SWIT Electronics CL-M100D User manual

Specification
Warning
Maintenance
1. Please use a soft dry cloth to clean the front panel of the product, or use a soft cloth dipped in a neutral detergent solution Wipe with a soft,
dry cloth.
2. Do not wipe the front panel with a wet cloth, anhydrous alcohol, gasoline, or the mixture of anhydrous alcohol and ether. Otherwise, the
front panel may be damaged.
CL-M100D Studio Panel LED Light
Ver:A
Tel:[phone]
Fax:[phone]
http://www.swit.cc
E-mail: [email protected]
USER MANUAL
SWIT Electronics Co.,Ltd.
Thank you for choosing SWIT products. Please read the instructions before using, and keep it for future reference.
Model
LED QTY
Color Temperature
Brightness
Illumination
Half Peak Beam Angle
CRI
TLCI
SSI（D55）
Working Voltage
Output Power
Dimension
Weight
CL-M100D
576pcs
2700K-6500K
0%-100%
3400 Lux@1m
About 62°
98
99
73
AC 100-240V,50/60Hz ; DC 11-17V
≤130W
See Fig.1、Fig.2、Fig.3
5.6Kg
130mm
173mm
370mm
275mm
146mm
245mm
300mm
Fig.1 CL-M100D Front View Fig.2 CL-M100D Side View
1.Do not disassemble the panel light or touch the interior with metal objects to avoid damage；
2.Do not store the panel light in dusty or wet environment to avoid damage；
3.USB interface is reserved interface, please use it according to the specified environment of the company's related products,
not for other purposes, so as not to cause loss；
4.Do not connect the output device of the DMX signal in the panel light network when using the mutual control function of the panel light,
otherwise the function can not be used normally；
5.Only use the light in the temperature range of -10℃-40℃.

Overall Dimension
LCD Information
Installation of safety rope
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭
1.Front View： 2.Back View
① U-Bracket
② York Connector
③ Diffuser
④ Fasten Knob
⑤ DMX OUT
⑥ DMX IN
⑦ USB
⑧ DC 11-17 IN
⑨ Power switch
⑩ DIMMER djusting knob
⑪ LCD
⑫ COLOR Temp adjusting knob
⑬ AC IN
⑭ AC OUT
Take“CCT=5600K，Dimmer=100%，Full capacity，DMX Communication mode，DMX address “008” for example：
Fig.5 LCD Information
Fig.6 Installation diagram of safety rope
① Current Mode⸺DMX Mode
② Current Mode⸺Group Mode
③ Current Dimmer value
④ Current communication address
⑤ Current color value
⑥ Power indicator
When lifting and using the lamps, please pass the safety rope
(hereafter referred to as "safety rope") through the lamp wire
hole and the round tube of the barn door according to the method
shown in Fig. 6, so as to establish an effective connection between
the product and the hanging devices such as hinges.
Precautions for use of safety rope are as follows:
1) If you use your own safety rope, please confirm that the load of
the safety rope is greater than that of this product;
2) The safety rope cannot be dragged on the rough surface;
3) Please check carefully before using the safety rope, where the
rope strand is broken or the number of broken wires in one twist
distance exceeds 6, the safety rope shall not be used.Safety rope
with obvious wear, corrosion, deformation and damage caused by heat or arc is not allowed to use;
4) The safety rope is strictly prohibited from contact with any charged body, hot object or flame;
5) The two safety rope buckles shall not be directly connected with each other, and D shackle in accordance with the load specifications
must be added.
① ② ③ ④ ⑤ ⑥
Fig.3 CL-M100D Front View Fig.4 CL-M100D Back View

Usage
Packing list
1. Installation
Mount the lamp head onto a light stand, then fix it in place by
tightening the T-Handle on the mounting column. Then loosen
/tighten the handbrake locking mechanism on the yoke to
adjust the tilt of the fixture.
Tips: Please use with safety rope when lifting lamps. See "Safety
Rope Assembly" for the assembly method of safety rope.
2. Power supply
This light support DC 11-17V（Polarity：Pin1＂－＂；Pin4＂+＂）、AC
100-240V 50/60Hz two ways of power supply， loop out is
supported when AC power is supplied，Maximum:20pcs .
3. Brightness/CCT setting and usage
This product supports two brightness/color temperature
adjustment modes: normal adjustment mode, fast adjustment
mode.Switch according to the brightness/color temperature
adjustment knob (Figure 4 ⑩/ unkind) . Users can quickly set
brightness and color temperature by combining these two
adjustment modes according to their needs.
3.1 Normal adjustment mode
1 ）C C T
Range：2700K-6500K，adjustment steps：50K；
2）Brightness
Range：0%-100%，adjustment steps：1%。
3.2 Fast adjustment mode
1 ）C C T
In this mode,these CCT can be choose quickly：2700K、
3200K，4500K，5600K，6500K；
2）Brightness
Range：0%-100%，adjustment steps：10%。
4. Communication address setting and usage
Hold the brightness adjustment knob (As shown in Figure 4 ⑩)
for about 2 seconds to enter the communication address setting
interface. The communication address setting range is 001-512.
The LCD (Figure 5 ④) blinks, indicating that the current position
is selected. Rotate the brightness adjustment knob (Figure 4 ⑩)
to set the current position and press the brightness adjustment
Knob (Figure 4 ⑩) to determine the current bit Settings and
enter the next bit Settings. When the last bit Settings are completed,
press the brightness adjustment knob (Figure 4 ⑩) or wait for
about 5 seconds to exit the communication address Settings.
5. Communication control mode setting and usage
Connect the lamps through DMX, and press the color tempera-
ture adjustment knob (FIG. 4) for about 2s to complete the
setting of the communication control mode of the lamps.
5.1 DMX Communication mode
"DMX" is displayed in the upper left corner of LCD (Fig. 5 ①),
indicating that the current communication control mode
supported by the lamp is DMX communication mode.In this
mode, the DMX signal output device is connected to the lamp
network, the communication address is set, and it can be used
normally.
A lamp occupies a total of two DMX control channels, the current
set DMX address (N) for brightness control, the current set
value of the next address (N+1) for color temperature control
For example：
DMX
communication
address Function
Intensity 0%-100%
Color temperature 2700K-6500K
DMX
Control
address
005
006
005
5.2 Mutual mode
"CH" is displayed in the upper left corner of LCD (Figure 5 ②),
indicating that the communication control mode currently
supported by the lamp is mutual control mode.In this mode,
the target lamps are set to the same communication address
and can be used normally without distinguishing the master
and slave machines.
Note: When using the mutual control function of lamps,
do not access the OUTPUT device of DMX signal in the
network of lamps, otherwise the function can not be
used normally;
6. USB usage
The USB port is a reserved port. Please use it according to the
environment specified by the company's related products.
Otherwise, the USB port may not be used for other purposes.
No.
1
2
3
4
Item
CL-M100D
AC power cable
Safety rope
AC loop out cable（optional）
Engineering kit
X 1
X 1
X 2
Client can purchase according to requirement
