 ms; 5= 300 ms; 6 = 600 ms; 7= 800 ms ¤enter number ¤§OK§.
Changing pause after line seizure
You can set the length of the pause inserted between pressing the talk key cand sending the phone number.
§Menu§ ¤P#Q5#1L ¤The number for the current pause length flashes: 1= 1 sec.; 2= 3 sec.; 3 = 7 sec.
¤enter number ¤§OK§.
Changing the pause after the recall key
§Menu§ ¤P#Q5#12 ¤The number for the current pause length flashes: 1= 800 ms; 2= 1600 ms;
3 = 3200 ms ¤enter number ¤§OK§.

13
Aton CL114 / Swisscom EN / A31008-M2402-F151-1-2X19 / Bali.fm / 13.07.2012
Template Bali, Version 1, 16.02.2012
Appendix
Entering letters/characters
Technical Data
Batteries
Technology: Nickel-metal-hydride (NiMH); Size: AAA (Micro, HR03); Voltage: 1,2 V; Capacity: 450 - 1000 mAh
Handset operating times/charging times
Your handset can charge batteries up to a capacity of 1000 mAh. The use of special high-performance batteries or bat-
teries with high capacities is not recommended for cordless phones.
The operating time of your device depends on the capacity and age of the batteries and the way it is used. (Standby
time/talk time/operating time are maximum possible values, charging times are typical values.)
General specifications
Standard characters
Press therelevant key the number of
times indicated.
Briefly press the hash key #to
switch from "Abc" to "123" mode,
from "123" to "abc" mode and from
"abc" to "Abc" mode.
Capacity (mAh) approx.
550 700 800 1000
Standby time (hours) 220 255 295 360
Talktime (hours) 14 17 19 24
Operating time for 1.5 hrs of calls per day (hours),
No Radiation mode switched off/on 115/85 135/95 150/110 190/135
Charging time in base station (hours) 67810
Charging time in charger (hours) 5.5 6.5 7 9
Base station power consumption
In standby mode
– Handset in base station
– Handset outside base station
ca. 1.0 W
ca. 0.8 W
During a call ca. 1.0 W
DECT standard is supported
GAP standard is supported
Range up to 300 m outdoors, up to 50 m indoors
Base station power supply 230 V ~/50 Hz
Environmental conditions in operation +5 °C to +45 °C, 20% to 75% relative humidity
1) Space
1x 2x 3x 4x 5x 6x 7x 8x 9x 10x 11x 12x 13x 14x 15x
11£$¥¤
2abc2äáàâãç
Idef3ëéèê
4ghi4ïíìî
5jkl5
Lmno6öñóòôõ
Mpqr s7ß
Ntuv8üúùû
Owx y z 9 ÿ ýæø å
Q.,?!0+-:¿¡"’ ;_
P* / ( ) <=>%
##@\ &§
1)

14
Aton CL114 / Swisscom EN / A31008-M2402-F151-1-2X19 / Bali.fm / 13.07.2012
Template Bali, Version 1, 16.02.2012
Faults and self-help with troubleshooting
Not every problem signifies a fault in your telephone. In some cases, problems can be resolved by briefly interrupting
the power supply to the base station (unplug the power supply unit and then plug it in again) or removing the battery
cells from the handset and reinserting them. The following information is designed to help you with specific problems.
Important: Some problems or faults can only be resolved if you take the complete device (base station, handset and con-
nection cable) to the place of purchase.
Warranty/Maintenance/Repair/ Approval
Warranty
The warranty period is 2 years as of the date of purchase. For warranty repair, the warranty card, filled out and stamped
by the place of purchase must accompany the faulty device. Excluded from the warranty are damages due to improper
use, wear and tear or tampering by others. The warranty does not include consumable materials and faults that have
only an insignificant affect on the value or usability of the product. In case of errors, please contact your place of pur-
chase.
Repair/Maintenance
Rental devices
If your phone does not operate properly, notify Technical Assistance (phone number 0800 800 800).
The repair*and the fault action are free of charge.
Purchased devices
Repair services are performed free of charge within the warranty period in accordance with the regulation of the war-
ranty certificate. If a repair is necessary, the device must be returned to the place of purchase.
If Technical Assistance is made available (also during the warranty period*)), the fault action is charged (route lump sum
price as well as expenses for time). The repair costs are additional outside the warranty period.
Help
If you have any general questions about products, services etc., please contact your Swisscom Information Centre (toll-
free number 0800 800 800).
Problem Cause Solution
Nothing appears on
thedisplay.
The handset is not switched on.
The batteries are flat.
Press the end call key afor approx. 5 seconds or place
the handset in the base station.
Charge or replace the batteries.
No wireless connec-
tion to the base sta-
tion, Base flashes in
the display.
The handset is outside the range of
the base station.
The base station is not turned on.
Move the handset closer to the base station.
Check the mains connector on the base station
¢page 3.
The display shows
Register HS or Put
into base.
Handset has not been registered
with the base station or has been
de-registered.
Register the handset ¢page 9.
Handset does not
ring.
The ring tone is deactivated.
The phone only rings if the phone
number has been transferred.
The phone does not ring in a spe-
cific time period.
Activate the ring tone ¢page 11.
Activate the ring tone for anonymous calls ¢page 11.
Deactivate the "Time Control" or change the time period
¢page 11.
You cannot hear a
ringer/dialling tone
from the fixed line
network.
The phone cord supplied has not
been used or has been replaced by
a new cord with the wrong jack
connections.
Please always use the phone cord supplied or ensure
that the pin connections are correct when purchasing
from a retailer: 3-4 assignment of telephone leads/
EURO CTR37.
Error tone sounds
after system PIN
prompt.
PIN forgotten.
The system PIN you have entered is
incorrect.
Reset the system PIN to the default 0000 ¢page 12.
All handsets are de-registered. All settings are reset.
All lists are deleted.
*An exception is damage to wearing parts (cable, labels, batteries etc.) and due to improper handling (damage from
dropping, infiltrated fluids etc.).

15
Aton CL114 / Swisscom EN / A31008-M2402-F151-1-2X19 / Bali.fm / 13.07.2012
Template Bali, Version 1, 16.02.2012
Contact with liquid
If the handset has come into contact with liquid:
1Switch the handset off and remove the battery immediately.
2 Allow the liquid to drain from the handset.
3 Pat all parts dry, then place the handset with the battery compartment open and the keypad facing down in a dry,
warm place for at least 72 hours (not in a microwave, oven etc.).
4Do not switch on the handset again until it is completely dry.
When it has fully dried out, you will usually be able to use it again.
Approval
This device is intended for analogue telephone connection in the Swiss network.
Country-specific requirements have been taken into consideration.
If you have any questions about the differences between the public phone networks, please contact your specialist
dealer or network provider.
Swisscom hereby declare that this device meets the essential requirements and other relevant regulations laid down in
Directive 1999/5/EC.
The Declaration of Conformity can be found on the following website:
www.swisscom.ch
under the heading "Online Shop", Telephones, Conformity Declaration.
Disposal
Batteries should not be disposed of in general household waste. Observe the local waste disposal regulations, details of
which can be obtained from your local authority.
All electrical and electronic products should be disposed of separately from the municipal waste stream via designated
collection facilities appointed by the government or the local authorities.
This crossed-out wheeled bin symbol on the product means the product is covered by the European Direc-
tive 2002/96/EC.
The correct disposal and separate collection of your old appliance will help prevent potential negative con-
sequences for the environment and human health. It is a precondition for reuse and recycling of used elec-
trical and electronic equipment.
For more detailed information about disposal of your old appliance, please contact your local council refuse centre or
the original supplier of the product.
!

16
Aton CL114 / Swisscom EN / A31008-M2402-F151-1-2X19 / Bali.fm / 13.07.2012
Template Bali, Version 1, 16.02.2012
Menu overview
Your phone has an extensive range of features. These are offered in the form of menus.
To select a function while the phone is in idle status, press §Menu§ (open menu), use the control key qto scroll to the
function you require and press §OK§ to confirm.
To return to idle status: press and hold the akey.
Not all of the functions described in this user guide are available in all countries.
é Alarm Clock
Activation ¢page 10
Wake-upTime ¢page 10
èAudio Settings
Handset Volume Earpiece/Speaker ¢page 11
Handset Sound Low/High ¢page 11
Ringer Volume ¢page 11
Ringer Melody External Calls/Internal Calls/Alarm Clock ¢page 11
Advis.Tones On/off
Battery Low On/off
êAnswer Machine
Play Messages Playing back messages on the network mailbox ¢page 9.
Net Mailbox Enter number of the network mailbox ¢page 9.
Language * ¢page 9
çSettings
Date/Time ¢page 4
Handset Language ¢page 11
Big Dial Font Set bigger digits for dialling.
Contrast Set the display contrast to 9 levels.
Time Control Activation/Settings ¢page 11
An.Call Silent ¢page 11
Auto Answer Activate/deactivate auto answer ¢page 6.
Register HS ¢page 9
De-register HS ¢page 9
Secur.Check Activate/deactivate security check.
(If activated: only encrypted DECT transmissions are possible.)
Reset Handset ¢page 12
Base Call list type Missed Calls/All Calls ¢page 8
System PIN Change system PIN (default is 0000).
Base Reset ¢page 12
Additional Repeater ¢page 12
XES Mode Activating/deactivating
(Activate in case of problems with echos on
an analogue port of a router.)
ECO DECT
¢page 1
No Radiation/Max. Range ¢page 1
Listening in ¢page 10
Preselection Presel. Number/With Preselect/Without Presel. ¢page 6

1
Aton CL114 / Swisscom / A31008-M2402-F151-1-2X19 / Leerseite.fm / 12.07.2012
Template Bali, Version 1, 16.02.2012

/ Schweiz de / Cover_back_151x195.fm / 12.07.2012
dt/fr/it 07/2012
