Symmons 0171-3DTP User manual

Model Numbers Specification
0171-3DTP (CD0171-3DTP)
Toilet Paper Holder
Installation Guide
0171-3DTP
Toilet Paper Holder
Toilet Paper Holder shall be made from metal
construction, plated in standard polished chrome
finish.
Dimensions
Note: Dimensions subject to change without notice.
5 1/16" (128 mm)
10 11/16" (271 mm)
11/16" (18 mm)
DIAMETER 2 5/8" (67 mm)
11/16" (18 mm)
DIAMETER
1 15/16" (50 mm)
DIAMETER 15/16" (24 mm)
DIAMETER
Limited Lifetime - to the original end
purchaser in consumer/residential
installations.
10 Years - for commercial/industrial
installations. Refer to
www.symmons.com/warranty for
complete warranty information.
Warranty

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2022 Symmons Industries, Inc. ■symmons.com ■[e-mail] ■ZV-2356 REV C ■ 032122
Parts Breakdown
C
B
A
A
B
B
Tools Required for Installation
Allen Wrench:
2.5 mm
Phillips Head
Screwdriver
Silicone
Notes:
1) For drywall 1/2 inch thick or less, insert anchor tool (C) into
drywall anchor (B) to secure behind wall prior to
installing trim
2) Apply a bead of silicone around the perimeter of trim
installed flush to finished wall.
WARNING: This product can expose you to chemicals including lead, which is known to the state of
California to cause cancer, birth defects, or other reproductive harm. For more information, go to www.
P65Warnings.ca.gov.
