SY SY-MHDBT-44P User manual

SY-MHDBT-44P
SY Electronics Ltd, Unit 7, Worrall Street, Salford, Greater Manchester, M5 4TH, United Kingdom
Tel: [phone] –Fax: [phone] –www.sy.co.uk
Installation Guide
4 x 4 HDMI Matrix Switcher
With
HDBaseT PoC Outputs
4 HDMI in to 4 HDBaseT + 2 mirrored HDMI out

SY-MHDBT-44P
www.sy.co.uk
The SY-MHDBT-44P is a HDMI matrix switcher with four HDMI inputs and four HDBaseT outputs, of which
outputs one and two also have mirrored HDMI outputs. This 1U rack-mountable 4 x 4 matrix switcher
provides a very powerful and tidy matrix solution, with built-in HDBaseT transmitters which can directly
power up to 4 remote SY-HDBT-70P-R receivers.
Can be used in wide range of applications and environments, including Residential, AV installations, Digital
Signage, school / colleges…
Features
Four HDMI input sources
Four HDBaseT outputs with two Mirrored HDMI output connectors on Zones 1 and 2
Provides PoC to directly drive SY-HD-70P-R remote receivers
HDMI 1.4a, DVI 1.1 compatible –HDCP compliant and supports 3D
De-Embedded audio outputs –S/PDIF and stereo analogue
RS232 to remote display locations via HDBaseT outputs
Control from front panel, IR remote control, RS232 commands and Ethernet
Manual EDID transfer from output port to input port
Front panel display for confirmation of switching actions or using configuration options
48V DC power input
Connectors and Controls
Front
Name
Description
Service
USB Type B for firmware updates
IR Sensor
Receives IR commands from the remote controller
Power LED
Indicates unit is powered
System Monitor
Displays the results of selection commands and menu options
Input Select
Selection buttons for inputs 1 to 4
These buttons also serve as menu navigation controls
Output Select
Selection buttons for outputs 1 to 4
AV Button
HDMI input to output deliminator
All Button
Sets input selection to all outputs
EDID Button
Copies EDID information from an output to an input

SY-MHDBT-44P
www.sy.co.uk
Rear
Name
Description
Master IR
Input from IR sensor that is routed to all IR outputs
IR OUT
Outputs to IR emitters to control local equipment from remote locations
HDMI Inputs 1 to 4
Input connectors for up to 4 HDMI video sources
Zones 1 to 4
Output connectors for up to 4 display zones
IR IN
IR sensor input - routed to the HDBaseT output of the same Zone Block
S/PDIF
De-embedded S/PDIF coaxial data output (RCA Connector)
Audio out
Stereo audio output connector (de-embedded)
RS232
Tx and Rx connection for controlling equipment via the HDBaseT output
HDMI Out
Mirrored HDMI output for local displays - Zone 1 and Zone 2 only
HDBaseT output
RJ45 HDBaseT connector output –Directly powers (PoC) remote SY-HD-70P-R
receivers to 60m
RS232
RS232 control port for SY-MHDBT-44P matrix
TCPIP
RJ45 Ethernet Connector
Power connector
48V DC supply input
Earthing Connection
Earth (ground) bonding point
Using the SY-MHDBT-44P HDMI Matrix Switcher
Connecting the Outputs and Inputs
Connect the input HDMI sources to the matrix HDMI INPUTS - connect the HDBaseT extenders to the
connectors in the OUPTUT group. Connect the power supply provided with the SY-MHDBT-44P.
To ensure safety and as a good practice, be sure to connect an earth bonding strap to the earthing point
on the rear of the SY-MHDBT-44P unit to a good local earthing point.
Using the Front Panel Controls
Use the following button sequence to make a video selection: Input number, AV, then Output number.
For example to select input 2 to output 4 press the following buttons: 2 AV 4, where 2is the INPUT
selection and 4is the selected OUTPUT.
To send a single input to all the outputs use the following button sequence:
Input number, then ALL button.

SY-MHDBT-44P
www.sy.co.uk
Using IR Remote Controls
Point the IR remote control key pad at the SY-MHDBT-44P and use the key pad buttons in the same
sequence as for using the front panel controls.
RS232 Control Commands
The following RS232 commands provide control of the SY-MHDBT-44P from a PC, laptop or programmable
control panel. The RS232 settings are: 9600 baud, 8 bits, no parity, and 1 stop bit.
All response values given in the following table are examples only. The actual response values will reflect
the changes that the transmitted RS232 command has just made.
The RS232 commands are case-sensitive and all numerical values are in decimal only.
Any punctuation marks shown in the RS232 command are part of the command and must be included
when sending the command.
Action
Command
Response
Check the matrix type
/*Type;
Lock the front panel buttons
/%Lock;
Locked
Unlock the front panel buttons
/%Unlock;
Unlocked
Check the software version
/^Version;
Turn response messages off
/:MessageOff;
Turn response messages on
/:MessageOn;
Revert to the previous switch state
Undo.
Enable Demo mode
Demo.
Set all outputs to input x
(where x is the input number)
xAll.
Set each output to its corresponding input number
All#.
Switch off all outputs
All$.
Set a single output (x) to its corresponding input channel
x#.
Switch off a single output (y)
y$.
Select a video input (x) to an output (y)
(Where x is the input number and y is the output number)
xVy.
Select a video input (x) and its IR inputs to an output (y)
(Where x is the input number and y is the output number)
xBy.
Select a IR input (x) to an output (y)
(Where x is the input number and y is the output number)
xRy.
Check the status of the matrix switches
Status.
Save the current matrix settings are preset p
(p is in the range 0 to 9)
Savep.
Set the matrix to the setting in preset p
(p is in the range 0 to 9)
Recallp.
Clear the stored setting in preset p
(p is in the range 0 to 9)
Clearp.

SY-MHDBT-44P
www.sy.co.uk
Action
Command
Response
Turn on the SY-MHDB-44P
PWON.
Turn off the SY-MHDB-44P
PWOFF.
Read the EDID information from the display device
connected to output x
EDIDGx.
Upgrade the EDID for input x via the RS232 port
EDIDUgradex.
Copy the EDID information from the display device at
output x to input y
EDIDMxBy.
Restore the factory default EDID data
EDIDMInit.
HDCP Management
/%y/x:z.
Set HDCP Management to automatic
%0801.
Set HDCP Management to manual
%0800.
Send data from PC to SY-HDBT-70P-R or SY-HDBT-100-R via
output x at baud rate y
See below for more details
/+x/y:******.
Check the connection status of the inputs
%9971.
Check the connection status of the outputs
%9972.
Check the HDCP status of the inputs
%9973.
Check the HDCP status of the outputs
%9974.
Check the switching status
%9975.
Check the output resolution
%9976.
Notes:
1. Value place holders g, p, x, y and z should be replaced with the actual input and output
numbers required for the RS232 command.
2. When selecting multiple outputs each output must be separated by a comma and may appear
in any order.
3. The EDIDUpgrade command must have a binary image file containing the new EDID information
within 10 seconds of the command being issued.

SY-MHDBT-44P
www.sy.co.uk
Sending RS232 Data from a PC to a HDBaseT Receiver
The command to send data from a PC given in the above table is used as follows:
RS232 command: /+x/y:******.
Value x represents the output channel to send the RS232 data to. This can be either 1 to 4 for each of the
four outputs respectively, or 5 to transmit the data through all four outputs simultaneously.
Value y ranges from 1 to 7 inclusive and represents the transmission baud rate as detailed below:
Y value
baud rate
1
2400
2
4800
3
9600
4
19200
5
38400
6
57600
7
115200
In the above command ****** represents the data to be transmitted to the remote location(s). This data
can be up to 48 bytes in length, full stop characters are allowed within the data values, but the last full
stop must be present to indicate the end of the command.
Using the EDID Upgrade Command
The EDID upgrade command requires careful consideration because there is a ten second time out period
within which the new EDID binary image must be sent to the SY-MHDBT-44P. If no data arrives within that
ten second window, then the command is automatically aborted.
The binary image must be a valid EDID data block in multiples of 128 bytes.
Specifications
General
HDMI Resolutions
Up to 1920 x 1200 @ 60Hz, including 1080p
HDMI Standard
HDMI 1.4a –Supports HDCP and 3D
Power Supply
100 to 240V AC, 50 / 60 Hz
Power Consumption
25 W max (Steady state - No output)
RS232
9600, 8 data bits, 1 stop bit, no parity –No handshaking
Environmental
Operating Temperature
0 - 40 °C non condensing
Physical
Dimensions (W x H x D)
483 x 44 x 235 mm (including flanges) –19 in 1U rack mount
Weight
2.2 kg

SY-MHDBT-44P
www.sy.co.uk
Figure 1 –SY-MHDBT-44P Connection Diagram

SY-MHDBT-44P
www.sy.co.uk
Safety Instructions
To ensure reliable operation of this product as well as protecting the safety of any person using or
handling these devices while powered, please observe the following instructions.
1. Use the power supplies provided. If an alternate supply is required, check Voltage, polarity and
that it has sufficient power to supply the device it is connected to.
2. Do not operate either of this product outside the specified temperature and humidity range
given in the above specifications.
3. Ensure there is adequate ventilation to allow this product to operate efficiently.
4. Repair of this equipment should only be carried out by qualified professionals as this product
contains sensitive devices that may be damaged by any mistreatment.
5. Only use this product in a dry environment. Do not allow any liquids or harmful chemicals to
come into contact with this product.
After Sales Service
1. Should you experience any problems while using this product, firstly refer to the Troubleshooting
section in this manual before contacting SY Technical Support.
2. When calling SY Technical Support, the following information should be provided:
Product name and model number
Product serial number
Details of the fault and any conditions under which the fault occurs.
3. This product has a two year standard warranty, beginning from the date of purchase as stated on
the sales invoice. Online registration of this product is required to activate the full three year
extended warranty. For full details please refer to our Terms and Conditions.
4. SY Product warranty is automatically void under any of the following conditions:
The product is already outside of its warranty period
Damage to the product due to incorrect usage or storage
Damage caused by unauthorised repairs
Damage caused by mistreatment of the product
5. Please direct any questions or problems you may have to your local dealer before contacting SY
Electronics.
