Symmons The Smart Choice Naru Trim Series Manual

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■[phone] ■ Fax: [phone]
©2014 Symmons Industries, Inc. ■ www.symmons.com ■ [email protected] ■ ZV-3051 REV 0 09/25/14
4103-TRM, 4105-TRM, 4106-TRM
Naru™Trim Series
Operation & Maintenance Manual
Model Numbers Specifications
4103-TRM Hand Shower Trim
4105-TRM Shower Trim with Hand Shower
4106-TRM Tub/Shower Trim with Hand
Shower
Tub/shower trim with hand shower and lever handle
includes wall connection, cradle for hand shower
mounting, in-line vacuum breaker, exible metal hose,
non-diverter tub spout, 3 mode hand shower and
3 mode showerhead with standard 2.5 gpm (9.5 L/min)
ow restrictor. Shower trim with hand shower and lever
handle includes all of the above less non-diverter tub
spout. Valve trim with hand shower and lever handle
includes all of the above less non-diverter tub spout and
3 mode showerhead. Components made from metal and
nonmetallic materials plated in standard polished
chrome nish.
Modifications Compliance
-1.5 1.5 gpm (5.7 L/min) flow restrictor
-2.0 2.0 gpm (7.6 L/min) flow restrictor
-412HSB 30" slide bar in place of wall cradle on
hand shower units
-PNL Polished nickel finish
-STN Satin nickel finish
-ASME A112.18.1; CSA B125.1
Warranty
Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
Note: Append appropriate -sufx to model number.
c

2
Dimensions
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■[phone] ■ Fax: [phone]
©2014 Symmons Industries, Inc. ■ www.symmons.com ■ [email protected] ■ ZV-3051 REV 0 09/25/14
Measurements
A Ø 2 1/4", 57 mm
B 8 1/4", 210 mm
C Ø 2 1/4", 57 mm
D
Female 1/2" IPS thread must
be recessed 7/8" from nished
wall
E 6", 152 mm right or left
F 77", 1956 mm
G Ø 7 1/2", 191 mm
H Ø 5", 127 mm
I 8", 203 mm
J4 3/4", 121 mm (4106-TRM)
4 7/8", 124 mm (4105-TRM)
K 2 1/8", 54 mm
L
32", 813 mm (4106-TRM)
45", 1143 mm
(4103-TRM, 4105-TRM)
M 12", 305 mm
N 2 1/4", 57 mm
O 3", 76 mm
P 1/2" NPT
Q 1/2", 13 mm
R(Rough in)
2 3/8" ± 1/2", 60 mm ± 13 mm
S 7 1/8", 181 mm
Notes:
1) All dimensions measured from nominal rough-in (see R as reference).
2) Dimensions are subject to change without notice.
A
C
C
H
H
G
G
K
K
L
L
M
M
F
F
B
B
D
D
J
J
I
I
N
N
O
O
R
R
S
S
Q
Q
P
P
E
E
Floor
Floor

3
Parts Breakdown
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■[phone] ■ Fax: [phone]
©2014 Symmons Industries, Inc. ■ www.symmons.com ■ [email protected] ■ ZV-3051 REV 0 09/25/14
Replacement Parts
Item Description Part Number
A
Z
Vacuum Breaker
60" Hose EF-104
B
C
Wall Elbow
Wall Elbow Flange T-444-KIT
D Showerhead 412SH
E
F
Shower Arm
Shower Arm Flange 300
G
H
Diverter Handle
Set Screw LLD-102
I Diverter Dome Cover LLD-101
J
K
L
Diverter Escutcheon
Mounting Screws
Mounting Plate
T-416A
M
N
O
P
Q
Cradle Mount
Cradle Mounting Screws
Washer
Cradle Arm
Set Screw
T-545
R
S
Shower Handle
Set Screw T-567
T Shower Dome Cover T-544
U
V
W
Shower Escutcheon
Mounting Screws
Mounting Plate
T-273-NS-K002
X Hand Shower 412W
Y Tub Spout 412TS
Notes:
1) Append -PNL to part number for polished nickel
nish; -STN for satin nickel.
2) Append -1.5 or -2.0 to showerhead or hand shower
for low ow.
Required for Installation
Adjustable wrench
Phillips head screwdriver
Allen wrench (1/8")
Plumber tape
C
F
X
U
A
B
V
Z
L
N
M
P
W
D
K
I
G
J
T
R
H
S
E
Q
O
Y

4
Installation
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■[phone] ■ Fax: [phone]
©2014 Symmons Industries, Inc. ■ www.symmons.com ■ [email protected] ■ ZV-3051 REV 0 09/25/14
Note:
For valve body installation, please
see valve body installation guides.
1) Install small plastic mounting
plate (L) to diverter valve
(4106-TRM diverter valve =
4-460E-BODY, 4105-TRM diverter
valve = 4-458E-BODY) and large
plastic mounting plate (W) to
shower valve (4000-BODY).
Secure small plasting mounting
plate with two screws (K) and large
plastic mounting screws with two
screws (V).
2) Attach diverter escutcheon (J) to
small plastic mounting plate (L).
Note: Tabs should snap into place.
3) Attach shower escutcheon (U) to
large plastic mounting plate (W).
Note: Tabs should snap into place.
4) Install shower dome cover (T)
and diverter dome cover (I) to
valves by turning clockwise.
5) Install diverter handle (G)
(4105-TRM and 4106-TRM only)
and shower handle (R) to valves.
Secure handles by tightening set
screws (H, S).
6) Install tub spout (Y) to pipe tting.
Turn clockwise to secure.
7) Install wall elbow (B) and ange (C)
to recessed pipe tting. Turn elbow
clockwise to tighten
1
1
2
L
K
V
W
J
L
UW
1
1
2
I
T
1
1
2
G
R
S
H
1
2
Y
1
2
B
C

5
Installation
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■[phone] ■ Fax: [phone]
©2014 Symmons Industries, Inc. ■ www.symmons.com ■ [email protected] ■ ZV-3051 REV 0 09/25/14
8) Press tab to remove mounting
plate (M2) from cradle mount
cover (M1).
Note: Mounting plate (M2) center
tabs must be horizontal for removal.
9) Place mounting plate (M2) in
position, mark and drill 1/8" pilot
holes into stud.
Option: Place mounting plate (M2) in
position, mark and drill 3/16" holes
into wall. Install anchors.
10) Install mounting plate (M2) .
Secure with two screws (N) .
Replace cradle mount cover (M1).
Note: Mounting plate (M2) center
tabs must be horizontal for
installation.
11) Attach cradle arm (P) and
washer (O) to cradle mount (M).
Secure with set screw (Q).
12) Attach shower arm (E) and
ange (F) to vertical shower pipe
turning clockwise to tighten.
13) Install shower head (D) to shower
arm (E) turning clockwise to
tighten.
14) Attach large end of hand
shower hose (Z) to hand
shower head (X). Attach small
end of hand shower hose (Z)
and gasket to in-line vacuum
breaker (A). Connect in-line
vacuum breaker to wall
elbow (B). Turn clockwise
to tighten.
2
1
M1
M2
1
3
2
M2
1
3
2
N
M2
M2
M1
3
1
4
2
Z
X
A
Z
B
1
2
D
E
1
2
E
F
1
2
M2
1
2
M
Q
O
P

6
Care and Cleaning
1) Clean nished trim area with a soft cloth using mild soap and water or a non-abrasive cleaner and then quickly rinse
with water.
Troubleshooting Chart
Problem Cause Solution
Finish is spotting. Elements in water supply may cause
water staining on nish.
Clean nished trim area with a soft
cloth using mild soap and water or a
non-abrasive cleaner and then
quickly rinse with water.
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■[phone] ■ Fax: [phone]
©2014 Symmons Industries, Inc. ■ www.symmons.com ■ [email protected] ■ ZV-3051 REV 0 09/25/14
1) Turn shower handle counterclockwise approximately
1/4 turn to put valve in cold position.
2) Turn shower handle counterclockwise approximately
1/2 turn to put valve in warm position.
3) Turn shower handle counterclockwise approximately
3/4 turn to put valve in hot position.
1) Diverter handle facing straight down is for diverter
function 1.
2) 4130-TRM & 4105-TMRM: Turn diverter handle
counterclockwise one full revolution for diverter
function 2.
4106-TRM: Turn diverter handle counterclockwise 1/4
turn for diverter function 2.
3) 4106-TRM: Turn diverter handle counterclockwise 3/4
turn for diverter function 3.
Operation
Temperature Control Diverter Control
5205-TRM 5206-TRM
