Symmons SGB Series User manual

Installation Instructions
Model Numbers
SGB-12........ 12 inch ADA Grab Bar
SGB-18........ 18 inch ADA Grab Bar
SGB-24........ 24 inch ADA Grab Bar
SGB-36........ 36 inch ADA Grab Bar
SGB-42........ 42 inch ADA Grab Bar
SGB-48........ 48 inch ADA Grab Bar
Need Help?
Symmons customer service:
P: ( 800) 796-6667
[email protected]
Mon - Fri 7:30 am - 6:00 pm EST

www.symmons.com/service
• Technical help
• Product information
• Warranty policy
1/4" carbide
tip drill bit for
wall tiles
1 2 3 4
5/32" drill bit
Tools and Materials
3" (77 mm)
diameter
press-on screwless
escutcheon
1-1/2" (38 mm)
bar diameter
1-1/2" (38 mm)
standard wall
stud width
Grab Bar must be
secured with at least
two (2) of three (3)
screws at each end on
top and bottom.
Six (6) #10 x 2"
(51 mm) wood
screws included
drill hole
5/32 inch
Visual Guide Wall Mounted Grab Bar SGB
Compliance
2010 ADA Standards for Accessible Design
Grab bar assembly complies with the
applicable requirements.
Finish Options
Append appropriate -sux to model
number
☐-STN Satin Nickel
-Polished chrome
(standard nish)
Wall Mounted Grab Bar SGB

Grab Bar Length
Model Length
Reference
grab bar length table
3" (77 mm)
diameter
Note: Dimensions subject to
change without notice.
press-on screwless
escutcheon
1-1/2" (38 mm)
bar diameter
1-1/2" (38 mm)
standard wall stud width
2" (x2)
(51 mm)
1" (x2)
(25 mm)
SGB-12 12" (305 mm)
SGB-18 18" (457 mm)
SGB-24 24" (610 mm)
SGB-36 36" (914 mm)
SGB-42 42" (1067 mm)
SGB-48 48" (1219 mm)
SGB-12........10-7/8" (276 mm)
SGB-18........16-7/8" (429 mm)
SGB-24........22-7/8" (581 mm)
SGB-36........34-7/8" (886 mm)
SGB-42........40-7/8" (1038 mm)
SGB-48........46-7/8" (1191 mm)
SGB-12........14-5/16" (364 mm)
SGB-18........20-5/16" (516 mm)
SGB-24........26-5/16" (668 mm)
SGB-36........38-5/16" (973 mm)
SGB-42........44-5/16" (1126 mm)
SGB-48........50-5/16" (1278 mm)
Grab Bar must be secured
with at least two (2) of three (3)
screws at each end on top and
bottom.
Six (6) #10 x 2"
(51 mm) wood screws
Dimensions Wall Mounted Grab Bar, SGB
Grab Bar Location
For proper mounting heights and location
consult with your state and local code ocial
having jurisdiction over the installation.
Solid Support
■ Grab Bar must be mounted with both
ends positioned over a wall stud. A stud
nder can be used to locate wall studs.
Contractor is responsible for installing
Grab Bar to wall studs as instructed.
■ Secure through wall board or tile to the
wall stud so as to hold a minimum of
250 pounds of force.
■ At least two (2) of the three (3) screws
provided must be used on each end of
the Grab Bar to properly secure.
Note: Standard size wall stud limits
using more than two (2) screws.
Installation Notes
Mounting Grab Bar
■ Drill all holes through wall board into
wood wall studs using a power drill
and a 5/32 inch drill bit.
■ Ceramic tiles - If installing Grab Bar
over ceramic tiles, rst drill a pilot hole
through the tile using a 1/4 inch carbide
tip drill bit to prevent damage to the tiles.
Next, drill a pilot hole into the wood wall
stud using the 5/32 inch drill bit.
Care and Cleaning
Mild soap and water or a non-abrasive
cleaner is recommended for cleaning.
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2018 Symmons Industries, Inc. ■symmons.com ■[email protected] ■ ZV-1088 REV B ■082118
