Symmetrikit SENCILLLA Instruction Manual

User Handbook
Simple,
Supportive
Seating

www.Symmetrikit.com 2
Max. Safe User Weight 150 kg / 24 stone / 330 lbs
THIS CHAIR HAS BEEN DESIGNED TO BE USED IN AREAS SUCH AS NURSING HOMES,
CARE HOMES, HOSPITALS AND PRIVATE DWELLINGS.
IMPORTANT – PLEASE READ THESE INSTRUCTIONS
THROUGH CAREFULLY AND RETAIN FOR FUTURE REFERENCE
The serial number is located on the bottom, rear
frame of the chair, underneath the zipped fabric as
shown in image. It is important to reference the serial
number during all communication with your local
supplier/The Helping Hand Company.

www.Symmetrikit.com3
• Safety Warnings & Guarantee 4
• Set up checklist 6
• Features 7
• Getting to know the handset 9
• Getting to know your chair 10
• Looking after your chair 14
• How to contact us 14
• Frequently Asked Questions 15
CONTENTS

www.Symmetrikit.com 4
INCORRECT USE OF THIS PRODUCT CAN CAUSE ACCIDENTS
• This is an electrical item and should be treated with caution
• Always ensure that there is nothing to obstruct the free movement of this chair, for example children,
pets, or solid objects, e.g. a wall
• This chair is not suitable for use by children. Any children in the vicinity must be supervised at all times
• Take care when adjusting positions to avoid trapping or pinching of body parts
• Only the occupant or a responsible person should operate this chair
• Exercise care when lowering into the chair as shock loads can severely damage this chair and its mechanism
• Make sure that all adjustable features are rmly secured before seating an individual
• Apply both brakes if the chair is in a satisfactory, stationary position
• DO NOT sit on footrest, or on the arms of this chair
This product should only be operated by a trained, competent person at all times. Please ensure that
all Sta and Users are familiar with the following restrictions.
When selecting and issuing a piece of equipment it is the responsibility of the Therapist to carry out a
risk analysis on its use. This is particularly pertinent for non-ambulant users who may require assisted
transfers.
Positioning requirements may change, therefore, the User should be regularly reassessed to ensure that
the SENCILLA Chair is adjusted appropriately. Incorrect adjustment may cause discomfort and lasting
problems.
It is recommended that Therapists and Carers complete the following checklist when assessing the
appropriate use of this product:
• Is the User’s posture acceptable in the SENCILLA Chair?
• Are there concerns about pressure and are they being addressed?
• Is the User considered to be safe in the SENCILLA Chair? A lap strap is recommended at all times.
• Does the User or others around them have any behaviours which would render the product unsafe?
• Is the SENCILLA Chair appropriate for the proposed environment?
• When using the SENCILLA Chair to provide dierent postures, always check the User’s respiratory
competence.
SAFE USE OF YOUR SENCILLA CHAIR
WARNINGS

www.Symmetrikit.com5
GUARANTEE
Your new SENCILLA Chair includes a ONE YEAR upholstery and TWO YEAR mechanical parts guarantee,
against defective materials and faulty workmanship from the date of purchase.
This guarantee is valid for fair wear and tear only and not valid in cases of misuse or uses other than
those specied in this instruction manual. We do not guarantee fabrics against shrinkage so please pay
careful attention to cleaning instructions on page 14. Certain movement patterns and behaviour may
accelerate fabric wear, this cannot be covered by guarantee.
Whilst electrical components are carefully chosen for the intended environment (dry/indoor) we cannot
guarantee components against damage from liquid ingress. Using the SENCILLA Chair in transit is NOT
recommended and will invalidate the warranty.
A monthly inspection of the SENCILLA Chair is recommended as well as a full annual service to maintain
function and longevity to ensure your chair is operating correctly.
• Servicing – parts can only be changed and repaired by a Helping Hand Trained Service Engineer.
• Castors will only work on very low pile carpet and hard level surfaces.
For more information please contact our Service Department on 01531 634468.
ANY SERIOUS INCIDENT THAT HAS OCCURRED IN RELATIONTO THIS CHAIR SHOULD
BE REPORTED TO THE MANUFACTURER AND THE COMPETENT AUTHORITY OF THE
MEMBER STATE IN WHICH THE USER AND/OR PATIENT IS ESTABLISHED.
DISPOSAL/ END OF USE FOR THE SENCILLA CHAIR
This product must be cleaned and disinfected prior to disposal within the local waste management
guidelines.
• BS 7176 2007 + A1 2001 -
Specication For Resistance To Ignition Of Upholstered Furniture Non-Domestic
• BS EN 1728 2012 -
Furniture. Seating. Test Methods For The Determination Of Strength And Durability
The SENCILLA Chair has been tested to:
FIRE
RETARDANT

www.Symmetrikit.com 6
SET UP CHECKLIST
Home access
• Access to main entrance (ramp/steps) clear of obstructions/trip hazards for
delivery vehicle (Home delivery via two person team as standard)
• External doorway wide enough, minimum doorway width 750mm
• Conrmed access if delivery involves use of lift or carry up in internal stairs
Room setting
• Internal door access width, minimum 750mm
• Adequate space around chair to allow full tilt & recline
• Each function of chair checked and working
• Demonstration on how to use chair
• Test function and t of chair
YOUR CHAIR IS READY FOR USE NOW YOUR CHAIR HAS BEEN FULLY INSTALLED IN THE CORRECT
POSITION, AND YOU, THE USER HAVE READ AND UNDERSTOOD THESE OPERATING INSTRUCTIONS.
YOUR NEW CHAIR
• Your SENCILLA chair can be easily adjusted to provide the necessary postural support and
pressure care to maximise comfort and relaxation.
• Multi adjustable - easily achieve the correct Seat depth, Seat width, Arm Rest height, Leg
Rest height and Back Rest height without having to use tools to ensure the very best Posture,
Pressure (Re-)Distribution and Comfort.
Adjustable postural support
Medium / high pressure relief as standard
Tilt in space, recline and leg rest elevation functions as standard
Moving room to room??

www.Symmetrikit.com7
FEATURES
Lumbar support
built in to backrest
2 x D rings for harnessing
Optional height adjustable,
padded headrest, giving
stability to the head and neck
Quick release
Gullwing arms
to assist with
transfer and easy
sling tting
Finger form and hip
bolsters for stability
Height adjustable
foot rest
Lap strap oering
extra security
100mm castors as
standard with easy
locking brakes at
the rear

www.Symmetrikit.com 8
The SENCILLA chair is available in three variants:
• Full Power (duplex powered for recline, tilt in space and leg rest) with remote and battery back-
up if mains power fails
• Dual Power (powered tilt in space and leg rest, with a manual gas strut for recline) with remote
and battery back-up if mains power fails
• Manual (all gas struts) with various hand levers
Dimensions...
Backrest height - Standard (690mm) Tall (840mm)
Seat Depth range - (380 - 525mm)
Seat Width range - (455 - 535mm)
Knee To Footplate Height - (370 - 500mm)
Arm Height range - (195 - 240mm)
Tilt in Space Range - 0º 20º
Backrest Recline Angle Range - 0º 20º
Legrest Angle Range - 20º- +45º
Footplate Angle Range - 180º
Maximum User Weight - 160kg
Options available
• Power Variants:
Full power / Dual power / Manual
• Seat cushions:
Standard / AIRZONE / GEL2 / Base kit
• Fabric:
Cuero - The modern alternative to Vinyl. Soft, vapour permeable
waterproof PU, exible and breathable but tough. Cuero is very easy to keep
clean and comes in a range of colours (as shown above).
Infection Control - Available in Blue/Blue or Black/Grey
• Optional
Headrest
Anti Tamper Device for the levers on Dual Powered and Manual chairs.

www.Symmetrikit.com9
GETTING TO KNOW THE FULL & DUAL HANDSET
NOTE: To lock any function, hold both
buttons for that function and then the
lock button (the indicator light for that
function will turn on).
To unlock any function, hold both buttons
for that function and then the unlock
button (the indicator light for that function
will turn o).
FULL Power
LED Indicator lights
1- battery - < 25% charge
2- recline locked
3- tilt in space locked
4- leg rest locked
1 2 3 4
Backward
RECLINE
Forward
RECLINE
Backward
TILT IN SPACE
Forward
TILT IN SPACE
downward
LEG REST
Upward
LEG REST
LOCK UNLOCK
DUAL Power LED Indicator lights
1- battery - < 25% charge
2- tilt in space locked
3- leg rest locked
1 2 3
Backward
TILT IN SPACE
Forward
TILT IN SPACE
downward
LEG REST
Upward
LEG REST
LOCK UNLOCK

www.Symmetrikit.com 10
GETTING TO KNOW YOUR CHAIR
Back recline
Leg Rest
Full Power - press on the remote
Full Power - press on the remote
Dual Power - press on the remote
Manual - use lever located
on the left handside of the
manual chair
Dual power - pull right hand
lever shown as
Manual - pull right hand lever
shown as
RECLINE
RECLINE
Tilt in space Full Power - press on the remote
Dual Power - press on the remote
Manual - pull left lever
shown as TILT

www.Symmetrikit.com11
Gull wing arms
Located towards the back of
each arm on the outside - as
shown, is a small release knob
that needs to be pulled out
whilst lifting the arm up.
Reverse this action to lower
each arm back in to its place.
Located towards the back of each arm on the inside - as shown below - is a small release clamp that needs
to be pulled up whilst lifting the arm up in order to adjust the height and then reclamp to hold the position.
Arm width adjustment (from 455 - 537mm)
Following on from the instructions above to lift the arms, underneath - unscrew the thumb wheels as shown
below - and move the arms to desired position/width before re-tightening. Lower the arm back down gently.
Arm height adjustment (from 195 - 240mm)

www.Symmetrikit.com 12
Seat depth adjustment - forward
Seat depth adjustment - backward
Remove the lower, rear
zipped cover to reveal
the adjustment lever
and handle on back of
seat pad. Gently pull
the lever upwards and
at the same time PUSH
the cushion handle/
pad away from you to
correct/desired position.
Remove the lower, rear
zipped cover to reveal
the adjustment lever
and handle on back of
seat pad. Gently pull
lever upwards and at
the same time PULL
the cushion handle/
pad towards you into
correct/desired position.
Foot rest/foot plate
Height adjustable x 2 thumb
screws
The foot rest is height
adjustable from 370-
504mm. To locate the
height adjustable screws
at the rear of the foot
rest - the chair should be
positioned in full tilt for
ease of access. Position
the foot plate at desired
height then re-tighten
both screws to hold into
place.

www.Symmetrikit.com13
Fitting
Anti-tamper devices for levers (tilt & recline)
You Will Need:
- 2.5mm Allen Key
- Stanley Knife
- Tape measure
What’s in the box:
1. Measure and cut 25mm o
the foam handle cover from
top end of handle.
2. There should be a clear
25mm gap for the anti
tamper device to slot into.
5. When anti tamper device is
lowered and resting on lever
- it is LOCKED.
6. When anti tamper device
is raised up from lever - it is
UNLOCKED and the levers
are free to be adjusted.
3. Clip on the larger part of
anti tamper device.
4. Screw the two parts
together with the screw, nut
and washer using the Allen
key - be careful not to lose
the nut orwasher.

www.Symmetrikit.com 14
To arrange a Service on your SENCILLA Chair, please contact us...
Tel: [phone]
www.Symmetrikit.com/service
[e-mail]
SYMMETRIKIT Postural Care
Bromyard Road
Ledbury
Herefordshire
HR8 1NS
LOOKING AFTER YOUR CHAIR
• Cuero upholstery should be wiped down using a damp, clean cloth with a solution
of mild detergent and lukewarm water
• If the upholstery is exposed to direct sunlight for long periods of time it will likely fade, where
possible use blinds/curtains for protection
• The frame of the chair can also be cleaned with a damp cloth and mild detergent if required.
• Your new Sencilla Chair is not to be used outdoors!

www.Symmetrikit.com15
FREQUENTLY ASKED QUESTIONS
• What if I have a problem with my chair?
In the highly unlikely event of a problem, please contact us on 01535 635388
• How do I keep my chair in tip top condition?
We recommend an annual inspection to check for wear and tear, and test mechanical integrity. For
further details please contact our Service team on 01531 634468 - remember to have your serial
number handy (location can be found on page 2).
• How do I go about obtaining new upholstery?
We reserve the right to withdraw colours or materials from the range but will always endeavour to
nd the closest match available. Please have the serial number of the chair to hand when you call.
• How will you use my personal details?
Your details are stored on a secure database and are protected by the Data Protection Act 1984. We
only store your details to cover your guarantees etc, we never pass your details to third parties. Credit
or debit card details are never stored and online card payment details are processed by a regulated
merchant service to protect you.

SYMMETRIKIT Postural Care
Bromyard Road, Ledbury
Herefordshire HR8 1NS
United Kingdom
Tel: [phone]
SYMMETRIKIT Postural Care, Bromyard Road, Ledbury, Herefordshire HR8 1NS
www.Symmetrikit.com [e-mail]
Please get in touch with us to nd out more...
SKLA3000IFU_1 Oct 2021
INTERNATIONAL ASSOCIATES
AUDITING & CERTIFICATION LTD
The Black Church, St. Mary’s Place,
Dublin D07 P4AX Ireland
