Symmons 0113-TP User manual

Model Numbers Specification
Warranty
Limited Lifetime - to the original end purchaser in
consumer/residential installations.
5 Years - for industrial/commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
0113-TP (CD0113-3TP)
Toilet Paper Holder
Installation Guide
0113-TP
Toilet Paper Holder
Toilet Paper Holder shall be made from metal construction,
plated in standard polished chrome nish.
Dimensions
Measurements
A Sq. 1-3/4", 44 mm
B(2x) Hole Size
Ø 5/16", 8 mm
C 1-3/16", 30 mm
D Ø 3/4", 19 mm
E 6-1/2", 165 mm
F Ø 15/16", 24 mm
G 3/8", 10 mm
H 3-7/16", 87 mm
Note: Dimensions subject to change without notice.
AA
EE
DD
GG
HH
FF
CC
BB

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2017 Symmons Industries, Inc. ■symmons.com ■[email protected] ■ZV-2010 REV A ■ 041417
Parts Breakdown
Replacement Parts
Item Description Part Number
A
B
C
Mounting Screws
Drywall Anchors
Anchor Tool
HW-03141
C
B
A
A
B
B
For California Residents
WARNING: This product contains chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm.
Tools Required for Installation
Allen Wrench:
2.5 mm
Phillips Head
Screwdriver
Silicone
Notes:
1) For drywall 1/2 inch thick or less, insert anchor tool (C) into
drywall anchor (B) to secure behind wall prior to installing trim.
2) Apply a bead of silicone around the perimeter of trim installed
ush to nished wall.
