SybronEndo Apex ID User manual

TABLE OF CONTENTS
313
English 1
Français 13
Deutsch 25
Español 37
Italiano 49
Português 61
Nederlands 73
Dansk 85
Norsk 97
Suomi 109
Svenska 121
Česky 133
Magyar 145
Polski 157
Русский 169
Hrvatski jezik 181
Srpski 193
Slovensky 205
Eesti 217
Lietuviškai 229
Română 241
Türkçe 253
Ελληνικα 265
繁體中文 277
한국어 289
日本語 301
077-0167_RevE_Apex_ID_IFU.indb 3 10/7/15 12:12 PM

2
FIGURES
Figure 1.1 Figure 1.6
Figure 1.2
Figure 1.7
Figure 1.3 Figure 1.8
Figure 1.4 Figure 1.9
Figure 1.5
Figure 2.1
Figure 2.2
Figure 2.4
Figure 2.5
Figure 2.3
Figure 2.6
Figure 2.7 Figure 2.8
Figure 3.3
Figure 2.10
Figure 2.12
Figure 2.13
Figure 2.11
Figure 3.4
Figure 3.1
Figure 3.2 Figure 3.6
Figure 3.5
FIGURES
Figure 2.14
Figure 2.9
English
077-0167_RevE_Apex_ID_IFU.indb 1-2 10/7/15 12:12 PM

2
FIGURES
Figure 1.1 Figure 1.6
Figure 1.2
Figure 1.7
Figure 1.3 Figure 1.8
Figure 1.4 Figure 1.9
Figure 1.5
Figure 2.1
Figure 2.2
Figure 2.4
Figure 2.5
Figure 2.3
Figure 2.6
Figure 2.7 Figure 2.8
Figure 3.3
Figure 2.10
Figure 2.12
Figure 2.13
Figure 2.11
Figure 3.4
Figure 3.1
Figure 3.2 Figure 3.6
Figure 3.5
FIGURES
Figure 2.14
Figure 2.9
English
077-0167_RevE_Apex_ID_IFU.indb 1-2 10/7/15 12:12 PM

4
3
FIGURES
Figure 4.1
Figure 4.5 Figure 4.8
Figure 4.9
Figure 4.10
Figure 5.1
Figure 4.6
Figure 4.7
Figure 4.2
Figure 4.3
Figure 4.4
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
DANGER
• Do not use on patients with pacemakers.
• Do not use with electrosurgery devices.
• Products or parts which have not been approved by SybronEndo shall not be connected or attached to this
product. Use of un-approved products or parts may result in malfunction of the device and injury to the patient.
• Do not use this device in the presence of oxygen-oxidized substances, nitrogen-oxidized substances or
combustible anesthetic mixtures.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
CAUTION
“Caution: Federal law restricts this device to sale by or on the order of a dentist.”
• This device is not waterproof. Exposure to moisture could result in electric shock or damage to the device.
• Do not disassemble the device. Disassembly and touching the inside of the device could result in electric shock
or burn. (If you disassemble the product intentionally, warranty shall not be honored irrespective of guarantee
period.)
• Disassembly or repair should only be done by those authorized by SybronEndo.
• This product is for dental operative use only.
• Confirm the device is operating normally prior to use.
• When the volume of battery is low, discontinue use and replace the batteries.
• Do not try to use in high humidity conditions.
• Protect the device from the effects of atmospheric pressure, wind, sun and salt.
• Do not use where explosive products or gases are stored.
• Stop using if not operating correctly.
• Not indicated for any use except for measuring the working length of root canals.
This manual provides instruction on how to measure the working length of root canals using the Apex ID
Electronic Apex Locator.
• This instruction manual has been prepared for use by dental professionals.
• This manual and the product may be subject to change without notice if required.
• The product has been tested for electromagnetic application test compliance with EN60601-1-2 and is designed to
protect against harmful interference when installed and operated according to instructions.This product could produce,
use, and discharge wireless wavelength energy; and it may cause harmful interference with other equipment nearby.
In this event, the user should resolve the interference using one or more of the recommendations described below:
o Increase the distance between the Apex ID and the device which is experiencing interference.
o Reinstall and restart the Apex ID again.
o Contact your distributor or SybronEndo.
SAFETY PRECAUTIONS
Please read this manual carefully.The purpose of this instruction manual is to provide effective & safe
operation of the Apex ID for users and patients.
SAFE OPERATION
Symbols:This instruction manual contains various symbols to assist the operator in correct and safe operation of
the device and to protect against injury, damage or loss of property.The symbols and meanings are as follows:
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
DANGER
Could result in injury or death.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
CAUTION
Could result in injury or death.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
NOTICE
May result in injury or death.
May result in incorrect data.
C
AB
C
AB
Radiographic
apex
Physiological apex
or apical constriction
Anatomical
apex or
apical
foramen
Figure 5.2
A) Distance between radiographic
apex and anatomical apex
B) Distance between physiological
apex and anatomic apex
C) Distance between radiographic
apex and physiological apex
077-0167_RevE_Apex_ID_IFU.indb 3-4 10/7/15 12:12 PM

4
3
FIGURES
Figure 4.1
Figure 4.5 Figure 4.8
Figure 4.9
Figure 4.10
Figure 5.1
Figure 4.6
Figure 4.7
Figure 4.2
Figure 4.3
Figure 4.4
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
DANGER
• Do not use on patients with pacemakers.
• Do not use with electrosurgery devices.
• Products or parts which have not been approved by SybronEndo shall not be connected or attached to this
product. Use of un-approved products or parts may result in malfunction of the device and injury to the patient.
• Do not use this device in the presence of oxygen-oxidized substances, nitrogen-oxidized substances or
combustible anesthetic mixtures.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
CAUTION
“Caution: Federal law restricts this device to sale by or on the order of a dentist.”
• This device is not waterproof. Exposure to moisture could result in electric shock or damage to the device.
• Do not disassemble the device. Disassembly and touching the inside of the device could result in electric shock
or burn. (If you disassemble the product intentionally, warranty shall not be honored irrespective of guarantee
period.)
• Disassembly or repair should only be done by those authorized by SybronEndo.
• This product is for dental operative use only.
• Confirm the device is operating normally prior to use.
• When the volume of battery is low, discontinue use and replace the batteries.
• Do not try to use in high humidity conditions.
• Protect the device from the effects of atmospheric pressure, wind, sun and salt.
• Do not use where explosive products or gases are stored.
• Stop using if not operating correctly.
• Not indicated for any use except for measuring the working length of root canals.
This manual provides instruction on how to measure the working length of root canals using the Apex ID
Electronic Apex Locator.
• This instruction manual has been prepared for use by dental professionals.
• This manual and the product may be subject to change without notice if required.
• The product has been tested for electromagnetic application test compliance with EN60601-1-2 and is designed to
protect against harmful interference when installed and operated according to instructions.This product could produce,
use, and discharge wireless wavelength energy; and it may cause harmful interference with other equipment nearby.
In this event, the user should resolve the interference using one or more of the recommendations described below:
o Increase the distance between the Apex ID and the device which is experiencing interference.
o Reinstall and restart the Apex ID again.
o Contact your distributor or SybronEndo.
SAFETY PRECAUTIONS
Please read this manual carefully.The purpose of this instruction manual is to provide effective & safe
operation of the Apex ID for users and patients.
SAFE OPERATION
Symbols:This instruction manual contains various symbols to assist the operator in correct and safe operation of
the device and to protect against injury, damage or loss of property.The symbols and meanings are as follows:
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
DANGER
Could result in injury or death.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
CAUTION
Could result in injury or death.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
NOTICE
May result in injury or death.
May result in incorrect data.
C
AB
C
AB
Radiographic
apex
Physiological apex
or apical constriction
Anatomical
apex or
apical
foramen
Figure 5.2
A) Distance between radiographic
apex and anatomical apex
B) Distance between physiological
apex and anatomic apex
C) Distance between radiographic
apex and physiological apex
077-0167_RevE_Apex_ID_IFU.indb 3-4 10/7/15 12:12 PM

6
5
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
NOTICE
• This product is for use by dental professionals only.
• To avoid electrical shock or explosion, keep the device away from high temperature or high humidity. Keep the
metal parts of this product away from conductors. Fire, electric shock, or damage may result.
• Do not put heavy items on the device. Fire or electric shock may result.
• Confirm all measurements of canal length with radiographs.
• Blocked root canals cannot be measured correctly.
• When you give this device to others, include the Instructions For Use.
• Remove the batteries if the Apex ID device is not likely to be used for sometime.
Label maintenance and repair:
• The label for notice or caution shall be maintained soundly with regular inspection.
• Replace: If the label for notice or caution has been lost or damaged, please contact SybronEndo for replacement.
1– INDICATIONS FOR USE AND PRINCIPLE OF OPERATION
1.1 – Indications for use
Apex ID is an Electronic Apex Locator designed for use in
measuring the working length of root canals.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
NOTICE Use the device to measure the working
length of root canals only.
1.2 – Principle of operation
Micro signals consisting of dual frequencies sent from
the unit return to the unit after travelling along the electric
circuit that is composed of: unit - probe cord – file holder -
file - patient - lip holder - probe cord. The impedance of the
electric circuit may be changed depending on the distance
between the end of a file and the apex of the root canal,
which results in a change in the micro signals that are
input back into the unit.The microprocessor of the unit
calculates the change in micro signals to convert the
difference into a distance value, which will be displayed
on the Apex ID LCD display.
2.2 – Accessories and their functions
Name Functions
Probe cord –Fig 1.8 Connects between the Apex ID & file holder & Lip Hook
Lip Hook – Fig 1.4 For contact to patient’s lip
File holder A –Fig 1.5 Touch to file (designed for molar teeth)
File holder B –Fig 1.6 Holds File
Checker –Fig 1.9 Confirms that the Apex ID is functioning correctly
2– DEVICE CONTENTS AND FUNCTIONS
2.3 –The features of the Apex ID and their functions
Feature Functions
LCD Screen –Fig 2.1 Shows the status of settings and indicates the distance
between the end of file inserted in root canal & root apex
Control panel –Fig 2.2 Select power ON/OFF & control functions
Stand –Fig 2.3 Placing the Apex ID on a counter
Battery compartment –Fig 2.4 Contains batteries 1.5V x 3 (DC 4.5V).
Probe cord jack –Fig 2.5 Connect to probe cord for measuring working length of
root canal
Up button (
SET
)–Fig 2.6 Push the button to increase the root apex standard value
by 0.1 and the volume of buzzer is increased 1 step up
Down button (
SET
)–Fig 2.7 Push the button to decrease the root apex standard value
by 0.1 and the volume of buzzer is decreased 1 step down
Setting button ( SET ) – Fig 2.8 Push the button to fix the setting mode
Power button (
SET
)–Fig 2.9 Push the button to turn the unit ON/OFF
Buzzer volume signal –Fig 2.10 Indicates the volume of the Buzzer
Graph signal –Fig 2.11 Graph shows the distance between the end of file and
root apex
Battery signal –Fig 2.12 Indicates remaining battery life
Root apex signal –Fig 2.13 Indicates when file has reached the apical foramen, or
the “0” point set by the operator
Numeric signal –Fig 2.14 Indicates the distance between the end of file & root apex
2.1 – Device contents and functions
Contents of product:
Apex ID Unit (1) – Fig 1.1
AAA Alkaline Batteries (3) – Fig 1.2
Stand (1) –Fig 1.3
Lip Hooks (5) –Fig. 1.4
File Holder A (1) – Fig 1.5
File Holder B (2) – Fig 1.6
Instructions For Use (1) –Fig 1.7
Probe Cord (1) –Fig 1.8
Checker (1) –Fig 1.9
3– PRODUCT SYMBOLS
Serial Number
Part Number
Manufacturing Date
CE Marking
Type B Applied Part
Caution
Authorized Representative
in the European Community
Consult Instructions for Use
CSA Marking
Dispose of Properly
Manufacturer
SN
REF
EC REP
SN
REF
EC REP
077-0167_RevE_Apex_ID_IFU.indb 5-6 10/7/15 12:12 PM

6
5
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
NOTICE
• This product is for use by dental professionals only.
• To avoid electrical shock or explosion, keep the device away from high temperature or high humidity. Keep the
metal parts of this product away from conductors. Fire, electric shock, or damage may result.
• Do not put heavy items on the device. Fire or electric shock may result.
• Confirm all measurements of canal length with radiographs.
• Blocked root canals cannot be measured correctly.
• When you give this device to others, include the Instructions For Use.
• Remove the batteries if the Apex ID device is not likely to be used for sometime.
Label maintenance and repair:
• The label for notice or caution shall be maintained soundly with regular inspection.
• Replace: If the label for notice or caution has been lost or damaged, please contact SybronEndo for replacement.
1– INDICATIONS FOR USE AND PRINCIPLE OF OPERATION
1.1 – Indications for use
Apex ID is an Electronic Apex Locator designed for use in
measuring the working length of root canals.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
NOTICE Use the device to measure the working
length of root canals only.
1.2 – Principle of operation
Micro signals consisting of dual frequencies sent from
the unit return to the unit after travelling along the electric
circuit that is composed of: unit - probe cord – file holder -
file - patient - lip holder - probe cord. The impedance of the
electric circuit may be changed depending on the distance
between the end of a file and the apex of the root canal,
which results in a change in the micro signals that are
input back into the unit.The microprocessor of the unit
calculates the change in micro signals to convert the
difference into a distance value, which will be displayed
on the Apex ID LCD display.
2.2 – Accessories and their functions
Name Functions
Probe cord –Fig 1.8 Connects between the Apex ID & file holder & Lip Hook
Lip Hook – Fig 1.4 For contact to patient’s lip
File holder A –Fig 1.5 Touch to file (designed for molar teeth)
File holder B –Fig 1.6 Holds File
Checker –Fig 1.9 Confirms that the Apex ID is functioning correctly
2– DEVICE CONTENTS AND FUNCTIONS
2.3 –The features of the Apex ID and their functions
Feature Functions
LCD Screen –Fig 2.1 Shows the status of settings and indicates the distance
between the end of file inserted in root canal & root apex
Control panel –Fig 2.2 Select power ON/OFF & control functions
Stand –Fig 2.3 Placing the Apex ID on a counter
Battery compartment –Fig 2.4 Contains batteries 1.5V x 3 (DC 4.5V).
Probe cord jack –Fig 2.5 Connect to probe cord for measuring working length of
root canal
Up button (
SET
)–Fig 2.6 Push the button to increase the root apex standard value
by 0.1 and the volume of buzzer is increased 1 step up
Down button (
SET
)–Fig 2.7 Push the button to decrease the root apex standard value
by 0.1 and the volume of buzzer is decreased 1 step down
Setting button ( SET ) – Fig 2.8 Push the button to fix the setting mode
Power button (
SET
)–Fig 2.9 Push the button to turn the unit ON/OFF
Buzzer volume signal –Fig 2.10 Indicates the volume of the Buzzer
Graph signal –Fig 2.11 Graph shows the distance between the end of file and
root apex
Battery signal –Fig 2.12 Indicates remaining battery life
Root apex signal –Fig 2.13 Indicates when file has reached the apical foramen, or
the “0” point set by the operator
Numeric signal –Fig 2.14 Indicates the distance between the end of file & root apex
2.1 – Device contents and functions
Contents of product:
Apex ID Unit (1) – Fig 1.1
AAA Alkaline Batteries (3) – Fig 1.2
Stand (1) –Fig 1.3
Lip Hooks (5) –Fig. 1.4
File Holder A (1) – Fig 1.5
File Holder B (2) – Fig 1.6
Instructions For Use (1) –Fig 1.7
Probe Cord (1) –Fig 1.8
Checker (1) –Fig 1.9
3– PRODUCT SYMBOLS
Serial Number
Part Number
Manufacturing Date
CE Marking
Type B Applied Part
Caution
Authorized Representative
in the European Community
Consult Instructions for Use
CSA Marking
Dispose of Properly
Manufacturer
SN
REF
EC REP
SN
REF
EC REP
077-0167_RevE_Apex_ID_IFU.indb 5-6 10/7/15 12:12 PM

8
7
4– BEFORE USE
4.1 – Check contents
• Confirm that all the components listed in the Contents
are in the box before using the device for the first
time. (Please refer to Kit Contents in section 2)
• Please check the exterior of the device for damage.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
NOTICE SybronEndo shall not be responsible
for any damage caused by misuse of the product.
4.2 – Check connection between probe cord and
file holder
Insert lip hook and file holder B into probe cord [Fig 3-1].
Insert probe cord into probe cord jack of the main unit.
[Fig 3-2]
After turning on the power, make sure there is a complete
circuit by touching file holder B to the lip hook.The screen
will show all bars lit and a dashed line on the lower light of
the screen [Fig. 5.1]. The tone will be steady.
Note: If the power button (
SET
) doesn’t work, make sure
that the insulation plastic is completely removed from
the battery cover in the back of the product. Remove the
insulation plastic piece before use. [Fig 3-4]
4.3 – Performance inspection with checker
Power on by pushing power button (
SET
). [Fig 3-5]
Plug in Checker (to the probe cord jack) provided in the
original packaging and see if the value on the LCD screen
is ‘0.5’. [Fig 3-6]
If ‘0.5’ is displayed on the LCD screen, the unit is ready
for clinical usage.
5– SET UP AND USE
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
NOTICE The standard value for the apex of
Apex ID is set as 0.0 at the factory. This value means
that the file has reached the anatomical foramen.
[Fig 5.2]
5.3 – Setting of the buzzer volume
Turn on the Apex ID by pushing the power button
(
SET
). [Fig 4-1]
Push the up button (
SET
) and down button (
SET
), simultane-
ously for about 3seconds, and push setting button ( SET )
once. [Fig 4-4]
Adjust the volume of the buzzer by pressing the up button
(
SET
) or the down button (
SET
). [Fig 4-2]
Push the setting button (
SET
) to keep the set volume.
[Fig 4-3]
5.4 – Measuring the working length of the root canal
Turn on the Apex ID by pushing the power button
(
SET
). [Fig 4-1]
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
NOTICE Before use, sterilize the lip hook
using a steam sterilizer at 121°C for 30 minutes.
Place the lip hook on the patient’s lip. [Fig 4-5]
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
NOTICE Place the lip hook on the opposite
side of the mouth from the tooth being measured.
Use with Stainless Steel hand file.
Insert the file into the canal. [Fig 4-6]
Attach the file holder B to the file (If using holder A, touch
the file below the handle with the file holder). [Fig 4-7]
Insert the file slowly into the root canal while checking the
graph and the number value on the screen. Stop insertion
when the distance between the file and root apex reaches
the standard value of the root apex (pre-set factory setting
at 0.0mm or your chosen value). As the file nears the
apical constriction, the unit will beep more rapidly. When
the apex is reached the file is touching the periodontal
membrane and a red bar will appear at the “Apex” on
the screen. As it goes past the apical constriction, the
frequency of beeps increases until the screen reads “-0.5.”
Then the sound will remain steady and the entire screen
will flash.
Continue inserting the file to -0.1 (if the standard value of
the root apex is set at 0.0) then move the file back until
0.0 is displayed on the screen. This helps to confirm the
location of the apex. [Fig 4-8~Fig 4-10]
After positioning the rubber stop of file on the tooth at the
reference point the file should be removed from the canal.
Measure the working length from the tip of the file to the
rubber stop with a ruler. After positioning the rubber stop
on the file to a reference point, the file should be removed
from the tooth.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
NOTICE The measurement result shown by
the Apex ID and the length of file may vary depending
on the operator’s angle of view.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
The insertion angle of the file after enlarging the
canal may vary from the original working length
measurement angle.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
Re-confirm the working length after enlarging
the canal.
Turn off the Apex ID by pushing the power button (
SET
).
The power will automatically shut off after 5 minutes
of non-use. The working length should be confirmed
byradiograph.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
NOTICE A radiograph may show a different
measurement result than the Apex ID.This is not an
indication of malfunction by the unit or the x-ray.
Often the apical foramen is located coronal to the
radiographic apex. [Fig 5.2] Another possibility is the
angle of the x-ray beam and film may be off angle to
the perpendicular.
5.1 – Probe cord connection
Connect the file holder and lip hook to the probe cord.
[Fig 3-1] The probe cord should be connected to the probe
cord jack of the main unit. [Fig 3-2]
5.2 – Setting the standard value for root apex
Turn on the product by pushing the power button (
SET
).
[Fig 4-1] The position of the file tip is shown by the canal
length indicator bar on the display. Working Length: The 0.5
reading indicates that the tip of the file is at or very near
the apical construction (physiological foramen). [Fig 5.2]
Push the up button (
SET
) and down button (
SET
) simultane-
ously for about 3seconds. [Fig 4-2]
Set at ‘0.0’ at this point by pushing the up button (
SET
) or
down button (
SET
). [Fig 4-2] Change back by following the
same process.
Push the setting button ( SET ) then the desired value of the
root apex shall be fixed. [Fig 4-3]
077-0167_RevE_Apex_ID_IFU.indb 7-8 10/7/15 12:12 PM

8
7
4– BEFORE USE
4.1 – Check contents
• Confirm that all the components listed in the Contents
are in the box before using the device for the first
time. (Please refer to Kit Contents in section 2)
• Please check the exterior of the device for damage.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
NOTICE SybronEndo shall not be responsible
for any damage caused by misuse of the product.
4.2 – Check connection between probe cord and
file holder
Insert lip hook and file holder B into probe cord [Fig 3-1].
Insert probe cord into probe cord jack of the main unit.
[Fig 3-2]
After turning on the power, make sure there is a complete
circuit by touching file holder B to the lip hook.The screen
will show all bars lit and a dashed line on the lower light of
the screen [Fig. 5.1]. The tone will be steady.
Note: If the power button (
SET
) doesn’t work, make sure
that the insulation plastic is completely removed from
the battery cover in the back of the product. Remove the
insulation plastic piece before use. [Fig 3-4]
4.3 – Performance inspection with checker
Power on by pushing power button (
SET
). [Fig 3-5]
Plug in Checker (to the probe cord jack) provided in the
original packaging and see if the value on the LCD screen
is ‘0.5’. [Fig 3-6]
If ‘0.5’ is displayed on the LCD screen, the unit is ready
for clinical usage.
5– SET UP AND USE
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
NOTICE The standard value for the apex of
Apex ID is set as 0.0 at the factory. This value means
that the file has reached the anatomical foramen.
[Fig 5.2]
5.3 – Setting of the buzzer volume
Turn on the Apex ID by pushing the power button
(
SET
). [Fig 4-1]
Push the up button (
SET
) and down button (
SET
), simultane-
ously for about 3seconds, and push setting button ( SET )
once. [Fig 4-4]
Adjust the volume of the buzzer by pressing the up button
(
SET
) or the down button (
SET
). [Fig 4-2]
Push the setting button (
SET
) to keep the set volume.
[Fig 4-3]
5.4 – Measuring the working length of the root canal
Turn on the Apex ID by pushing the power button
(
SET
). [Fig 4-1]
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
NOTICE Before use, sterilize the lip hook
using a steam sterilizer at 121°C for 30 minutes.
Place the lip hook on the patient’s lip. [Fig 4-5]
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
NOTICE Place the lip hook on the opposite
side of the mouth from the tooth being measured.
Use with Stainless Steel hand file.
Insert the file into the canal. [Fig 4-6]
Attach the file holder B to the file (If using holder A, touch
the file below the handle with the file holder). [Fig 4-7]
Insert the file slowly into the root canal while checking the
graph and the number value on the screen. Stop insertion
when the distance between the file and root apex reaches
the standard value of the root apex (pre-set factory setting
at 0.0mm or your chosen value). As the file nears the
apical constriction, the unit will beep more rapidly. When
the apex is reached the file is touching the periodontal
membrane and a red bar will appear at the “Apex” on
the screen. As it goes past the apical constriction, the
frequency of beeps increases until the screen reads “-0.5.”
Then the sound will remain steady and the entire screen
will flash.
Continue inserting the file to -0.1 (if the standard value of
the root apex is set at 0.0) then move the file back until
0.0 is displayed on the screen. This helps to confirm the
location of the apex. [Fig 4-8~Fig 4-10]
After positioning the rubber stop of file on the tooth at the
reference point the file should be removed from the canal.
Measure the working length from the tip of the file to the
rubber stop with a ruler. After positioning the rubber stop
on the file to a reference point, the file should be removed
from the tooth.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
NOTICE The measurement result shown by
the Apex ID and the length of file may vary depending
on the operator’s angle of view.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
The insertion angle of the file after enlarging the
canal may vary from the original working length
measurement angle.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
Re-confirm the working length after enlarging
the canal.
Turn off the Apex ID by pushing the power button (
SET
).
The power will automatically shut off after 5 minutes
of non-use. The working length should be confirmed
byradiograph.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
NOTICE A radiograph may show a different
measurement result than the Apex ID.This is not an
indication of malfunction by the unit or the x-ray.
Often the apical foramen is located coronal to the
radiographic apex. [Fig 5.2] Another possibility is the
angle of the x-ray beam and film may be off angle to
the perpendicular.
5.1 – Probe cord connection
Connect the file holder and lip hook to the probe cord.
[Fig 3-1] The probe cord should be connected to the probe
cord jack of the main unit. [Fig 3-2]
5.2 – Setting the standard value for root apex
Turn on the product by pushing the power button (
SET
).
[Fig 4-1] The position of the file tip is shown by the canal
length indicator bar on the display. Working Length: The 0.5
reading indicates that the tip of the file is at or very near
the apical construction (physiological foramen). [Fig 5.2]
Push the up button (
SET
) and down button (
SET
) simultane-
ously for about 3seconds. [Fig 4-2]
Set at ‘0.0’ at this point by pushing the up button (
SET
) or
down button (
SET
). [Fig 4-2] Change back by following the
same process.
Push the setting button ( SET ) then the desired value of the
root apex shall be fixed. [Fig 4-3]
077-0167_RevE_Apex_ID_IFU.indb 7-8 10/7/15 12:12 PM

10
9
7– MAINTENANCE AND STORAGE
7.1 – Sterilization
The ‘Lip Hook’ and ‘File holder A’ should be sterilized at
121°C for 30 minutes with high-pressure steam.
The ‘File holder B’ should be sterilized at a temperature
of 121°C for 30 minutes with high-pressure steam in a
sterilization pouch, then dried at least 10 minutes after
sterilization.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
CAUTION Parts used in direct intraoral
contact are to be steam sterilized.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
NOTICE It is highly recommended to place
File holder B in a sterilization pouch for autoclaving.
• The metal of the File holder B may be corroded
when it is in direct contact with steam.
• Temperature should not exceed 135°C during
sterilization as the product may be damaged.
7.2 – Recommended sterilizer type
• Sterilizer: Vacuum type (B)
• Sterilization temperature: 121°C,
• Sterilization time: 30min
7.3 – Method used to validate recommended
sterilization method:
Sterility Assurance Level (SAL): 10-6
1) Sterilization validation samples are wrapped with BIs.
2) 3 times of sterilization cycles as a half cycle are carried
out at 121°C for 15 minutes.
3) 1 time of sterilization cycle as a full cycle is carried out
at 121°C for 30 minutes.
4) Incubate BIs at 55~60°C for 7days.
7.4 – Sterilizer used for validation
• Manufacturer: DAIHAN LABTECH CO., LTD
• Model name: LAC-5105SP
• Serial No. : 20101202138
• Control No. : TE-10-23
• Valuable room: 100 liter
• Power supply: AC 220V, 50/60Hz
• Pressure: 2.6kgf/cm2
• Range of sterilization temperature: 105°C~135°C
7.5 – Cleaning
Clean the Apex ID or probe cord with dry gauze and a
small amount of ethanol. Any ethanol left on the product
after cleaning should be completely wiped off with a dry
cloth.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
CAUTION Use protective sleeves on the cords
and Apex ID during operation, followed by removal
of the sleeve and wiping with alcohol after operation.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
CAUTION Do not use the Apex ID when wet
with ethanol. There is a possibility of electric shock
or product damage.
7.6 – Operating, Storage,Transport
The Apex ID should be operated in temperatures ranging
from 10~40°C, atmospheric pressure 70~106 Kpa
and relative humidity 30~75%. The Apex ID should be
stored and transported in temperatures ranging from
-20~50°C, atmospheric pressure 70~106 Kpa and relative
humidity5~90%.
7.7 – Disposal
Dispose of the product in accordance with your local
waste disposal regulations and/or laws
6– GUIDE FOR ACCURATE MEASUREMENT
Turn on the Apex ID prior to use.
Plug the Checker [Fig 1-9] (provided in the original packaging)
into the probe cord jack [Fig 2-5] and confirm the value on
the LCD screen is 0.5.
It is recommended to insert the file into the canal first and
then connect the file to the file holder.
If the signals do not change as the file approaches the
APEX, it is possible the root canal is too dry; therefore it
should be filled with an irrigant.
Necrotic tissue or other matter in the root canal may affect
accuracy. It is advisable to take several measurements
during enlargement of the canal.
Start with a larger file at first. If the APEX indication (graph
and numeric signal on the screen) does not reach the
APEX, gradually try a smaller file to measure the working
length of the root canal.
To minimize error, it is recommended the working length
be measured more than twice.
If root canals within a tooth are connected, as in the case
of multiple root canals with anastomoses or cracks, miss-
measurement is possible. It is recommended to verify the
tooth’s anatomy radiographically.
Contact with metal restorations by the file during
measurements may result in errors.
Remove blood or exudate from the canal before
measurement.
In cases where the foramen is not completely formed or
the foramen has been overly expanded, the measurement
value of the working length may be shorter than the actual
measurement value.
• Rated voltage: DC4.5V (1.5V Alkaline Battery AAA x 3EA)
• Input current: less than DC 60mA
• Power consumption: less than 0.27VA
• Patient auxiliary current: less than AC 10µA
• Oscillation frequency: 500Hz ±0.2Hz, 5kHz ±0.002kHz
• Size: W70mm ±1mm x D25mm ±1mm x H100mm
±1mm
• Weight: 390g ±15g (including stand, except battery)
• Protection type and level against electric shock:Type B
applied part
• Internally powered equipment, Ordinary equipment
(IPX0)
• Continuous operation time: 62hours (at 1250mAh
Battery x 3EA)
8–TROUBLE SHOOTING
Problem Possible Causes Solutions
No power Low Battery / No Battery Replace the batteries
No power Battery replacement does not solve
the problem
Check the connection to the batteries
No buzzer sound No sound setting Adjust the buzzer volume
Power ON, but no measurements
show
Probe cord disconnected from the
main unit
Check the connection of Probe cord
and the main unit
Power ON, but not measured File holder disconnected from Probe
cord
Check the connection of file holder
and Probe cord
If any problems occur, refer to the table below. If there are any further problems or issues please contact your distributor
or SybronEndo.
9– PRODUCT SPECIFICATIONS
10 – GUIDANCE AND MANUFACTURER’S DECLARATION
Guidance and manufacturer’s declaration – electromagnetic emissions
The Apex ID is intended for use in the electromagnetic environment specified below. The customer or the user of the
Apex ID should assure that it is used in such an environment.
Emissions test Compliance Electromagnetic environment - guidance
RF emissions CISPR 11 Group 1 The Apex ID uses RF energy only for its internal functions.Therefore, its
RF emissions are very low and are not likely to cause any interference in
nearby electronic equipment.
RF emissions CISPR 11 Class A The Apex ID is suitable for use in all establishments including domestic and
those directly connected to the public low-voltage power supply network
that supplies buildings used for domestic purposes.
077-0167_RevE_Apex_ID_IFU.indb 9-10 10/7/15 12:12 PM

10
9
7– MAINTENANCE AND STORAGE
7.1 – Sterilization
The ‘Lip Hook’ and ‘File holder A’ should be sterilized at
121°C for 30 minutes with high-pressure steam.
The ‘File holder B’ should be sterilized at a temperature
of 121°C for 30 minutes with high-pressure steam in a
sterilization pouch, then dried at least 10 minutes after
sterilization.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
CAUTION Parts used in direct intraoral
contact are to be steam sterilized.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
NOTICE It is highly recommended to place
File holder B in a sterilization pouch for autoclaving.
• The metal of the File holder B may be corroded
when it is in direct contact with steam.
• Temperature should not exceed 135°C during
sterilization as the product may be damaged.
7.2 – Recommended sterilizer type
• Sterilizer: Vacuum type (B)
• Sterilization temperature: 121°C,
• Sterilization time: 30min
7.3 – Method used to validate recommended
sterilization method:
Sterility Assurance Level (SAL): 10-6
1) Sterilization validation samples are wrapped with BIs.
2) 3 times of sterilization cycles as a half cycle are carried
out at 121°C for 15 minutes.
3) 1 time of sterilization cycle as a full cycle is carried out
at 121°C for 30 minutes.
4) Incubate BIs at 55~60°C for 7days.
7.4 – Sterilizer used for validation
• Manufacturer: DAIHAN LABTECH CO., LTD
• Model name: LAC-5105SP
• Serial No. : 20101202138
• Control No. : TE-10-23
• Valuable room: 100 liter
• Power supply: AC 220V, 50/60Hz
• Pressure: 2.6kgf/cm2
• Range of sterilization temperature: 105°C~135°C
7.5 – Cleaning
Clean the Apex ID or probe cord with dry gauze and a
small amount of ethanol. Any ethanol left on the product
after cleaning should be completely wiped off with a dry
cloth.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
CAUTION Use protective sleeves on the cords
and Apex ID during operation, followed by removal
of the sleeve and wiping with alcohol after operation.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
CAUTION Do not use the Apex ID when wet
with ethanol. There is a possibility of electric shock
or product damage.
7.6 – Operating, Storage,Transport
The Apex ID should be operated in temperatures ranging
from 10~40°C, atmospheric pressure 70~106 Kpa
and relative humidity 30~75%. The Apex ID should be
stored and transported in temperatures ranging from
-20~50°C, atmospheric pressure 70~106 Kpa and relative
humidity5~90%.
7.7 – Disposal
Dispose of the product in accordance with your local
waste disposal regulations and/or laws
6– GUIDE FOR ACCURATE MEASUREMENT
Turn on the Apex ID prior to use.
Plug the Checker [Fig 1-9] (provided in the original packaging)
into the probe cord jack [Fig 2-5] and confirm the value on
the LCD screen is 0.5.
It is recommended to insert the file into the canal first and
then connect the file to the file holder.
If the signals do not change as the file approaches the
APEX, it is possible the root canal is too dry; therefore it
should be filled with an irrigant.
Necrotic tissue or other matter in the root canal may affect
accuracy. It is advisable to take several measurements
during enlargement of the canal.
Start with a larger file at first. If the APEX indication (graph
and numeric signal on the screen) does not reach the
APEX, gradually try a smaller file to measure the working
length of the root canal.
To minimize error, it is recommended the working length
be measured more than twice.
If root canals within a tooth are connected, as in the case
of multiple root canals with anastomoses or cracks, miss-
measurement is possible. It is recommended to verify the
tooth’s anatomy radiographically.
Contact with metal restorations by the file during
measurements may result in errors.
Remove blood or exudate from the canal before
measurement.
In cases where the foramen is not completely formed or
the foramen has been overly expanded, the measurement
value of the working length may be shorter than the actual
measurement value.
• Rated voltage: DC4.5V (1.5V Alkaline Battery AAA x 3EA)
• Input current: less than DC 60mA
• Power consumption: less than 0.27VA
• Patient auxiliary current: less than AC 10µA
• Oscillation frequency: 500Hz ±0.2Hz, 5kHz ±0.002kHz
• Size: W70mm ±1mm x D25mm ±1mm x H100mm
±1mm
• Weight: 390g ±15g (including stand, except battery)
• Protection type and level against electric shock:Type B
applied part
• Internally powered equipment, Ordinary equipment
(IPX0)
• Continuous operation time: 62hours (at 1250mAh
Battery x 3EA)
8–TROUBLE SHOOTING
Problem Possible Causes Solutions
No power Low Battery / No Battery Replace the batteries
No power Battery replacement does not solve
the problem
Check the connection to the batteries
No buzzer sound No sound setting Adjust the buzzer volume
Power ON, but no measurements
show
Probe cord disconnected from the
main unit
Check the connection of Probe cord
and the main unit
Power ON, but not measured File holder disconnected from Probe
cord
Check the connection of file holder
and Probe cord
If any problems occur, refer to the table below. If there are any further problems or issues please contact your distributor
or SybronEndo.
9– PRODUCT SPECIFICATIONS
10 – GUIDANCE AND MANUFACTURER’S DECLARATION
Guidance and manufacturer’s declaration – electromagnetic emissions
The Apex ID is intended for use in the electromagnetic environment specified below. The customer or the user of the
Apex ID should assure that it is used in such an environment.
Emissions test Compliance Electromagnetic environment - guidance
RF emissions CISPR 11 Group 1 The Apex ID uses RF energy only for its internal functions.Therefore, its
RF emissions are very low and are not likely to cause any interference in
nearby electronic equipment.
RF emissions CISPR 11 Class A The Apex ID is suitable for use in all establishments including domestic and
those directly connected to the public low-voltage power supply network
that supplies buildings used for domestic purposes.
077-0167_RevE_Apex_ID_IFU.indb 9-10 10/7/15 12:12 PM

12
11
Guidance and manufacturer’s declaration – electromagnetic immunity
The Apex ID is intended for use in the electromagnetic environment specified below. The customer or the user of the
Apex ID should assure that it is used in such an environment.
Immunity test IEC 60601test level Compliance level Electromagnetic environment – guidance
Electrostatic
discharge (ESD)
IEC61000-4-2
±6kV contact
±8kV air
±6kV contact
±8kV air
Floors should be wood, concrete or ceramic tile.
If floors are covered with synthetic material, the
relative humidity should be at least 30%.
Electrical fast
transient/burst
IEC61000-4-4
±2kV for power
supply lines
±1kV for input/
output lines
±2kV for power
supply lines
Main power quality should be that of a typical
commercial or hospital environment.
Surge IEC 61000-4-5 ±1kV differential
mode
±2kV common
mode
±1kV differential
mode
±2kV common
mode
Main power quality should be that of a typical
commercial or hospital environment.
Voltage dips, short
interruption, and
voltage variations on
power supply input
lines IEC 60601-4-11
<5% UT (>95% dip
in UT) for 0.5 cycle
40% UT (60% dip in
UT) for 5 cycles
70% UT (30% dip
in UT)
< 5% UT (>95% dip
in UT) for 5s
<5% UT (>95% dip
in UT) for 0.5 cycle
40% UT (60% dip
in UT) for 5 cycles
70% UT (30% dip
in UT) < 5% UT
(>95% dip in UT)
for 5s
Main power quality should be that of a typical
commercial or hospital environment. If the user
of the Apex ID requires continued operation
during power main interruptions, it is
recommended that the model Apex ID be
powered from an uninterruptible power supply
or battery.
Power
frequency(50/60 Hz)
IEC 61000-4-8
3 A/m 3 A/m Power frequency magnetic fields should be at
levels characteristic of a typical location in a
typical commercial or hospital environment.
Conducted RF
IEC61000-4-6
Radiated RF
IEC 61000-4-3
3 V/m
150 kHz to 80MHz
3V/m
80 MHz to 2.5GHz
3 V/ms
150 kHz to 80MHz
3V/m
80 MHz to 2.5GHz
Portable and mobile RF communications
equipment should be used no closer to any part
of the Apex ID, including cables, than the
recommended separation distance calculated
from the equation applicable to the frequency of
the transmitter.
Recommended separation distance
d=[3.5/V1]√P
d=[3.5/E1]√P 80MHz to 800MHz
d=[7/E1]√P 800MHz to 2.5GHz
Where P is the maximum output power rating of
the transmitter in watts (W) according to
the transmitter manufacturer and d is the
recommended separation distance in meters (m).
Field strengths from fixed RF transmitters, as
determined by an electromagnetic site survey, a
should be less than the compliance level in each
frequency range.b
Interference may occur in the vicinity of
equipment marked with the following
symbol:
Note: UT is the A.C. mains voltage prior to application of the test level.
Note: At 80MHz and 800MHz, the higher frequency range applies.
Note: These guidelines may not apply in all situations. Electromagnetic
propagation is affected by absorption and reflection from structures,
objects and people.
Field strengths from fixed transmitters, such as base stations for radio
(cellular/cordless) telephones and land mobile radios, amateur radio,
AM and FM radio broadcast and TV broadcast cannot be predicted
theoretically with accuracy.To assess the electromagnetic environment
due to fixed RF transmitters, an electromagnetic site survey should be
considered. If the measured field strength in the location in which the
Apex ID is used exceeds the applicable RF compliance level above, the
Apex ID should be observed to verify normal operation. If abnormal
performance is observed, additional measures may be necessary, such
as re-orienting or relocating the Apex ID.
bOver the frequency range 150kHz to 80MHz, field strengths should be
less than [V1] V/m.
11 – QUALITY GUARANTEE AND RESPONSIBILITY
Quality Certificate
Product Name: Electronic Apex Locator Model: Apex ID
Consumer Date of Purchase: Guarantee period: Device -3 years / Accessory -6 Months
Manufactured for: SybronEndo Contact: 714.516.7979
Address: 1332 S Lone Hill Ave., Glendora, CA 91740-5339
SN
REF
EC REP
If a problem has occurred during the guarantee period due to manufacturing or natural failures please contact SybronEndo.
Warranty service shall be provided without charge during the guarantee period.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
NOTICE
WARRANTY AND EXCLUSIONS
Warranty
SybronEndo warrants the Apex ID electronic apex locator to be free from defects in materials and workmanship for a
period of 3 years from the original date of purchase, and consumables (excluding batteries) for 6 months from date of
purchase in accordance with SybronEndo’s warranty regulations. If the Apex ID shows any defect within the specified
warranty period that are not excluded from this warranty, SybronEndo shall, at its discretion, either replace or repair
Apex ID using suitable new or reconditioned parts. In the case other parts are used which constitute an improvement,
SybronEndo may, at its discretion, charge the customer for the additional cost of these parts. If the warranty claim
provides to be justified, the product will be returned to the user freight prepaid.
Warranty claims other than those indicated herein, are expressly excluded.
Exclusions
Damages and defects caused by the following conditions are not covered by the warranty:
• Improper handling/disassembly/modifying, neglect or failure to operate the unit in compliance with the instructions
given in the Instruction for Use/User Manual.
• Force majeure or any other condition that is beyond the control of SybronEndo.
• This device is manufactured for the uses specified in this Instruction for Use. SybronEndo shall not be responsible
for any damages caused by customer misuse or uses other than those specified.
Responsibility
SybronEndo shall not be responsible for damages or injuries caused by any of the following:
• Use by unauthorized personnel.
• Changes to or modifications of the device.
• Use of other manufacturer’s devices or parts with the Apex ID.
• Use of unapproved parts or repair of the device by unauthorized parties.
• Disregard of the care or cautions listed in the instruction manual.
• Use of the device for any applications not included in the instruction manual.
• Use of a power supply other than that specified in the instruction manual.
• Fire, flood, lightning or from natural disasters.
• Customer carelessness or intentional misuse.
077-0167_RevE_Apex_ID_IFU.indb 11-12 10/7/15 12:12 PM

12
11
Guidance and manufacturer’s declaration – electromagnetic immunity
The Apex ID is intended for use in the electromagnetic environment specified below. The customer or the user of the
Apex ID should assure that it is used in such an environment.
Immunity test IEC 60601test level Compliance level Electromagnetic environment – guidance
Electrostatic
discharge (ESD)
IEC61000-4-2
±6kV contact
±8kV air
±6kV contact
±8kV air
Floors should be wood, concrete or ceramic tile.
If floors are covered with synthetic material, the
relative humidity should be at least 30%.
Electrical fast
transient/burst
IEC61000-4-4
±2kV for power
supply lines
±1kV for input/
output lines
±2kV for power
supply lines
Main power quality should be that of a typical
commercial or hospital environment.
Surge IEC 61000-4-5 ±1kV differential
mode
±2kV common
mode
±1kV differential
mode
±2kV common
mode
Main power quality should be that of a typical
commercial or hospital environment.
Voltage dips, short
interruption, and
voltage variations on
power supply input
lines IEC 60601-4-11
<5% UT (>95% dip
in UT) for 0.5 cycle
40% UT (60% dip in
UT) for 5 cycles
70% UT (30% dip
in UT)
< 5% UT (>95% dip
in UT) for 5s
<5% UT (>95% dip
in UT) for 0.5 cycle
40% UT (60% dip
in UT) for 5 cycles
70% UT (30% dip
in UT) < 5% UT
(>95% dip in UT)
for 5s
Main power quality should be that of a typical
commercial or hospital environment. If the user
of the Apex ID requires continued operation
during power main interruptions, it is
recommended that the model Apex ID be
powered from an uninterruptible power supply
or battery.
Power
frequency(50/60 Hz)
IEC 61000-4-8
3 A/m 3 A/m Power frequency magnetic fields should be at
levels characteristic of a typical location in a
typical commercial or hospital environment.
Conducted RF
IEC61000-4-6
Radiated RF
IEC 61000-4-3
3 V/m
150 kHz to 80MHz
3V/m
80 MHz to 2.5GHz
3 V/ms
150 kHz to 80MHz
3V/m
80 MHz to 2.5GHz
Portable and mobile RF communications
equipment should be used no closer to any part
of the Apex ID, including cables, than the
recommended separation distance calculated
from the equation applicable to the frequency of
the transmitter.
Recommended separation distance
d=[3.5/V1]√P
d=[3.5/E1]√P 80MHz to 800MHz
d=[7/E1]√P 800MHz to 2.5GHz
Where P is the maximum output power rating of
the transmitter in watts (W) according to
the transmitter manufacturer and d is the
recommended separation distance in meters (m).
Field strengths from fixed RF transmitters, as
determined by an electromagnetic site survey, a
should be less than the compliance level in each
frequency range.b
Interference may occur in the vicinity of
equipment marked with the following
symbol:
Note: UT is the A.C. mains voltage prior to application of the test level.
Note: At 80MHz and 800MHz, the higher frequency range applies.
Note: These guidelines may not apply in all situations. Electromagnetic
propagation is affected by absorption and reflection from structures,
objects and people.
Field strengths from fixed transmitters, such as base stations for radio
(cellular/cordless) telephones and land mobile radios, amateur radio,
AM and FM radio broadcast and TV broadcast cannot be predicted
theoretically with accuracy.To assess the electromagnetic environment
due to fixed RF transmitters, an electromagnetic site survey should be
considered. If the measured field strength in the location in which the
Apex ID is used exceeds the applicable RF compliance level above, the
Apex ID should be observed to verify normal operation. If abnormal
performance is observed, additional measures may be necessary, such
as re-orienting or relocating the Apex ID.
bOver the frequency range 150kHz to 80MHz, field strengths should be
less than [V1] V/m.
11 – QUALITY GUARANTEE AND RESPONSIBILITY
Quality Certificate
Product Name: Electronic Apex Locator Model: Apex ID
Consumer Date of Purchase: Guarantee period: Device -3 years / Accessory -6 Months
Manufactured for: SybronEndo Contact: 714.516.7979
Address: 1332 S Lone Hill Ave., Glendora, CA 91740-5339
SN
REF
EC REP
If a problem has occurred during the guarantee period due to manufacturing or natural failures please contact SybronEndo.
Warranty service shall be provided without charge during the guarantee period.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
NOTICE
WARRANTY AND EXCLUSIONS
Warranty
SybronEndo warrants the Apex ID electronic apex locator to be free from defects in materials and workmanship for a
period of 3 years from the original date of purchase, and consumables (excluding batteries) for 6 months from date of
purchase in accordance with SybronEndo’s warranty regulations. If the Apex ID shows any defect within the specified
warranty period that are not excluded from this warranty, SybronEndo shall, at its discretion, either replace or repair
Apex ID using suitable new or reconditioned parts. In the case other parts are used which constitute an improvement,
SybronEndo may, at its discretion, charge the customer for the additional cost of these parts. If the warranty claim
provides to be justified, the product will be returned to the user freight prepaid.
Warranty claims other than those indicated herein, are expressly excluded.
Exclusions
Damages and defects caused by the following conditions are not covered by the warranty:
• Improper handling/disassembly/modifying, neglect or failure to operate the unit in compliance with the instructions
given in the Instruction for Use/User Manual.
• Force majeure or any other condition that is beyond the control of SybronEndo.
• This device is manufactured for the uses specified in this Instruction for Use. SybronEndo shall not be responsible
for any damages caused by customer misuse or uses other than those specified.
Responsibility
SybronEndo shall not be responsible for damages or injuries caused by any of the following:
• Use by unauthorized personnel.
• Changes to or modifications of the device.
• Use of other manufacturer’s devices or parts with the Apex ID.
• Use of unapproved parts or repair of the device by unauthorized parties.
• Disregard of the care or cautions listed in the instruction manual.
• Use of the device for any applications not included in the instruction manual.
• Use of a power supply other than that specified in the instruction manual.
• Fire, flood, lightning or from natural disasters.
• Customer carelessness or intentional misuse.
077-0167_RevE_Apex_ID_IFU.indb 11-12 10/7/15 12:12 PM

26
ABBILDUNGEN
Abb. 1.1 Abb. 1.6
Abb. 1.2
Abb. 1.7
Abb. 1.3 Abb. 1.8
Abb. 1.4 Abb. 1.9
Abb. 1.5
Abb. 2.1
Abb. 2.2
Abb. 2.4
Abb. 2.5
Abb. 2.3
Abb. 2.6
Abb. 2.7 Abb. 2.8
Abb. 3.3
Abb. 2.10
Abb. 2.12
Abb. 2.13
Abb. 2.11
Abb. 3.4
Abb. 3.1
Abb. 3.2 Abb. 3.6
Abb. 3.5
ABBILDUNGEN
Abb. 2.14
Abb. 2.9
Deutsch
077-0167_RevE_Apex_ID_IFU.indb 25-26 10/7/15 12:12 PM

26
ABBILDUNGEN
Abb. 1.1 Abb. 1.6
Abb. 1.2
Abb. 1.7
Abb. 1.3 Abb. 1.8
Abb. 1.4 Abb. 1.9
Abb. 1.5
Abb. 2.1
Abb. 2.2
Abb. 2.4
Abb. 2.5
Abb. 2.3
Abb. 2.6
Abb. 2.7 Abb. 2.8
Abb. 3.3
Abb. 2.10
Abb. 2.12
Abb. 2.13
Abb. 2.11
Abb. 3.4
Abb. 3.1
Abb. 3.2 Abb. 3.6
Abb. 3.5
ABBILDUNGEN
Abb. 2.14
Abb. 2.9
Deutsch
077-0167_RevE_Apex_ID_IFU.indb 25-26 10/7/15 12:12 PM

28
27
ABBILDUNGEN
Abb. 4.1
Abb. 4.5 Abb. 4.8
Abb. 4.9
Abb. 4.10
Abb. 5.1
Abb. 4.6
Abb. 4.7
Abb. 4.2
Abb. 4.3
Abb. 4.4
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
GEFAHR
• Nicht bei Patienten mit Herzschrittmachern verwenden.
• Nicht zusammen mit elektrochirurgischen Geräten verwenden.
• Produkte oderTeile ohne Zulassung durch SybronEndo dürfen nicht an dieses Produkt angeschlossen oder daran
befestigt werden. Die Verwendung nicht zugelassener Produkte oder Teile kann zu Funktionsstörungen des Geräts
und Verletzungen des Patienten führen.
• Verwenden Sie dieses Gerät nicht in Gegenwart von unter Sauerstoff oxidierenden Stoffen, unter Stickstoff
oxidierenden Stoffen oder entzündlichen Mischungen von Anästhesiegasen.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
VORSICHT
„Achtung: Bundesgesetze (USA) beschränken dieses Gerät auf Kauf durch einen oder im Auftrag eines Zahnarzts.“
• Das Gerät ist nicht wasserdicht. Die Einwirkung von Feuchtigkeit kann zu Stromschlag oder Schäden am Gerät führen.
• Das Gerät darf nicht demontiert werden. Demontage und Berührung vonTeilen im Inneren des Geräts können zu
Stromschlag oder Verbrennungen führen. (Falls Sie das Gerät absichtlich demontieren, erlischt unabhängig von der
verbleibenden Garantiezeit die Garantie.)
• Demontage oder Reparatur sind ausschließlich durch von SybronEndo autorisierte Fachleute durchzuführen.
• Das Produkt ist nur zur dentaloperativen Verwendung vorgesehen.
• Überzeugen Sie sich vor der Benutzung des Geräts von dessen Funktionsfähigkeit.
• Sollte die Batterieladung schwach werden, ist die Verwendung zu unterbrechen und ein Austausch der Batterien
vorzunehmen.
• Versuchen Sie nicht, das Gerät bei hoher Luftfeuchtigkeit zu verwenden.
• Das Gerät ist vor den Auswirkungen von Luftdruck, Wind, Sonne und Salz zu schützen.
• Das Gerät nicht in Bereichen verwenden, in denen explosive Produkte oder Gase gelagert werden.
• Die Verwendung ist sofort einzustellen, wenn das Gerät nicht ordnungsgemäß funktioniert.
• Das Gerät ist für keine andere Anwendung als zur Messung der Arbeitslänge von Wurzelkanälen geeignet.
Dieses Handbuch enthält die Gebrauchsanweisung zur Messung der Arbeitslänge von Wurzelkanälen mithilfe
des elektronischen Apex-Locators Apex ID.
• Dieses Anweisungshandbuch wurde ausschließlich für die Verwendung durch Zahnmediziner erstellt.
• Das Handbuch und das Produkt unterliegen notwendigen Änderungen ohne vorherige Ankündigung.
• Das Produkt wurde auf elektromagnetische Anwendungsverträglichkeit gemäß EN60601-1-2 geprüft und schützt
konstruktionsbedingt vor schädlichen Störungen, sofern es entsprechend der Gebrauchsanweisung eingesetzt und
bedient wird. Das Produkt kann unter Umständen Funkenergie erzeugen, verwenden und freisetzen; diese könnte
schädliche Störungen bei anderen in der Nähe befindlichen Geräten verursachen. Falls eine solche Situation eintritt,
sollte der Benutzer die Störung anhand einer oder mehrerer der im Folgenden empfohlenen Maßnahmen beheben:
o Erhöhen Sie den Abstand zwischen dem Apex ID und dem Gerät, bei dem die Störung auftritt.
o Setzen Sie das Apex ID erneut ein und starten Sie es noch einmal.
o Wenden Sie sich an Ihren Händler oder an SybronEndo.
SICHERHEITSMASSNAHMEN
Lesen Sie sich dieses Handbuch gründlich durch. Zweck dieser Gebrauchsanweisung ist es, den effektiven
und sicheren Betrieb des Apex ID für Benutzer und Patienten sicherzustellen.
SICHERER BETRIEB
SYMBOLE: In dieser Gebrauchsanweisung werden verschiedene Symbole verwendet, die den Anwender
beim richtigen und sicheren Einsatz des Geräts unterstützen und vor Verletzungen, Schäden oderVerlust von
Eigentum schützen sollen. Dabei handelt es sich um folgende Symbole:
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
VORSICHT
Könnte zu Verletzungen oder
zum Tod führen.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
HINWEIS
Kann eventuell zu Verletzungen oder zumTod führen.
Kann eventuell zu fehlerhaften Daten führen.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
GEFAHR
Könnte zu Verletzungen oder
zum Tod führen.
C
AB
C
AB
Wurzelspitze
auf der Rönt-
genaufnahme
Physiologische
Wurzelspitze bzw.
apikale Konstriktion
Abb. 5.2
A = Abstand zwischen der Wurzelspitze
auf der Röntgenaufnahme und der
anatomischen Wurzelspitze.
B = Abstand zwischen der
physiologischen Wurzelspitze und
der anatomischen Wurzelspitze.
C = Abstand zwischen der Wurzelspitze
auf der Röntgenaufnahme und der
physiologischen Wurzelspitze
Anatomische
Wurzelspitze
bzw. Wurzel-
spitzenöffnung
077-0167_RevE_Apex_ID_IFU.indb 27-28 10/7/15 12:12 PM

28
27
ABBILDUNGEN
Abb. 4.1
Abb. 4.5 Abb. 4.8
Abb. 4.9
Abb. 4.10
Abb. 5.1
Abb. 4.6
Abb. 4.7
Abb. 4.2
Abb. 4.3
Abb. 4.4
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
GEFAHR
• Nicht bei Patienten mit Herzschrittmachern verwenden.
• Nicht zusammen mit elektrochirurgischen Geräten verwenden.
• Produkte oderTeile ohne Zulassung durch SybronEndo dürfen nicht an dieses Produkt angeschlossen oder daran
befestigt werden. Die Verwendung nicht zugelassener Produkte oder Teile kann zu Funktionsstörungen des Geräts
und Verletzungen des Patienten führen.
• Verwenden Sie dieses Gerät nicht in Gegenwart von unter Sauerstoff oxidierenden Stoffen, unter Stickstoff
oxidierenden Stoffen oder entzündlichen Mischungen von Anästhesiegasen.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
VORSICHT
„Achtung: Bundesgesetze (USA) beschränken dieses Gerät auf Kauf durch einen oder im Auftrag eines Zahnarzts.“
• Das Gerät ist nicht wasserdicht. Die Einwirkung von Feuchtigkeit kann zu Stromschlag oder Schäden am Gerät führen.
• Das Gerät darf nicht demontiert werden. Demontage und Berührung vonTeilen im Inneren des Geräts können zu
Stromschlag oder Verbrennungen führen. (Falls Sie das Gerät absichtlich demontieren, erlischt unabhängig von der
verbleibenden Garantiezeit die Garantie.)
• Demontage oder Reparatur sind ausschließlich durch von SybronEndo autorisierte Fachleute durchzuführen.
• Das Produkt ist nur zur dentaloperativen Verwendung vorgesehen.
• Überzeugen Sie sich vor der Benutzung des Geräts von dessen Funktionsfähigkeit.
• Sollte die Batterieladung schwach werden, ist die Verwendung zu unterbrechen und ein Austausch der Batterien
vorzunehmen.
• Versuchen Sie nicht, das Gerät bei hoher Luftfeuchtigkeit zu verwenden.
• Das Gerät ist vor den Auswirkungen von Luftdruck, Wind, Sonne und Salz zu schützen.
• Das Gerät nicht in Bereichen verwenden, in denen explosive Produkte oder Gase gelagert werden.
• Die Verwendung ist sofort einzustellen, wenn das Gerät nicht ordnungsgemäß funktioniert.
• Das Gerät ist für keine andere Anwendung als zur Messung der Arbeitslänge von Wurzelkanälen geeignet.
Dieses Handbuch enthält die Gebrauchsanweisung zur Messung der Arbeitslänge von Wurzelkanälen mithilfe
des elektronischen Apex-Locators Apex ID.
• Dieses Anweisungshandbuch wurde ausschließlich für die Verwendung durch Zahnmediziner erstellt.
• Das Handbuch und das Produkt unterliegen notwendigen Änderungen ohne vorherige Ankündigung.
• Das Produkt wurde auf elektromagnetische Anwendungsverträglichkeit gemäß EN60601-1-2 geprüft und schützt
konstruktionsbedingt vor schädlichen Störungen, sofern es entsprechend der Gebrauchsanweisung eingesetzt und
bedient wird. Das Produkt kann unter Umständen Funkenergie erzeugen, verwenden und freisetzen; diese könnte
schädliche Störungen bei anderen in der Nähe befindlichen Geräten verursachen. Falls eine solche Situation eintritt,
sollte der Benutzer die Störung anhand einer oder mehrerer der im Folgenden empfohlenen Maßnahmen beheben:
o Erhöhen Sie den Abstand zwischen dem Apex ID und dem Gerät, bei dem die Störung auftritt.
o Setzen Sie das Apex ID erneut ein und starten Sie es noch einmal.
o Wenden Sie sich an Ihren Händler oder an SybronEndo.
SICHERHEITSMASSNAHMEN
Lesen Sie sich dieses Handbuch gründlich durch. Zweck dieser Gebrauchsanweisung ist es, den effektiven
und sicheren Betrieb des Apex ID für Benutzer und Patienten sicherzustellen.
SICHERER BETRIEB
SYMBOLE: In dieser Gebrauchsanweisung werden verschiedene Symbole verwendet, die den Anwender
beim richtigen und sicheren Einsatz des Geräts unterstützen und vor Verletzungen, Schäden oderVerlust von
Eigentum schützen sollen. Dabei handelt es sich um folgende Symbole:
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
VORSICHT
Könnte zu Verletzungen oder
zum Tod führen.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
HINWEIS
Kann eventuell zu Verletzungen oder zumTod führen.
Kann eventuell zu fehlerhaften Daten führen.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
GEFAHR
Könnte zu Verletzungen oder
zum Tod führen.
C
AB
C
AB
Wurzelspitze
auf der Rönt-
genaufnahme
Physiologische
Wurzelspitze bzw.
apikale Konstriktion
Abb. 5.2
A = Abstand zwischen der Wurzelspitze
auf der Röntgenaufnahme und der
anatomischen Wurzelspitze.
B = Abstand zwischen der
physiologischen Wurzelspitze und
der anatomischen Wurzelspitze.
C = Abstand zwischen der Wurzelspitze
auf der Röntgenaufnahme und der
physiologischen Wurzelspitze
Anatomische
Wurzelspitze
bzw. Wurzel-
spitzenöffnung
077-0167_RevE_Apex_ID_IFU.indb 27-28 10/7/15 12:12 PM

30
29
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
HINWEIS
• Das Produkt ist nur zur Verwendung durch Zahnmediziner vorgesehen.
• Zur Vermeidung von Stromschlägen oder Explosionen ist das Gerät von hohenTemperaturen und Luftfeuchtigkeiten
fernzuhalten. Die Metallteile des Produkts sind von elektrisch leitenden Materialien fernzuhalten. Es besteht die
Gefahr von Brand, Stromschlag oder Beschädigung.
• Legen Sie keine schweren Gegenstände auf das Gerät. Es besteht die Gefahr von Brand oder Stromschlag.
• Lassen Sie alle Messungen der Kanallänge durch Röntgenaufnahmen bestätigen.
• Blockierte Wurzelkanäle können nicht ordnungsgemäß gemessen werden.
• Bei Weitergabe dieses Geräts ist auch diese Gebrauchsanweisung zu übergeben.
• Entfernen Sie die Akkus aus dem Apex ID-Gerät, wenn dieses wahrscheinlich länger nicht benutzt werden wird.
Wartung und Reparatur des Sicherheitsetiketts:
• Das Etikett für Sicherheitshinweise und Warnungen muss in ordnungsgemäßem Zustand gehalten werden,
wasdurch regelmäßige Kontrolle sicherzustellen ist.
• Ersatz: Sollte das Etikett für Sicherheitshinweise und Warnungen verloren gegangen oder beschädigt sein,
mussbei SybronEndo ein Ersatzetikett angefordert werden.
2.1 –Teile des Lieferumfangs und ihre Funktionen
Lieferumfang:
Apex ID-Gerät (1) – Abb. 1.1
AAA-Alkali-Batterien (3) – Abb. 1.2
Halterung (1) – Abb. 1.3
Lippenhaken (5) – Abb. 1.4
Instrumentenhalter A (1) – Abb. 1.5
Instrumentenhalter B (2) – Abb. 1.6
Gebrauchsanweisung (1) – Abb. 1.7
Sondenkabel (1) – Abb. 1.8
Prüfmodul (1) – Abb. 1.9
1– INDIKATIONEN UND FUNKTIONSPRINZIP
1.1 – Indikationen
Apex ID ist ein elektronischer Apex-Locator, der für
die Messung der Arbeitslänge von Wurzelkanälen
vorgesehenist.
Rx ONLY
Temperature
-20C to 50C
Humidity
5% to 90%
Consult
Instructions
For Use
Dispose
Of
Properly
Handle
With
Care
Keep
Dry
Type B
Applied
Part
Caution
For Dental
Use Only
This
Side Up
Stack 12
Maximum
12
0120
HINWEIS Das Gerät darf ausschließlich zur
Messung der Arbeitslänge von Wurzelkanälen
verwendet werden.
1.2 – Funktionsprinzip
Aus zwei Frequenzen bestehende Mikrosignale, die
vom Gerät ausgesendet werden, kehren zum Gerät
zurück, nachdem sie den elektrischen Stromkreis
durchwandert haben, der folgende Stationen umfasst:
Gerät – Sondenkabel – Instrumentenhalter – Instrument –
Patient – Lippenhaken – Sondenkabel. Die Impedanz des
elektrischen Stromkreises kann sich in Abhängigkeit von
der Entfernung zwischen dem Ende eines Instruments
und dem Apex des Wurzelkanals ändern, was eine
Änderung der Mikrosignale bewirkt, die wieder in das
Gerät eingespeist werden. Der Mikroprozessor des
Geräts misst die Änderungen an den Mikrosignalen und
rechnet die Differenz in einen Entfernungswert um, der
dann auf der LCD-Anzeige des Apex ID erscheint.
2.2 – Zubehörteile und ihre Funktionen
Name Funktionen
Sondenkabel – Abb. 1.8 Stellt die Verbindung zwischen dem Apex ID und dem
Instrumentenhalter und dem Lippenhaken her
Lippenhaken – Abb. 1.4 Stellt den Kontakt mit der Lippe des Patienten her
Instrumentenhalter A – Abb. 1.5 Berührt das Instrument (für Molare vorgesehen)
Instrumentenhalter B – Abb. 1.6 Hält das Instrument
Prüfmodul – Abb. 1.9 Bestätigt die ordnungsgemäße Funktionsweise des
ApexID
2–TEILE DES LIEFERUMFANGS UND IHRE FUNKTIONEN
2.3 – Ausstattungsmerkmale des Apex ID und ihre Funktionen
Ausstattungsmerkmal Funktionen
LCD-Anzeige – Abb. 2.1 Zeigt die aktuellen Einstellungen sowie den Abstand
zwischen dem in den Wurzelkanal eingeführten
Instrument und dem Wurzel-Apex an
Bedienfeld – Abb. 2.2 Ermöglicht EIN/AUS-Schalten und die Steuerung des
Geräts
Halterung – Abb. 2.3 Dient der Aufstellung des Apex ID
Batteriefach – Abb. 2.4 Enthält die Batterien 3 x 1,5 V (DC 4,5 V)
Buchse für Sondenkabel – Abb. 2.5 Dient dem Anschließen des Sondenkabels zur Messung
der Arbeitslänge des Wurzelkanals
Auf-Taste (
SET
) – Abb. 2.6 Durch Drücken derTaste erhöht sich der Standardwert
des Wurzel-Apex um 0,1 und die Summer-Lautstärke um
einen Schritt nach oben.
Ab-Taste (
SET
) – Abb. 2.7 Durch Drücken derTaste verringert sich der Standardwert
des Wurzel-Apex um 0,1 und die Summer-Lautstärke um
einen Schritt nach unten.
Einstelltaste ( SET ) – Abb. 2.8 Durch Drücken derTaste wird der Einstellungsmodus
übernommen.
EIN/AUS-Taste (
SET
) – Abb. 2.9 Dient dem Ein- und Ausschalten des Geräts
Summer-Lautstärke-Signal – Abb. 2.10 Zeigt die Lautstärke des Summers an
Grafisches Signal – Abb. 2.11 Die grafische Abbildung zeigt den Abstand zwischen
dem Ende des Instruments und dem Wurzel-Apex.
Batterie-Signal – Abb. 2.12 Zeigt die verbleibende Batterielebensdauer an
Wurzel-Apex-Signal – Abb. 2.13 Zeigt an, wenn das Instrument das apikale Foramen bzw.
den vom Anwender eingestellten Nullpunkt erreicht hat
Numerisches Signal – Abb. 2.14 Zeigt den Abstand zwischen dem Ende des Instruments
und dem Wurzel-Apex an
3– PRODUKTSYMBOLE
Seriennummer
Teilenummer
Herstellungsdatum
CE-Konformitätszeichen
Typ B Anwendungsteil
Vorsicht
Autorisierte EU-Vertretung
Gebrauchsanweisung
beachten
CSA-Konformitätszeichen
Fachgerecht entsorgen
Hersteller
SN
REF
EC REP
SN
REF
EC REP
077-0167_RevE_Apex_ID_IFU.indb 29-30 10/7/15 12:12 PM
