Quick Start Guide
ARC-PS™
(Adaptive Remote
Control - Power Supply)
To download the latest version of SymNet Designer, the Windows application that
controls all SymNet hardware, go to: www.symetrixaudio.com
SymNet
TM
Audio
Matrix
What Ships in the Box
R
An ARC-PS hardware device.
R
One PS-
5
switching power supply
which provides 15 volts DC @
1.33
amperes.
NOTE: The PS-5 will accept
a 100-240V AC input. A power cable
for domestic use is supplied for
the PS-5. Export customers should
supply the appropriate substitute
cable for their locale.
R
This Quick Start Guide.
R
An RJ-45 Incompatibility Warning sheet.
What You Need to Provide
R
A Windows PC with 300MHz or higher
Pentium and:
•
WIN 98SE, ME, 2000 or XP.
•
10-15 MB free storage space.
•
1024x768 graphics capability.
•
16-bit or higher colors.
•
CD-ROM drive or Internet connection.
•
64MB RAM (WIN 98SE/ME), 128MB
RAM (WIN 2000/XP).
R
One or more of the following connec-
tion materials:
•
Shielded twisted pair wire to connect
the ARC-PS RS-485 terminal block to
the RS-485 port of a master SymNet
DSP or CobraLink (Ring x, Address 1)
hardware device.
•
CAT-5 cables to connect any ARC(s) to
the ARC-PS.
Getting Help
SymNet Designer, the Windows applica-
tion that controls all SymNet hardware,
includes a help module which acts as a
complete user’s guide for both hardware
(including the ARC-PS) and software.
A printable copy is also available at
www.symetrixaudio.com.
If you have questions beyond the scope
of the help module, contact our Customer
Support Group in the following ways:
Tel
[phone]
8:00 am to 4:30 pm
Monday through Friday,
Pacific Time
Email
[e-mail]
Web
www.symetrixaudio.com
Important Safety
Instructions.
1.
Read these instructions.
2.
Keep these instructions.
3.
Heed all warnings.
4.
Follow all instructions.
5.
Do not use this apparatus near water.
6.
Clean only with dry cloth.
7.
Do not block any ventilation open-
ings. Install only in accordance with
the manufacturer’s instructions.
8.
Do not install near any heat sources
such as radiators, heat registers,
stoves, or other apparatus (including
amplifiers) that produce heat.
9.
Do not defeat the safety purpose of
the polarized or grounding-type plug.
A polarized plug has two blades with
one wider than the other. A grounding
type plug has two blades and a third
grounding prong. The wide blade or
the third prong are provided for your
safety. If the provided plug does not
fit into your outlet, consult an electri-
cian for replacement of the obsolete
outlet.
10.
Protect the power cord from being
walked on or pinched particularly at
plugs, convenience receptacles, and
the point where they exit from the
apparatus.
11.
Only use attachments/accessories
specified by the manufacturer.
12.
Use only with the cart,
stand, tripod, bracket,
or table specified by
the manufacturer, or
sold with the apparatus.
When a cart is used, use caution
when moving the cart/apparatus com-
bination to avoid injury from tip-over.
13.
Unplug this apparatus during light-
ning storms or when unused for long
periods of time.
14.
Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in
any way, such as power-supply cord
or plug cord is damaged, liquid has
been spilled or objects have fallen
into the apparatus, the apparatus has
been exposed to rain or moisture,
does not operate normally, or has
been dropped.
AVIS:
NE PAS OUVRIR
Il ne se trouve a l’interieur aucune piece pourvant entre reparée l’usager.
SEE OWNERS MANUAL. VOIR CAHIER D’INSTRUCTIONS.
S’adresser a un reparateur compétent.
RISQUE DE CHOC ELECTRIQUE
No user serviceable parts inside. Refer servicing to qualified service personnel.
CAUTION
WARNING:
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK DO NOT EXPOSE
THIS EQUIPMENT TO RAIN OR MOISTURE
DO NOT OPEN
RISK OF ELECTRIC SHOCK
The lightning flash with arrowhead
symbol within an equilateral triangle is
intended to alert the user of the pres-
ence of uninsulated “dangerous voltage”
within the product’s enclosure that may
be of sufficient magnitude to constitute
a risk of electric shock to persons. The
exclamation point within an equilateral
triangle is intended to alert the user of
the presence of important operating and
maintenance (servicing) instructions in
the literature accompanying the product
(i.e. this Quick Start Guide).
CAUTION
To prevent electric shock,
CAUTION To prevent electric shock, CAUTION
do not use the polarized plug supplied
with the unit with any extension cord,
receptacle, or other outlet unless the
prongs can be fully inserted.
Power Source.
The ARC-PS
hard-
ware uses a switching power supply that
automatically adjusts to the applied volt-
age. Ensure that your AC mains voltage
is somewhere between 100-240 VAC,
50-60 Hz.
Use only the power cord and
connector specified for the product and
your operating locale.
User Serviceable Parts.
There
are no user serviceable parts inside the
SymNet™ ARC-PS
. In case of failure,
customers inside the U.S. should refer
all servicing to the Symetrix factory.
Customers outside the U.S. should
refer all servicing to an authorized
Symetrix distributor. Distributor con-
tact information is available online at
www.symetrixaudio.com.
Before You Begin

2/5
Quick Start Guide
ARC-PS™
(Adaptive Remote
Control - Power Supply)
To download the latest version of SymNet Designer, the Windows application that
controls all SymNet hardware, go to: www.symetrixaudio.com
SymNet
TM
Audio
Matrix
3/5
Quick Start Guide
Overview, ARC Network Design, System Connection
Overview
The ARC-PS is a 1 rack space power supply and data router
for the SymNet ARC. It is designed to allow easy connection
of multiple ARCs to a SymNet device by distributing data
and power over CAT-5 cable from one of the 8 RJ-45 jacks
on its rear panel. Each ARC-PS provides up to 8 home run
connections, via the 8 RJ-45 jacks on its rear panel. Multiple
ARCs may be daisy chained on each of the 8 RJ-45 jacks for
a recommended maximum of 4 ARCs per RJ-45 port.
ARC Network Design
The ARC can be powered two ways: (1) over CAT-5 via the
ARC-PS or Control I/O, or (2) by local 6 to 15 VDC power
supplied to the ARC’s terminal block connections.
Warning!
The RJ-45 connectors on the ARC-
PS are only for use with the ARC.
DO NOT plug
the RJ-45 connectors on the ARC-PS into any
RJ-45 connector labeled “SYMLINK”, “HOMERLINK” or
“ETHERNET”.
The RJ-45 connectors on the ARC, ARC-PS
and Control I/O can carry anywhere from 6 to 15 VDC which
can damage SymLink, HomerLink and Ethernet circuitry.
The ARC’s power requirements vary depending on the
voltage supplied to it. At 15V DC, it uses approximately
115 mA, while at 6V DC it uses approximately 300 mA
maximum. As the voltage goes from 15 to 6 VDC, the current
requirement increases accordingly.
ARCs can be daisy-chained and fed power over this daisy-
chain from the ARC-PS. However, as the length of the cable
increases, so does the resistive line loss, which lowers the
voltage available at each subsequent ARC. The actual power
drain on each output from the ARC-PS can vary substantially
depending on the number of ARCs and the distance each of
them is separated by. In order to assist with system design,
Symetrix has available a Microsoft Excel spreadsheet that
can help a system designer determine power requirements
based upon cable length, number of ARCs and the power
supply to be used. This spreadsheet can be downloaded from
the SymNet Technical Support pages at:
http://www.symetrixaudio.com/SymNet_Web/index.htm
The following table gives some indication of cabling
limitations, based on DC power only (the table is not relevant
if only RS-485 is distributed via the ARC-PS): minimum
stated distances assume 28 gauge CAT-5 cabling, maximum
stated distances assume 24 gauge CAT-5 cabling.
CABLE LENGTH LIMITATIONS FOR ARC DC POWER
OVER CAT-5 CABLE
Total cable length
(to end of chain)
Number of ARCs in 1 daisy
chain
224-640 ft.
4
276-792 ft.
3
350-1028 ft.
2
486-1396 ft.
1
If power is not distributed over CAT-5,
the ARC’s RS-485 will
be limited to 1000 ft in a star network configuration and 4000
ft in a daisy-chain network configuration. Longer distances
may be possible using third party RS-485 extender products.
Disclaimer:
From time to time we test the compatibility of
our own products with those of third parties. While we are
happy to share with our customers the results of our own
studies as well as other possibly unsubstantiated information
regarding these third party products, it is the policy of
Symetrix, Inc. to neither endorse, recommend nor support
products manufactured and/or supplied by third parties.
The responsibility of choosing third party products which
are compatible with Symetrix products rests solely with the
qualified contractor, consultant or system designer.
System Connection
Using shielded twisted pair wire, connect the RS-485 terminal
block of the ARC-PS to the RS-485 port of a master SymNet
DSP or CobraLink (at Ring x, Address 1) hardware device.
Then, CAT-5 cable should be distributed amongst the
ARCs in the system preferably in a star configuration or in
minimal daisy chains according to the limitations outlined
previously. Finally, power can be applied to the ARC-PS and
programming may commence.
ARC-PS
SymNet
Audio Matrix
MANUFACTURED BY SYMETRIX, INC.
LYNNWOOD, WA USA
THIS UNIT CONTAINS NO USER SERVICEABLE PARTS
www.symetrixaudio.com
+15VDC
1.33A
RS-485
FABRIQUÉ AUX E.-U. PAR SYMETRIX, INC. LYNNWOOD, WA
PAS DES ELEMENTS SERVIABLE PAR UTILISATEUR
867 4 3 2 15
POWER
POWER INPUT
B- A+

2/5
Quick Start Guide
3/5
Quick Start Guide
ARC-PS™
(Adaptive Remote
Control - Power Supply)
To download the latest version of SymNet Designer, the Windows application that
controls all SymNet hardware, go to: www.symetrixaudio.com
SymNet
TM
Audio
Matrix
System Connection... continued, RS-485 Termination
CAT-5 CABLE PINOUT FOR POWER AND RS-485 DISTRIBUTION
Pin #
Function
1
Ground
2
Ground
3
Ground
4
RS-485 “A”
5
RS-485 “B”
6
Ground
7
Power
8
Power
WARNING:
When designing a system, one must be careful
not to double power any ARCs. If all pins on the CAT-5
connections are used, power can travel over the CAT-5 cable
and reach any ARC on that particular chain. So, power over
CAT-5 could potentially come from the ARC-PS or from an
ARC that is powered locally and then daisy chained via CAT-
5 to other ARCs. In general, it is recommended to use only
one type of connector on the ARCs, either the RJ-45s (with
CAT-5 cable) or the terminal blocks.
RS-485 Termination
The ARC-PS features an RS-485 termination jumper. Jumper
J9 on the PCB directly behind the RS-485 terminal block
connector enables and disables termination. Terminated
and open positions are labeled on the PCB silkscreen. For
maximum signal integrity, follow the termination guidelines
below:
RS-485 TERMINATION GUIDELINES
Daisy chain length
Termination
0 - 200 ft.
No termination required
200 - 1000 ft. (if powering over
CAT-5)
Terminate at ARC
> 1000 ft. (or if not powering over
CAT-5)
Terminate at ARC-PS
(or Control I/O) and at
the last ARC in each
chain
For star configurations, terminate at the ARC-PS.

5/5
Quick Start Guide

5/5
Quick Start Guide
ARC-PS™
(Adaptive Remote
Control - Power Supply)
To download the latest version of SymNet Designer, the Windows application that
controls all SymNet hardware, go to: www.symetrixaudio.com
SymNet
TM
Audio
Matrix
Warranty and Service
The Symetrix Limited Warranty
Symetrix, Inc. expressly warrants that the product will be free
from defects in material and workmanship for eighteen (18)
months from the date the product is shipped from the factory.
Symetrix's obligations under this warranty will be limited to
repairing or replacing, at Symetrix's option, the part or parts
of the product which prove defective in material or workman-
ship within eighteen (18) months from the date the product
is shipped from the factory, provided that the Buyer gives
Symetrix prompt notice of any defect or failure and satisfac-
tory proof thereof. Products may be returned by Buyer only
after a Return Authorization number (RA) has been obtained
from Symetrix. Buyer will prepay all freight charges to return
the product to the Symetrix factory. Symetrix reserves the
right to inspect any products which may be the subject of any
warranty claim before repair or replacement is carried out.
Symetrix may, at its option, require proof of the original date of
purchase (dated copy of original retail dealer's invoice). Final
determination of warranty coverage lies solely with Symetrix.
Products repaired under warranty will be returned freight
prepaid via United Parcel Service by Symetrix, to any location
within the Continental United States. Outside the Continental
United States, products will be returned freight collect.
The foregoing warranties are in lieu of all other warran-
ties, whether oral, written, express, implied or statutory.
Symetrix, Inc. expressly disclaims any IMPLIED warran-
ties, including fitness for a particular purpose or mer-
chantability. Symetrix's warranty obligation and buyer's
remedies hereunder are SOLELY and exclusively as
stated herein.
This Symetrix product is designed and manufactured for use
in professional and studio audio systems and is not intended
for other usage. With respect to products purchased by
consumers for personal, family, or household use,
Symetrix
expressly disclaims all implied warranties, including but
not limited to warranties of merchantability and fitness for
a particular purpose.
This limited warranty, with all terms, conditions and disclaim-
ers set forth herein, shall extend to the original purchaser and
anyone who purchases the product within the specified war-
ranty period.
Symetrix does not authorize any third party, including any
dealer or sales representative, to assume any liability or make
any additional warranties or representation regarding this
product information on behalf of Symetrix.
This limited warranty gives the buyer certain rights. You may
have additional rights provided by applicable law.
Note:
Some Symetrix products contain embedded software
and may also be accompanied by control software intended
to be run on a personal computer. Said software is specifically
excluded from this warranty.
Limitation of Liability
The total liability of Symetrix on any claim, whether in contract,
tort (including negligence) or otherwise arising out of, con-
nected with, or resulting from the manufacture, sale, delivery,
resale, repair, replacement or use of any product will not
exceed the price allocatable to the product or any part thereof
which gives rise to the claim. In no event will Symetrix be liable
for any incidental or consequential damages including but not
limited to damage for loss of revenue, cost of capital, claims
of customers for service interruptions or failure to supply,
and costs and expenses incurred in connection with labor,
overhead, transportation, installation or removal of products,
substitute facilities or supply houses.
Servicing the ARC-PS
If you have determined that your ARC-PS requires repair ser-
vices and you live outside of the United States please contact
your local Symetrix dealer or distributor for instructions on how
to obtain service. If you reside in the U.S. then proceed as
follows.
Return authorization
At the Symetrix factory, Symetrix will perform in-warranty or
out-of-warranty service on any product it has manufactured for
a period of three (3) years from date of discontinued manufac-
ture.
Before sending anything to Symetrix, please contact our
Customer Service Department for a return authoriza-
tion (RA) number. The telephone number is (425) 778-
7728. Additionally support is available via E-mail through
[email protected] or via the web site
http://www.symetrixaudio.com.
In-warranty repairs
To get your ARC-PS repaired under the terms of the warranty:
1. Call us for an RA number (have the serial number, ship-
ping and contact information and description of the problem
ready).
2. Pack the unit in its original packaging materials.
3. Include your name, address, daytime telephone number,
and a brief statement of the problem.
4. Write the RA number on the
outside
of the box.
5. Ship the unit to Symetrix, freight prepaid. We do not accept
freight collect shipments.
Just do these five things, and repairs made in-warranty will
cost you only one way freight charges. We'll pay the return
freight.
If you don't have the factory packaging materials, we rec-
ommend using an oversize box. Wrap the unit in a plastic
bag, surround it with bubble-wrap, and place it in the box
surrounded by Styrofoam peanuts. Be sure there is enough
clearance in the box to protect the rack ears. We won't return
the unit in anything but Symetrix packaging for which we will
have to charge you. If the problem is due to operator misuse
or error, you will have to pay for both parts and labor. In any
event, if there are charges for the repair, you will pay for the
return freight. All charges will be COD unless you have made
other arrangements (prepaid, Visa or Mastercard).
Out-of-warranty repairs
If the warranty period has passed, you'll be billed for all neces-
sary parts, labor, packaging materials, and freight charges.
Please remember, you must call for an RA number before
sending the unit to Symetrix.
© 2003, Symetrix, Inc. All rights reserved. Printed in the United States of America. Symetrix Part Number
53ARPS1A04.
The information in this Quick
Start Guide is subject to change without notice. Symetrix, Inc. shall not be liable for technical or editorial errors or omissions contained herein; nor is
it liable for incidental or consequential damages resulting from the furnishing, performance, or use of this material. Mention of third-party products is
for informational purposes only and constitutes neither an endorsement nor a recommendation. Symetrix assumes no responsibility with regard to the
performance or use of these products. Under copyright laws, no part of this Quick Start Guide may be reproduced or transmitted in any form or by any
means, electronic or mechanical, without permission in writing from Symetrix, Inc. If, however, your only means of access is electronic, permission
to print one copy is hereby granted. Product names mentioned herein may be trademarks and/or registered trademarks of their respective owners.
