Symmons Dia Series Manual

Model Number Specification
Modifications
Dimensions
1 mode showerhead (352SH) and 3 mode
showerhead (352SH-3) include standard 2.5 gpm
(9.5 L/min) ow restrictors. Components made from
metal and nonmetallic materials plated in standard
polished chrome nish.
Dia™Showerhead Series
Operation & Maintenance Manual
352SH, 352SH-3
352SH
Dia 3” 1 Mode Showerhead
Notes: Dimensions subject to change without notice.
352SH-3
Dia 3” 3 Mode Showerhead
Compliance
-ASME A112.18.1; CSA B125.1
-WaterSense: 2.0 gpm (7.6 L/min) Max.
1.5 gpm (5.7 L/min) Min.
-1.5
1.5 gpm (5.7 L/min) flow restrictor
-2.0
2.0 gpm (7.6 L/min) flow restrictor
-STN
Satin Nickel finish
Warranty
Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
Certied by
IAPMO R&T
c
Note: Append appropriate -sufx to model number.
AA
B
B
D
D
C
C
352SH
352SH-3
Measurements
A 4 1/4”, 108 mm
B 4 1/8”, 105 mm
C 4 3/4”, 121 mm
D 4 1/2”, 114 mm
Tools Required for Installation
Plumber tape

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
©2015 Symmons Industries, Inc. ■www.symmons.com ■[email protected] ■ZV-3046 REV A ■ 020415
Installation Operation
1) Install showerhead to shower arm (not included)
turning clockwise to tighten.
1) Turn showerhead to desired mode of operation.
1
2
Troubleshooting Chart
Finish is spotting. Elements in water supply may cause
water staining on nish.
Clean nished trim area with a soft
cloth using mild soap and water or a
non-abrasive cleaner and then quickly
rinse with water.
Showerhead is leaking from shower
arm when valve is in “on” position.
Coupling connecting showerhead
to shower arm is cracked or washer
inside coupling is worn.
Inspect coupling and washer
and replace showerhead if
necessary.
