  9. Symmons Dia 0323-TP-DPST User manual

Symmons Dia 0323-TP-DPST User manual

Dia®
Model Numbers Specification
Warranty
Limited Lifetime - to the original end purchaser in
consumer/residential installations.
5 Years - for industrial/commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
0323-TP-DPST
Toilet Paper Holder
Installation Guide
0323-TP-DPST
Toilet Paper Holder
Toilet Paper Holder shall be made from metal construction,
plated in standard polished chrome nish.
Dimensions
Measurements
A 6", 152 mm
B (2x) Ø 1-7/8", 48 mm
C(4x) Hole Size
Ø 5/16", 8 mm
D (2x) 3/4", 19 mm
E 5/8", 16 mm
F 3-7/16", 87 mm
Note: Dimensions subject to change without notice.
AA
BB
CC
DD
EE
FF
Options/Modifications
☐-STN Satin Nickel finish
Note: Append appropriate -sufx to model number.
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: (800) 796-6667 ■ Fax: (800) 961-9621
Copyright © 2019 Symmons Industries, Inc. ■symmons.com ■[email protected] ■ZV-2481 REV C ■ 052919
Parts Breakdown
C
B
A
A
B
B
Tools Required for Installation
Allen Wrench:
2 mm
Drill
Phillips Head
Screwdriver
Silicone
Replacement Parts
Item Description Part Number
A
B
C
Mounting Screws
Drywall Anchors
Anchor Tool
RA-017
Notes:
1) For drywall 1/2 inch thick or less, insert anchor tool (C) into
drywall anchor (B) to secure behind wall prior to installing trim.
2) Apply a bead of silicone around the perimeter of trim installed
ush to nished wall.
WARNING: This product can expose you to chemicals including lead, which is known to the state of California to
cause cancer, birth defects, or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
