SPECIFICATION SHEET
Symbol LS4208
Increase performance with Motorola’s
next-generation scanner for customers
who value productivity
With the Symbol LS4208 handheld laser bar code
scanner, you’re able to effortlessly speed throughput,
even with bar codes in poor condition. Wherever
you need to quickly capture and process data —
such as at the retail checkout counter, in pharmacies
and hospitals, and in light warehouse environments
— this ergonomically designed scanner helps you
increase accuracy, improve productivity, cut maintenance
costs and reduce the risk of downtime.
Benefit from innovative features never before
delivered by a single scanner
The Symbol LS4208 delivers intuitive, productivity-
enhancing functionality that allows even your novice
users to quickly capture data. Its innovative multi-line
rastering scan pattern virtually eliminates the need
for end-user training, and lets you scan all types of
one-dimensional (1D) bar codes, including damaged
symbols or stacked reduced space symbology
(RSS) bar codes.The PDF configuration expands the
decoding capabilities to include PDF417, microPDF and
composite symbologies. In addition, the scanner’s
19-inch scanning range and superior motion
tolerance gives users greater flexibility to rapidly
and accurately capture data from a variety of items
without pausing between scans, while recently
added faster scanning and decoding capabilities
mean employees are able to process more items
more rapidly and spend less time keying in data.
Minimize your chances of downtime
Designed for constant, rigorous use in retail, office
and light industrial settings, the Symbol LS4208
provides you with reliability you’ll be able to depend
on. Along with a 6 ft. drop spec that allows the
scanner to keep on running even after dropped
repeatedly to concrete, the Symbol LS4208 also
offers single circuit-board construction. By eliminating
the failure points commonly found with interconnect
ribbon cables, this unique design feature helps to
lower your total cost of ownership.
Future-proof your investment
The Symbol LS4208 provides you with next-
generation technology today and the adaptability
to meet your needs in the future. The scanner’s
multi-interface and universal cables enable
connection to a variety of hosts, allowing you to
easily update your systems. In addition, since the
Symbol LS4208 is designed for the newest and
emerging 1D symbologies such as RSS bar codes,
as well as PDF and other variants (PR configuration),
you’ll be able to continue using the same device for
all your scanning requirements, even though your
requirements may change.
Protect your investment with comprehensive
services and support
Even the most durable scanners require a support
plan. That’s why Motorola’s Enterprise Mobility
Services cover every aspect of your Symbol LS4208 —
to ensure all of your support needs are met.
Handheld scanner
FEATURES
1D, PDF and composite
code scanning
Available in both 1D only
(SR) and PDF/Composite
(PR) configurations to
support a wide range of
productivity-enhancing
applications
Multi-line rastering
scan pattern
Improves productivity by
reducing the need to rescan
bar codes or key in data,
resulting in shorter lines at
the retail point of sale
Superior motion tolerance
Enables end users to quickly
move from one bar code to
the next without hesitation
Wide working range
Reads good quality as well
as poor quality codes at
similar ranges, reducing the
need for the user to move
the scanner back and forth

Motorola’s Service from the Start Advance Exchange
Support provides next-business-day delivery of
a replacement device for true service peace of
mind. This offer also includes Motorola’s unique
Comprehensive Coverage, which extends normal
wear and tear to cover accidental damage to exit
windows, scan elements and more at no extra
charge — virtually eliminating your unforeseen
repair expenses.
For more information about the Symbol LS4208,
please contact us at +1.800.722.6234 or
+1.631.738.2400 or visit us on the Web at:
www.symbol.com/ls4208.
SPECIFICATION SHEET
Symbol LS4208
motorola.com
Part number SS-LS4208. Printed in USA 08/07. MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. Symbol is a registered trademark of
Symbol Technologies, Inc. All other product or service names are the property of their respective owners. ©Motorola, Inc. 2007. All rights reserved. For system, product or services
availability and specific information within your country, please contact your local Motorola office or Business Partner. Specifications are subject to change without notice.
Checkpoint Electronic Article
Surveillance (EAS)
Offers dual functionality to
improve return on investment
and save critical counter space
Durable construction and
patented, single circuit-
board design able to
withstand multiple 6-ft
(1.8 m) drops to concrete
Lowers the total cost of
ownership by protecting
against downtime from
accidental drops
Plug-and-play setup,
intuitive scanning
Enables rapid deployment
and immediate use without
formal training, allowing new
and experienced employees
to immediately help improve
operational efficiency
Remote management-ready
Reduces total cost of
ownership by enabling
remote, network-based
device management
Optional hands-free
Intellistand
Enables presentation
scanning and automatic
switching between hands-
free and handheld modes
RSS bar code support
Supports the latest
symbologies to future-
proof your investment
Symbol LS4208 Specifications
Symbol LS4208 Specifications
Physical characteristics
Dimensions: 6.7 in. H x 3.7 in. L x 2.7 in. W
17 cm H x 9.3 cm L x 6.8 cm W
Weight: Approximately 6.4 oz. (181 g)
Voltage and current: 5 +/-10%VDC @ 140 mA (155 mA on
PR configuration)
Stand by: <35 mA (60mA on PR
configuration)
Color: Cash Register White or Twilight Black
Performance characteristics
Light source: 650 nm laser diode
Motor frequency: 50Hz
Decode rate: 200 decodes per second
Roll:1± 35°
Pitch:2± 60°
Yaw : 3± 60°
Print contrast: 25% minimum reflectance
Nominal working 5 mil (Code 39):
range: 1.5 to 5.5 in./ 3.81 to 13.97 cm
13 mil (100% UPC/EAN):
0 to 19 in./0 to 48.25 cm
10 mil (Code 39):
0 to 14 in./0 to 35.56 cm
20 mil (Code 39):
0 to 29 in./0 to 73.66 cm
Multi-line aiming At 5 in. distance: approx. 0.5 in. (1.3 cm)
coverage: At 10 in. distance: approx. 1 in. (2.5 cm)
Motion tolerances: Horizontal velocity: 200 in. (508 cm)/second
Vertical velocity: 200 in. (508 cm)/second
Angular velocity: 200 in. (508 cm)/second
Decode capability: UPC/EAN and with supplementals, Code
39, Code 39 Full ASCII, Tri-optic Code 39,
RSS Variants, UCC/EAN 128, Code 128,
Code 128 Full ASCII, Code 93, Codabar
(NW1), Interleaved 2 of 5, Discrete 2 of 5
MSI, Codell, IATA, Bookland EAN, Code 32
PR configuration adds decoding of PDF417,
microPDF and composite codes (CC-A,
CC-B and CC-C)
Interfaces supported: On-board multiple interface with: RS-232C
(Standard, Nixdorf, ICL, & Fujitsu);
IBM 468x/469x; Keyboard Wedge; USB
(Standard, IBM SurePOS, Macintosh);
Laser/Wand Emulation. In addition,
Synapse Adaptive Connectivity allows
for connectivity to all of the above plus
many non-standard interfaces
User environment
Operating temp.: 32° to 122° F (0° to 50° C)
Storage temp.: -40° to 158° F (-40° to 70° C)
Humidity: 5% to 95% (non-condensing)
Drop specs: Withstands repeated 6 ft. (1.8m) drops
to concrete
Ambient light Immune to normal artificial indoor and
immunity: natural outdoor (direct sunlight) lighting
conditions
EAS support: Optional Checkpoint EAS
Regulatory
Electrical safety: UL1950, CSA C22.2 No. 950, EN60950/
IEC950
Laser safety: CDRH Class II, IEC Class 2
EMI/RFI: FCC Part 15 Class B, ICES-003 Class B,
European Union EMC Directive,
Australian SMA
Accessories
Mounting options: Intellistand with adjustable height of
5 – 10 in. (12.7 – 25.4 cm) and adjustable
angle (0° – 90°); Desktop and wall-mount
holders also available
Power supplies: Power supplies available for applications
that don’t supply power over the host cable
Warranty
Subject to the terms of Motorola’s hardware warranty
statement, the Symbol LS408 handheld scanner products are
warranted against defects in workmanship and materials for
a period of five years from the date of shipment. The Liquid
Polymer Scan Element includes a limited lifetime warranty. For
the complete Motorola hardware product warranty statement,
go to symbol.com/warranty
Recommended Service
Service from the Start Advance Exchange Support
NOTICE: Repairs of this product may require the use of Motorola proprietary
parts (and/or Motorola proprietary information). Motorola will sell these parts (and
provide this proprietary information) only to end-user customers for self-service. It
is Motorola’s policy not to sell these parts to third-party service providers and not to
allow a third-party service provider to act as an ordering or receiving agent for the
parts necessary to repair this product. Applicable in the U.S. For all other countries,
please contact your Motorola account manager or the local Motorola Customer Service
representative in your area for further details.
1 - Roll (Tilt): Controlled by rotating the wrist clockwise or counterclockwise
2 - Pitch: Controleed by dropping or raising the wrist
3 - Skew (Yaw): Controlled by rotating the wrist from left to right or vice versa
